1 AC charging cable
1 Quick Start Guide
1 Wireless Party Speaker
What’s in the Box?
Check to make sure you
have everything below
Quick
Start Guide
Get to Know Your Party Speaker Get to Know Your Party Speaker Let’s Get Started!
01
Wireless Party Speaker
Quick Start Guide
字体：Graphik Regular
正文字号：不小于8PT
Black
VERMILLION
ICE
料号
变更提出人 变更原因
项目名称
日期
包装工程师
设计版本
尺寸(mm)
材质
页码P数
颜色
表面处理
工艺
条码要求
装订方式
产品型号
部件名称
平面工程师
无条码
风琴折 线装 其它胶装骑马钉包心折
有条码（清晰易扫描）
说明书类说明：
1、公差（mm）：0<a≦50（+0.3/-0.2），
50<a≦150（+1/-0.5），>150
（+1.5/-1。有特殊要求的，按标示公
差执行。
2、要求图文清晰可辨，内容完整，折叠正确，
无重影，墨屎、杂点、脏点、异物、粉点、
套印不准。
3、尺寸按展开尺寸及成型外尺寸测量计算。
A0
6页（12P）
黑色+2专
展开尺寸480X80mm，成型尺寸80X80mm
128g铜版纸
版本：A/4
PA2322说明书
无
有：
是否有可参考
刀模
颜色
RoHS2.0、Reach
包装指令94/62/EC
大豆油墨印刷
无氯漂白工艺
粘合剂为非石油基
环保要求
油墨中禁止使用
矿物油（法国）
TPCH（美国）
光油 防刮花哑膜哑膜光胶UV油水性光油 水性哑油哑油
无 烫金 烫银 击凸 击凹 压网 其它局部UV
无
22年WMPA2322户外音箱
12.005.0004.005200
PA2322
说明书
黄敏慧
20221209
金沛
1. LED screen
2. Source
3. Bluetooth
4. Power
5. Master volume control
6. Previous track
7. Play/Pause
8. Next track
9.Party sync
10. Bass boost
11. Party light
12. AC charging port
13. USB-A - charging
port for mobile
devices
14. Reset
We’d love to hear from
you. Scan with your
Walmart app and let us
know what you think.
100094812
1 59 4 3 4 6 0 0 5 0 5
Need help? We're here for you every day
7 a.m. – 9 p.m. CST. 1-888-516-2630 Give us a call!
12
13 14 1615 17
AC IN
MIC
MIC AUX IN
5V 2.1A
RESET
1
3
4
6
7 8
10
9
11
5
2
Connect to your device through Bluetooth®
wireless technology, search for the entry
"onn. Party Speaker M".
Press & hold to power on/off the speaker.
Press & Hold
onn. Party Speaker M
Bluetooth
Bluetooth
Devices
Press x 1
Listen to Your Favorite Radio Stations
Charge Your Party Speaker
1. Press to select FM mode.
1. Connect your
Microphone or Guitar
to the MIC/Guitar port.
2. Play Guitar through
the speaker.
3. Singing through
Microphone when
music playing in
Bluetooth/AUX/FM
mode.
4. Adjust the Microphone
or Guitar volume
through MIC knob.
Want to Sing a Song? Want More Lighting Eects?
2. Press or to scan and select FM stations
channel by channel.
Press & hold or to seek (jump to the
next available station).
3.
FM
2. Quick press to switch
between 6 different multicolor
lightings.
Press & hold to turn on/off
the party light.
1.
Want Your Party to the Next Level?
02
If you have 2 onn. wireless party speakers,
power on both speakers, press of each
speaker to enter Party Sync Mode.
When two speakers are connected, you will
hear “left channel, right channel”.
Use your mobile device to pair with the party
speaker through Bluetooth wireless
technology.
Press again to disconnect Party Sync
Mode.
1.
2.
3.
4.
Stereo
10m/33ft
07060504
4.
5.
In FM Mode, press and hold
to assign a preset number for
the current station, and press
to save, the LED screen will
show “SAV” which means the
station has been saved
successfully. The preset
number can be changed by
pressing and .
In FM Mode, press repeatedly
to select a preset radio station.
Tips:
– Always keep the charging port
dry before connecting to AC
power.
AC IN
MIC
MIC AUX IN
5V 2.1A
RESET
Wired Use? Yes!
1. Use a 3.5mm Aux cable (not included) to
connect the speaker to your audio source.
2. In AUX mode, can’t be controlled
on speaker, you can ONLY control them by
your audio source device.
(not included)
03
AUX IN
More tips:
(not included)
The battery icon will flash
when charging, it will remain
solid white once fully charged.
battery performing well. A prolonged empty battery may
result in fewer hours of usage between charges.
– USB-A charging port with emergency
power can charge your other smart
devices (5V 2.1A output), when this
Party Speaker is powered on.
– Do not sit on the speaker to avoid possible
damages.
