Elite 200 V2
Portable Power Station
User Manual V2.0
Important Instructions
For the best experience and performance,
fully charge your unit and update to the latest firmware
before first use. See the appendix "Update Firmware via
BLUETTI App" for guidance.
Read and understand this manual before use and keep
it handy for future reference.
Tips
1. Charge the unit before first use.
2. Do not use solar panels with open circuit voltage higher than 60V. Solar input
voltage range for the unit is 12V-60V.
3. If the unit's SoC falls below 5%, please recharge the unit in time. If the SoC drops to 0,
power off the unit and charge it for at least 30 minutes before restarting.
4. The unit is for off-grid use only. Do not connect its AC output to the grid.
5. If not used for more than 3 months, charge the unit to 40%-60% SoC and store it
with the power off. For optimum battery life, discharge and charge the unit every 3
months.
Legal Information
Copyright © ShenzhenPowerOakNewenerCo., Ltd. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any
means without the prior written consent of ShenzhenPowerOakNewenerCo., Ltd.
Shenzhen PowerOak Newener Co., Ltd.
F19, BLD No.1, Kaidaer, Tongsha RD No.168, Xili street, Nanshan, Shenzhen, China
Website: https://www.bluettipower.com/
Notice
BLUETTI's products and services are subject to the terms and conditions agreed upon
during purchase. Some aspects described in this manual may not be available under
your purchase contract. Unless otherwise specified in the contract, BLUETTI makes no
express or implied representations or warranties regarding the contents of this manual.
The contents of this manual are subject to change without notice. Please obtain the
latest version from BLUETTI official website.
If you have any questions or concerns about this manual, please contact BLUETTI
support for further assistance.
Safety Information
What's in the Box
Get to Know Your Elite 200 V2
Elite 200 V2 Overview
Display Screen
Use Your Elite 200 V2
Power On/Off
Charging
Power Your Devices
Configure Your Elite 200 V2
Setting Mode
AC Charging Mode
Power Lifting Mode
ECO Mode
View Device Information
UPS Feature
Grid Self-adaption Mode
Adjust Grid Input Current
System Switch Recovery
Maintenance and Care
Specifications
Troubleshooting & FAQ
Contents
1
2
3
3.1
3.2
4
4.1
4.2
4.3
5
5.1
5.2
5.3
5.4
6
7
8
9
10
11
12
13
Appendix
Compliance
05
08
09
09
10
11
11
12
14
15
15
16
16
16
17
17
19
20
20
21
22
23
24
27
1. Safety Information
WARNING - When using the product, basic precautions should always be followed,
including the following:
• Read all the instructions before using the product.
• Handle the product with care, avoiding drops, violent impacts, or tilting.
• To reduce the risk of injury, close supervision is necessary when the product is used near
children.
• Do not put fingers or foreign objects into the product's ports.
• Use of an attachment not recommended or sold by the manufacturer may result in a
risk of fire, electric shock, or injury to persons.
• Do not move the product during operation to avoid poor connections.
• Do not expose the battery to high temperatures, as this may cause an explosion or
leakage of flammable liquids or gases.
• Do not use the product in the rain or high humidity environments.
• Do not use a battery pack or appliance that is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behavior resulting in fire, explosion or risk of injury.
• Handle the product with caution in low air pressure environments to prevent explosions
or leaks.
• Charge the product in a well-ventilated area.
• Under abusive conditions, liquid may be ejected from the product's battery; avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally
seek medical help. Battery liquid may cause irritation or burns.
• In case of fire, use a dry powder fire extinguisher appropriate for the product.
• Never dispose of the product's battery in fire, hot ovens, or by cutting it.
• Do not operate the product with a damaged cord, plug, or output cable.
• To reduce the risk of damage to the electric plug and cord, pull the plug rather than the
cord when disconnecting the product.
• Do not disassemble the product; take it to a qualified service person if service or repair is
required. Incorrect reassembly may result in a risk of fire or electric shock.
• Unplug the product before any servicing to prevent electric shock.
• WARNING - RISK OF EXPLOSIVE GASES. Follow these instructions and those published
by manufacturer of any equipment you intend to use in vicinity of the product to
reduce risk of battery explosion.
INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS
JUST POWER ON 05
Disposal and Recycling
1. Take old electronic components and batteries to designated recycling centers. This
prevents improper disposal and supports material recovery.
2. If possible, fully discharge the batteries and then place them in designated battery
recycling boxes. The batteries in this product contain hazardous chemicals. Do not
dispose of them with regular household waste. Please follow local laws and regulations
for proper battery disposal.
3. If a battery cannot fully discharge due to product malfunction, do not place it in the
battery recycling box. Instead, contact a professional battery recycling organization for
safe handling.
• When charging with lead-acid batteries or using the product to charge them, follow
these safety precautions:
a. Wear eye and clothing protection; do not touch eyes when working near a battery.
b. No smoking, sparks, or flames near the battery or engine.
c. Avoid dropping metal tools onto the battery to prevent sparks or short circuits.
Attention
Not permitted on aircraft.
• WARNING - RISK OF ELECTRIC SHOCK. Never use the product to power tools to cut or
access live parts, wirings or materials containing them, such as building walls.
• Have servicing performed by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the product is maintained.
• The symbols on unit and its accessories are intended to remind you to read the
instructions in the literature accompanying the product before operation and maintenance.
• The socket-outlet should be installed near the product and easily accessible for safety
purposes.
• Caution: The output of USB-C port is classified as PS3 according to standard IEC 62368-1.
Consider implementing safeguards against fire, such as a fire enclosure, for connected
equipment or accessories.
JUST POWER ON06
Grounding Instructions (For AC charging only)
• This product must be grounded when connected to the grid. If this product should
malfunction, grounding provides a path of least resistance for electric current to reduce
the risk of electric shock.
• The product is equipped with an AC charging cable having an equipment grounding
conductor and a grounding plug. The plug must be plugged into an appropriate outlet
that is properly installed and grounded in accordance with all local codes and ordinances.
• WARNING - Improper connection of the grounding conductor can result in a risk of
electric shock. Check with a qualified electrician if you're in doubt as to whether the
product is properly grounded. Don't modify the plug provided with the product – if it'll
not fit the outlet, have a proper outlet installed by a qualified electrician.
SAVE THESE INSTRUCTIONS
JUST POWER ON 07
2. What's in the Box
The following accessories are not included.
Please purchase optional accessories below at https://www.bluettipower.com
Note: All images are for reference only.
Elite 200 V2
Portable Power Station
AC Charging Cable
Type B plug - Type A plug
(70.87in / 1.8m)
Solar Charging Cable
MC4 - XT60
(59.06in / 1.5m)
Grounding Screw Documentation
USB-C to USB-C Cable
(78.74in / 2m)
Car Charging Cable
Cigarette Lighter Plug - XT60 (F)
(28.35in / 0.72m)
12V DC Power Cable*
Cigarette Lighter Plug - DC5521 (F)
(28.35in / 0.72m)
Elite 200 V2
Portable Power Station
User Manual
V1.0
Important Instructions
For the best experience and performance,
fully charge your unit and update to the latest firmware
before first use. See the appendix "Update Firmware via
BLUETTI App" for guidance.
Read and understand this manual before use and keep
it handy for future reference.
Lead-acid Battery Charging Cable
Cigarette Lighter Plug - Clamps
(19.69in / 0.5m)
* Used to charge devices with DC5521 input using Elite 200 V2's cigarette lighter port.
Optional Accessories
JUST POWER ON08
3. Get to Know Your Elite 200 V2
DC Power Button
LCD Display
Power Button
AC Power Button
AC Outlet
Grounding Terminal*
Circuit Breaker
AC Input
USB-A Ports
USB-C Ports
Cigarette Lighter Port (Car Outlet)
DC Input
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
⑫
* Used for grounding when powering certain equipment. For assistance, contact
us or seek guidance from the appendix "Grounding Guidelines".
3.1 Elite 200 V2 Overview
1 4 5
6
7
8
9
10
2 3
11
12
JUST POWER ON 09
* Progress Bar: Fill up while charging and deplete while discharging.
DC Input: Charges from solar panels, cars, or lead-acid batteries.
Fan: Flashing for abnormal fan operation.
