B210
Expansion Battery
User Manual V3.0
Please read this manual carefully before use and keep it for future reference.
Warning
1. Charge the unit before first use.
2. Do not use solar panels with open circuit voltage higher than 60VDC. Solar input
voltage range for the unit is 11V-60VDC.
3. Charge the unit immediately when the SoC drops below 5%. If the SoC drops to 0,
power off the unit and charge it for at least 30 minutes before restarting.
4. If not used for more than 3 months, charge the unit to 40%-60% SoC and store it
with the power off. For optimum battery life, discharge and charge the unit every 3
months.
Notice
BLUETTI's products, services, and features are subject to the agreed-upon terms and
conditions during purchase. Please note that some products, services, or features
described in this manual may not be available under your purchase contract. Unless
otherwise specified in the contract, BLUETTI makes no representations or warranties
of any kind, express or implied, with respect to the contents of this manual.
The contents of this manual are subject to change without notice. Please get the
latest version from official BLUETTI website.
If you have any questions or concerns about this manual, please contact BLUETTI
support for further assistance.
Thank You!
Thank you for making BLUETTI a part of your family.
From the very beginning, BLUETTI has tried to stay true to a sustainable future
through green energy storage solutions while delivering an exceptional
eco-friendly experience for our homes and our world.
That's why BLUETTI makes its presence in 100+ countries and is trusted by
millions of customers across the globe.
Copyright © ShenzhenPowerOakNewenerCo., Ltd. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by
any means without the prior written consent of ShenzhenPowerOakNewener
Co., Ltd.
France
Germany
Netherlands
Safety Instructions
Packing List
Product Overview
Power ON / OFF
Charging
Discharging
AC240 + B210 Expansion Connection
BLUETTI App
Specifications
Troubleshooting
FAQ
Contents
1
2
3
4
5
6
7
8
9
10
11
Appx. 1 FCC Statement
Appx. 2 IC Caution
Appx. 3 Consignes de sécurité
05
09
11
12
12
15
15
17
18
19
20
21
22
23
1. Safety Instructions
Read this manual for instructions on the proper use and safety information for the
product. The safety instructions provided herein are for illustrative purposes that include
but are not limited to those listed in this manual. Actual operation shall comply with all
applicable safety standards. If you have any questions, feel free to contact BLUETTI
support or your local BLUETTI dealers.
1.1 Statement
To ensure a safe operation, it's crucial to observe and adhere to the following conditions:
• Always operate or store the product in the conditions specified in this manual.
• Avoid unauthorized disassembly, component replacement, or modification of software
codes.
BLUETTI shall not be liable for damages resulting from the following circumstances：
• Force majeure events such as earthquakes, fires, storms, floods, or mudslides.
• Damage caused by the customer's own transportation.
• Damage resulting from inadequate storage conditions as specified in the manual.
• Damage caused by customer negligence, improper operation, or intentional actions.
• System or hardware damage caused by third parties or customers, including but not
limited to improper handling and installation not in accordance with the instructions in
this manual.
1.2 General Requirements
INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS
IMPORTANT SAFETY INSTRUCTIONS
WARNING:
When using this product, basic precautions should always be followed, including the
following:
• Read all the instructions before using the product.
• To reduce the risk of injury, close supervision is necessary when the product is used near
children.
• Do not put fingers or hands into the product. And do not insert foreign objects into any
ports of the product.
JUST POWER ON 05
• Use of an attachment not recommended or sold by the manufacturer may result in a risk
of fire, electric shock, or injury to persons.
• To reduce the risk of damage to the electric plug and cord, pull the plug rather than the
cord when disconnecting the product.
• Do not use a battery pack or appliance that is damaged or modified, as they may exhibit
unpredictable behavior resulting in fire, explosion, or personal injury.
• Do not operate the product with a damaged cord or plug, or a damaged output cable.
• Do not attempt to replace the internal battery or any other component of the product by
anyone other than authorized personnel. There are no end-user serviceable components.
Do not disassemble the product, take it to a qualified service person when service or
repair is required. Incorrect reassembly may result in a risk of fire or electric shock.
• To reduce the risk of electric shock, unplug the product from the outlet before attempting
any instructed servicing.
• WARNING - RISK OF EXPLOSIVE GASES. To reduce the risk of battery explosion, follow
these instructions and those published by the battery manufacturer and manufacturer of
any equipment you intend to use in the vicinity of the battery. Review cautionary markings
on these products and engines.
