Model
1.0L Type
1.8L Type
Toshiba Mechanical Rice Cooker / Warmer
Instruction Manual
For household use
●
●
Please read the instruction manual and use it correctly for your own safety.
Before using, please read “Safeguards” and “Please follow the instructions”.
●
After reading, please keep the instruction manual at a place where any person
who is going to use this cooker can find and see it.
Thank you for purchasing Toshiba rice cooker.All pictures in this manual are
subject to material objects,and are only used for function display reference.
Contents
IMPORTANT SAFEGUARDS.............. 1
PRODUCT SPECIFICATION .............. 2
GETTING STARTED ........................... 3
OPERATION INSTRUCTIONS............ 4
PRECAUTIONS .................................. 5
TROUBLE SHOOTING ....................... 6
RC-10JRNH
RC-18JRNH
1
1. This appliance is for
household use only.
Do not use outdoors.
2. Children should be
supervised to ensure
that they do not play
with the appliance.
When using electrical appliances, basic safety
precautions should be followed including the following:
Caution
IMPORTANT SAFEGUARDS
IMPORTANT SAFEGUARDS
1. This appliance is not
intended for use by
persons (including
children) with reduced
physical, sensory or
mental capabilities, or
lack of experience
and knowledge,
unless they have
been given
supervision or
instruction concerning
use of the appliance
by a person
responsible for their
safety.
2. This appliance is
intended to be used in
household and similar
applications such as:
- Staff kitchen areas
in shops, office and
other working
environments;
3. Do not immerse any
part of the appliance
in water or other
liquid.
4. The heating element
surface is subject to
residual heat after
use, do not touch.
- farm houses;
- by clients in hotels,
motels and other
residential type
environments;
- bed and breakfast
type environments;
3. If the supply cord is
damaged, it must be
replaced by a special
cord or assembly
available from the
manufacture or its
service agent.
4. Please turn off and
unplug the appliance
before cleaning,
maintenance or
relocation and whenever
it is not in use.
5. Warning: Misuse may
cause potential injury.
6. Warning: Avoid spillage
on the connector.
2
Up lid
PRODUCT SPECIFICATION
Thank you for purchasing the TOSHIBA rice cooker, please
read this instruction manual carefully before using. Keep it
cautiously after reading for future reference.
At first use, there might be an odor from plastic, etc. This odor
will disappear after using .
COVER PLATE
Removeable coverplate Non-removeable
coverplate
INNER POT
WATER HOLDER
Take out the water
holder, pour out the
rice water, and
replace it after
cleaning. Attention
to remove the action
should be slow to
prevent water spills.
Up lid
Control panel
“COOK” SWITCH
Press the button to enter
the cooking status.
“KEEP WARM” INDICATOR
Display when power on and finish
cooking. It is preferable for the rice to be
kept warm for less than 12hrs, because
long time keep warm may have a
negative impact on rice.
PRODUCT SPECIFICATION
Caution
All pictures in this manual are subject to material objects,
and are only used for function display reference.
Never heat the inner pot on other stoves to
avoid deformation.
Take the inner pot out of the electric rice
cooker, wash it with household liquefied
detergent and rinse with fresh water and then
wipe it dry with soft cloth. Never use a metal
brush or other harsh tools to wash in order to
avoid damage to the inner pot.
According to the frequency of use, the inner
pot may be a phenomenon of discoloration or
markings, but does not affect the health and
use of.
Accessories
Heating
220-240V~
50/60Hz
500-595 1.0
1-5.5
Rated Voltage
Rated
Power(W)
Cooking
Capacity(L)
Cooking
Method
Spoon Spatula
Measuring Cup Power Cord Steamer
Model
650-774 1.8
2-10
Rice Quantity
Body
Dimension(mm)
(Cup)
RC-10JRNH
RC-18JRNH
255*240*254 2.2
280*263*289 2.8
Body
Weight(kg)
GETTING STARTED
1. Before using the appliance for the first time, clean the parts of the rice cooker
thoroughly. Make sure all the parts are completely dry before you start using
the appliance.
