Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 19k
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright
©
2019 by Harbor Freight Tools
®
. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
To ols required for assembly and se rv ic e m ay n ot b e i nc lu de d .
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 For technical questions, please call 1-888-866-5797. Item 56791
SaFety OperatiOn MaintenanceSetup
table of contents
Safety .................................................2
Specifications .....................................8
Setup ..................................................8
Operation ............................................9
Maintenance ......................................11
Parts List and Diagram ......................14
Warranty ............................................16
WarninG SyMBOLS anD DeFinitiOnS
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
iMpOrtant SaFety inFOrMatiOn
General power tool Safety Warnings
read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term ″power tool″ in the warnings refers to your battery‑operated (cordless) power tool.
Work area Safety
1. Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which
may ignite the dust or fumes.
3. Keep children and bystanders
away while operating a power tool.
Distractions can cause you to lose control.
Page 3For technical questions, please call 1-888-866-5797.Item 56791
SaFetyOperatiOnMaintenance Setup
electrical Safety
Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric shock.
personal Safety
1. Stay alert, watch what you are
doing and use common sense when
operating a power tool. Do not use
a power tool while you are tired or
under the influence of drugs, alcohol
or medication. A moment of inattention
while operating power tools may
result in serious personal injury.
2. use personal protective equipment.
always wear eye protection.
Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or
hearing protection used for appropriate
conditions will reduce personal injuries.
3. prevent unintentional starting.
ensure the power Switch is in the
off-position before connecting
to power source, picking up or
carrying the tool.
Carrying power tools with your finger on the
Power Switch or energizing power tools that
have the Power Switch on invites accidents.
4. Do not overreach. Keep proper
footing and balance at all times.
This enables better control of the
power tool in unexpected situations.
5. Only use safety equipment
that has been approved by an
appropriate standards agency.
Unapproved safety equipment may
not provide adequate protection.
Eye protection must be ANSI‑approved
and breathing protection must be
NIOSH‑approved for the specific
hazards in the work area.
power tool use and care
1. Do not force the power tool. use
the correct power tool for your
application. The correct power tool
will do the job better and safer at the
rate for which it was designed.
2. Do not use the power tool if the
power Switch does not turn it on
and off. Any power tool that cannot
be controlled with the Power Switch is
dangerous and must be repaired.
3. Disconnect the battery pack from
the power tool before making any
adjustments, changing accessories, or
storing power tools. Such preventive
safety measures reduce the risk of
starting the power tool accidentally.
4. Store idle power tools out of the
reach of children and do not allow
persons unfamiliar with the power tool
or these instructions to operate the
power tool. Power tools are dangerous
in the hands of untrained users.
5. Maintain power tools. check for
misalignment or binding of moving
parts, breakage of parts and any other
condition that may affect the power tool’s
operation. if damaged, have the power
tool repaired before use. Many accidents
are caused by poorly maintained power tools.
6. use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to
be performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
Page 4 For technical questions, please call 1-888-866-5797. Item 56791
SaFety OperatiOn MaintenanceSetup
Battery tool use and care
1. recharge only with the charger
specified by the manufacturer.
A charger that is suitable for one type
of battery pack may create a risk of fire
when used with another battery pack.
2. use power tools only with
specifically designated battery packs.
Use of any other battery packs may
create a risk of injury and fire.
3. When battery pack is not in use, keep
it away from other metal objects, like
paper clips, coins, keys, nails, screws
or other small metal objects, that can
make a connection from one terminal
to another. Shorting the battery terminals
together may cause burns or a fire.
4. under abusive conditions, liquid may be
ejected from the battery; avoid contact.
if contact accidentally occurs,
flush with water. if liquid contacts eyes,
additionally seek medical help.
Liquid ejected from the battery
may cause irritation or burns.
Service
Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
Heat Gun Safety Warnings
1. Hidden areas behind walls, ceilings,
floors, soffit boards, and other panels
may contain flammable materials that
could be ignited by the heat gun when
working in these locations. The ignition of
these materials may not be readily apparent
and could result in property damage and
injury to persons. When working in these
locations, keep the heat gun moving in a
back-and-forth motion.
