WYBOT WY210 S2 Pro Charging Dock High-end Cordless Robotic User Manual

WYBOT S2Pro(WY210)

Robotic Pool Cleaner

User Manual

Read through the entire manual before running your new

robotic pool cleaner, and keep this manual handy

for your reference.

MODE

www.wybotpool.com

E-mail: [email protected]

Facebook: @WybotPool

WYBOTICS CO.,LTD

No.30,Zhongnan 4th Street West Zone,TEDA Tianjin,China

All trade names are registerred trademarks of respective

manufacturers listed.

Thank you for choosing WYBOT products, your support means a lot to us. Continu-

ous providing the best solution to free you up from pool cleaning and enjoy your

family time is always our pursuit.

WYBOT Robotic Pool Cleaner is dedicated to serving you high efficiency, low power

consumption, easy operation and thorough pool cleaning work.

Its unique appearance and reliable functions as one-button activation, powerful

suction and scrubbing, fine filtration, smart navigation, remote control, and high

compatibility with various pool shapes and constructions materials assure you a

convenient, intelligent, and optimal pool cleaning.

Feel free to contact us by Email or visit our website with any questions. We are very

glad to

hear your advice on our continuous improvement.

Caution

Failure to operate the device as per the warnings can cause a damage to the device

or personal damage.

1. Firmly stick the station hook onto a flat wall with the tape included.

2. If the pool liners comes away or is damaged, please repair it before sticking the

charging station on the wall.

3. Fully charge the unit before first use.

4. Do not over charge the cleaner, which will reduce the battery life.

5. Charge the cleaner prior to being stored for a long time (over 6 months) to main

tain an optimal battery life.

6. Remember to wash and clean the filter basket after each use.

7. Store the cleaner in a cool and ventilated place, away from direct sunshine or

any heat source.

8. Use only the pool cleaner in the following water conditions:

Chlorine

Temperature

NaCl

Read the manual carefully before you use the cleaner. Your safety is the most

important thing. Please read through and operate the device as per instructions,

WYBOTICS Co., Ltd. is not held liable for any loss or injury caused by improper use.

Warning

Failure to operate the device as per the warnings can result in serious injury,

electrocution or death.

1. Use only the accessories recommended or sold by WYBOTICS Co., Ltd.

2. Use only the original and authorized charging station. Avoid charging any

other types of devices with this station. Improper use may result in overheating

or corrosive liquid leakage from the battery.

3. Cut off power supply when doing any maintenance or removing it from the pool.

4. In case of any abnormal operation from the charging station, cut off the power supply

immediately, and remove the robotic cleaner from the station. Contact professionals at

once.

5. Make sure the electrical outlet is protected by a ground fault circuit interrupter

(GFCI) and an earth leakage interrupter (ELI).

6. Do not use a cord-damaged charger to avoid any electrical shock.

7. Do not try to use nonauthorized extension cord to connect the charger to the

station.

8. Never allow children to ride on the cleaner/docking station or play with them as

toys.

9. Do not allow child to operate or maintain the device or docking station.

10. Do not enter the pool when the cleaner is working in it.

11. Never expose or charge the device in flammable environments.

12. Only licensed professionals can disassemble the sealed parts of the clean-

er/docking station.

13. Do not operate the cleaner while pool filter is running.

Max 4 mg/L

7.0 - 7.8

41 - 95 ℉ (5 - 35 ℃)

Maximum 5000 PPM

WYBOT S2PRO(WY210) AT A GLANCE

Product External Overview

Product Internal Overview

Packing List

INSTALL YOUR DOCKING STATION

GET STARTED

Charge your new WYBOT S2Pro(WY210)

Setup your new WYBOT S2Pro(WY210)

Connect to your App

Choose your cleaning mode

Run your new WYBOT S2Pro(WY210)

DO A FILTER CLEANING

PUT IT BACK TO DOCKING STATION

HOW TO DETACH THE DOCKING STATION

DEVICE SPECIFICATION

LIMITED WARRANTY

HOW TO MAINTAIN YOUR DEVICE

FAQ & TROUBLE SHOOTING

CERTIFICATION

WYBOT CUSTOMER CARE

CONTENTS

WYBOT S2PRO(WY210) AT A GLANCE

Product External Overview

MODE

Handle

Remove and transport the device with it

LED Indicator

Different light colors to indicate device status

Cleaning Mode

Customize cleaning needs on the cleaner

Pump

pump out water through the window

on/off Button

Turn on/ turn off the device

Track

Enhance device’s capability in climbing walls

and various obstacles

Scrubbing Brush

Knock loose all dirt and roll them all into the

device

a Start/Stop

Press to start/stop pool cleaning

b Indicator

Indicate status of the docking station

c Home

Press to call the cleaner back

Charging Port

Connect the charger

Lid Open Button

Open the cover to take out the filter basket

Product Internal Overview

Do not operate the device when the top cover or scrubbing brushes are broken.