2. To prevent the damage of the non-stick coating in the inner pot, use a
separate container to wash the rice.
3. Measure the rice using the measuring cup provided. Do not exceed the
quantities indicated on the inside of the inner pot.
4. Place the washed rice into the inner pot.
5. Add water to the level indicated on the scale inside the inner pot that
corresponds to the number of cups of rice used.
6. Dry the outside of the inner pot.
7. Place the inner pot in the rice cooker.
8. Close the lid of the rice cooker until a ‘click’ sound is heard.
9. Plug in the power cord into the rice cooker and to the wall socket and switch
on the mains.
GETTING STARTED
3
OPERATION INSTRUCTIONS
Rice measuring and washing
• The measuring cup is mainly used to measure the amount of rice. A flat cup of
rice is 0.18L (approx.150g).
• Do not wash rice directly with the inner pot to avoid scratching its non-stick layer,
distortion it due to collision or result in a lower heat efficiency due to poor contact
with the electric heating plate.
1
Put washed rice into the inner pot and add water to the
corresponding level (e.g.,add water to high level “3” if 3 cups
of rice are to be cooked), add or reduce the amount of water
depending on your personal taste highest level.
2
Mop up the interior and exterior of the inner pot with dry
cloth, place it into the cooker body. Turn the inner pot gently
for several times to allow its bottom come into contact with
the electric heating plate.
• No foreign matter can be allowed between inner pot and electric heating plate.
• Make sure the cover is properly closed, otherwise the cooking effect may be
affected.
3
If necessary, put the steam case into the inner pot when
cooking, then put the food into the steam case directly or
in a tray.
4
Press down the cover until it snaps in place.
5
Cooking
The “WARM” lamp is illuminated after plugging into the outlet. The Rice Cooker are
entering the cooking process until you have pressed the “COOK”. Otherwise, the
Rice Cooker will still in warming process (Please be sure that you have pressed the
“Cooking” Otherwise, the Rice Cooker will still in warming process).
OPERATION INSTRUCTIONS
4
6
When cooking is finished, the cooking switch will pop up and
a “Click” will be heard. At the same time, the cooking light will
go out and keep warm light will go on.
Special Hint:
Rice is best served 15 minutes after cooking.
7
When filling bowl with rice, the attached spoon, not metal
spoon, should be used to avoid scuffing the non-sticky
coating of inner pot and causing exfoliation of coating at the
same time, dry grain of cooked rice should be removed.
8
In order to keep cleanness and sanitation, please clean up
the rice water in water holder after cooking.
9
STEAM FUNCTION (MANUAL CONTROL)
Add appropriate amount of water into the inner pot.
The amount of water varies according to the quantity of food to be steamed.
Ensure that the water level does not exceed the height of the steam case.
Insert the steam case into the inner pot and place the food on the plate or on
the steam case.
Press “COOK” button to start the cooking. The light indicator will switch
to “COOK”
If steam food together with rice cooking, "WARM" indicator will light up after
rice cooking finished
1
2
3
If steam food without rice cooking (use steam function only), when steam food
is fully cooked, please press "WARM" button manually, otherwise the rice
cooker won't change to "WARM" automatically.
NOTE: To ensure even steaming, the food should be spread out evenly and
should not be piled up.
4
PRECAUTIONS
SAFE NOTE
CLEAN
Take the inner pot out of the electric rice cooker, wash it
with domestic liquefied detergent and rinse with fresh
water and then wipe it dry with soft cloth.
* Do not use metal brush or other harsh tools to wash inner
pot to avoid damaging the non- stick coating on its
surface.
Take the water holder down and spill over water or soup
and then install it after washing clean.
The grain of cooked rice or other sundries may attach to
electric hot tray, the fine sand paper can be used for grind
them away and wipe it with soft cloth to keep the dully
contact between inner pot and electric heating plate.
The inner pot cannot be heated on any other furnace,
otherwise it can be deformed easily .
The cooked rice start to keep warm, it is not suitable for
eating immediately and it will more soft and delicious if let
it stewing for 15 minutes.
The time of keeping warm don’t exceed 12 hours in order
to avoid the cooked rice off flavor.