Lingering or pausing in one spot could
ignite the panel or the material behind it.
2. Extreme care should be taken when
stripping paint. The peelings, residue and
vapors of paint may contain lead, which
is poisonous. Any pre-1977 paint may
contain lead and paint applied to homes
prior to 1950 is likely to contain lead. Once
deposited on surfaces, hand-to-mouth
contact can result in the ingestion of lead.
Exposure to even low levels of lead can
cause irreversible brain and nervous system
damage; young and unborn children are
particularly vulnerable. Before beginning any
paint removal process you should determine
whether the paint you are removing contains
lead. This can be done by your local health
department or by a professional who uses
a paint analyzer to check the lead content
of the paint to be removed. LEAD BASED
PAINT SHOULD ONLY BE REMOVED BY
A PROFESSIONAL AND SHOULD NOT
BE REMOVED USING A HEAT GUN.
3. Exercise CAUTION when using this
product outdoors. To reduce the risk
of electric shock, keep extension cord
connection dry and off the ground.
4. Persons removing paint should
follow these guidelines:
a. Move the work piece outdoors.
If this is not possible, keep the work
area well ventilated. Open the
windows and put an exhaust fan in one
of them. Be sure the fan is moving
the air from inside to outside.
b. Remove or cover any carpets,
rugs, furniture, clothing, cooking
utensils and air ducts.
c. Place drop cloths in the work area
to catch any paint chips or peelings.
Wear protective clothing such as extra
work shirts, overalls and hats.
Page 5For technical questions, please call 1-888-866-5797.Item 56791
SaFetyOperatiOnMaintenance Setup
d. Work in one room at a time.
Furnishings should be removed or
placed in the center of the room and
covered. Work areas should be sealed
off from the rest of the dwelling by
sealed doorways with drop cloths.
e. Children, pregnant or potentially pregnant
women, and nursing mothers should not
be present in the work area until the work
is done and all clean up is complete.
f. Wear a dust respirator mask or a dual filter
(dust and fume) respirator mask which
has been approved by the Occupational
Safety and Health Administration (OSHA),
the National Institute of Safety and
Health (NIOSH), or the United States
Bureau of Mines. These masks and
replaceable filters are readily available
at major hardware stores. Make sure
the mask fits. Beards and facial hair
may keep masks from sealing properly.
Change filters often. DiSpOSaBLe
paper MaSKS are nOt aDeQuate.
g. Use caution when operating the Heat Gun.
Keep the Heat Gun moving, as
excessive heat will generate fumes
which can be inhaled by the operator.
h. Keep food and drink out of the work area.
Wash hands, arms and face and
rinse mouth before eating or drinking.
Do not smoke or chew tobacco
in the work area.
i. Clean up all removed paint and
dust by wet mopping the floors.
Use a wet cloth to clean all walls, sills and
any other surface where paint or dust is
clinging. DO nOt SWeep, Dry DuSt
Or VacuuM. Use a high phosphate
detergent or trisodium phosphate
(TSP) to wash and mop areas.
j. At the end of each work session put
the paint chips and debris in a double
plastic bag, close it with tape or twist
ties and dispose of properly.
k. Remove protective clothing and work
shoes in the work area to avoid carrying
dust into the rest of the dwelling. Wash
work clothes separately. Wipe shoes
off with a wet rag that is then washed
with the work clothes. Wash hair and
body thoroughly with soap and water.
5. When working with plastics, varnish, or
similar materials, gases develop that are
easily flammable and can lead to explosions.
Be prepared for flames to develop and keep
suitable fire extinguishing means at hand.
6. The Nozzle becomes very hot. Do not
lay the Heat Gun on flammable surfaces
when operating the Gun or immediately
after turning the Gun off. Always set the
Heat Gun on a flat, level surface so that
the Nozzle tip is directed upwards and
away from the supporting surface.
7. Do not use the Heat Gun near
flammable materials.
8. Do not point the Heat Gun at people or
animals. The intense heat can injure them.
9. Do not touch the tube of the heating
element or the Nozzle when they are hot.
They will be hot enough to cause burns
during use and for some time afterwards.
