A5P | 01
3500263
Please read all instructions carefully before use and
retain for future reference.
CAUTION Do not immerse in water.
Protect your eyes.
Protect your ears.
Protect your hands.
Wear a dust mask.
ATTENTION This appliance has a thermal cut out
switch. The thermal cut out will activate and shut down
the appliance should the appliance overheat.
Unplug from the mains and or battery and allow to cool
for 30 minutes before re-use.
Do not use chemicals or detergents that are toxic,
ammable, or high in acidic/alkaline base with this
Pressure Washer.
Always use a detergent that has been specically
manufactured for pressure washer use.
Always exercise extreme caution when using the
Pressure Washer not to direct the water jet at items
other than the surface intended.
The user is responsible for using this Pressure Washer
safely and as instructed in this manual. DOMU Brands
Ltd cannot be held responsible for damage to property
resulting from misuse of the Pressure Washer, or the
use of detergents not suitable for the intended task.
To reduce the risk
of electric shock
or injury, do not
expose to wet
conditions.
Risk of explosion.
Do not spray with
ammable liquids.
WARNING – RISK OF INJECTION! Unit will start
spraying when trigger is squeezed. When turning the
unit o after use, high pressure still exists inside the
hose and unit. Point the lance in a safe direction and
discharge the excess pressure. NEVER direct the high
pressure water stream at people or animals.
A5P | 01
Please read all instructions carefully before use and retain
for future reference.
INTENDED
USE Only operate the power tool/machine
for its intended purpose and within the parameters
Specified in this manual.
This power tool/machine is for domestic use only.
This power tool/machine is not intended for use by
persons with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless supervised or given appropriate
instruction concerning the product’s use by a person
responsible for their safety.
GENERAL PRECAUTION Do not allow to be used as a
toy. Children should be supervised to ensure they do not
play with the power tool/machine.
If the power tool/machine is not functioning properly,
has been dropped, damaged, left outdoors, or immersed
in liquid, do not use, contact DOMU Brands Customer
Services.
Do not use the power tool/machine if any parts appear to
be faulty, missing or damaged.
Ensure all parts are securely attached before use.
RISK OF PERSONAL INJURY Avoid body contact with
earthed or grounded surfaces such as pipes,radiators,
ranges and refrigerators. There is an increased risk of
electric shock if your body is earthed or grounded.
Prevent unintentional starting. Ensure the switch is in the
o position before connecting to the power source and/
or battery pack, picking up or carrying the tool. Carrying
power tools with your nger on the switch, or energising
power tools that are switched on, invites accidents.
Do not operate power tools in explosive atmospheres
such as in the presence of ammable liquids, gases or
dust. Power tools create sparks which may ignite the
dust or fumes.
Always wear eye protection. Any power tool can throw
foreign objects into your eyes and cause permanent
eye damage. Always wear safety goggles (not glasses)
that comply with ANSI safety standard Z87.1. Every day
glasses have only impact resistant lenses.
Do not expose power tools to rain or wet conditions.
Water entering the power tools will increase the risk of
electric shock.
Stay alert, watch what you are doing and use common
sense when operating a power tool/machine. Do not
use a power tool/machine while you are tired or under
the inuence of drugs, alcohol or medication. A moment
of inattention while operating power tool/machine may
result in serious personal injury.
Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal
injuries.
Prevent unintentional starting. Ensure the switch is in the
o-position before connecting to power source and/or
battery pack, picking up or carrying the tool.
Carrying power tool/machine with your nger on the
switch or energizing power tool/machine that have the
switch on invites accidents.
Remove any adjusting key or spanner before turning the
power tool/machine on. A spanner or a key left attached
to a rotating part of the power tool/machine may result in
personal injury.
Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool/
machine in unexpected situations.
Dress appropriately. Do not wear loose clothing or
jewellery.
Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair can be caught
in moving parts.
If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust-related hazards.
WORK AREA SAFETY Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
Do not operate power tool/machine in explosive
atmospheres, such as in the presence of ammable
liquids, gases or dust.
Power tool/machine create sparks which may ignite the
dust or fumes.
Keep children and bystanders away while operating a
power tool/machine. Distractions can cause you to lose
control.
GENERAL POWER TOOL USE AND CARE Do not force
the power tool/machine. Use the correct power tool/
machine for your application. The correct power tool/
machine will do the job better and safer at the rate for
which it was designed.
Do not use the power tool/machine if the switch does not
turn it on and o. Any power tool/machine that cannot
be controlled with the switch is dangerous and must be
repaired.