AC Input: Charges from a wall outlet or generator.
DC/AC Output: Output is active.
Remaining Time: Remaining charging or discharging time.
Battery Status: for charging, for discharging.
Low Battery: SoC below 5%. CHARGE THE UNIT IN TIME.
3.2 Display Screen
①
②
③
④
⑤
⑥
⑦
⑧
⑨
Progress Bar*
Turbo Charging
ECO Mode
State of Charge (SoC)
Silent Charging
DC Input*
Bluetooth Connection
WiFi Connection
Fan*
⑩
⑪
⑫
⑬
⑭
⑮
⑯
⑰
⑱
AC Input Power
AC Output Power
Inverter Voltage
Inverter Frequency
AC Input*
DC Output*
AC Output*
Power Lifting Mode
Remaining Time*
Battery Status*
Low Temperature
High Temperature
Overload
Overcurrent
System Fault
DC Output Power
Low Battery*
DC Input Power
⑲
⑳
㉑
㉒
㉓
㉔
㉕
㉖
㉗
51 2 3 4 6 7 8 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
JUST POWER ON10
Power On
Press the power button; the lit button indicates that the Elite 200 V2 is on standby.
Power Off
Long press the power button for about 2 seconds to turn off the unit.
AC On/Off
Press AC power button when Elite 200 V2 is on.
DC On/Off
Press DC power button when Elite 200 V2 is on.
Note:
• When Elite 200 V2 is on, press the power button to turn on/off the display.
• If there is no DC or AC output for over one minute, the Elite 200 V2 automatically
powers off.
• By default, the display turns off after one minute of inactivity. You can adjust the
sleep time via the app.
4. Use Your Elite 200 V2
4.1 Power On/Off
JUST POWER ON 11
Note:
• Make sure your car has power and the engine is running while charging.
• The Elite 200 V2 has a safety feature that stops charging when your car's battery is
too low, preventing the battery from being over-discharged.
Note: Do not plug the unit's AC charging cable into its own AC outlets, as this could
damage the connected device.
4.2 Charging
AC Charging (Wall Outlet)
Plug the Elite 200 V2 into a standard wall outlet. It stops charging when fully charged to
prevent overcharging. For quicker charging, enable Turbo Charging in the app. This lets
the Elite 200 V2 reach 80% charge in approximately 1 hour and 100% in about 1.4 hours, at
an ambient temperature of 25°C (77°F).
Car Charging
Connect the Elite 200 V2 to your car's 12V or 24V cigarette lighter port or socket using the
car charging cable. It charges at up to 96W with a 12V port and 192W with a 24V port.
JUST POWER ON12
Note:
• Make sure the solar panel(s) meets the following requirements:
Voc: 12V-60V Current: 20A Max. Power: 1,000W Max.
• For quicker charging, use both MC4 connectors on the DC input cable. They will
be connected in parallel. Ensure both sets of MC4 have the same power rating
and type of solar panels. For example, if one set has two 200W (20V/10A) panels in
series, the other set should also have two 200W (20V/10A) panels of the same type
in series.
Solar Charging
Connect the solar panel(s) either in series or parallel, and use the solar charging cable to
link them to Elite 200 V2. With a continuous input of 1,000W, the Elite 200 V2 reaches full
capacity in about 2.4 hours.
In the app, set the DC input source to "PV" or "other" in the advanced mode. The
charging strategies for these two sources are shown below:
* U: Solar input voltage; I: Input current
PV
other
11V ≤ U* ≤ 16V, I* ≤ 8.2A
16V < U ≤ 60V, I ≤ 20A
11V ≤ U ≤ 30V, I ≤ 8.2A
30V < U ≤ 60V, I ≤ 20A
DC Input Source Advanced Mode Settings Non-Advanced Mode Settings
/
JUST POWER ON 13
Note:
• Make sure the generator delivers a pure sine wave output with matching voltage
and frequency.
• It's recommended to enable the Grid Self-Adaption mode when charging the
Elite 200 V2 with a generator.
Note: When servicing the devices connected to the unit, remember to unplug
them from the outlets. Even if the AC output is turned off, physically unplugging
the devices is necessary for complete disconnection.