10. Do not use the Heat Gun on glass.
11. Do not use the Heat Gun as a hair dryer.
12. Do not heat up materials that can be
damaged by high temperatures.
13. Maintain labels and nameplates on the tool.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
14. Avoid unintentional starting.
Prepare to begin work before
turning on the tool.
15. Do not leave the tool unattended when the
Battery Pack is connected. Turn off the tool,
and remove the Battery Pack before leaving.
16. The battery Charger gets hot
during use. The Charger’s heat
can build up to unsafe levels and
create a fire hazard if it does not
receive adequate ventilation, due to an
electrical fault, or if it is used in a
hot environment.
Do not place the Charger on a flammable
surface. Do not obstruct any vents on the
Charger. especially avoid placing the
charger on carpets and rugs; they are not
only flammable, but they also obstruct
vents under the charger.
Page 6 For technical questions, please call 1-888-866-5797. Item 56791
SaFety OperatiOn MaintenanceSetup
Place the Charger on a stable, solid,
nonflammable surface (such as a stable
metal workbench or concrete floor) at least
1 foot away from all flammable objects, such
as drapes or walls. Keep a fire extinguisher
and a smoke detector in the area.
Frequently monitor the Charger and
Battery Pack while charging.
17. This product is not a toy.
Keep it out of reach of children.
18. People with pacemakers should
consult their physician(s) before use.
Electromagnetic fields in close proximity to
heart pacemaker could cause pacemaker
interference or pacemaker failure.
19. The warnings, precautions, and instructions
discussed in this instruction manual cannot
cover all possible conditions and situations
that may occur. It must be understood by the
operator that common sense and caution are
factors which cannot be built into this product,
but must be supplied by the operator.
Lithium Battery Safety Warnings
LitHiuM BatterieS StOre a LarGe
aMOunt OF enerGy anD WiLL Vent
Fire Or eXpLODe iF MiStreateD:
1. DO nOt DO any OF tHe FOLLOWinG
tO tHe Battery pacK:
a. Open,
b. Drop,
c. Short-circuit,
d. puncture,
e. incinerate, or
f. expose to temperatures
greater than 140°F.
2. Keep Battery pack dry.
3. Charge Battery Pack only according
to its Charger’s instructions.
4. Inspect Battery Pack before every use;
do not use or charge if damaged.
SaVe tHeSe inStructiOnS.
Page 7For technical questions, please call 1-888-866-5797.Item 56791
SaFetyOperatiOnMaintenance Setup
Grounding
tO preVent eLectric SHOcK anD DeatH FrOM incOrrect GrOunDinG:
check with a qualified electrician if you are in doubt as to whether the outlet is
properly grounded. Do not modify the power cord plug provided with the charger.
Do not use the charger if the power cord or plug is damaged. if damaged, have it
repaired by a service facility before use. if the plug will not fit the outlet, have a proper outlet
installed by a qualified electrician.This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in a polarized outlet only one
way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician. Do not modify the plug in any way.
extension cords
note: Extension cords must not be used with this item’s Charger.
Symbology
Double Insulated
V
Volts
~
Alternating Current
a
Amperes
n
0
xxxx/min.
No Load Revolutions
per Minute (RPM)
WARNING marking concerning
Risk of Eye Injury.
Wear ANSI-approved safety
goggles with side shields.
Read the manual before
set-up and/or use.
WARNING marking concerning
Risk of Fire.
Do not cover Charger
ventilation ducts.
Charge on fireproof
surface only.
WARNING marking concerning
Risk of Electric Shock.
Properly connect
Charger’s power cord to
appropriate outlet.
WARNING marking concerning
Risk of Explosion.
Do not puncture, short, or
open battery packs and do not
charge damaged battery packs.
Page 8 For technical questions, please call 1-888-866-5797. Item 56791
SaFety OperatiOn MaintenanceSetup
Specifications
Battery Type Bauer 20V Li-ion
Charger Type Bauer 20V Li-ion
Maximum Temperature 895°F
Setup - Before use:
read the entire iMpOrtant SaFety inFOrMatiOn section
at the beginning of this manual including all text under
subheadings therein before set up or use of this product.
note: For additional information regarding the parts listed in the following
pages, refer to Parts List and Diagram on page 14.
