EX 125 ES
Original instructions
425_101_EX125ES_4-0.indd 2 17.06.13 09:11
Accessory
Aufnahme
aufschrauben
IIIII
IV
V
I
2
II
1.
2.
VELCRO
Press carefully the fuzzy side of sanding disc against the packaging
pad,as rmly as possible.
Align holes in the sanding disc to those on the sander to increase dust
extraction efficiency.
3
I
1...2...3...4...5...6
Start Stop
425_101_EX125ES_4-0.indd 3 17.06.13 09:12
4
III
ø 32 mm
AP 300 ELCP
click
3.
4.
4.
3.
2.
4.
1.
1
2
425_101_EX125ES_4-0.indd 4 17.06.13 09:12
5
IV
425_101_EX125ES_4-0.indd 5 17.06.13 09:12
Applying too much pressure will reduce
the efficiency of the tool
6
English
WARNING! Read all safety warnings and all instruc-
tions, including those given in the accompanying brochure.
Failure to follow the warnings and instructions may result in electric
shock, re and/or serious injury.
Save all warnings and instructions for future reference.
SAFETY INSTRUCTIONS
Wear ear protectors. Exposure to noise can cause hearing loss.
Appliances used at many dierent locations including open air should
be connected via a residual current device (FI, RCD, PRCD) of 30mA
or less.
Always wear goggles when using the machine. It is recommended to
wear gloves, sturdy non slipping shoes and apron.
Before doing any work on the machine, pull the plug out of the
socket.
Only plug-in when machine is switched o.
Keep mains lead clear from working range of the machine. Always
lead the cable away behind you.
Before use check machine, cable, and plug for any damages or
material fatigue. Repairs should only be carried out by authorised
Service Agents.
The dust produced when using this tool may be harmful to health.
Do not inhale the dust. Use a dust absorption system and wear a
suitable dust protection mask. Remove deposited dust thoroughly,
e.g. with a vacuum cleaner.
Do not use machines on any material containing asbestos.
This machine is suitable only for dry sanding.
SPECIFIED CONDITIONS OF USE
This eccentric sander is a versatile machine. The following work can
be carried out with it: Coarse sanding and grinding, Fine sanding
and polishing, Rubbing down weather-beaten paint, Polishing up
Do not use this product in any other way as stated for normal use.
scratches on crylic glass, Etc.a
MAINS CONNECTION
Connect only to single-phase AC current and only to the
system voltage indicated on the rating plate. It is also possible
to connect to sockets without an earthing contact as the design
conforms to safety class II.
TECHNICAL DATA
Random Orbital Sander
EX 125 ES
Rated input 300 W
No-load speed 7000-12000 min
-1
Orbital travel diameter 2,4 mm (3/32”)
Dimensions of grinding plate 125 mm
Weight according EPTA-Procedure 01/2003 1,7 kg
Noise/Vibration Information
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level (K=3dB(A))
Sound power level (K=3dB(A))
Wear ear protectors!
80,0 dB(A)
91,0 dB(A)
Total vibration values (vector sum in the three axes) determined according to EN 60745.
Vibration emission value a
h
Uncertainty K=
7,4 m/s
2
1,5 m/s
2
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 60745 and
may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for dierent applications, with
dierent accessories or poorly maintained, the vibration emission may dier. This may signicantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched o or when it is running
but not actually doing the job. This may signicantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eects of vibration such as: maintain the tool and the accessories, keep
the hands warm, organisation of work patterns.
7
English
MAINTENANCE
The ventilation slots of the machine must be kept clear at all times.
Use only AEG accessories and spare parts. Should components need to
be replaced which have not been described, please contact one of our
AEG service agents (see our list of guarantee/service addresses).
SYMBOLS
Please read the instructions carefully before starting the
machine.
CAUTION! WARNING! DANGER!
Always disconnect the plug from the socket before
carrying out any work on the machine.
Accessory - Not included in standard equipment, availa-
ble as an accessory.
Do not dispose of electric tools together with household
waste material! In observance of European Directive
2002/96/EC on waste electrical and electronic equipment
and its implementation in accordance with national law,
electric tools that have reached the end of their life must
be collected separately and returned to an environmen-
tally compatible recycling facility.
Class II construction, tool in which protection against
electric shock does not rely on basic insulation only, but
in which additional safety precautions, such as double
insulation or reinforced insulation, are provided.
Regulatory Compliance Mark (RCM). Product meets
applicable regulatory requirements.
Techtronic Industries (Australia) Pty. Ltd.
Level 1, 660 Doncaster Road,
Doncaster, VIC 3108,
Australia
Techtronic Industries N.Z. Limited
18-26 Amelia Earhart Avenue,
Mangere, Auckland 2022,
New Zealand
CUSTOMER SERVICE HOTLINE
Australia
Web: www.aegpowertools.com.au/register
Customer service: 1300 361 505
New Zealand
Web: www.aegpowertools.co.nz/register
Customer service: 0800 279 624
Always wear goggles when using the machine.
Wear ear protectors!
Wear a suitable dust protection mask.
Wear gloves!
Techtronic Industries GmbH
Max-Eyth-Straße 10
71364 Winnenden
Germany
Techtronic Industries (Australia) Pty. Ltd.
Level 1, 660 Doncaster Road,
Doncaster, VIC 3108,
Australia
Techtronic Industries N.Z. Limited
18-26 Amelia Earhart Avenue,
Mangere, Auckland 2022,
New Zealand
www.aegpowertools.com.au
www.aegpowertools.co.nz
961067451-03