4.3 Power Your Devices
AC Outlets
DC Outlets
Generator Charging
Connect the Elite 200 V2 to a generator using the AC charging cable. The charging stops
automatically when fully charged.
12V / 10A
100W Max. per port
5V / 3A
2,600W Max.
JUST POWER ON14
5.1 Settings Mode
Enter the Mode: Press and hold the AC and DC power buttons simultaneously for about
2 seconds. The frequency icon flashes.
Exit the Mode: Press and hold both the AC and DC power buttons again.
If left idle for 1 minute, the Elite 200 V2 automatically exits without saving any changes.
5. Configure Your Elite 200 V2
Adjust settings in Settings Mode.
• Turn off the AC power before setting the frequency.
• Press the DC power button to navigate through the items, and press the AC
power button to adjust.
Press AC or DC button to switch frequencies, toggle WiFi and Bluetooth, and
activate modes like Power Lifting, Standard and Silent Charging, and ECO.
For advanced settings and features - such as Grid Self-Adaption mode, UPS mode,
setting the maximum grid input current, and detailed ECO mode settings - use
the BLUETTI app. Refer to the app manual for more details.
P01
P03
P04
P05
P06
P07
Frequency
Charging Mode
Power Lifting Mode
ECO Mode
Bluetooth
WiFi
Page Code Setting
JUST POWER ON 15
5.2 Charging Mode
The Elite 200 V2 offers three charging modes: Standard, Turbo, and Silent. Set Standard
and Silent modes directly on the display, and use the app to activate Turbo mode. By
default, the unit charges in Standard mode.
5.3 Power Lifting Mode
Power Lifting mode is disabled by default. It allows Elite 200 V2 to power up to 3,900W
pure resistive loads like kettles, electric blankets, hairdryers, and similar heating devices.
Mode
AC
Input
Solar
Input
AC + Solar
Input
AC Charging Time
(Estimated)
Note
1.6 hrs
3 hrs
80% in 1 hour,
100% in 1.4 hrs
Battery-friendly
Quick recharge
16dB to 30dB
Note:
• To activate the Turbo mode, please contact BLUETTI support for help.
• When Turbo mode is enabled, the maximum grid input current automatically
increases to 15A. In Standard or Silent mode, it reverts to 12A.
• The data above is for reference only. Noise levels were tested at an ambient
temperature of 25°C (77°F) and may vary based on the environment, distance,
and operating power.
Note:
• AC-ECO mode is not available when charging with AC power.
• Press the AC power button to turn on/off AC-ECO and DC-ECO modes together,
and use the BLUETTI app to control them separately.
• Disable the ECO mode when connecting small devices under 60W or critical
appliances such as lights and refrigerators.
Note: This mode is only for pure resistive loads rated 2,600W-3,900W. While the
Elite 200 V2 can handle such loads, its actual output power is still 2,600W.
5.4 ECO Mode
AC-ECO and DC-ECO modes are enabled by default. The Elite 200 V2 shuts off the AC or
DC output after a period of low or no load.
1,440W
Max.
1,800W
Max.
800W
Max.
800W
Max.
1,000W
Max.
1,000W
Max.
800W
Max.
2,400W
Max.
2,400W
Max.
Standard
Turbo
Silent
JUST POWER ON16
• Standard
Elite 200 V2 charges using available solar and grid power, with a priority on solar.
Connect Elite 200 V2 to the wall, and it directly draws power from the outlet to operate
connected devices. It swiftly switches to battery power within 15 ms during an outage.
Set UPS modes in the app.
6. View Device Information
7. UPS Feature
View device information in Setting Mode, too.
• Go to the P01 frequency page and long press the DC power button to view the
unit's SN. Press the DC power button again to navigate through other information.
• When on Fault History page, long press the AC power button for about 2 seconds,
then release to clear the history.
Serial Number (SN)
Error Code
Fault History
Version
Page Code Information
AC Loads
Input power
from grid
Time
Time
Backup
output power
(W)
(W)
JUST POWER ON 17
• Time Control
Save costs by scheduling Elite 200 V2 to charge during off-peak hours and power devices
during peak hours.
• PV Priority
Efficiently uses solar energy. Elite 200 V2 initially charges from the grid to a set SoC and
seamlessly switches to solar replenishment.