Functions
nozzle
trigger
trigger
Lock
power LeD
Hook
collar
Page 9For technical questions, please call 1-888-866-5797.Item 56791
SaFetyOperatiOnMaintenance Setup
Operating instructions
read the entire iMpOrtant SaFety inFOrMatiOn section
at the beginning of this manual including all text under
subheadings therein before set up or use of this product.
charging Battery pack
Charge battery before using this tool. Follow instructions
included with battery charger ( sold separately).
uses
tO preVent SeriOuS inJury FrOM acciDentaL OperatiOn:
release the trigger and remove Battery pack before adjusting tool or installing accessories.
The Heat Gun can be used for:
• Shrinking of shrink tubing, packaging
and electrical components.
• Deforming of articles made from
acrylic, PVC, and polystyrene
tubing, plates, and profiles.
• Welding of thermoplastic polymer,
flooring materials of PVC and
linoleum, PVC-coated fabric,
wallpaper, tarpaulins and foils.
• Soldering of tin, special silver solder,
SMD elements, cable lugs, and for
loosening soldered connections.
• Paint removal. Removal of old coatings of
oil paint, varnish, and synthetic plaster.
• Drying of color shade samples,
filter, adhesives, construction
joints and stucco forms.
• Joining adhesives. Large surface
gluing with contact adhesives,
activation of pressure, or heat
sensitive adhesives, acceleration
of bonding processes, releasing of
bonding points as well as releasing or
bonding of edge bond or veneer.
• Defrosting of icy stairs and
steps, door locks, trunk lids, car
doors or metal water pipes.
• Disinfection. With the tool set at the
highest setting, animal sites/stables may
be disinfected. Wood worm infestation
may be controlled. Do not heat up the
wood surface too much or it can burn.
Workpiece and Work area Set up
1. Designate a work area that is clean
and well lit. The work area must not
allow access by children or pets to
prevent distraction and injury.
2. Secure loose workpieces using a
vise or clamps (not included) to
prevent movement while working.
3. There must not be objects, such
as utility lines, nearby that will
present a hazard while working.
4. Remove all flammable and heat sensitive
materials from the work area.
5. Plan an insulated, non-flammable surface
for the gun to cool down on after use.
6. Keep multiple class ABC fire
extinguishers readily accessible while
working and while workpiece cools.
Page 10 For technical questions, please call 1-888-866-5797. Item 56791
SaFety OperatiOn MaintenanceSetup
General Operating instructions
1. Insert fully charged Battery Pack
into base of Heat Gun, making sure
it clicks into place securely.
WarninG! to prevent personal injury or
property damage, do not leave the Heat Gun
unattended while pointed at surfaces or
objects.
cautiOn! Do not touch work area with
the Heat Gun; it could scorch or ignite.
cautiOn! Do not block air Vents
when Heat Gun is in use, it could
cause the tool to over-heat.
2. If using either of the included accessories,
attach accessory to Collar before use.
3. Turn on Heat Gun by pushing Trigger Lock
in either direction and pulling Trigger.
cautiOn! Do not drop
anything into the nozzle.
4. Release Trigger to power off Heat Gun.
note: After Trigger is released, there
is a 6-second time lapse before the
motor and LED light turn off.
5. To prevent accidents, turn off the Heat Gun
and remove its Battery Pack after use.
Allow the Heat Gun to cool down on an
insulated, non-flammable surface.
cautiOn! after use, do not touch
nozzle until it has had time to cool.
cautiOn! Do not leave work area
until Heat Gun has cooled. Be alert
for indications of concealed fire.
6. Allow time for the Heat Gun to cool
then clean and store the Heat Gun
indoors out of children’s reach.
7. If desired, use Hook to hang Heat
Gun after use. Lift Hook from slot and
hang carefully in selected location.