– Fully charge the battery if you might not
use this speaker in the near future. Place it
in a cool, dry place.
– Recommend to charge it at least one time
for every 6 months, in order to keep the
– To ensure it is waterproof, always close the
protective cover securely.
15. Microphone
volume control
16. 1/4" Microphone/
Guitar port
17. 3.5 mm AUX input
December 06, 2022_V1
12.005.0004.06405
22年WMPA2322户外音箱
12.005.0004.03800
PA2322(美国版)
安规手册
黄敏慧
20221124
吴凉新
料号
变更提出人 变更原因
项目名称
日期
包装工程师
设计版本
尺寸(mm)
材质
页码P数
颜色
表面处理
工艺
条码要求
装订方式
产品型号
部件名称
平面工程师
无条码
风琴折 线装 其它胶装骑马钉包心折
有条码（清晰易扫描）
说明书类说明：
1、公差（mm）：0<a≦50（+0.3/-0.2），
50<a≦150（+1/-0.5），>150
（+1.5/-1。有特殊要求的，按标示公
差执行。
2、要求图文清晰可辨，内容完整，折叠正确，
无重影，墨屎、杂点、脏点、异物、粉点、
套印不准。
3、尺寸按展开尺寸及成型外尺寸测量计算。
A0
4页（8P）
展开尺寸：240x80，成型尺寸：80x80
80g书纸
版本：A/4
PA2322美国版安规手册
无
有：
是否有可参考
刀模
颜色
RoHS2.0、Reach
包装指令94/62/EC
大豆油墨印刷
无氯漂白工艺
粘合剂为非石油基
环保要求
油墨中禁止使用
矿物油（法国）
TPCH（美国）
光油 防刮花哑膜哑膜光胶UV油水性光油 水性哑油哑油
无 烫金 烫银 击凸 击凹 压网 其它局部UV
无
LEGAL & COMPLIANCE
80mm
80mm
1. Warning: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
2. NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
□Reorient or relocate the receiving antenna.
□Increase the separation between the equipment and receiver.
□Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
□Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules and ISED Canada
License-exempt RSS Standard(s). Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.
This equipment should be installed and operated with a minimum
distance of 20 cm between the radiator and your body.
1. Read these instructions – All the safety and operating instructions
should be read before this product is operated.
2. Keep these instructions – The safety and operating instructions
should be retained for future reference.
3. Heed all warnings – All warnings on the appliance and in the
operating instructions should be adhered to.
4. Follow all instructions – All operating and use instructions should be
followed.
5. Do not use this apparatus near water – The appliance should not be
used near water or moisture – for example, in a wet basement or near a
swimming pool, and the like.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding plug.
Apolarized plug has two blades with one wider than the other. A
grounding plug has two blades and a third grounding prong. The wide
blade or the third prong is provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for replacement of
the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at the plugs, convenience receptacles, and at the point
where they exit from the apparatus.
CAUTION:
Risk of explosion if the battery is replaced by an incorrect type
– replacement of a battery with an incorrect type that can defeat a
safeguard (for example,in the case of some lithium battery types);
– disposal of a battery into fire or a hot oven, or mechanically crushing
or cutting of a battery, that can result in an explosion;
– leaving a battery in an extremely high temperature surrounding
environment that can result in an explosion or the leakage of flammable
liquid or gas;
– a battery subjected to extremely low air pressure that may result in an
explosion or the leakage of flammable liquid or gas.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart or rack is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
13. Unplug the apparatus during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualified personnel. Servicing is required when
the apparatus has been damaged in any way, such as power supply
cord or plug is damaged, liquid has been spilled or objects have fallen
into the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
15. Do not install this equipment in a confined or built-in space such as a
book case or similar unit, and maintain well-ventilated conditions. The
ventilation should not be impeded by covering the ventilation openings
with items, such as newspaper, tablecloths, curtains, etc.
16. WARNING：To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture. The apparatus shall not be
exposed to dripping or splashing and that objects filled with liquids,
such as vases, shall not be placed on apparatus.
17. WARNING: The mains plug is used as disconnect device, the
disconnect device shall remain readily operable.
18. This equipment is a Class II or double insulated electrical
appliance. It has been designed in such a way that it does
not require a safety connection to electrical earth.
19.
- This lightning flash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of non-insulated
“dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
- Warning: To reduce the risk of electric shock, do not remove cover (or
back) as there are no user-serviceable parts inside. Refer servicing to
qualified personnel.
- The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
instructions in the literature accompanying the appliance.
20. The equipment shall be used at maximum 35 degree C ambient
temperature.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Party sync mode compatible model list
AAAGRY100006896
AAAGRY100006897
AAAAQU100006897
AAAGRY100006902
100008734
100008736
100094813
100094812
100097809
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONSIMPORTANT SAFETY INSTRUCTIONSIMPORTANT SAFETY INSTRUCTIONS