Disconnect the plug from the power source and/or the
battery pack from the power tool/machine before making
any adjustments, changing accessories, or storing power
tool/machine tools. Such preventive safety measures
reduce the risk of starting the power tool/machine
accidentally.
Store idle power tool/machine out of the reach of children
and do not allow persons unfamiliar with the power tool/
machine or these instructions to operate the power tool/
machine.
Power tool/machines are dangerous in the hands of
untrained users.
Maintain power tool/machines. Check for misalignment
or binding of moving parts, breakage of parts and any
other condition that may aect the power tool/machines
operation. If damaged, have the power tool/machines
repaired before use. Many accidents are caused by
poorly maintained power tool/machines.
Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
Use the power tool/machine accessories and tool bits in
accordance with these instructions, take into account the
working conditions and the work to be performed.
Use of the power tool/machine for operations dierent
from those intended could result in a hazardous situation.
CLEANING & MAINTENANCE Never soak or immerse
electrical components and or a component that has a
plug attached.
Disconnect the plug from the power source before
making any adjustments, changing accessories, or
storing. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
Ensure the motor has fully stopped before cleaning,
clearing a blockage, checking, or carrying out any
A5P | 01
maintenance on the tool.
Maintain your power tool. Check for misalignment or
binding of moving parts, breakage of parts and any other
condition that may aect the power tool’s operation. If
damaged, have the power tool repaired by a qualied
repair person before use. Many accidents are caused by
poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
Regularly check external nuts and xings to ensure
vibration caused by normal use has not balance to
loosen them.
Store idle power tools out of reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the Breaker.
Locate the power tool out of reach of children, in a dry,
locked unit.
Make sure that the cord is located so that it will not
be stepped on, tripped over, or otherwise subjected to
damage or stress.
Remove the plug from the mains socket / battery (where
applicable) before carrying out any adjustment or
maintenance.
Always store the power tool/machine in a dry place.
If the power cord is damaged, it must be replaced by a
qualied service technician.
Keep the ventilation slots and motor housing as free of
dirt and dust as possible (where applicable).
Clean the power tool/machine by rubbing it with a clean
cloth and blow it clean using low-pressure compressed
air is recommended.
Ensure you have all the pieces listed. If you are missing
any components, contact our customer services
department at
[email protected] DO NOT proceed with assembly if
any components are missing.
CONNECTING THE PRESSURE WASHER In order
to avoid a hazard due to inadvertent resetting of the
thermal cut-out, this machine must not be supplied
through an external switching device such as a timer, or
connected to a circuit that is regularly switched on and
o by the utility.
Connect to the non-potable water supply only. The
Pressure Washer is not intended to be connected to
the potable water mains. If necessary, please use only
inlet hose-set approved by IEC 61770. If connecting this
Pressure Washer to potable water mains, a back-ow
preventer must be installed in the water pipe to prevent
dirty water owing back into the drinking water system.
This Pressure Washer is not designed to pump hot
water. Do not connect to a hot water supply as this will
signicantly reduce the life of the pump.
Do not use with damaged cable or plug. If damaged it
must be replaced by a qualied engineer or authorised
service agent in order to avoid a hazard.
The electrical supply connection shall be made by a
qualied person and comply with IEC 60364-1. The
electric supply to this Pressure Washer should include
either a Residual Current Device (RCD) that will interrupt
the supply if the leakage current to earth exceeds 30 mA
for 30ms, or a device that will prove the earth circuit.
The use of an extension cord is not recommended.
If unavoidable, use only extension cords intended
for outdoor use. These are identied by the mark
“Acceptable for use with outdoor pressure washers;
store indoors while not in use”. Use only extension
cords with an electrical rating equal to or greater than
the rating of the Pressure Washer.
Inadequate extension cords can be dangerous. If the
use of an extension cord is unavoidable, it must be
suitable for outdoor use, and the connection must be
kept dry and o the ground. It is recommended that this
is accomplished by means of a cord reel which keeps
the socket at least 60mm above the ground. The plug
and socket must be of watertight construction.
Do not use damaged extension cords. Examine the
extension cord before use and replace if damaged. Do
not abuse the extension cord. Do not pull on the cord
to disconnect. Keep the cord away from heat and sharp
edges.
Always disconnect the cord from the receptacle before
disconnecting the Pressure Washer from the extension
cord.
The Pressure Washer shall be disconnected from its
power source by removing the plug from the socket
outlet during cleaning or maintenance and when
replacing the machine to another function.