• PERSONAL PRECAUTIONS
a. Wear complete eye protection and clothing protection. Avoid touching eyes while work-
ing near the battery.
b. Never smoke or allow a spark or flame in the vicinity of the battery or engine.
c. Be extra cautious to reduce the risk of dropping a metal tool onto the battery. It might
spark or short-circuit the battery or other electrical parts which may cause an explosion.
• When charging the internal battery, work in a well ventilated area and do not restrict
ventilation in any way.
• Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause irritation or burns.
• Do not expose the product to fire or excessive temperature. Exposure to fire or temperature
above 80°C (176°F) may cause an explosion.
• Have servicing performed by a qualified repair person using only identical replacement
parts. This will ensure that safety is maintained.
JUST POWER ON06
• Do not stack anything on top of the product while in storage or while in use. Do not move
the product while operating as vibrations and sudden impacts may lead to poor connections
to the hardware inside.
• In case of fire, use only a dry powder fire extinguisher appropriate for the product.
• WARNING - RISK OF ELECTRIC SHOCK. Never use the product to supply power tools to
cut or access live parts or live wirings, or materials that may contain live parts or live
wirings inside, such as building walls, etc.
1.3 Handling Requirements
During transportation or storage, take care to avoid dropping, violently impacting, or
tilting the product as it may result in internal damage. If necessary, use mechanical
assistance such as carts or adjustable height workbenches to ensure safe handling.
1.4 Storage Instructions
• When the SoC drops to 5%, please charge the product immediately.
• Before storing the product, charge it to 40% to 60% SoC to keep it in optimal condition.
In addition, power off the unit and disconnect all electrical connections from it.
• Store the product in a cool and dry place, keeping it away from flammable or combustible
materials and gases.
• The product can be safely stored within a temperature range of -20°C to 45°C ( -4°F to
113°F). However, if the storage duration exceeds one month, it's recommended to maintain
an ideal storage temperature of around 30°C (86°F).
• Fully cycle the product every 3 months to maintain the battery's health. It's NOT recommended
to store the unit for extended periods of time, as it may affect its performance and overall
lifespan.
Recommended number of people based on the weight of product
Weight
＜18kg (39.7lbs)
18kg～32kg (39.7lbs～70.5lbs)
32kg～55kg (70.5lbs～121.3lbs)
＞55kg (121.3lbs)
Number of people
1
2
3
4 or a cart
JUST POWER ON 07
If the SoC drops to 0 (during storage or upon startup), take the following actions to
safely restart the product:
• Shut down immediately.
• Charge within 48 hours.
• Keep it at an ambient temperature of 5°C to 35°C (41°F to 95°F) for 6 hours before
charging. It's recommended to charge the product via an AC source. If charging via solar
energy, ensure that your solar system provides an output of more than 100W.
The symbol displayed is intended to remind you to read the instructions in the
literature accompanying the product before operation and maintenance.
• Connect the product to a socket-outlet that has an earthing connection using the power
cord provided.
• The socket-outlet should be installed near the product and easily accessible for safety
purposes.
• Never dispose of a battery by throwing it into fire or a hot oven, or by mechanically crushing
or cutting it, as these may cause it to explode.
• Avoid leaving batteries in extremely high-temperature environments, as this can result in
an explosion or the leakage of flammable liquid or gas.
• The battery subjected to extremely low air pressure may result in an explosion or the
leakage of flammable liquid or gas.
• Attention should be drawn to the environmental aspects of battery disposal.
• Please refer to the information on the exterior bottom enclosure for electrical and safety
information before installing or operating the apparatus.
SAVE THESE INSTRUCTIONS
BLUETTI shall not be liable for any equipment damage caused by the violation of the
above instructions.
JUST POWER ON08
2. Packing List
Item Picture Qty.
B210 Expansion Battery
1
Solar Charging Cable
1
1
Standard Accessories
Battery Expansion Cable
B210
Expansion Battery
User Manual V3.0
Please read this manual carefully before use and keep it for future reference.
Product Documentation
1
1
Warranty Card
JUST POWER ON 09
Item Picture
USB-C to USB-C Cable (output)
(100W Max. Compatible
with USB-C devices.)