AC Loads
Period
Load Power
Charge
Grid
Discharge Discharge Discharge
Elite 200 V2Elite 200 V2 Elite 200 V2
0:00 6:00 12:00 18:00 24:00
AC Loads
SoC
100%
Remain capacity
only from solar
energy
Charging from
utility grid
Battery capacity
0%
JUST POWER ON18
• Custom
Personalize charging/discharging schedule, set battery SoC limits, and control the
schedule and grid input switches.
When charging with an unstable generator or grid power, or if consumption power
exceeds charging power, enable this mode in the app. The Elite 200 V2 automatically
adjusts to handle power fluctuations, protecting the unit and connected devices from
potential issues due to variations in power quality.
8. Grid Self-adaption Mode
Attention: Not for devices like data servers or workstations that require high-performance
UPS. BLUETTI assumes no liability for issues arising from violating this restriction.
Period
Load Power
Charge
Grid
Discharge Discharge Discharge
Elite 200 V2Elite 200 V2 Elite 200 V2
0:00 6:00 12:00 18:00 24:00
AC Loads
Unstable
grid
Unstable
generator
Charging and
discharging
AC Loads
JUST POWER ON 19
The default maximum grid input current is 12A. Use the app to increase it up to 15A.
9. Adjust Grid Input Current
When the battery runs out and the unit shuts down, it saves the ON/OFF status of the
AC and DC power buttons.
• If connected to grid power, the saved settings will automatically restore when the
battery reaches 5%.
• If not connected to grid power, the settings will only restore if the battery reaches 5%
and at least 30 minutes have passed since the unit turned off.
For example, in standard UPS mode, if a refrigerator is plugged into the AC outlet of the
Elite 200 V2 and the grid power goes out, the unit will provide immediate backup power.
If the battery depletes, the unit will shut off but retain the AC output status as ON. When
grid power returns and the battery is above 5%, the unit will automatically turn the AC
output back ON to continue powering the refrigerator.
10. System Switch Recovery
Note:
• For settings above 12A, please contact BLUETTI support for help.
• If the current is set above 12A, the Elite 200 V2 switches to Turbo charging mode.
For settings of 12A or below, it switches to Standard charging mode.
Note:
• During recovery, the AC and DC output settings can be adjusted via the app.
• To restore power immediately, turn off this feature.
JUST POWER ON20
• If the unit's SoC falls below 5%, please recharge the unit in time.
• Before storing, charge to 40%-60% SoC, then power off and disconnect all cables.
• Store it in a cool, dry place, away from flammable materials.
• Safe storage temperature: -10°C to 40°C (14°F to 104°F). For storage over a month, keep
it below 35°C (95°F).
• Fully cycle every 6 months to maintain battery health.
• Avoid extended storage; it may impact performance and lifespan.
If SoC drops to 0 during storage or startup:
• Shut down immediately.
• Charge within 48 hours.
• Keep it at 5°C to 35°C (41°F to 95°F) for 6 hours before charging.
• Recommended to charge via an AC source; if using solar energy, ensure an input of
over 100W.
11. Maintenance and Care
JUST POWER ON 21
12. Specifications
Battery Capacity
Battery Type
Weight
Dimensions (L × W × H)
Charging Temperature
Discharging Temperature
2,073.6Wh (54Ah)
LiFePO
4
24.2kg (53.35lbs)
350 × 250 × 323.6mm (13.78 × 9.84 × 12.74in)
0°C to 40°C (32°F to 104°F)
-20°C to 40°C (-4°F to 104°F)
Model Elite 200 V2
Storage Temperature
Up to 1 month: -10°C to 40°C (14°F to 104°F)
More than 1 month: -10°C to 35°C (14°F to 95°F)
Before storage, keep the unit's SoC between 40% and 60%.
Fully cycle it every 6 months. For transport, keep it at 25°C
(77°F).
Operating Humidity
AC Output
DC Output
Cigarette Lighter Port
2 × USB-A
AC Input
DC Input (XT60PM-M)
AC + DC Input
Uninterruptible Power Supply (UPS)
Switchover Time
Noise
10% to 90%
2,600W in total, 120V, 21.6A, 50Hz / 60Hz
12V / 10A
5V / 3A
1,800W Max. (Charging + Bypass)
1,000W Max., 12V to 60V, 20A Max.
