Rechargeable
Battery Work Light
PARTS IDENTIFICATION
SKU No: 370-5480
MODEL No: Z-1800-A6-A01
1
Stretch Stand
ETL listed Adapter
Magnet
Battery Box
ON/OFF Switch
DC Charging Port
1. Rated Power(W) : 15W
2. CCT(K): 4000K
3. CRI: 80
4. Lumen(lm): 1800lm (Ni-Mh 2700mA/pcs)
1300lm (Adapter)
5. Lighting Effect(lm/w): 120lm/w
6. Modes: Low-Middle-High
7. Adaptor: Input 100-240V
Output 6.5V/1.8A
8. Running Time: Low 4h Middle 2.5h High 2h
(Base on Ni-Mh 2700mAH/pcs)
9. Charging Time: 5h
10. Battery Type: Ni-Mh Rechargeable Battery AA*4
Dry Battery AA*4
*No Battery Included
11. With Magnet
SKU No: 370-5480
MODEL No: Z-1800-A6-A01
1 YEAR LIMITED WARRANTY
CUSTOMER SERVICE
TROUBLESHOOTING
SAFETY INFORMATION
BATTERY/ADAPTER OPERATIONS(BATTERIES NOT INCLUDED)
2
1. Integrated LED’s never need to be replaced.
2. DO NOT look directly at the LED lens.
3. RECOMMENDED:Use AA Rechargable Batteries (>2200mAh).
4. After operating (Light-ON),please allow batteries proper cooling time before touching or replacing.
1. Place DRY or Rechargeable batteries into battery compartment.
For ON/OFF operations,please press ON/OFF button located
on the backside of the light.
2. When operating the light with Rechargeable batteries,
use the included adapter plug to recharge batteries.
Dimmable setting, 25% - 50% - 100% - Off
3. The light can be operated without batteries (DRY
or Rechargable).For non-battery operations, please
use the included plug-in adapter.
4. Powerful magnets on the stand can be used for
hanging on any metal object(s).
5. This light can be used while recharging.
Magnet
PROBLEM POSSIBLE CAUSES CORRECTIVE ACTIONS
The work light will
not work
Low battery power
Replace new batteries
No battery power
Change the batteries
5. NEVER submerge the light and or cord in water.
Using wrong adapter Use correct adapter
For question/comments, please contact at 1-855-508-3883 or through an authorized reseller.
This product is guaranteed against failure due to the factory defects in materials workmanship
for one year from the date of purchase. This warranty does not cover normal wear of parts or
damage resulting from any misuse of the product.
Important: This warranty is only valid if the product has been purchased through an authorized
reseller. Proof of purchase is required for repair or replasement. Misuse of the product
includes but is not limited to :washing the product,using in extreme weather conditions,open-
ing the products, or try to remodel the product.