Optional Accessories
(Available on official BLUETTI website)
Lead-acid Battery Charging Cable
（Charge the B210 via a lead-acid battery.）
Car Charging Cable
（Charge B210 via the car's
cigarette lighter port.）
PV Voltage Regulator
（Convert high solar panel voltage to
a suitable level for battery charging.）
12V DC Power Cable
（Charge 12V devices with DC5521 ports,
such as routers, GPS, etc.）
T5
00 AC Adapter
（Charge the B210 via a wall outlet.）
AC Power Cable
（Work with the AC adapter.）
JUST POWER ON10
3. Product Overview
The BLUETTI B210 Expansion Battery is a versatile and powerful battery pack with a
capacity of 2,150Wh. It is designed to work in tandem with the BLUETTI AC240 inverter,
which allows you to expand your battery capacity to 10,136Wh by connecting up to four
B210 batteries in parallel.
The B210 can also work independently as a power source for specific DC appliances. With
USB-A, USB-C, and 12V cigarette lighter outputs, the B210 is compatible with a wide range
of devices, from laptops and smartphones to car fridges and camping heaters. Additionally,
the B210 offers a variety of charging options, including solar, car cigarette lighter, 12V
lead-acid battery, or power adapter, so no matter where you are, you can always keep the
B210 charged and ready to go.
2 3 4 65
8
10
1
9
7
Cigarette Lighter Port
USB-A Port
DC Power Button
Bleed Valve
Input Port
⑥
⑦
⑧
⑨
⑩
Battery Expansion Port
Battery Expansion Port
Power Button
USB-C Port
SoC / Alarm Indicator
①
②
③
④
⑤
JUST POWER ON 11
4. Power ON / OFF
5. Charging
The B210 can be charged using a standard wall outlet, solar energy, a car power source, or
in combination with the AC240 power station.
Notice：
• Double-check that all cables are firmly plugged in.
• Avoid getting plugs and ports wet to prevent any potential damage.
5.1 Wall Outlet
Simply plug the B210 into a standard wall outlet to start charging. It typically takes about
4.8-5.3 hours for a full charge at an ambient temperature of 25°C (77°F), and the charging
automatically stops once the battery is fully topped up.
To power on the B210, press and hold the Power Button for about 2 seconds, the SoC
indicator will light up.
The B210 has a built-in feature that allows it to power on and starts charging as soon as it
detects input from a connected power source (e.g., wall outlet, solar panel, etc.).
To restart the B210, simply press and hold the Power Button for more than 2 seconds to
shut down all outputs and turn off the unit. Press the button again to turn it back on.
Note: To completely turn off the B210, please disconnect all power sources, such as solar
panels and adapter.
JUST POWER ON12
5.2 Solar Panel(s)
Connect the solar panel(s) to B210 via the solar charging cable. With a continuous input
of 500W, B210 will automatically stop charging in 4.5-5 hours. However, please note that
the charging time may vary based on weather conditions, sunlight intensity, panel
orientation, and other variables.
Note: Make sure your solar panel(s) meet the following requirements:
Voc: 11V-60V Current: 10A Max. Power: 500W Max.
5.3 Car Outlet
Connect the B210 to the vehicle's 12V cigarette lighter port via the car charging cable.
The B210 also automatically stops charging when it's fully charged.
Note: Make sure your vehicle meets the following conditions for charging:
• The vehicle is capable of supplying power.
• The vehicle's engine is running during the charging process.
• If you unplug the solar charging cable from the B210 and you're not using any DC
outputs, the B210 will automatically shut down after about 4 hours.
For solar panel(s) with an open circuit voltage between 60V and 145V, you can still use
them to charge the B210. Simply connect the solar panel(s) to the B210 via the PV
Voltage Regulator, and you can enjoy seamless and hassle-free solar charging.
Notice：
JUST POWER ON 13
Attention:
The B210 has a low voltage disconnect function designed to protect your vehicle's
battery during charging. If the input voltage drops below 8V, the unit will automatically
stop charging to prevent over-discharging and potential damage to the battery.
5.4 AC240 Power Station
To charge both the AC240 and B210 simultaneously, connect the two units using the
battery expansion cable provided. Then, plug the AC240 into a standard wall outlet.
Attention:
It's recommended to fully charge the B210 before connecting it to AC240.
JUST POWER ON14
6. Discharging
The B210 is equipped with three DC outlets, including a USB-C port, a USB-A port, and a
cigarette lighter port, which allow you to charge a variety of devices.