Warning: Never use products with bleach or chlorine
or any other corrosive materials, including liquids
containing solvents (I.E Gas, Oils ETC) Tri-Sodium
Phosphate products, Ammonia or Acid base cleaners.
These Chemicals will harm the unit and cause damage
to the surface being cleaned. Always read the label.
SUITABLE OPERATING CONDITIONS Operate only in
daylight or good articial light.
Do not operate whilst tired or under the inuence of
medication, drugs or alcohol.
Keep your work area clean. Cluttered areas invite
accidents.
Always check the area to be worked on for wire and
other debris that could cause damage to the Pressure
Washer and injury to the operator.
Never operate the Pressure Washer in a closed building,
or in or near an explosive environment.
Never use the Pressure Washer in areas containing
combustible dust, liquids or vapours.
Do not expose the Pressure Washer to rain or wet
conditions. Water entering the Pressure Washer will
increase the risk of electric shock.
Always wear substantial footwear and long trousers
whilst operating the Pressure Washer.
Always wear safety glasses or goggles and protective
clothing when operating or performing maintenance.
Keep children, pets and bystanders away whilst
operating the Pressure Washer. Distractions can cause
you to lose control.
SAFETY INFORMATION FOR USE Before use, know
how to stop this Pressure Washer and bleed pressure
quickly. Be acutely familiar with the controls.
Never operate the Pressure Washer without all
components properly connected.
Do not operate the Pressure Washer with the Water Inlet
screen removed. Keep the Water Inlet screen clear of
debris and sediment.
Use only the nozzle supplied with this Pressure Washer.
High pressure hoses, ttings and couplings are
important for the safety of the machine. Use only
hoses, ttings and couplings recommended by the
manufacturer.
A5P | 01
Always turn the water supply on rst before turning the
Pressure Washer on. Running the pump dry can cause
serious damage.
Make sure the inlet water pressure remains between
0.01MPa and 0.4MPa.
Always hold the Lance and Lance Trigger Handle rmly
when starting and operating the Pressure Washer.
Be aware of the recoil caused by the water jet when the
Pressure Washer is switched on.
Be aware of the danger of the kickback force when
engaging the Lance Trigger Handle and grasp rmly.
Never place your hand or ngers over the spray tip
whilst operating the Pressure Washer.
Keep hair, loose clothing, ngers, and all parts of body
away from openings and moving parts.
Do not overreach. Keep proper footing and balance at
all times.
Exercise extreme caution when reversing or pulling the
Pressure Washer towards you.
Always be sure of your footing on slopes.
Walk, never run.
Keep clear of the nozzle. Never direct high pressure
spray at yourself, or any other person or animal.
WARNING! Risk of injection or severe injury. Keep clear
of the nozzle. Do not discharge streams at persons or
animals. This Pressure Washer is to be used only by
trained operators.
Do not direct the Pressure Washer at electrical
apparatus or wiring.
Do not direct the Pressure Washer at ammable liquids.
The motor on this Pressure Washer does not run
continuously. It runs only when the Lance Trigger Handle
is squeezed. After following the start up procedures in
this manual, turn the Pressure Washer on and squeeze
the Lance Trigger Handle to activate.
Release the Lance Trigger Handle when changing from
high to low pressure modes. Failure to do so could
result in damage.
Never permanently engage the Lance Trigger Handle.
Always engage the Safety Lock on the Lance Trigger
Handle, even when spraying is stopped for a moment.
This Pressure Washer should only be used with a
suitable detergent. The use of other cleaning agents
or chemicals may adversely aect the safety of the
Pressure Washer.
Always follow detergent manufacturer’s
recommendations on the label for proper use of
detergents. Always protect eyes, skin, and respiratory
system from detergent use.
In the event of an accident involving detergents making
contact with unsuitable surfaces, rinse with plenty of
clean water.
Never allow the machine to run with the Lance Trigger
Handle released (Safety Lock on) for more than one
1 minute at a time. Resulting heat build up will cause
damage to the pump.
If a foreign body or other debris becomes accidentally
entangled with the Pressure Washer, stop the machine
immediately, disconnect from the mains, and do not use
again until cleared.
If the Pressure Washer makes any unusual sounds,
or starts to vibrate abnormally, stop the machine
immediately, disconnect from the mains, and investigate
the cause. Do not use again until the problem has been
resolved (see ‘Troubleshooting’ for possible solutions).
Do not leave the Pressure Washer unattended whilst
connected to the mains.
Never leave the Lance Trigger Handle assembly
unattended whilst the Pressure Washer is running.
When moving the machine, always transport by the
Carry Handle.