2,400W Max.
≤15 ms
16dB to 50dB
AC Charging
1,800W Max., 120V, 15A Max., 50Hz / 60Hz
(80% in 1 hr, 100% in 1.4 hrs @10°C to 30°C / 50°F to 86°F)
100W Max. per port,
5V / 3A, 9V / 3A, 12V / 3A, 15V / 3A, 20V / 3A, 20V / 5A
2 × USB-C (PD 3.0)
JUST POWER ON22
Error Code Description
Inverter overload
Inverter short circuit
Unit overload
PV overvoltage
PV overtemperature
DC output short circuit
DC output overcurrent
E001
E002
E003
E026
E033
E039
E065
E067
Solution
On the Error Code page, the and error code appears simultaneously on the screen.
See the table below for guidance.
13. Troubleshooting & FAQ
• Check device power usage.
• Reduce load if too high.
• Check device power usage.
• Check devices for short circuits.
• Wait 10 mins for the unit to cool down.
• Turn on the AC output again.
• Check device power usage.
• Check devices for short circuits.
• Check if the AC and DC output is above 2,800W.
• Ensure the PV input voltage is within 12V-60V.
• Wait 10 mins for the unit to cool down.
• Re-enable the PV input.
DC output overtemperature
Charging temperature too high
Charging temperature too low
Discharging temperature too high
Discharging temperature too low
Grid overvoltage
Grid undervoltage
Grid overfrequency
Grid underfrequency
/
E068
E085
E086
E087
E088
E113
E114
E115
E116
Others
• Check device power usage.
• Reduce load if too high.
• Wait 10 mins for the unit to cool down.
• Restart your devices.
• Wait for the unit to cool down before charging
it again.
• Place the unit in an ambient temperature
range of 0°C to 40°C (32°F to 104°F).
• Wait for the unit to cool down before using it
again.
• Place the unit in an ambient temperature
range of -20°C to 40°C (-4°F to 104°F).
• Verify home grid voltage.
• Contact utility company if necessary.
• Verify home grid voltage.
• Contact utility company if necessary.
• Verify home grid frequency.
• Contact utility company if necessary.
• Verify home grid frequency.
• Contact utility company if necessary.
• Contact BLUETTI support for help.
Inverter overtemperature
protection, AC output off
JUST POWER ON 23
FAQ (Frequently Asked Questions)
Q1:
A:
Q2:
A:
Q3:
A:
Q4:
A:
Q5:
A:
Q6:
A:
How do I know whether my devices will work with this product?
Keep the total AC power below 2,600W. Some devices with motors or compressors
may start at 2-4 times their rated power, which could easily overload the Elite 200 V2.
Can I use third-party solar panels to charge this product?
Yes, you can use third-party solar panels with open circuit voltage of 12V-60V and
MC4 connectors. Avoid mixing different types of solar panels.
Can it charge and discharge at the same time?
Yes, the Elite 200 V2 supports pass-through charging.
Why is the charging power often too low?
The built-in BMS adjusts the charging power based on battery temperature and SoC
to protect the battery and extend its life.
How to calculate the operation time?
Operation time = Battery Capacity x DoD x η ÷ (Load + Elite 200 V2 Self-consumption)
Note: DoD (Depth of Discharge) is 90%. η (inverter efficiency) is over 85%. The Elite 200 V2
self-consumption is about 10W.
Why does a warning come up when using a diesel heating pump with the
cigarette lighter port?
The pump may require more initial power to start. Use a compatible adapter to start
and run the pump with our AC outlets.
Appendix
Update Firmware via BLUETTI App
Keeping firmware updated is IMPORTANT for optimal performance. For detailed instructions,
refer to the app user manual in the app.
1. Download the BLUETTI app
Scan the QR code or search for “BLUETTI” in the App
Store or Google Play to download the app.
JUST POWER ON24
2. Log in or sign up
Log in with a BLUETTI account. If there is no
account, create one by following the on-screen
instructions.
3. Bind the unit
• Tap Add Device directly or
access My Devices > Add
Device to start the process.