Note: To ensure optimal performance, avoid short-circuiting the ports and keep them dry
during use or storage. Additionally, do not block or cover the ports while ensuring proper
ventilation.
Port
Cigarette Lighter Port
USB-A
USB-C
Specifications
12V / 10A
QC 3.0, 18W Max.
PD 3.0, 100W Max.
Compatible Loads
12V DC appliances up to 120W power.
e.g. car refrigerator, air conditioner
Mobile phones and other small loads.
Mobile phones, laptops, etc.
7. AC240 + B210 Expansion Connection
The AC240 is compatible with up to 4 B210 units, providing an impressive total capacity of
up to 10,136Wh. To connect them:
Step 1: Make sure both AC240 and B210 are turned off.
Step 2: Connect them using the battery expansion cable.
Step 3: Power the AC240 on and the B210 turns on automatically. The displays on the
AC240's screen.
JUST POWER ON 15
AC240 + 1 × B210
AC240 + 4 × B210
If you want to add more B210 units, please set up the system as shown.
Attention：
The AC240 connects to the upper battery expansion port of B210.
JUST POWER ON16
8. BLUETTI APP
Scan the QR code below or search "BLUETTI" in the App Store or Google Play to download
the BLUETTI App.
Attention：
Only when connected with the AC240 can you use the app to view the operating status
of the B210 and upgrade its firmware over-the-air (OTA). For detailed instructions on
how to use the app to manage B210, please refer to the BLUETTI App User Guide.
JUST POWER ON 17
9. Specifications
Battery Capacity
Cell Type
DC Input
Weight
Dimensions (L × W × H)
Charging Temperature
Discharging Temperature
Storage Temperature
Working Humidity
Noise
Working Altitude
2,150Wh (42Ah)
Lithium Iron Phosphate (LiFePO4, LFP)
500W Max.
27.9kg / 61.5lbs
416.6mm × 282.4mm × 269.5mm / 16.4in × 11.1in × 10.6in
0°C to 40°C / 32°F to 104°F
-20°C to 40°C / -4°F to 104°F
Up to 1 month: -20°C to 45°C / -4°F to 113°F
Up to 3 months: -20°C to 30°C / -4°F to 86°F
Up to 12 months: -20°C to 25°C / -4°F to 77°F
10% to 90%
40dB Max.
2,000m / 6,561ft
Model B210
Cigarette Lighter Port × 1
USB-A × 1
USB-C ×1
12VDC / 10A
18W Max. (QC3.0: 5V / 3A; 9V / 2A; 12V / 1.5A)
100W Max. (PD3.0: 5 / 9 / 12 / 15 / 20V 3A; 20V / 5A, with built-in EMark chip)
DC Output
Power
Voltage
Current
470W Max.
58.8VDC
8A Max.
T500 / T500S Input
Interface
Power
Voltage
Current
DC Input
Input Voltage
Input Current
51.2VDC
60A Max.
Battery Expansion Port × 2
2-pin Aviation Socket
500W Max.
11VDC to 60VDC
10A Max.
JUST POWER ON18
JUST POWER ON 19
10. Troubleshooting
In case of a B210 failure, the Power Button or DC Power Button light will flash. If the latter
flashes, press and hold it for about 3 seconds, and the SoC indicator will start flashing.
Please refer to the table below for helpful guidance.
Flashing Indicator Description
BMS failure
PV input overvoltage or
charging temperature
too high
DC output overload
Power off the B210, and disconnect
all electrical connections.
Ensure that PV input voltage is
within the range of 11VDC to 60VDC;
when the temperature is too high,
wait for it to cool down before
charging.
Check if the power consumption of
your devices is too high.
Reduce the load if necessary.
Power Button Light
Second SoC Indicator
Third SoC Indicator
Troubleshooting
DC output overcurrent
Operating temperature
too high or too low
/
Check if the power consumption of
your devices is too high.
Reduce the load if necessary.
Recommended charging temperature:
0°C to 40°C / 32°F to 104°F
Recommended discharging temperature:
-20°C to 40°C / -4°F to 104°F
Please contact BLUETTI support
for assistance.
Fourth SoC Indicator
Fifth SoC Indicator
Others
11. FAQ
Q1:
A:
Q2:
A:
Q3:
A:
Q4:
A:
Q5:
A:
Q6:
A:
Can I use third-party solar panels to charge this product?
