Clean Air, Healthy Life
User Manual
Model: AS200
H13 True HEPA Air Purifier
Specifications
Rated Power
CADR
36W
110+CFM / 187+ m³/h
Package Contents
1 x Airspark AS200 Air Purifier
1 x 4-Stage HEPA Filter (Pre-Installed)
1 x User Manual
Noise Level
23-52dB
General Safety Information
• Only use your air purifier as described in this manual.
• Do not touch the plug with wet hands.
• Do not use without removing the plastic wrap from the filter.
The purifier will not filter air, and may overheat, causing a fire
hazard.
• Do not wash or use filter repeatedly.
• Do not place anything into any opening on the air purifier.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabili-
ties, or lack of experience and knowledge.
• Children should be supervised to ensure that they do not
play with the appliance.
• If the supply cord is damaged, it must be replaced by the
manufacturer.
• Do not place it close or on the top of a heating object (such
as a fireplace, a heater, or places with possible inflammable
glass)
• Do not expose the purifier to extremes of temperature,
humid areas or outdoors.
• Do not sit or place heavy objects on the air purifier.
• Do not use your air purifier if it is damaged or not working
correctly, or if the cord or plug is damaged, or wall socket is
loose. Do not try to repair it yourself.
• Never place the cord near any heat source.
• Please unplug the purifier in case of cleaning or storage. Or
low insulation may cause electric shock or fire due to short
circuit.
• Keep the inside of the air purifier dry. To prevent moisture
buildup, avoid placing in rooms with major temperature
changes or underneath air conditioners.
Getting Started
1) Remove the plastic bag from the filter
1.1. Flip the air purifier over. Twist the filter cover counter-
clockwise and open it.
(Figure 1.1)
1.2. Remove the filter from its plastic packaging.
(Figure 1.2)
2) Re-attach the filter
2.1. Secure the filter on the filter cover.
(Figure 2.1)
2.2. Place the filter back into the purifier. Twist clockwise to
lock.
(Figure 2.2)
Figure 1.1 Figure 2.2Figure 2.1Figure 1.2
Welcome to clean air with Airspark. Enjoy your health and
wellness journey with Airspark air purifier.
7.9x7.9x16.9 in
20x20x43 cm
Temperature: 14°F–104°F / -10°C–40°C
Humidity: < 85% RH
6.6lb / 3kg
AC 120V, 60Hz
Power Supply
Air Purifier Weight
Air Purifier Dimensions
Operating Conditions
About the Filter
1. Activated Carbon Filter
Physically absorbs various odors, such as pet odors, VOCs,
smoke, cooking smell, and fumes.
2. H13 True HEPA Filter
Captures 99.97% of 0.3-micron particles, such as smoke,,
pollen, pet dander and other airborne particles.
3. Enhanced Pollen & Pet Filter
Helps to relieve coughing, sneezing, chronic symptoms caused
by pet hair, pet dander and pollens.
4. Pre-Filter
Captures large particles such as dust, fibers, hair, and pet fur.
Operation of Buttons
On/Off Button
Tap to turn the air purifier on/off.
Fan Speed Button
Tap to Cyclely change fan speeds: 1 (low)
to 4 (high).
Sleep Mode/Led Light Button
Tap once to turn off LED Light.
Tap a second time to Sleep Mode.
Sleep Mode Note:
• All lights will be turned off except at half brightness.
• Sleep Mode operates quietly by using the lowest fan speed.
• Tapping any button will exit Sleep Mode.
Timer Button
Tap Cyclely change timer options: 2/4/8/12
hours.
Check Filter Indicator
Glow red when the filter should be checked.
Press and hold for 3 seconds to reset.
Getting to Know Your Air Purifier
Clean the Air Purifier and Filter
• Before cleaning, the appliance must be disconnected from
the supply mains.
• The outer pre-filter should be cleaned every 2–4 weeks to
increase the efficiency and extend the life of your filter.
• Clean the pre-filter using a soft brush or vacuum hose to
remove hair, dust, and large particles (Figure 3.1).
• Do not clean the filter with water or other liquids.
• Clean the air inlet and outlet with a soft brush (every 1-2
months)
• Clean the product body with dry, soft cloth (every 2~4 weeks)
(Figure 3.2)
• If your Air Purifier will not be used for more than 30 days, we
recommend that you: wrap the air purifier and the filter in
packaging and storing in a dry place.
1
4
5
7
8
9
10
3
2
6
11
1. Power On/Off Button
2. Fan Speed Indicators
3. Fan Speed Adjust
4. Sleep/LED Light Button
5. Timer Indicators.
6. Timer Button
7. Check Filter Indicator
8. Air Outlet
9. LED Light
10. Housing
11. 360° Air Inlet
4
3
2
1
Figure 3.1
Figure 3.2
When Should I Replace the Air Purifier Filter?
Resetting the Check Filter Indicator
A. Reset the Check Filter Indicator when glow red.
1. Replace the air purifier filter.
2. Turn on the air purifier.
3. Press and hold for 3 seconds will turn off when
successfully reset.
B. Reset before lights up.
1. Press and hold for 3 seconds, lights will glow red.
2. Press and hold again for 3 seconds, lights will turn off
when successfully reset.
• The filter should be replaced every 4–6 months. You will
need to replace your filter which depends on how often you
use your air purifier. Using your air purifier in an environ-
ment with relatively high pollution will need to replace the
filter more often, even if is off.
• will glow red as a reminder to check or replace the air
filter. The indicator should turn on within 3–6 months
• You may also need to replace your filter if you notice:
• Increased noise when the air purifier is on.
• Decreased airflow.
• Unusual odors.
• A visibly clogged filter.
Note: Remember to reset after changing the filter.
Replacing the Air Purifier Filter
1. Unplug the air purifier. Flip the air purifier over and remove
the filter cover (see Getting Started).
2. Remove the old filter.
3. Clean out any remaining dust or hair inside the purifier
using a vacuum hose. Do not use water or liquids to clean
the purifier or filter (Figure 3.2).
4. Unwrap the new filter and place it into the housing.
(see Getting Started).
5. Replace the cover. Plug in the air purifier.
6. Press and hold the button for 3 seconds, lights will
turn off when successfully reset.
Warranty Information
Product Name: Airspark H13 True HEPA Air Purifier
Model: AS200
Terms & Policy
• Airspark Corporation warrants all products to be of the
highest quality, service and warranty for 2 years, effective from
the date of purchase to the end of the warranty period. Warranty
lengths may vary between different product categories.
• If you have any questions or concerns about your new
product, please contact our helpful Customer Support Team.
Clean Air, Healthy Life