• Select the unit from the
available device list, or choose
Add Manually and enter the
unit's serial number (SN).
• Alternatively, tap Scan on the
Home page or in Add Device
page to bind via QR code.
4. Connect via Bluetooth
On the My Devices page, tap the unit and
select Bluetooth as the connection method.
JUST POWER ON 25
Use a cable with OT terminals for grounding. Connect one end to the grounding terminal
with a grounding screw and the other end to the wall outlet or home distribution box ground.
Note:
• Ensure the unit remains powered on and connected during the update.
• Keep your phone and the unit close together (recommended range: 5m / 16.4ft).
• Do not exit app until done.
Grounding Guidelines
Only use the grounding terminal when the product is connected to the home grid using
a 2-pin cable, or if the wall outlet's grounding is ineffective, and the connected device
features a metal case.
5. Check for Firmware Updates
Tap Upgrade to access the Upgrade page.
The app will check for the latest firmware version
available for the unit.
6. Download and Install the Update
If a new firmware update is available, tap
Upgrade and follow the on-screen instructions.
JUST POWER ON26
• FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio / TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
IMPORTANT NOTE: FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum
distance of 20cm between the radiator and your body.
Compliance
• IC Caution
This device contains licence-exempt transmitter(s) / receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
JUST POWER ON 27
• Sécurité Information
AVERTISSEMENT -
Quand en utilisant le produit, basique précautions devrait toujours
être suivi, y compris le suivant:
• Lire tous le instructions avant en utilisant le produit.
• Poignée le produit avec se soucier, éviter gouttes, violent impacts, ou basculement.
• À réduire le risque de blessure, fermer surveillance est nécessaire quand le produit est
utilisé près enfants.
• Faire pas mettre des doigts ou étranger objets dans le des produits ports.
• Utiliser de un pièce jointe pas recommandé ou vendu par le fabricant peut résultat
dans un risque de feu, électrique choc, ou blessure à personnes.
• Faire pas se déplacer le produit pendant opération à éviter pauvre Connexions.
• Faire pas exposer le batterie à haut les températures, comme ce peut cause un explosion
ou fuite de inflammable liquides ou des gaz.
• Faire pas utiliser le produit dans le pluie ou haut humidité environnements.
INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS
RF exposure statement: The equipment complies with IC Radiation exposure limits set
forth for uncontrolled environments. This equipment should be installed and operated
with a minimum distance of 20cm between the radiator and your body.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme
aux CNR d’Innovation, Sciences et Développement économique Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions
suivantes:
(1) L' appareil ne doit pas produire de brouillage;
(2) L' appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d' en compromettre le fonctionnement.
Déclaration d'exposition aux RF : L'équipement est conforme aux limites d'exposition
aux rayonnements IC définies pour les environnements non contrôlés. Cet équipement
doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et
votre corps.
CAN ICES-3 (B)/NMB-3(B) (Canada)
This Class B digital apparatus complies with Canadian ICES-003.
JUST POWER ON28
• Faire pas utiliser un batterie paquet ou appareil que est endommagé ou modifié.
Endommagé ou modifié batteries peut exposition imprévisible comportement
résultant dans feu, explosion ou risque de blessure.
• Poignée le produit avec prudence dans faible air pression environnements à prévenir
explosion ou des fuites.
• Charge le produit dans un bien ventilé zone.
• Dans des conditions abusives, du liquide peut être éjecté de la batterie du produit ;
éviter contact. En cas de contact accidentel , rincer à l'eau. Si le liquide entre en contact
avec les yeux, chercher médical aide. Batterie liquide peut cause irritation ou des
brûlures.
• Dans cas de feu, utiliser un sec poudre feu extincteur approprié pour le produit.
• Jamais disposer de le des produits batterie dans feu, chaud les fours, ou par Coupe il.
• Faire pas fonctionner le produit avec un endommagé corde, prise, ou sortir cable.
• À réduire le risque de dommage à le électrique prise et corde, tirer le prise plutôt que le
cordon quand déconnexion le produit.
• Faire pas démonter le produit; prendre il à un qualifié service personne si service ou
réparation est requis. Incorrect remontage peut résultat dans un risque de feu ou
électrique choc.