If there is any liquid leakage from the sealed part, stop charging or running

the device.

Filter Basket (180µm)

Store collected dirt and debris, need to be installed

before cleaning, and washed after each use.

Sealed Part

Important components are sealed there.

For your safety, do not try to disassemble it

without authorization.

Filter Foam (Cotton foam)

An auxiliary filter to help trap the fine dirty

particles. Recommend to use it for floor

cleaning.

Please do not install it when the pool

water is heavy dusty, it may influence the

operation of the cleaner.

Packing List

Device x 1

User Manual x 1

Filter x 2

Charger x 1Quick Start Guide x 1

Floating Parts

Hook x 1

MODE

Docking Station x 1

Adhensive Tapes

INSTALL YOUR DOCKING STATION

WYBOT S2 Pro is equipped with a docking&wireless charging station that you can

find in your package.

You need to install this station onto your pool wall to create a good working condi-

tion for WYBOT S2 Pro. Please follow below steps.

Take out three included adhensive

gel nano tapes, and stick them onto

the marked area on the station hook

back side.

Adhere the station hook onto the

tape that you have sticked firmly and

horizontally.

Place the main body of the station

onto the hook.

Hook Front Side

Hook Back Side

Minimum distance: 100mm

Note:

1. This charging station is suggested to be sticked onto a flat and smooth wall

surface, rough surface such as pebble material may not work very well.

2. The station hook bottom shall be 20mm higher than the waterline.

3. The water depth of the installation area shall reach 1.2m at least, and there

should be no steps, sitting area or light under the docking station.

Find a flat wall 20mm above the

waterline with a smoother surface

and less dirt. Use a cloth to dry the

surface. Ensure the area is not

smaller than the hook.

Cure for at least 48 hours

without bearing any weight.

Note:

1. It is highly recommended to install the docking station of the WYBOT S2Pro

onto a pool wall of regular shape pool, otherwise it may affect the working of it.

2. Double check the connections before starting the cleaning.

Insert the included extended charging

line to the socket on the line of the st-

ation.

Stretch out the charging line and plug

the adaptor into a power outlet that

should be at least 3.5m(11.5ft) away

from the pool.

Plug the adaptor into a power supply,

and the LED indicators turn solid

blue.

GET STARTED

The device has a lithium-ion rechargeable battery, and you need to charge the batte-

ry before first use or when the battery is low.

Charge your new WYBOT S2Pro(WY210)

Note:

1. For reducing fire risk, keep your docking station beneath the water when

staring charging.

2. No charging devices on shore using docking station.

MODE

Turn on the device and the indicators

on the front turn solid blue.

Hold the handle of the cleaner, and put it

into the pool vertically.

After 20s of self-calibration of the

cleaner, press the home button to

call it back to the docking station.

Fully Charged！

Start to fully charge itselft automa-

tically.

MODE

Note:

1. For maintaining a favourite working status, you need to keep the docking

station always being powered on.

2. When yellow light flashes, the robotic pool cleaner will back to the docking

station for the inductive charging.

3. If red LED light is on, you can find solution from trouble shooting in this

manual or call for service.

Indication

Solid

Flashing

Solid

Flashing

Breathing (bright to dim)

Solid or flashing

Status

Power On

Under working

Connecting to App

Low battery or under

self-parking in the pool

Self-parking completion

Fault

LED Light

Device

Robotic

Pool

Cleaner

Solid

Solid or flashing

Power On

Able to control the robot

Fault

Docking

Station

charging

Baterry Level

Solid

Flashing or Solid

Setup your new WYBOT S2Pro(WY210)

You can download the WYBOT App to your smart mobile device by scanning QR code

below, or from Google Play or App Store.

Connect to your App

iOS Android

iOS 15.0 or later Android 8.0 or later

You can choose a cleaning mode for your cleaner on the device or through the app

after connecting to your App.

Choose your cleaning mode

Select a mode via the toggle

Indication

Icon

Toggle a cleaning mode

Wall*1 then floor*1 (default)

There are two types of full-pool cleaning in the app, you can customize this icon there.

Pool floor cleaning

There are three types of floor cleaning in the app, you can customize this icon there.

Pool walls cleaning

MODE

Note:

Before connection to your App, please ensure your cleaner is charging on the

docking station.

Note:

1. There are more cleaning mode options in the app, and you can refer to it below.

2. You should modify your cleaning modes via App when out of pool.

3. If the device restarts, it will automatically enter the cleaning mode you set

last time.

Mode

Cleaning Coverage

Standard Full Pool

Floor Only

Wall Only

Waterline

Wall then floor (Combo)

Eco floor

Turbo Floor

Wall+ Floor+Waterline

Pool Floors

Pool Walls

Pool Waterline

Wall *1+ Floor *1

Eco mode, floor cleaning only

Strong cleaning, floor cleaning only

Run your new WYBOT S2Pro(WY210)

MODE

Let it move back to the pool floor.

