MFS-JSQ-22F
Evaporative Humidifier
User's Guide
Thanks for your purchase.
We provide a one-year warranty.
If any quality issues,
replacement or refund is available.
Please feel free to contact us via E-mail:
Precautions
Thank you for purchasing our humidifier MFS-JSQ-22F.
Please read this manual carefully before using
and keep it for future reference.
All pictures shown are for illustration purposes only.
Actual products may vary due to product enhancement.
Safety Guide
Components
Placement
Installation
Water filling&Use of Essential Oil
Control Panel& Remote Control
Maintenance
FAQ
Product Specifications
Warranty
1-2
3
4
5
6
7-8
9
10-11
12
13
Contents
0101
Safety Guide
0101
01010101
Do not disassemble or modify the machine.
Do not subject the machine to strong impacts.
Turn off the machine before moving it.
Do not connect the machine to a socket that exceeds the rated voltage or use an
extension cable, as this may cause fire or electric shock.
If the plug or wire becomes abnormally hot, stop using the machine immediately.
Do not unplug the power plug with wet hands, as this may cause electric shock or injury.
Do not use acidic detergents in the main body, as they may produce toxic gas.
Children should use the machine under adult supervision.
When the machine is not in use for more than 24 hours, please pour out the water from
the water tank and main body to prevent mold or impurities from harming your health.
Before the first use, leave the machine at room temperature for 30 minutes to avoid
damage to the water tank due to sudden temperature changes.
Do not put essential oil into the main body or water tank, as this may cause water
leakage, deformation or failure.
Do not block the outlet or add water to the mist outlet, as this may cause water leakage,
deformation or failure.
Do not block the outlet or add water to the mist outlet, as this may cause water leakage,
deformation or failure.
Keep a safe distance when the humidifier is working, especially if you have a sensitive
respiratory tract.
02
Safety Guide
02
02
Use the machine at normal room temperature, which ranges from 5°C to 40°C.
When the room temperature drops below 0°C, please pour out the water in the water
tank and sink to avoid freezing and damaging the machine.
Note: The above safety guide is for your reference only. Please read the user manual
carefully before using the machine. If you have any questions, please contact customer
service.
Components
03
LED Display
Aroma Box
Main Body
Air Intake
Adapter
Power Connector
Filter
Water Tank
UV Light
Remote Control
Water Level
Window
POWER
UV
HUMIDITY
TIMER
FAN SPEED
SLEEP
Place the humidifier in a horizontal position that is more than 20 cm away from walls,
furniture, household appliances, and other objects.
Do not use the humidifier in the following situations to avoid water leakage, signal
jamming, damage or injury:
In direct sunlight.
On an unstable platform.
In high temperatures, humidity, or dust.
Near the air conditioner, heater, or stove.
Under tables, or on the carpets, bedding,
etc.
Near the radio and other objects that emit
radio waves.
Near mobile phones, computers, and other
precision instruments.
Placement
04
Installation
05
1. Take the main body out of the packaging and remove the remote
control and other accessories from the water tank.
2. Before using the remote control, remove the insulating plasticssheet.
3. Remove the protective bag of the filter.
4. Place the main body on the water tank properly.
5. When not in use for a long time, please clean the filter and the water
tank.
6. Scan the QR code to get using manual.
Water Filling & Use of Essential Oil
06
There are two types of water filling:
Open the cover and
add water from the
top.
②①
Add water from
the water tank.
Aroma oil can be poured into the aroma box,
which is located on the top of the product and
can be opened by turning.
Place a tissue or sponge underneath before
adding essential oil.
Do not put essential oil directly into the water
tank or sink,as it may cause water leakage,
deformation or failure.
Be sure to turn off the power before supplying
water.
Remove the outer bag of the water filter when
using it for the first time.
Add water below 40°C to the water tank.
Do not let the water into the fan to avoid
machine failure.
Do not add mineral water, plasma water, or tap
water that has been left for a long time. If mold
or impurities breed, it may cause health
problems.
①
②
Control Panel& Remote Control
07
Power Button
Humidity Set Indicator
UV Light Indicator
Timer Button
Relative humidity(RH)
Percentage Indicator
Fan Speed Level Indicator
Humidity Set Button
Timer Indicator
Fan Speed Button
Sleep Mode Indicator
TIMER
HUMID
08
The operation of remote control is the same as the control panel.
The display will dim automatically if no operation.