• Débrancher le produit avant n'importe lequel entretien à prévenir électrique choc.
• AVERTISSEMENT - RISQUE DE EXPLOSIF DES GAZ. Suivre ces instructions et ceux
publié par le fabricant de tout équipement que vous avez l'intention d'utiliser à proxim-
ité du produit pour réduire risque de batterie explosion.
• AVERTISSEMENT - RISQUE DE éLECTRIQUE CHOC. Jamais utiliser le produit à pouvoir
outils à couper ou accéder en direct les pièces, cablages ou matériaux contenant eux, tel
comme batiment des murs.
• Avoir entretien effectué par un qualifié réparation personne en utilisant seulement
identique remplacement les pièces. Ce volonté assurer que le sécurité de le produit est
entretenu.
• Les symboles sur l'appareil et ses accessoires sont destinés à vous rappeler de
lire le instructions dans le littérature accompagnant le produit avant opération et
entretien.
• Le Prise de courant devrait être installée près le produit et facilement accessible pour
sécurité fins.
• Prudence: Le sortir de USB-C port est classifié comme PS3 selon à standard CEI 62368-1.
Envisagez de mettre en oeuvre des mesures de protection contre l'incendie, telles
qu'une enceinte coupe-feu, pour les équipements connectés . ou accessoires.
JUST POWER ON 29
Élimination et Recyclage
1. Apportez les vieux composants électroniques et les piles aux centres de recyclage
désignés. Ce empêche non conforme élimination et les soutiens matériel récupération.
2. Si possible, déchargez complètement les batteries, puis placez-les dans la batterie
désignée boîtes de recyclage. Les piles de ce produit contiennent des produits
chimiques dangereux. Ne pas disposer de eux avec régulier ménage déchets. S'il te plaît
suivre locale lois et règlements pour approprié batterie élimination.
3. Si un batterie ne peut pas pleinement décharge exigible à produit mauvais
fonctionnement, faire pas lieu il dans le boîte de recyclage des piles. Contactez plutôt une
organisation professionnelle de recyclage de batteries pour sûr manutention.
• Quand mise en charge avec plomb-acide batteries ou en utilisant le produit à charge
eux, suivre ces sécurité précautions:
a. Porter oeil et vêtements protection; faire pas touche yeux quand fonctionnement
près un batterie.
b. Non fumeur, des étincelles, ou flammes près le batterie ou moteur.
éviter goutte métal outils sur le batterie à prévenir des étincelles ou court circuits.
Attention
Pas permis sur avion.
Mise à la terre Instructions (Pour CA mise en charge seulement)
• Ce produit doit être mis à la terre lorsqu'il est connecté au réseau. Si ce produit devait
mauvais fonctionnement, mise à la terre fournit un chemin de moins résistance pour
électrique actuel à réduire le risque de électrique choc.
• Le produit est équipé d'un cable de chargement CA doté d'une mise à la terre conducteur
et une fiche de mise à la terre. La fiche doit être branchée dans une prise appropriée
que est correctement installée et fondé dans conformité avec tous locale codes et
ordonnances.
• AVERTISSEMENT - Une mauvaise connexion du conducteur de terre peut entraîner un
risque de choc électrique. Vérifiez auprès d'un électricien qualifié si vous avez des
doutes quant à savoir si le produit est correctement fondé. Ne le faites pas modifier le
prise fourni avec le produit – si ca va pas ajuster le sortie, avoir un approprié sortie
installée par un qualifié électricien.
SAUVEGARDER CES INSTRUCTIONS
JUST POWER ON30
@ BLUETTI Official
@bluetti.inc @bluetti.inc@ bluetti_inc
Need Help? We're here for you!
Visit Us
SHENZHEN POWEROAK NEWENER CO., LTD.
19F, Block A, Kaidaer Bldg., No. 168 Tong Sha Rd, Shenzhen, China
BLUETTI Power Inc.
6185 S Valley View Blvd, Ste D, Las Vegas, NV 89118, US
+1 800-200-2980 (Mon-Sun 9:00-17:00)
service@bluettipower.com
Certificate
Inspector:
QC:
P/N: 17.0303.0811-01A1
