INSTRUCTION
MANUAL
Percussion Massage Device
1
Thank you for purchasing OPOVE M3 Pro. This instruction
manual contains important information about safety, usage
and warranty. Use the product as described and keep this
manual for future reference.
1.Safety Instructions 2
2.Product Description 3
3.Packing List 4
4.Technical Parameters 4
5.Operating Instructions 5
6.Warranty 6
7.FAQ 7
Table of Content
2
• Do not operate continuously for more than one hour. Allow the OPOVE M3 Pro to
rest for 5 minutes before re-using.
• Do not remove screws or attempt to disassemble in case of the electric shock,
explosions, exposure to chemicals and other risks.
• Never leave the charging or working OPOVE M3 Pro unattended.
• Do not place your fingers, hair, or other parts of the body near the trigger of the
OPOVE M3 Pro while massaging, as they may cause pinched.
• Use the OPOVE M3 Pro only on the body’s soft tissue. Do not use on the Adam's
apple, axilla, genitals or any hard or bony area of the body.
• Use the OPOVE M3 Pro only on the body for no more than 20 seconds per region
continuously in case of bruising.
• Check treated areas frequently and immediately stop at the first sign of pain or
discomfort.
• Do not expose the OPOVE M3 Pro to sun or fire. Keep it away from the heat
source.
• Do not immerse in water. Keep the OPOVE M3 Pro vent free of dust and debris.
• Do not use any massage attachments other than the ones provided by OPOVE.
• For adult use only. Children shall not use and play with the appliance.
• （Please charge the OPOVE M3 Pro with the original charger.）
• Turn off the OPOVE M3 Pro for storage or travel. Keep out of reach of children.
• To protect the environment, please dispose the OPOVE M3 Pro in accordance
with local laws and regulations.
• Patients with osteoporosis
• Heart disease and those who wear electro medicine and pacemakers
• Infants
• Pregnant woman
• Physical trauma
• People who had a surgery recently
Note: Please consult a doctor or technical support if you are not sure whether can
use the massager.
Safety Instructions
The people who should not use it
Flat For large muscles such as legs, hips,etc.
For large muscles such as chest, backs, etc.Ball
For targeted precise muscle, hands,
foot, and other trigger points.
Bullet
Suggested Use
Percussion
Accuracy
Force
Sensibility
Massage
attachment
Cushion
For Achilles tendon, both sides of spine muscles.Fork
For shoulders, muscles around the iliotibial band.Shovel
For muscles near bone, beginners and
people who are sensitive to pain
3
Product Description
To make it easier to understand the different usages of the massage attachments,
we simulate the force sensibility and percussion accuracy for each of them. Generally,
ten out of ten, the more pointed it is, the more sensible force it has. The less the
contact area is, the more accurate percussion it provides.
1 2 3 54 6
Li Battery:
2600mAh
MADE IN CHINA
ONOFF
DC IN:
25.2V 1A
speed
switch button
charging
port
switch
button
4
Packing List
Technical Parameters
Adjust Speed
Percussion Frequency
Stroke Length
Input
1-5 Speed Levels
1300-2500/min
12mm
25.2V-1.0A
Item Net Weight 2.43lbs (1.1kg)
Item Size 9.9*6.9*2.8inch (251*176*71mm)
2600mAh
Battery Capacity
5
3. The average run-time is 4-8 hours depending on speed level and pressure applied
during use. And the average charging time is about 2.5 hours.
1. Fully charge the device before first use.
4. Please do not use this device while charging.
5. Fully charge the OPOVE M3 Pro before the long-term non-use.
Step 1
Choose a suitable massage attachment according to your needs. Rotate it firmly into
the massage gun.
Step 2
With the power switch in the ON position, the battery indicator will light up. Press the
Speed Setting Button once to turn the device on to Level 1, twice to turn the device
to Level 2, three times to turn the device to Level 3, four times to turn the device to
Level 4, and five times to turn the device to Level 5. Press the Speed Setting Button
again will turn the device into the standby mode. The working speed is indicated by
the speed level indicator.
2. When charging, the battery indicator on the back is pulsating. Full charge is
indicated when the top of the battery indicator lights stop pulsating.
Charging
Operating Instructions
Attach
Rotate the attachment
slightly and push it in.
拆卸
Detach
Rotate the attachment
slightly and pull it out.
拆卸
05
04
03
02
01
6
THE WARRANTY EXCLUDES:
a. Damage caused by accident, abuse, mishandling, or transport;
b. Units subjected to unauthorized repair or disassembly;
c. Units not used in accordance with OPOVE instructions;
d. Damage exceeding the cost of the product;
e. Deterioration of the delivered product resulting from abnormal storage and/or
safeguarding conditions on the client’s premises, and
f. Failure to provide the dated proof of purchase.
Step 3
With the Speed Level in 1-5 position, press and hold the Speed Setting Button for 2
seconds, the device goes into the standby mode. Switch off the device completely by
moving the Power Switch to the OFF position.
Note：
• With the standby mode, the device will go into sleep mode after 10 minutes without
operation. The screen light will turn off on the sleep model. Press the Speed Setting
Button to go into the standby mode.
• The device will automatically turn off after 30 minutes of continuous use. Please
press the Speed Setting Button again for further use.
Warranty
IF WITHIN 12 MONTHS FROM THE DATE OF PURCHASE, THIS PRODUCT FAILS DUE
TO A DEFECT IN MATERIAL OR WORKMANSHIP, OPOVE LIMITED WILL REPAIR OR
REPLACE THE PRODUCT, OR NECESSARY COMPONENTS, FREE OF CHARGE.
Some states and countries do not allow a limitation of damages, so the foregoing
limitation may not apply to you.
This warranty guarantees specific legal rights, and other rights may vary from country
to country and from state to state. This warranty service is available through the
operating policies and procedures of OPOVE Limited and all OPOVE international
distributors. If you are a client, please contact the appropriate OPOVE business entity,
dealer or retailer, from whom you directly purchased the product for warranty and
return authorization procedures. This warranty is initiated and executed by OPOVE
Limited.
7
Unable to
charge
Stops working
during massage
Abnormal
noise
Reasons
The charger is not
compatible.
Power cord is not
plugged in tightly.
The battery runs out.
Touch the Speed Setting
Button or ON/OFF Power
Switch accidentally.
The pressure force is over
stall force, the device turn
off.
The device automatically
turns off after 30 minutes
of continuous use.
The attachment is not
plugged in tightly.
Trouble shooting
Make sure to use the original
charger during charging.
Make sure the power cord
is attached in place.
Please charge the device
with the original charger.
Please check the Speed Setting
Button and the ON/OFF power
switch.
Press the Speed Setting Button
to turn on the device again.
Press the Speed Setting Button
to turn on the device again.
Make sure the attachment is
attached in place.
FAQ
Questions
8
Warranty Card
Note: Be assured the above info is not disclosed. It is only used for after-sales service.
Recipient’s Name
Contact Information
Return Reason
(The device is guaranteed for 12 months, from date of purchase,
providing not damaged by the user.)
Order ID
Recipient’s Address
replace repairreturn
www.opove.com
Designed by opove