Press the start/stop button on the

docking station or click the start

cleaning button to start the pool

cleaning.

The cleaner begins to clean walls, floor

and waterline as default or your set

through App.

You can control the cleaner remotely

and complete the specific area

cleaning via the App.

The device will automatically move to

the docking station when finishing

cleaning or battery is low.

Remove the cleaner from the dock-

ing station and power it off.

DO A FILTER CLEANING

Press the filter cover handle and lift the cover up.

Note:

1. You should ensure the device is power off when open the top cover.

2. You need to clean the filter basket after each use.

Take out the filter basket and cotton

foam.

Empty all debris and rinse it with clean

water.

As electric components inside the

cleaner, store the cleaner in a cool

and ventilated place, away from di-

rect sunshine or any heat source.

Charge the cleaner prior to being

stoed for a long time (over 6 mon-

ths) to maintain an optimal battery

life.

After rinsing, put the filter basket and

cotton foam into the cleaner and close

the cover.

MODE

PUT IT BACK TO DOCKING STATION

Turn on the device and put it into the

pool vertically.

MODE

Press the home button to call the

cleaner back to the docking station.

If your cleaner is powered off because of the low battery, you can put the

cleaner onto the docking station manually.

Hold the handle of the cleaner, and emerge

it into pool water vertically.

Shake the cleaner horizontally to empty

trapped air inside.

MODE

Put the cleaner onto the docking station

carefully or put it into the pool and call it to

the docking station.

Start to fully charge itselft automa-

tically and keep standing by for next

cleaning cycle.

MODE

HOW TO DETACH THE DOCKING STATION

There are two small fasteners on the top of

the docking station, and you can push them

to remove the main part from the hook.

Detach it successfully.

Note:

1. As electric components inside the docking station and cleaner, store the

cleaner in a cool and ventilated place, away from direct sunshine or any heat

source.

2. Charge the cleaner prior to being stored for a long time (over 6 months) to

maintain an optimal battery life.

1. All WYBOT pool cleaners in the market have been inspected and licensed to be

sold as per local laws.

2. The warranty duration for battery, motor and PCB is two (2) years from the purchas

ing date. Consumable parts, including filter basket, brush, wheels etc., are beyond

warranty.

3. The warranty apply only to original buyers, and not valid to resale and any other

kinds of transfer.

LIMITED WARRANTY

DEVICE SPECIFICATION

Model

Pool Size

Depth

Device Dimension

Weight

Runtime

Charging Time

Voltage

Power

Charger Input

Charger Output

Battery Capacity

Filtration

Flow Rate

Moving Speed

Water Resistance

OTA upgrading

App Connection

WYBOT S2Pro (WY210)

Up to 300

(3229.173ft²)

9.8ft (3m)

400(L)*390(W)*255(H) mm

157(L)*154(W)*100(H) inch

8.5 Kg (Robotic cleaner)+3.3Kg (Station)

3.5 hours

3 hours (direct charging)

Battery/25.9V

90W

100-240V, 47-63Hz

29.4V/3A

7800mAh

Double-level

14m³/H (3962GPH)

10m/min.

IPX8

Available

4. Any damages to the unit caused by improper use, unauthorized repair or disas-

sembly are not covered by WYBOTICS Co., Ltd.’s warranty.

5.The order number or record must be presented for any claim or repair within the

warranty period.

Note:

If your device do not work after a long-term low battery life or being off, please

contact after-sale team for help. For your safety, do not try to disassemble it

without authorization.

You should follow the steps to store your cleaner to maintain good performance.

a) Ensure the device is power off

b) Dry out the cleaner and filter basket

c) Fully charge the battery

d) Store the cleaner in a cool and ventilated place, away from direct sunshine,

heat source, frost and squeezing with an ambient temperature between 5℃/ 41

℉ and 45℃ / 113℉.

e) Charge the cleaner every three months to ensure an optimal battery life.

HOW TO MAINTAIN YOUR DEVICE

Q: What pool shapes and construction materials is the cleaner suitable for?

A: The machine can be applied to rectangle, oval, or irregular shapes of in-ground

swimming pools. Applicable construction materials include PVC, guinite, tile and

other materials.

Q: Will obstacles such as steps, shallow water areas, drains, slopes etc. in the

swimming pool affect the running?

A: The machine can climb steps, drains, and shallow water areas. The above obstacl-

es may influence its cleaning path, but will not affect the operation of the machine.

Q: Are the WYBOT App able to control the device when cleaning under water?

A: Since the signal can not be transferred under water, you need to preset the clean-

ing mode and cleaning path before put into the pool.

FAQ & TROUBLE SHOOTING

If you encounter the following situations when using the cleaner, you can check

the table and solve them by yourself.

Issues

Possible Causes

WYBOT WY210 S2 Pro Charging Dock High-end Cordless Robotic Pool Cleaner

Product's Documents

User Manual

Specifications

WYBOT WY210 Questions and Answers
