Beverage Cooler
MERV115T3AST
USER MANUAL
Warning notices: Before using this product, please read this manual carefully and keep it for future reference.
The design and specifications are subject to change without prior notice for product improvement.
Consult with your dealer or manufacturer for details.
The diagram above is just for reference. Please take the appearance of the actual product as the standard.
01
THANK YOU LETTER
Thank you for choosing Midea! Before using your new Midea product, please read
this manual thoroughly to ensure that you know how to operate the features and
functions that your new appliance offers in a safe way.
CONTENTS
THANK YOU LETTER
------------------------------------------------- 01
SPECIFICATIONS
------------------------------------------------------ 02
PRODUCT OVERVIEW
-----------------------------------------------03
PRODUCT INSTALLATION
------------------------------------------04
OPERATION INSTRUCTIONS
--------------------------------------- 07
CLEANING AND MAINTENANCE
----------------------------------08
TROUBLESHOOTING
-------------------------------------------------09
02
SPECIFICATIONS
Product model MERV115T3AST
Volume 3.3 cu.ft.(93 L)
Rated Voltage 115 V~
Rated Frequency 60 Hz
Rated Current 1.0 A
Refrigerant
R600a
Amount 1.06 oz (30 g)
Product Dimension ( W x D x H) 18.5x17.3x33.3 in(470 x 440 x 845 mm)
03
PRODUCT OVERVIEW
Names of components
1
Light switch
4
Shelf
2
Temperature-control knob
5
Levelling foot
3
Door Handle
ATTENTION
The picture above is only for reference. The actual conguration will depend on the physical
product or statement by the distributor.
04
PRODUCT INSTALLATION
Install Instruction
Finding a suitable location
• This cooler is designed to be free standing only, and should not be recessed or built-
in.
• The cooler should be placed in a well-ventilated indoor place; the ground shall be
at and sturdy .
• Keep away from heat and avoid direct sunlight. Do not place the cooler in moist or
watery places to prevent rust or reduction of insulating effect.
Dimensions and Clearances
• Too small of a distance from adjacent items may result in the degradation of
freezing capability and increased electricity costs. Allow over 100 mm of clearance
from each adjacent wall when installing the appliance.
Providing a proper power supply
• Check your local power source. This cooler requires a
AC 115V, 60 Hz
power
supply.
• Use a receptacle that accepts the grounding prong. The power cord is equipped
with a 3-prong (grounding) plug which mates with a standard 3-prong (grounding)
wall outlet to minimize the possibility of electric shock hazard from this cooler.
CAUTION
The cooler should always be plugged into its own individual electrical outlet which
has a voltage rating that matches the rating plate.
Never unplug your cooler by pulling on the power cord. Always grip the plug rmly
and pull straight out from the outlet.
Start to use
• The cooler shall stay for half an hour before connecting power when it is rstly
started.
• The cooler shall run 2 to 3 hours before loading fresh or frozen foods; the cooler
shall run for more than 4 hours in summer in advance considering that the ambient
temperature is high.
05
Recommended layout for beverage can in the cabinet
• Do not let the beverage can tough the back side of cooler in order to maintain
good air circulation in the cabinet.
• The capacity of beverage can storage is calculated based on the standard size
can 355ml(outline size
Φ
65mm*125mm,12oz) , oversized beverage can may
impact on the number of can storage in the cabinet.
ATTENTION
Due to different temperature zones generated due to air circulation in the beverage cooler,
the upper area’s temperature is higher than the low area.
Tips for energy saving
• The beverage cooler shall be placed in room dry and ventilated. The beverage
cooler can not be put under direct sunlight or next to heat source(such
as radiator, stove, etc.), and a suitable insulation board shall be applied if
necessary.
• Try to shorten opening time of beverage cooler’s door.
• Put beverage into beverage cooler after it has cooled down
Inner row
Top shelf-6 cans
Second shelf-16 cans
Third shelf-16 cans
Middle row
Top shelf-5 cans
Second shelf-5
cans Third shelf-5
cans Base-6 cans
Outer row
Top shelf-11 cans
Second shelf-15
cans Third shelf-15
cans Base-15 cans
Total beverage
can storage-115cans
06
Reversing the door swing
1.
Change the installation location of the upper hinge
(5) of the beverage cabinet, then the opening
direction of the door could be changed at will. Please
follow the following instructions for the change of
the opening direction of the beverage cabinet’s door
(for instance: from right-handed door to left-handed
door): close the glass door of the beverage cabinet,
use a blade to remove the rivet (2) carefully, loose
the mounting cover (3) of the door hinge and three
positioning bolts (4) and remove the upper hinge (5).
2.
Open the door of the beverage cabinet and detach
the glass door of which with tremendous care.