Do not operate continuously for periods longer than
those marked on the product or indicated in the
instructions.
Do not use for long periods without rest due to vibration
to hands and arms.
Never disconnect the High Pressure Hose from the
Pressure Washer whilst the system is pressurized. To
de-pressurize the Pressure washer, turn both the power
and water supply o, then squeeze the Lance Trigger
Handle 2~3 times.
Use only as described in this manual and do not
exceed maximum capacity. Use only DOMU Brands
recommended attachments.
CLEANING & MAINTENANCE Ensure the ventilation
slots are kept clean at all times. Blocked ventilation slots
can cause overheating and damage to the motor.
Always remove the Lance from the Lance Trigger Handle
before cleaning debris from the tip.
Modication of the Pressure Washer or tampering with
its parts is not permissible.
For safety reasons, use only original spare parts
supplied by, or approved by, the manufacturer.
Never attempt to alter factory settings.
Altering factory settings could damage the machine and
will void the warranty.
Do not lubricate any parts, or carry out any maintenance
or repair work other than that shown in this manual,
or as advised by the DOMU Brands Customer Care
Helpline.
STORAGE.
Never store the Pressure Washer outdoors or where it
could freeze as this can seriously damage the pump.
TECHNICAL SPECIFICATION
Rated Voltage 220V - 240V ~
Rated Power 1600W
Rated Frequency 50/60Hz
Rated Pressure 90bar
Max Pressure 130bar
Rated Flow 5.5L/min
Max Pressure Water Supply 12bar
Max Water Temperature 50ºC
A5P | 01
1. Short Handle
2. Accessory Holder
3. Lance Hook
4. Switch
5. Nozzle
6. Extension Wand
7. High Pressure Lance
8. Cleaning Pin
9. Pressure Hose
10. Water Inlet Connector
11. Power Cord Hook
12. Detergent Bottle
COMPONENTS
1
11
2
3
4
5
12
6
9
8
7
10
A5P | 01
ASSEMBLY
3.5*16
4.8*20
x2
11
3
1
A5P | 01
ASSEMBLY
6
7
4
A5P | 01
ASSEMBLY
9
9
Push to Release
A5P | 01
ASSEMBLY
10
A5P | 01
SAFETY LOCK OFF
SAFETY LOCK OFF
<50cm
<50cm
Ensure that the water source is not placed more
than 50cm lower than the Pressure Washer inlet.
Ensure that the water source is not placed more
than 50cm higher than the Pressure Washer inlet.
After starting the Pressure Washer, wait for water
to flow out from the Lance, and then connect the
nozzle to use.
Unlocked
Locked
A5P | 01
SPRAY NOZZLE ADJUSTMENT
UNBLOCKING THE LANCE
When the nozzle is clogged, it will cause the pump to
build pressure and may cause unit to surge, you can
clean the nozzle inserting needle into the tip to rid of the
deposits.
For the adjustable nozzle, you can lubricate the nozzle
collar(high pressure to low pressure) by using non-water
soluble grease regularly.
9
The adjustable nozzle will allow you to use any variety of spray patterns from a full fan spray
(Fig 1)
to a direct
stream spray
(Fig 2)
.
When using the pressure washer to clean wood decks, siding, vehicles etc., always start using the fan spray
and begin spraying from a minimum 36” away to avoid damaging the surface of the material you are cleaning.
Always begin by spraying in a testing area free and clear of people and objects.
A5P | 01
12
USING THE DETERGENT BOTTLE
A5P | 01
SWITCHING OFF / ON
USING THE DETERGENT BOTTLE
4
A5P | 01
AUTO ON/OFF
BLEEDING THE LANCE
The Pressure Washer is equipped with an automatic on/
o switch.
The Pressure Washer will only run when the power
switch is in the ON position and the trigger on the lance
is squeezed.
When you release the trigger to stop spraying water
through the lance, the motor on the Pressure Washer
will automatically shut o.
Simply squeeze the trigger again to resume using the
cleaner. To stop using the Pressure Washer, release the
trigger and switch the unit to the OFF position.
The unit should be turned completely OFF while not in
use or while unattended.
It is very important to bleed the lance before using the
Pressure Washer.
To bleed the lance, simply connect the garden hose to
the Pressure Washer and squeeze the trigger BEFORE
turning the electrical supply on.
This allows any air trapped inside the Pressure Washer
and lance to be removed before using the unit.
Continue holding trigger for approximately one minute
to allow any excess air out of the unit. Water will ow
through the lance at low pressure during this procedure.