The earthed wall socket should be used and the plug must be inserted
reliably. Do not use multipurpose socket while using other electric appliance
at the same time.
When do not use it, please pull the power cord out of the socket.
Please make sure the power plug is fully inserted into socket.
otherwise the element may be burnt out by poor connection.
The electric rice cooker can not be placed on unstable, wet place; fully
otherwise it will be damaged or go wrong.
When cooking, the steam port is extraordinary hot, do not close face or
hands to avoid scald.
The body and cover of electric rice cooker cannot be washed water or in
water, otherwise the insulator will be damaged become dangerous.
If the power cord is damaged, it must be changed with new power cord
produced by the manufacturer.
Do not let a child operate the product alone. Put it out of the reach of
children to avoid electric shock, scald and other dangerous accident.
1
2
3
1
2
3
1
2
3
4
5
6
7
8
PRECAUTIONS
5
TROUBLE SHOOTING
No.
TROUBLE SHOOTING
6
Malfunction
Causes Solution
The light
is off.
1
2
3
4
The light is
on.
Cooked rice is crude or time
of cooking is too long.
Cook rice burnt or cannot
keep warm automatically
Circuit of electric rice cooker is
not connected to power supply.
1. Wiring connection of indicator
light has loosened.
2. Indicator light is damaged.
1. Wiring in the middle has
loosened.
2. Electric-thermal tube has burnt
out.
1. Cooking time is insufficient.
2. Heating plate is deformed.
3. Inner pot is declined and one
side is hanging in the air.
4. There is foreign matter
between inner pot and heating
plate.
5. Inner pot is deformed.
1. The keys of cooking rice and
lever link gear is not working.
2. The steel magnet temperature
limiter is out of work.
3. The temperature controller is
burnt out wiring of it is
loosened.
Inspect whether the switch, plug and socket
connector, fuse and leading wire of power supply
are in good condition and insert the plug reliably
It should be sent to an authorized service
department for maintenance.
1. Cook rice according to required conditions.
2. The fine sand paper can be used for