Control Panel& Remote Control
This button turns on the humidifier when pressed. The display will light
up, and the humidifier will start working.
This button allows you to set the humidity level between 40-90%
inincrements of 5%. The humidifier will automatically stop working when
the surrounding humidity reaches the set value. Long press to light up the
UV light.
Press the button to enter sleep mode, and the display will shut off and
humidifier keep working. Long press Fan Speed button on the LED
display to enter sleep mode.
This button lets you set the timer for the humidifier to shut down
automatically after 1-14 hours. Each touch increases the timer by 1 hour.
Press this button to contorl fan speed level. Long press to enter sleep
mode.
Press the button to light up the UV light. Long press Humidity button on
the LED display to enter sleep mode.
Sleep
Timer
Fan Speed
Humidity
UV Light
Power
External
Water Sink& tank
Maintenance
Wash the essential oil tray and filter with clean water arnd leave
it dry before installing back.
Wipe the external humidifier with a clean soft damp cloth or
sponge lower than 40°C to remove dust and dirt.
If the dirt is stubborn, soak the cloth in a neutral detergent before
wiping.
Make sure the main body is completely dry before use.
Clean the water sink and tank 1-2 times a week as water can
cause minerals and organic matter to accumulate, affecting the
function of the humidifier.
Use a soft cloth or brush to clean the internal surfaces of the sink
and tank.
For stubborn dirt, soak the cloth in white vinegar or baking soda
before wiping.
Replace the filter in 3-6 months. (Depending on the hardness of
the water)
09
10
Q： Why doesn't the display light up after turning on the power?
A：It's possible that water has entered the circuit board. Air-dry the main body for one
day. If it still can't be turned on, please contact customer service via email.
Q：Why doesn't the mist come out?
Q：Why is the humidity value not consistent with the room humidity?
A：Ensure the humidity sensor is not blocked or wet. A diffeerence of 5-10 degrees is
within the normal range. If it's not within this range, please contacct customer
service via email.
Q：Why is the fan stop?
FAQ
A：This evaporative humidifier turns dry air into a moist humidifier through a
turbofan engine device. It is forced to diffuse into the air as moist air by mixing
the filter and moisture. Simultaneous air scouring as the air flows through the
filter removes airborne pathogens, dust and particulate matter. Filtration
purification leads to an increase in environmental humidity and cleanliness.
A：When the ambient humidity exceeds the set value, the fan will automatically
stop. Set higher humidity or cancel the humidity setting.
FAQ
Q：Why is there scale in the water tank or filter?
A：Tap water contains minerals that can adhere to objects. Clean the water tank
and filter regularly. Replace the filter 3-6 months.
Q： Why is there interference with the TV remote control signal?
A：Keep the humidifier 1m away from the TV or other objects that ermit radio
waves.
Q： Why is the floor wet or there is water around the humicdifier?
A：The humidity may be too high or the humidifier may be placed ira non-ventilated
place, causing the mist to not fully evaporate.
11
Product Name Evaporative Humidifier
Model Number MFS-JSQ-22F
Operation Mode Low Medium High
Max Mist Output 400ml/h
Adapter Working Voltage AC 100-240V~ 50/60Hz
Product Working Voltage DC 12V
Rated Current 1A
Rated Power
7W
Noise ≤48dB
Product Specifications
12
Size 8.2*8.2*13.7 inches
Net weight 1.7 kg
Basic Function
1-14 Hours Timer
3 Fan Speed Setting
40-90% Humidity Setting
Warranty Period
Our company provides a one-year warranty starting from the date of purchase.
Warranty Requirements
In order to receive warranty service, please follow these steps:
Provide the warranty card and the order number.
Please note that we cannot provide warranty service if you are unable to provide the
above information.
Thank you for choosing our product, and we hope you enjoy using it. If you have any
questions or concerns, please don't hesitate to contact us.
Describe the problems you are experiencing in detail and provide pictures or videos
if possible.
Non-Warranty Policy
The following conditions are not covered by the warranty:
Damage that occurs after the warranty period has expired.
Damage caused by natural disasters or other force majeure events.
Any damage caused by use that does not follow the requirements outlined in the
User Manual.
Failure or damage caused by the forced use of the product.
The user disassembles or repairs the product without authorization.
Send an email to [email protected]
Warranty
If you need to return the product, please make sure that it is intact and that
the packaging boxes and accessories are complete.
13
