I
mportant!
It is essential that you read the instructions in this manual
before operating this machine.
Subject to technical modifications.
2
2
VELCRO
START
STOP
11
10
8
12
13
6
Remove the battery pack before
starting any work on the machine.
Electronic Variable Speed
3
3
VELCRO
START
STOP
11
10
8
12
13
6
Remove the battery pack before
starting any work on the machine.
Electronic Variable Speed
4
4
1
2
2
1
click
Remove the battery pack
before starting any work on
the machine.
5
5
75-100 %
50-75 %
25-50 %
0-25 %
6
6
1
2
VELCRO
Press carefully the fuzzy side of
sanding disc against the packaging
pad,as firmly as possible.
Ensure holes on paper are aligned
with holes in sander.
7
7
START
STOP
8
8
1...2...3...4...5...6
9
9
1
2
Accessory
ø 30.6 mm
10
10
11
11
WARNING! Read all safety warnings and all instructions,
including those given in the accompanying brochure. Failure
to follow the warnings and instructions may result in electric shock,
re and/or serious injury. Save all warnings and instructions for
future reference.
RANDOM ORBITAL SANDER SAFETY WARNINGS
Wear ear protectors. Exposure to noise can cause hearing loss.
ADDITIONAL SAFETY AND WORKING INSTRUCTIONS
Always wear goggles when using the machine. It is recommended
to wear gloves, sturdy non slipping shoes and apron.
The dust produced when using this tool may be harmful to health
(e.g. when working oak or beech wood, stones, paint, which could
contain lead or other harmful chemicals). Do not inhale the dust.
Use a dust absorption system and wear a suitable dust protection
mask. Remove deposited dust thoroughly, e.g. with a vacuum
cleaner.
Do not use machines on any material containing asbestos.
This machine is suitable only for dry sanding.
Remove the battery pack before starting any work on the machine.
Do not dispose of used battery packs in the household refuse or
by burning them. AEG Distributors offer to retrieve old batteries to
protect our environment.
Do not store the battery pack together with metal objects (short
circuit risk).
Use only System PCLS chargers for charging System PCLS battery
packs. Do not use battery packs from other systems.
Never break open battery packs and chargers and store only in dry
rooms. Keep dry at all times.
Battery acid may leak from damaged batteries under extreme load
or extreme temperatures. In case of contact with battery acid wash
it off immediately with soap and water. In case of eye contact rinse
thoroughly for at least 10 minutes and immediately seek medical
attention.
SPECIFIED CONDITIONS OF USE
This random orbital sander is a versatile machine. The following
work can be carried out with it: Coarse sanding and grinding,
Fine sanding and polishing, Rubbing down weather-beaten paint,
Polishing up scratches on acrylic glass, Etc.
To provide the best adhesion, it is recommended that you clean the
backing pad and the sanding disc backing occasionally by brushing
them lightly with a small brush. Do not use this product in any other
way as stated for normal use.
ADVICE FOR OPERATION
Only use original AEG sanding and polishing tools with
self-adhesive velcro fastening.
BATTERIES
Battery packs which have not been used for some time should be
recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance
of the battery pack. Avoid extended exposure to heat or sunshine
(risk of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged,
after used.
To obtain the longest possible battery life remove the battery pack
from the charger once it is fully charged.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below 27°C and
away from moisture
Store the battery packs in a 30% - 50% charged condition Every six
months of storage, charge the pack as normal.
TRANSPORTING LITHIUM BATTERIES
Lithium-ion batteries are subject to the Dangerous Goods
Legislation requirements.
Transportation of those batteries has to be done in accordance with
local, national and international provisions and regulations.
■ The user can transport the batteries by road without further
requirements.
■ Commercial transport of Lithium-Ion batteries by third parties is
subject to Dangerous Goods regulations. Transport preparation
and transport are exclusively to be carried out by appropriately
trained persons and the process has to be accompanied by
TECHNICAL DATA RANDOM ORBITAL SANDER
BEX18-125
Battery voltage 18 V
No-load speed 7000 - 11000 min
-1
No-load orbital stroke rate 1400 - 2200 min
-1
Orbital travel diameter 2.4 mm
Dimensions of grinding plate 125 mm
Weight - not including battery pack 1.39 kg
BATTERY AND CHARGER
Compatible battery pack
(not included)
Compatible charger
(not included)
L1815R
L1820R
L1830R
L1840R
L1850R
L1860R
BL1218
AL1218G
Use AEG 18V battery and charger only
12
12
corresponding experts.
When transporting batteries:
■ Ensure that battery contact terminals are protected and
insulated to prevent short circuit.
■ Ensure that battery pack is secured against movement within
packaging.
■ Do not transport batteries that are cracked or leak. Check with
forwarding company for further advice
BATTERY PACK PROTECTION
The battery pack has overload protection that protects it from being
overloaded and helps to ensure long life. Under extreme stress the
battery electronics switch off the machine automatically. To restart,
switch the machine off and then on again. If the machine does not
start up again, the battery pack may have discharged completely. In
this case it must be recharged in the battery charger.
MAINTENANCE
The ventilation slots of the machine must be kept clear at all times.
Use only AEG accessories and AEG spare parts. Should
components need to be replaced which have not been described,
please contact one of our AEG service agents (see our list of
guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please state
the Article No. as well as the machine type printed on the label and
order the drawing at your local service agents or directly at:
Techtronic Industries (Australia) Pty. Ltd.
PO Box 1065
Mount Waverley VIC 3149
Tel. no. 1300 361 505
Australia
Techtronic Industries N.Z. Ltd.
PO Box 12-806
Penrose AUCKLAND 1642
Tel no. 0800 279 624
New Zealand
SYMBOLS
Safety alert
Regulatory Compliance Mark (RCM). Product
meets applicable regulatory requirements.
Please read the instructions carefully before
starting the machine.
Remove the battery pack before starting any work
on the machine.
Do not dispose of electric tools together with
household waste material! In observance of
European Directive 2002/96/EC on waste electrical
and electronic equipment and its implementation
in accordance with national law, electric tools that
have reached the end of their life must be collected
separately and returned to an environmentally
compatible recycling facility.
www.aegpowertools.com.au
Techtronic Industries GmbH
Max-Eyth-Straße 10
71364 Winnenden
Germany
Techtronic Industries N.Z. Limited
18-26 Amelia Earhart Avenue,
Mangere, Auckland 2022,
New Zealand
Techtronic Industries (Australia) Pty. Ltd.
31 Gilby Road,
Mount Waverley VIC 3149,
Australia
961004158-02