correcting slight deformation but the severly
deformed one should be sent to
maintenance department for replacement.
3. Turn the inner pot lightly to make it return to
normal.
4. Clean it up with fine sand paper
5. Send to designated service department.
It should be sent to an authorized
service department for maintenance.
Heating plate is
not hot.
Heating plate is
hot.
Heating plate is
not hot.
Addition: Any technical improvements shall be placed in the
revised manual without notice; for any changes in appearance
and color, those of the actual product shall prevail.
All the contents in this material have been subjected to carefully
check.
For any mistake and omission in printing or misunderstanding the
contents, the TOSHIBA keeps the right of interpretation.
SPECIAL STATEMENT
型號
1.0L 型
1.8L 型
東芝機械電飯煲/保溫鍋
使用說明書
供家庭使用
目錄
重要安全措施...........................................1
產品規格................................................. 2
開始使用................................................. 3
操作說明................................................. 4
注意事項................................................. 5
故障排除................................................. 6
● 感謝您購買東芝電飯煲。本手冊中的所有圖片僅用於功能展示，請以實物為凖。
● 為了您自己的安全，請閱讀使用說明書並正確使用。使用前，請閱讀“安全措施”
和“請按照說明操作”。
● 閱讀後，請將使用說明書放在用户便於發現的地方以供參考。
RC-10JRNH
RC-18JRNH
1
使用電器時，應遵循以下基本的安全預防措施：
小心
重要安全措施
重要安全措施
1. 本機可供肢體傷殘、感
官或精神上有障礙或缺
乏相關經驗及知識的人
員（包括兒童）使用，
前提是他們在使用本機
時受到監督或得到安全
使用指導。
2. 本機適用於家庭和類似
的應用領域，
- 例如商店、辦公室和
其他工作環境的員工
廚房區域；
- 農舍；
- 酒店、汽車旅館、家
庭旅館環境中的顧客
- 其他住宅類型環境中
的顧客。
3. 如果電源線損壞，則必
須採用製造商或其維修
代理商提供的專用電源
線或元件更換。
4. 在清潔、維護或重新安
置之前以及不使用時，
請關閉電源並拔下插
頭。
5. 警告：誤用可能會造成
潛在傷害。
6. 警告：避免溢出物濺到
接頭上。
1. 本機僅供家庭使用。請
勿在戶外使用。
2. 請看管好兒童，避免其
玩耍電器。
3. 請勿將本機任何部件浸
入水中或其他液體中。
4. 加熱元件表面使用後會
有餘熱，請勿觸摸。
2
附件
加熱
220-240V~
50/60Hz
500-595 1.0
1-5.5
額定電壓
額定功率
(W)
容量（L） 烹飪方法
飯勺
量杯 電源線 蒸籠
型號
650-774 1.8
2-10
米量（杯）
外形尺寸
(mm)
重量
(kg)
產品規格
蓋板
可拆卸蓋板 不可拆卸蓋板
內膽
接水盒
上蓋
控制台
“煮飯”開關
“保溫”指示燈
產品規格
小心
本手冊中的所有圖片僅用於功能展示，請以實物為凖。
感謝您購買東芝電飯煲。使用前，請仔細閱讀本使用說明書。閱
讀後請妥善保管以備將來參考。
首次使用時可能會有塑膠等氣味。使用後氣味會消失。
切勿在其他爐灶上加熱內膽，以免變
形。
將內膽從電飯煲中取出，用家用洗滌
液清洗，用清水沖洗，然後用軟布擦
乾。切勿使用金屬刷或其他刺激性工
具清洗，以免損壞內膽。
根據使用頻率，內膽可能會出現變色
或斑紋現象，但不影響健康和使用。
取出接水盒，倒
出米水，清潔後
裝回原位。注意
取下動作應緩慢
，以防止濺水。
開機和完成烹飪時顯示。米飯最佳
