ITEM NUMBER: HKCDRW2
PARTS
TOOLS NEEDED
A
B
E
0361506A
Drawer divider (F) is included. Place
3 long strips in drawer first with slots
facing upward. Place 3 small strips
over long strips so they inter-lock.
x3
F
F
x3
*Overall weight limit of items
stored in drawer must not
exceed 15 lbs/6.8 kg.
2
Pull drawer slides (B) out of drawer (A) as far as they can be pulled out. Push lever up or down to release
drawer slide (B) from the drawer (A) completely. Repeat on the other side. Set drawer aside.
ASSEMBLY
B
1
2
Screws will go through holes in slides and insert into these two hole locations on side panels.
ATTACH SLIDES HERE
B
1
1
A
B
B
x2
1
2
2
3
ASSEMBLY
B
B
1
3
Attach slides (B) into inside of panels as shown using three screws (E). IMPORTANT: Slide away inner slide
to expose appropriate screw holes. See step 4 for correct screw locations.
B
1
2
IMPORTANT:
Inner slide has been removed for clarity.
Use this hole to first mount front location
B
1
4a
2
1
OUTER SLIDE
INNER SLIDE
Use a ashlight to help
locate the holes.
4
ASSEMBLY
A
B
B
1
5
2
Pull slides (B) out of cabinet. Slide the drawer (A) into ends of drawer slides (B) located inside cart and
slide all the way in to lock.
HKC2000 is model shown
IMPORTANT:
Inner slide has been removed for clarity.
Use this hole to mount rear location second.
B
1
4b
2
2