Page 11For technical questions, please call 1-888-866-5797.Item 56791
SaFetyOperatiOnMaintenance Setup
Maintenance and Servicing
procedures not specifically explained in this manual must
be performed only by a qualified technician.
tO preVent SeriOuS inJury FrOM acciDentaL OperatiOn:
remove Battery pack before performing any inspection,
maintenance, or cleaning procedures.
tO preVent SeriOuS inJury FrOM tOOL FaiLure:
Do not use damaged equipment. if abnormal noise or vibration
occurs, have the problem corrected before further use.
cleaning, Maintenance, and Lubrication
1. BeFOre eacH uSe, inspect the general
condition of the tool. Check for:
• loose hardware,
• misalignment or binding of moving parts,
• cracked or broken parts,
• blocked Air Vents,
• damaged electrical wiring, and
• any other condition that may
affect its safe operation.
2. aFter uSe, wipe external surfaces
of the tool with clean cloth.
3. Li-Ion BATTERY MUST BE RECYCLED OR
DISPOSED OF PROPERLY.
Do not short, incinerate or open battery.
4. WarninG! if the supply cord
of this power tool is damaged,
it must be replaced only by a
qualified service technician.
Page 12 For technical questions, please call 1-888-866-5797. Item 56791
SaFety OperatiOn MaintenanceSetup
troubleshooting
problem possible causes Likely Solutions
Heat Gun will
not turn on.
1. Battery discharged.
2. Internal damage or wear.
(Switch, for example.)
1. Connect Battery to gun.
2. Have technician service tool.
Temperature
insufficient.
1. Heat Gun not allowed enough
time to reach heat level.
2. Blocked Air Vents.
1. After increasing heat setting,
wait for a minute for the gun to
reach the desired heat level.
2. Check that air vents are clear.
Unsatisfactory
results.
Inappropriate heat for task. Adjust heat setting or distance to
workpiece to compensate.
Follow all safety precautions whenever diagnosing or
servicing the tool. Disconnect power supply before service.
Page 13For technical questions, please call 1-888-866-5797.Item 56791
SaFetyOperatiOnMaintenance Setup
record product’s Serial number Here:
note: If product has no serial number, record
month and year of purchase instead.
note: Some parts are listed and shown
for illustration purposes only, and are not
available individually as replacement parts.
Page 14 For technical questions, please call 1-888-866-5797. Item 56791
SaFety OperatiOn MaintenanceSetup
parts List and Diagram
parts List
part Description Qty
1 Right Housing 1
2 Right Battery Extension 1
3 Back Cover 1
4 Motor Fan 1
5 Heating Element 1
6 Metal Cover 1
7 Front Cover 1
8 Trigger 1
9 Trigger Spring 1
part Description Qty
10 Switch Cover 1
11 Switch 1
12 LED Light Cover 1
13 Safety Push Rod 1
14 Left Housing 1
15 Screw 8
16 Left Battery Extension 1
17 PCBA 1
18 Reducer Nozzle 1
19 Heat Deflector Nozzle 1
Page 15For technical questions, please call 1-888-866-5797.Item 56791
SaFetyOperatiOnMaintenance Setup
Diagram
1 3
1 6
1 7
1 8
1 9
1 2
1 1
1 0
9
8
4
5
6
1
2
1 4
1 5
7
3
26541 agoura road • calabasas, ca 91302 • 1-888-866-5797
pLeaSe reaD tHe FOLLOWinG careFuLLy
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND
ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE
MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY
OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS
TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF
THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN
BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE
BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS
TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING
OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality
and durability standards, and warrants to the original purchaser that this product is free from
defects in materials and workmanship for the period of 90 days from the date of purchase. This
warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence or
accidents, repairs or alterations outside our facilities, criminal activity, improper installation,
normal wear and tear, or to lack of maintenance. We shall in no event be liable for death,
injuries to persons or property, or for incidental, contingent, special or consequential damages
arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to
you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with
transportation charges prepaid. Proof of purchase date and an explanation of the complaint
must accompany the merchandise. If our inspection verifies the defect, we will either repair or
replace the product at our election or we may elect to refund the purchase price if we cannot
readily and quickly provide you with a replacement. We will return repaired products at our
expense, but if we determine there is no defect, or that the defect resulted from causes not
within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also
have other rights which vary from state to state.