3.
Dismantle the door axle sleeve (6) at lower part of
the glass door, door stopper block screws (8)and
door stopper (7),and x them to left side.
4.
Dismantle the levelling foot (10), positioning bolts
(4) and lower hinge (9), then exchange the parts of
right and left sides and later use the reverse method
to install the levelling foot and positioning bolts.
5.
Put the aforesaid glass door on the lower hinge,
install the door axle sleeve (6) back and x the
upper hinge (5). Align the door with the cabinet and
check the tightness of gasket, and then install all the
ornaments (1) (2).
ATTENTION
The picture above is only for reference. The actual conguration will depend on the physical
product or statement by the distributor.
07
OPERATION INSTRUCTIONS
Control panel
* The actual control panel may differ from model to model.
Temperature Control
The temperature inside the beverage cooler is adjusted by the temperature
control knob.
• “1, 2, 3, 4, 5, 6, OFF” on the knob does not represent a specic temperature
value.The smaller the number, the higher the temperature inside the beverage
cooler; the higher the number, the lower the temperature inside the beverage
cooler.
• “OFF” indicates that the compressor has stopped working.
• The lamp can be adjusted by a light switch.
08
CLEANING AND MAINTENANCE
Stop using the beverage cooler
If the beverage cooler left unused for a long time, please:
1.
Unplug the beverage cooler;
2.
Clean the beverage cooler;
3.
Keep the beverage cooler door open.
Clean the beverage cooler
• Dusts behind the beverage cooler and on the ground shall be timely to improve the
cooling effect and energy saving.
• Check the door gasket regularly to make sure there are no debris.
• Clean the door gasket with a soft cloth dampened with soapy water cleaned or
diluted detergent.
• The interior of the beverage cooler should be cleaned regularly to avoid odor.
• Please turn off the power before cleaning interior, remove all foods, drinks ,shelves,
etc.
• Use a soft cloth or sponge to clean the inside of the beverage cooler, with two
tablespoons of baking soda and a quart of warm water. Then rinse with water and
wipe clean. After cleaning, open the door and let it dry naturally before turning on
the power.
• For areas that are difcult to clean in the beverage cooler (such as narrow
sandwiches, gaps or corners), it is recommended to wipe them regularly with a soft
rag, soft brush, etc. and when necessary, combined with some auxiliary tools (such
as thin sticks) to ensure no contaminants or bacterials accumulation in these areas.
• Do not use soaps, detergents, spray cleaners, etc. to clean the inside of your
beverage cooler as these may create odors or contamination.
• Clean the shelves with a soft cloth dampened with soapy water or diluted detergent.
Then rinse with water and dry with a soft cloth or dry naturally.
• Wipe the outer surface of the beverage cooler with a soft cloth dampened with
soapy water, detergent, etc., and then wipe dry. Do not rub or scratch the surface of
the glass door to prevent the door from being broken or scratched.
• Do not use hard brushes, clean steel balls, wire brushes, abrasives(such as
toothpastes),organic solvents (such as alcohol, acetone, banana oil, etc.), boiling
water, acid or alkaline items, which may damage the beverage cooler surface and
interior. Boiling water and organic solvents such as benzene may deform or damage
plastic parts.
• Do not rinse directly with water or other liquids during cleaning to avoid short
circuits or affect electrical insulation after immersion.
09
TROUBLESHOOTING
The following simple issues can be handled by the user. Please call the after-sale
service department if the issues are not solved.
Problem Possible reason
Not work
• Whether the cooler is plugged and connected to power
• Low voltage
• Failure power or tripping circuit.
Long-time operation
of the compressor
• It is normal that cooler operates for longer time in summer
when the ambient temperature is higher
• Do not put too much beverage s in the cooler at one time;
• Frequent opening of cooler door.
Light not work
• Whether the cooler is connected to power, whether the
indicator light is damaged.
Loud noises
• Whether the oor is at, whether the placement of cooler is
stable;
• Whether the cooler accessories are properly placed.
Over heat on
sidewall
• The cooler enclosure may emit heat during running specially
in summer, this is caused by the radiation of the condenser,
and it is a normal phenomenon.
Surface
condensation
• Condensation: condensation phenomenon will be detected
on the exterior surface and door seals of the cooler when the
ambient humidity is high, this is a normal phenomenon, and
after wiping with towel, turns up the set temperature of the
appliance properly.
Airow sound
Buzz
Clatter
• Refrigerants circulating in the refrigerant lines will produce
eruption of sound and grunts which is normal does not affect
the cooling effect.
• Buzz will be generated by running compressor specially when
starting up or shutting down.
• The solenoid valve or electric switch valve will clatter which is
a normal phenomenon and does not affect the operation.