保溫時間不超過12小時，否則會對
米飯產生負面影響。
按下按鈕進入煮飯狀態。
RC-10JRNH
RC-18JRNH
255*240*254 2.2
280*263*289 2.8
開始使用
開始使用
3
1. 首次使用本機前，請徹底清潔電飯煲的部件。在開始使用本機之前，請確
保所有部件完全乾燥。
2. 為防止損壞內膽的防粘塗層，請使用單獨的容器淘洗稻米。
3. 使用提供的量杯估量米量。請勿超過內膽內側指示的數量。
4. 將淘洗過的米放入內膽中。
5. 向內膽中加水至相應米量對應的水位。
6. 擦乾內膽的外側。
7. 將內膽放入電飯煲中。
8. 關閉電飯煲的蓋子，直到聽到“哢噠”聲。
9. 將電源線插入電飯煲和牆壁插座，然後打開電源。
操作說明
1
5
量米和淘洗
•
量杯主要用於衡量米量。一平杯是0.18升（約150克）。
•
請勿直接用內膽淘洗稻米，以免刮傷防粘層，使其因碰撞
而變形，或由於與電熱板接觸不良而導致熱效率降低。
2
將淘洗過的米放入內膽中，加水至相應的水位（例如，要煮3
杯米，則加水至水位“3”），可根據個人口味添加或減少水
量。
3
用乾布擦拭內膽的內外側，將其放入電飯煲。輕輕轉動內膽
數次，使其底部與電熱板接觸。
•
內膽和電熱板之間不得有異物。
•
確保蓋子正確關閉，否則烹飪效果可能會受到影響。
按下蓋子直至其卡入到位。
4
如有需要，可在煮飯時將蒸籠放入內膽中，將食物放在盤子
上或蒸籠上一同蒸煮。
操作說明
操作說明
4
6
烹飪
插入插座後，“WARM”指示燈亮起。按下“COOK”開關
後電飯煲進入烹飪程式。否則，電飯煲將一直處於保溫狀態
（請確保已按下“COOK”，否則，電飯煲將一直處於保溫狀
態）。
7
烹飪完成後，烹飪開關彈出並發出“哢嗒”聲。同時，
COOK指示燈熄滅，保溫指示燈亮起。
特別提示：
煮飯後保溫15分鐘米飯口味最佳。
8
盛飯時，請使用提供的飯勺，而不是金屬勺子，以免刮傷內
膽的防粘塗層，同時造成塗層脫落，應去除乾燥的米飯。
9
為了保持清潔衛生，請在烹飪後清潔接水盒中的米水。
蒸煮功能（手動控制）
1
2
向內膽中加入適量的水。
水量根據要蒸煮的食物的量而變化。
蒸籠放入內膽後，確保水位不超過蒸籠的底部。將蒸籠放入內膽中，將食物
放在盤子上或蒸籠上。
按下COOK键
3
如非與烹調米飯同步進行（只蒸煮食物），當食物蒸煮完成後，必須手動
按下”WARM”鍵，電飯煲才會自動保溫。
4
開始烹飪。指示燈將切換到“COOK”
如與烹調米飯同步進行，”WARM”鍵會在米飯烹調完成後亮起。
注意：為確保均勻蒸煮，請將食物均勻鋪開，避免堆放。
注意事項
安全注意事項
清潔方法
1
2
3
1
2
3
1
2
3
4
5
6
7
8
注意事項
5
內膽不能在任何其他爐灶上加熱，否則容易變形。
煮熟的米飯開始保溫，不適合立即食用，煲15分鐘後會更
加柔軟可口。
保溫時間不超過12小時，以避免煮熟的米飯出現異味。
從電飯煲中取出內膽，用家用洗滌液清洗，用清水沖洗，
然後用軟布擦乾。
*切勿使用金屬刷或其他刺激性工具清洗，以免損壞其表面
的防粘塗層。
取下接水盒，倒掉水或湯，清洗乾淨後再重新裝上。
米飯顆粒或其他雜物可能會附著在電熱盤上，可以用細砂
紙將其研磨掉並用軟布擦拭，以保持內膽與電熱板之間的
良好接觸。
應使用接地的牆壁插座，並請確保插頭已完全插入插座。在使用其他電器時
請勿使用多功能插座。
不使用時，請將電源線從插座中拔出。
請確保電源線完全插入插座，否則元件可能因連接不良而燒壞。
電飯煲不能放置在不穩定或潮濕的場所，否則會損壞或出錯。
烹飪時，蒸氣口非常熱，請勿靠近面部或手部，以免燙傷。
電飯煲的機身和蓋子不能用水沖洗或浸入水中，否則會損壞絕緣體而引起
危險。
如果電源線損壞，必須使用製造商生產的新電源線更換。
請勿讓兒童獨自操作本機。請將其放置在兒童接觸不到的地方，以避免觸
電、燙傷等危險事故。
故障排除
編號
故障排除
6
故障
原因 解決方法
燈熄滅。1
2
3
4
燈亮起。
煮的米飯夾生或烹飪時間過
長。
米飯燒焦或不能自動保溫
電飯煲的電路沒有連接電源。
1.指示燈的接線連接鬆動。
2.指示燈損壞。
1.中間的接線鬆動。
2.電熱管燒壞。
1.烹飪時間不足。
2.加熱板變形。
3.內膽傾斜，一側懸空。
4.內膽與加熱板之間有異物。
5.內膽變形。
1.煮飯按鍵和杠杆連杆裝置不起
作用。
2.鋼制磁鐵溫度限制器失靈。
3.溫度控制器燒壞其接線鬆動。
檢查電源的開關、插頭和插座連接器、保險絲和
引線是否完好，並完全插入插座。
交給授權服務部門進行維護。
1.根據要求的條件煮飯。
2.細砂紙可用於修正輕微變形，但嚴重變形應交
由維修部門更換。
3.輕輕轉動內膽使其恢復正常。
4.用細砂紙清潔。
5.交給指定的服務部門。
交給授權服務部門進行維護。
加熱板不熱。
加熱板熱。
加熱板不熱。
特別聲明
增加：本產品的任何技術改進都會加入修訂手冊中，恕不另行通
知；外觀和顏色的變化以實物為凖。
本手冊的所有內容均經過仔細檢查。
對於印刷錯誤和遺漏或對內容的理解分歧，東芝擁有解釋權。