Yes, you can. However, make sure your solar panels have an open circuit voltage of
11V-60V and are equipped with MC4 connectors. It's also important not to mix
different types of solar panels.
Can it charge and discharge at the same time?
Yes. It supports pass-through charging. The B210 comes with the premium LiFePO4
battery and proprietary Battery Management System to ensure that it can charge
and discharge at the same time.
Why is the charging power often too low?
B210 has a built-in intelligent BMS that automatically adjusts the charging power in
response to the battery temperature and SoC, thus protecting the battery and
extending its service life.
How to upgrade the firmware of B210?
Connect it to AC240, pair the system with BLUETTI App, and you can upgrade the
firmware including ARM, DSP, HMI and BMS over-the-air (OTA).
Why does the B210 automatically turn itself on?
When the B210 detects input from connected power sources such as solar panels
and wall outlets, it will automatically turn on and start charging.
If I forget to turn off the B210, will it automatically power off by itself?
If the B210 is not connected to any power sources or electrical appliances, it'll
automatically turn off after 4 hours of inactivity.
JUST POWER ON20
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio / TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
IMPORTANT NOTE: FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum
distance of 20cm between the radiator & your body.
Appx. 1 FCC Statement
JUST POWER ON 21
This device contains licence-exempt transmitter(s) / receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
RF exposure statement: The equipment complies with IC Radiation exposure limits set
forth for uncontrolled environments. This equipment should be installed and operated
with a minimum distance of 20cm between the radiator and your body.
CAN ICES-3 (B)/NMB-3(B) (Canada)
This Class B digital apparatus complies with Canadian ICES-003.
Appx. 2 IC Caution
JUST POWER ON22
Appx. 3 Consignes de sécurité
Lisez ce manuel pour savoir comment utiliser correctement le produit et connaître les
consignes de sécurité correspondantes. Les exigences en matière de sécurité sont
fournies à titre d'exemple et comprennent, sans s'y limiter, les exigences énumérées
dans le présent manuel. Le fonctionnement réel doit être conforme à toutes les normes
de sécurité applicables. Si vous avez des questions, n'hésitez pas à contacter l'équipe de
support BLUETTI ou votre revendeur local.
1) Déclaration
Pour garantir un fonctionnement sûr, il est essentiel de respecter les conditions suivantes:
• Utilisez ou stockez toujours le produit dans les conditions spécifiées dans ce manuel.
• Évitez tout démontage, tout remplacement des composants ou toute modification des
codes logiciels non autorisés.
BLUETTI n'est pas responsable des dommages résultant des circonstances suivantes:
•
Les cas de force majeure tels que les tremblements de terre, les incendies, les
tempêtes, les inondations ou les coulées de boue.
• Les dommages causés par le transport du client.
• Les dommages résultant de conditions de stockage inadéquates telles que spécifiées
dans le manuel.
• Les dommages causés par la négligence du client, une mauvaise utilisation ou des
actions intentionnelles.
• Les dommages occasionnés au système ou au matériel par des tiers ou des clients, y
compris, mais sans s'y limiter, une manipulation ou une installation non conforme aux
consignes du présent manuel.
• L'utilisation du produit avec des appareils nécessitant une alimentation sans interruption
(ASI) de haute performance, y compris, mais sans s'y limiter, les serveurs de données, les
stations de travail, les équipements médicaux et d'autres appareils similaires.
AVERTISSEMENT–Les précautions de base suivantes doivent toujours être prises lorsque
vous utilisez ce produit:
a. Lisez l'ensemble des consignes avant toute utilisation du produit.
b. Pour réduire le risque de blessure, une surveillance étroite est nécessaire lorsque vous
utilisez le produit à proximité d'enfants.
c. Ne placez pas vos doigts ou vos mains à l'intérieur du produit. N'insérez pas de corps
étrangers dans les ports du produit.