A5P | 01
CLEAN UP AND STORAGE
CLEAN UP AND STORAGE
SHUTTING DOWN THE CLEANER.
Turn the Pressure Washer off.
Turn off the water supply.
Before disconnecting high-pressure hose
connection, point the lance in a safe direction and
press the trigger to release the excess water.
Disconnect the hight-Pressure Washer and lance.
Disconnect the garden hose from the Pressure
Washer.
Remove excess water from the pump by tipping
the unit on both sides to drain any remaining water
from the inlet and outlet fittings.
SHUTTING DOWN THE CLEANER.
Turn the Pressure Washer off.
Turn off the water supply.
Before disconnecting high-pressure hose connec-
tion, point the lance in a safe direction and press
the trigger to release the excess water.
Disconnect the hight-Pressure Washer and lance.
Disconnect the garden hose from the Pressure
Washer.
Remove excess water from the pump by tipping
the unit on both sides to drain any remaining water
from the inlet and outlet fittings.
Remove water intake filter and flush with water to
remove dirt and debris, return filter once cleaned.
Empty and clean the detergent reservoir.
Wipe away any remaining water on any parts or
components.
Ensure the safety lock is on.
Store the Pressure washer and accessories in an
area with temperatures above (0º) 32ºF
A5P | 01
CLEANING TIPS
WOOD AND VINYL DECKS
Rinse deck and surrounding area with fresh water. If
using detergent, ll the detergent reservoir and apply to
the area being cleaned at low pressure.
For optimal results, reduce your work area to smaller
sections and clean each section one at a time. Allow the
detergent to rest on the surface for a few minutes and
then rinse at high pressure.
NOTE: Do not let the cleanser dry.
Always clean from left to right and top to bottom for
best results. Rinse at high pressure using the fan spray
keeping the tip of the spray nozzle at least 6-9 inches
from the cleaning surface.
Maintain a further distance from the cleaning area when
using a direct spray. Caution: For softer woods, increase
the distance from the cleaning area.
CARS, BOATS, AND MOTORCYCLES
Rinse cleaning and surrounding area with fresh water. If
using detergent, ll the detergent reservoir and apply to
the area being cleaned at low pressure.
To achieve the best results, clean one side at a time.
Allow the detergent to rest on the surface for a few
minutes, but do not let the detergent dry.
Rinse at high pressure using the fan spray in a sweeping
motion keeping the tip of the spray nozzle at least 8
inches from the cleaning surface.
Maintain a further distance from the cleaning area when
using a direct spray. Wipe surface dry for a polished
nish
BARBECUE GRILLS, POWER EQUIPMENT, AND
GARDEN TOOLS
Rinse cleaning and surrounding area with fresh water. If
using detergent, ll the detergent reservoir and apply to
the area being cleaned at low pressure.
Allow the detergent to rest on the surface for a few
minutes, but do not let the detergent dry.
Rinse at high pressure using the fan spray keeping
the tip of the spray nozzle at least 1-3 inches from the
cleaning surface. Maintain a further distance from the
cleaning area when using a direct spray.
A5P | 01
A5P | 01
EN
DISPOSAL INFORMATION Please recycle where facil-
ities exist. Check with your local authority for recycling
advice.
CUSTOMER SERVICE If you are having difficulty using
this product and require support, please contact
WARRANTY To register your product and find out if you
qualify for a free extended warranty please go to
www.vonhaus.com/warranty. Please retain a proof of
purchase receipt or statement as proof of the purchase
date. The warranty only applies if the product is used
solely in the manner indicated in the warnings page of
this manual, and all other instructions have been followed
accurately. Any abuse of the product or the manner in
which it is used will invalidate the warranty. Returned
goods will not be accepted unless re-packaged in its
original packaging and accompanied by a relevant and
completed returns form. This does not affect your stat-
utory rights. No rights are given under this warranty to a
person acquiring the appliance second-hand or for com-
mercial or communal use.
COPYRIGHT All material in this instruction manual are
copyrighted by DOMU Brands.Any unauthorised use
may violate worldwide copyright, trademark, and other
laws.
THANK YOU
Thank you for purchasing your product/appliance. Should
you require further assistance with your pur-chase, you
can contact us at
VonHaus is a registered trademark of DOMU Brands Ltd.
Made in China for DOMU Brands. Unit 30, Stakehill
Industrial Estate, Middleton, Manchester M24 2RW.
Authorised Representative: Authorised Representative
Service, 77 Camden Street Lower,Dublin, D02 XE80,
Ireland.
C