2) Exigences générales
CONSIGNES RELATIVES AU RISQUE D'INCENDIE, D'ÉLECTROCUTION OU DE BLESSURE
CONSIGNES DE SÉCURITÉ IMPORTANTES
JUST POWER ON 23
d. L'utilisation d'un accessoire non recommandé ou vendu par le fabricant peut entraîner
un risque d'incendie, d'électrocution ou de blessure.
e. Pour réduire le risque d'endommagement de la fiche et du câble électriques, tirez au
niveau de la fiche plutôt que sur le cordon lors du débranchement.
f. N'utilisez pas un bloc-batterie ou un appareil endommagé ou modifié, car ils peuvent
présenter un comportement imprévisible entraînant un risque d'incendie, d'explosion ou
de blessure.
g. N'utilisez pas le produit avec un câble ou une fiche endommagés, ou un câble de sortie
endommagé.
h. SEUL du personnel autorisé peut remplacer la batterie interne ou tout autre composant
du produit. Aucun composant ne peut être réparé par l'utilisateur final. Ne démontez pas
le produit par vous-même, adressez-vous à un technicien qualifié pour tout service de
réparation ou d'entretien. Un réassemblage incorrect peut entraîner un risque d'incendie
ou d'électrocution.
i. Pour réduire le risque d'électrocution, débranchez le produit de la prise avant de
procéder à toute opération d'entretien prévue dans les consignes.
j. AVERTISSEMENT – RISQUE DE GAZ EXPLOSIFS. Pour réduire le risque d'explosion de la
batterie, suivez ces consignes ainsi que les consignes du fabricant de la batterie et du
fabricant de tout équipement que vous avez l'intention d'utiliser à proximité de la batterie.
Examinez les mises en garde apposées sur ces produits et sur les moteurs.
k. PRÉCAUTIONS PERSONNELLES
1)Protégez-vous complètement et portez des vêtements et des lunettes de protection.
Évitez tout contact avec les yeux lorsque vous travaillez à proximité de la batterie.
2)Ne fumez JAMAIS et ne produisez JAMAIS d'étincelles ou de flammes à proximité de la
batterie ou du moteur.
3)Travaillez avec une extrême prudence et évitez toute chute d'outil métallique sur la
batterie. Cela pourrait provoquer une étincelle ou un court-circuit de la batterie ou d'autres
pièces électriques, entraînant par conséquent un risque d'explosion.
l. Lorsque vous chargez la batterie interne, travaillez dans un endroit bien ventilé et ne
limitez en rien la ventilation.
m. Dans des conditions abusives, du liquide peut être éjecté de la batterie, évitez tout
contact. En cas de contact accidentel, rincez à l'eau. Si le liquide entre en contact avec les
yeux, consultez immédiatement un médecin. Le liquide éjecté de la batterie peut provo-
quer des irritations ou des brûlures.
n. N'exposez pas le produit au feu ou à une température excessive. L'exposition au feu ou à
une température supérieure à 130°C peut entraîner un risque d'explosion.
o. Confiez l'entretien du produit à un réparateur qualifié qui utilisera uniquement des
pièces de rechange identiques, de manière à assurer une sécurité continue.
JUST POWER ON24
3) Consignes de mise à la terre
Ce produit doit être mis à la terre. En cas de dysfonctionnement ou de panne, la mise à
la terre fournit un chemin de moindre résistance pour le courant électrique afin de
réduire le risque d'électrocution. Ce produit est équipé d'un câble muni d'un conducteur de
mise à la terre et d'une fiche de mise à la terre. La fiche doit être branchée dans une prise
correctement installée et mise à la terre conformément à tous les codes et règlements
locaux.
AVERTISSEMENT
Une mauvaise connexion du conducteur de mise à la terre de l'équipement peut
entraîner un risque d'électrocution. Vérifiez auprès d'un électricien qualifié en cas de
doutes quant à la mise à la terre de l'appareil. Ne modifiez pas la fiche fournie avec le
produit. Si elle n'est pas adaptée à la prise, faites installer une prise adéquate par un
électricien qualifié.
4) Consignes de stockage
a. Lorsque le SoC atteint 5%, veuillez charger le produit immédiatement.
b. Avant de stocker le produit, veuillez le charger de manière à ce que le SoC soit compris
entre 40% et 60% afin de préserver l'état optimal du produit. De plus, éteignez le
produit et débranchez toutes les raccordements électriques de celui-ci.
c. Stockez le produit dans un endroit frais et sec, à l'écart des matériaux et des gaz
inflammables ou combustibles.
p. N'utilisez PAS le produit dans des conditions humides. Si le produit est mouillé, veuillez
le sécher soigneusement avant de l'utiliser.
q. Veuillez assurer une ventilation adéquate pendant l'utilisation et ne pas obstruer les
ouvertures du ventilateur. Une ventilation inadéquate peut causer des dommages
permanents sur le produit.
r. NE placez RIEN sur la surface supérieure du produit lors de l'utilisation ou du stockage.
NE déplacez PAS le produit pendant son fonctionnement, car les vibrations et les chocs
soudains peuvent conduire à de mauvaises connexions avec le matériel à l'intérieur.
s. En cas d'incendie, seul un extincteur à base de poudre sèche est adapté au produit.
t. AVERTISSEMENT – RISQUE DE CHOC ÉLECTRIQUE. N'utilisez jamais le produit pour
alimenter des outils électriques dans le but de couper ou d'accéder à des pièces ou des
câbles sous tension, ou à des matériaux pouvant contenir des pièces ou des câbles sous
tension, tels que les murs d'un bâtiment, etc.
u. Pour éviter tout contact avec des liquides, n'utilisez pas ce produit par temps de pluie ou
dans des environnements à forte humidité.
JUST POWER ON 25
• Mettez-le immédiatement hors tension.
• Chargez-le dans les 48heures.
• Placez-le à une température ambiante comprise entre 5℃ et 35℃ (entre 41℉ et 95℉)
pendant 24heures avant de le charger. Il est recommandé de charger le produit via
une source CA. Si vous le chargez à l'aide de l'énergie solaire, assurez-vous que votre
système solaire fournit une puissance supérieure à 100W.
BLUETTI n'est pas responsable des dommages causés à l'équipement en raison du
non-respect des consignes ci-dessus.
CONSERVEZ CES CONSIGNES
Le symbole représenté vous rappelle de lire les consignes figurant dans la
documentation accompagnant le produit avant toute utilisation ou tout entretien.
• Branchez le produit sur une prise de courant avec mise à la terre à l'aide du câble
d'alimentation fourni.
• La prise de courant doit être installée à proximité du produit et facilement accessible
pour des raisons de sécurité.
• Concernant l'élimination, ne JAMAIS procéder aux actions suivantes pour cause de
risque d'explosion: ne jamais placer une batterie au feu ou dans un four chaud et ne
jamais écraser ou couper mécaniquement une batterie.
• Évitez de placer les batteries dans des environnements à très haute température, car
cela peut entraîner une explosion ou une fuite de liquide ou de gaz inflammable.
• Les batteries soumises à une pression d'air extrêmement basse peuvent entraîner une
explosion ou une fuite de liquide ou de gaz inflammable.
• Il convient d'attirer l'attention sur les critères environnementaux quant à l'élimination
des batteries.
• Avant toute installation ou utilisation de l'appareil, veuillez vous référer aux informations
figurant sur le dessous extérieur de l'appareil pour obtenir des informations sur les
caractéristiques électriques et la sécurité.
Si le SoC chute à 0 (pendant le stockage ou au démarrage), prenez les mesures
suivantes pour redémarrer le produit en toute sécurité:
d. Le produit peut être stocké en toute sécurité à une température comprise entre -20℃
et 40 ℃ (entre -4℉ et 104℉). Toutefois, si la durée de stockage dépasse un mois, il est
recommandé de maintenir une température de stockage idéale d'environ 30℃ (86℉).
Afin de maintenir le produit en bon état, veuillez décharger et charger complètement
l'appareil au moins une fois tous les 3mois. l n'est PAS recommandé de stocker l'appareil
pendant des périodes prolongées, car cela peut altérer les performances et la durée de
vie générale du produit.
JUST POWER ON26
@ BLUETTI Support
@ BLUETTI Official
@bluetti.inc@ bluetti_inc @bluetti_official service@
bluettipower.com
For more information, please visit:
Web: https://www.bluettipower.com
SHENZHEN POWEROAK NEWENER CO., LTD.
Add: F19, BLD No.1, Kaidaer, Tongsha Rd No.168, Xili Street,
Nanshan, Shenzhen, China
USA Agent
Company: BLUETTI POWEROAK INC
Add: 6185SVALLEYVIEWBLVDSTEDLASVEGAS
NEVADA89118UnitedStates
FRN: 0033559824
Customer Service
Tel: 800-200-2980 (Monday to Sunday 9:00-17:00)
Email: sale@bluettipower.com (Pre-sales),
service@bluettipower.com (After-sales)
P/N:17.0303.0631-02A2
Certificate
Inspector:
QC:
