Robotic Pool Cleaner
User Manual
Read through the entire manual before running your new
robotic pool cleaner, and keep this manual handy
for your reference.
www.wybotpool.com
E-mail: [email protected]
Facebook: @WybotPool
WYBOTICS CO.,LTD
No.30,Zhongnan 4th Street West Zone,TEDA Tianjin,China
All trade names are registerred trademarks of respective manufacturers listed.
WYBOT C2Pro Vision WYBOT C2Pro
Thank you for choosing WYBOT products, your support means a lot to us. Continu-
ous providing the best solution to free you up from pool cleaning and enjoy your
family time is always our pursuit.
WYBOT Robotic Pool Cleaner is dedicated to serving you high efficiency, low power
consumption, easy operation and thorough pool cleaning work.
Its unique appearance and reliable functions as one-button activation, powerful
suction and scrubbing, fine filtration, smart navigation, remote control, and high
compatibility with various pool shapes and constructions materials assure you a
convenient, intelligent, and optimal pool cleaning.
Feel free to contact us by Email or visit our website with any questions. We are very
glad to hear your advice on our continuous improvement.
Read the manual carefully before you use the cleaner. Your safety is the most
important thing. Please read through and operate the device as per instruc-
tions, WYBOTICS Co., Ltd. is not held liable for any loss or injury caused by
improper use.
Failure to operate the device as per the warnings can result in serious injury,
electrocution or death.
1. Use only the accessories recommended or sold by WYBOTICS Co., Ltd.
2. Use only the original and authorized charger. Avoid charging any other
types of devices with this charger. Improper use may result in overheating
or corrosive liquid leakage from the battery.
3. Power off the robot when doing any maintenance or removing it from the
pool.
4. Ensure the charging port is dry before plugging in the charger end.
5. Make sure the electrical outlet is protected by a ground fault circuit
interrupter (GFCI) and an earth leakage interrupter (ELI).
6. Do not use a cord-damaged charger to avoid any electrical shock.
7. Do not try to use nonauthorized extension cord to connect the charger to
the robot.
8. Never allow children to ride on the cleaner/docking station or play with it
as a toy.
9. Do not allow child to operate or maintain the device or docking station.
10. Do not enter the pool when the robot is working in it.
11. Never expose or charge the device in flammable environments.
12. Only licensed professionals can disassemble the sealed parts of the
robot.
Warning
Safety Instructions
Cautions
Safety Instructions
Failure to operate the device as per the cautions can cause a damage to the
device.
1.
Charge the unit before first use.
2.
Do not over charge the cleaner, which will reduce the battery life.
3.
Charge the cleaner prior to being stored for a long time (over 6 months) to main-
tain an optimal battery life.
4.
Do not operate the cleaner while pool filter is running.
5.
Remember to wash and clean the filter basket and HEPA after each use.
6. Store the cleaner in a cool and ventilated place, away from direct sunshine
or any heat source.
7. Use only the pool cleaner in the following water conditions:
Max 4 mg/L
7.0 - 7.8
41 - 95 ℉ (5 - 35 ℃)
Maximum 5000 PPM
Chlorine
pH
Temperature
NaCl
01
01
02
03
04
04
06
06
07
08
09
11
12
13
13
14
16
16
CONTENTS
01 / WYBOT AT A GLANCE
Product External Overview
Product Internal Overview
Packing List
02 / GET STARTED
Charge your new WYBOT
Setup your new WYBOT
Connect to your App
Choose your cleaning mode
Run your new WYBOT
Dirt hunting mode (special for WYBOT C2Pro Vision)
03 / DO A FILTER CLEANING
04 / DEVICE SPECIFICATION
05 / LIMITED WARRANTY
06 / HOW TO MAINTAIN YOUR DEVICE
07 / FAQ & TROUBLE SHOOTING
08 / CERTIFICATION
09 / WYBOT CUSTOMER CARE
a
b
01 / WYBOT AT A GLANCE
c
d
f
Product External Overview
c
d
e
a
b
g
f
On/off Button
Turn on/ turn off
the device
Handle
Remove and transport
the device with it
Track
Enhance device’s capability
in climbing walls and various
obstacles
Pump
Pump out water through
the window
Charging Port
Connect the charger to
the cleaner
g
LED Indicator
Different light colors to
indicate device status and
current cleaning mode
01
Scrubbing Brush
Knock loose all dirt and roll
them all into the device
h
j
Camera (WYBOT C2PRO Vision)
Vision technology for
high-efficiency cleaning
j
Sonar Sensors
Detect and avoid obstacles
in the pool
e
h
Product Internal Overview
01 / WYBOT AT A GLANCE
Packing List
01 / WYBOT AT A GLANCE
Device x 1
User Manual x 1
Filters x 2
Charger x 1
Quick Start Guide x 1
K
02 03
m
Lid Open Button
Open the cover to take out the filters
m
Water Outlet
Quick release of the water.
k
o
Filter Basket
Store collected dirt and debris,
remember to install it before start
cleaning, and wash it after each use.
n
n
o
Floating Blocks
Ultra-fine Filter
An auxiliary filter to help trap the fine
dirty particles on the floor. Recommend
to use it in ‘turbo floor mode’ only.
Please do not install it when the floor is
heavily soiled, it may influence the
operation of the cleaner.
Charge your new WYBOT
02 / GET STARTED
The device has a lithium-ion rechargeable battery, and you need to charge the
battery before first use and when the battery is low.
Connect your device to a power outlet using the included cable and adaptor.
1. When charging ,you should ensure your device at least 3m (appr. 10ft) away
from the edge of the pool.
2. For reducing fire risk, keep your device and adaptor away from direct
sunshine or water when charging.
3. For your important safety, you need to double check the device is powered
off and the charging port is dry before charging.
4. The best charging environment is temperature at 32℉ -95℉ (0℃ -35℃), RH
at 5%-95%.
Note:
Charge your new WYBOT
02 / GET STARTED
04 05
Fully Charged！
The adaptor has an indicator, Which will display blue light indicating the power
supply status.
The LED indicators on the top of the cleaner turn solid green light when fully
charged.
Below is the indication of the LED lights, you may refer to it to know different device
status.
LED Light Indication
Solid
Flashing
Solid
Flashing
Solid or flashing
Status
Power On
Under working
Connecting to App & Current
cleaning mode
Low battery or under
self-parking in the pool
Fault
Flashing
Solid
Charging in progress
Fully charged
Setup your new WYBOT
02 / GET STARTED
02 / GET STARTED
1. When yellow light flashes, you should charge the device immediately.
2. If red LED light is on, you can find solution from trouble shooting in this manual
or call for service.
Note:
You can download the WYBOT App to your smart mobile device by scanning QR
code below, or from Google Play or App Store.
Connect to your App
iOS
iOS 15.0 or later
Android 8.0 or later
Android
Choose your cleaning mode
You can choose a cleaning mode for your cleaner through the app after connecting
to your App or pressing the ‘on/off button’.
Setup your new WYBOT
06 07
Turn on the device by pressing the on/off button. The LED indicator on the top will
display a solid green to display current battery level and then a solid blue
when the device is on. If the battery level is too low to start cleaning, the LED lights
will show a flashing .
Low battery！
Cleaning Mode
Standard full pool
Floor only
Wall only
Wall then floor (Combo)
Cleaning Coverage
Wall+ Floor+Waterline
Pool floors
Pool walls
Wall *1+ Floor *1
Eco floor
Eco mode, floor cleaning only
Dirt Hunting (Floor cleaning)
(WYBOT C2 Vision only)
Vision-based cleaning path
Icon (Robot)
1. You should modify your cleaning modes when out of pool. The default mode is
Wall then floor
2. If the device restarts, it will automatically enter the cleaning mode you set
last time.
Note:
Turbo floor
Powerful cleaning mode
(floor cleaning only)
Waterline only
Pool waterline
02 / GET STARTED
Run your new WYBOT
1
Hold the handle of the robot, and put it
into the pool vertically.
2
Let it sink down to the floor to empty tra-
pped air inside.
To achieve an optimal cleaning performance, you should ensure the water
depth of the pool is at least 19.5 in (50 cm) high from the top of the device.
Note:
2
08 09
4
02 / GET STARTED
About 20 seconds of self-calibration,
the indicator light will turn to be a flashing
blue. The cleaner is ready to clean.
3
4
The cleaner begins to clean walls, floor
and waterline as default or your set
through App.
Run your new WYBOT
(Special for WYBOT C2Pro Vision)
Dirt hunting mode (floor cleaning only)
If you have chose the dirt hunting cleaning mode through the APP, your cleaner will
start cleaning floor in a high-efficiency cleaning path after entering the pool.
During the cleaning, the camera on the front of the cleaner will automatically detect
and target for the dirt in front when has recognized them.
Detect, and perform
a targeted cleaning!
The robot needs to enrich its recognition of the dirt from the start, and it may turn on
and record its floor dirt types during cleaning. It will reach its best targeted cleaning
performance after one month of cleaning.
Your WYBOT continues enhancing its capability. Please help to update it to have the
best cleaning experience.
1. The camera on the front is protected by a film when out of the factory, please
peel it off if before running the “Dirt-hunting cleaning mode”.
2. The camera on the robot will only be turned on when being underwater.
3. The dirt hunting cleaning mode is performed based on vision, thus the camera
must be kept from any dust or scratch as it may decrease its performance.
Note:
10 11
02 / GET STARTED
Run your new WYBOT
5
The device will automatically move to
stop by the edge of wall when finishing
cleaning or battery low.
6
Insert the included hook into
a pool pole and lift the cleaner out of
the pool.
Take the cleaner out of the pool verti-
cally to drain inside water out quickly.
7
03 / DO A FILTER CLEANING
1
Push the lid open button up to open the
cover.
2
Take out the filter basket and HEPA.
3
Empty all debris and rinse it with clean
water.
4
After rinsing, put the filter basket and
cotton foam into the cleaner and close
the cover.
1. As electric components inside the cleaner, store the cleaner in a cool and
ventilated place, away from direct sunshine or any heat source.
2. Charge the cleaner prior to being stored for a long time (over 6 months) to
maintain an optimal battery life.
Note:
12 13
05 / LIMITED WARRANTY
06 / HOW TO MAINTAIN YOUR DEVICE
You should follow the steps to store your cleaner to maintain good performance.
a) Ensure the device is power off
b) Dry out the cleaner and filter drawer
c) Fully charge the battery
d) Store the cleaner in a cool and ventilated place, away from direct sunshine,
heat source, frost and squeezing with an ambient temperature between 5℃/
41℉ and 45℃ / 113℉.
e) Charge the cleaner every three months to ensure an optimal battery life.
If your device do not work after a long-term low battery life or being off, please
contact after-sale team for help. For your safety, do not try to disassemble it
without authorization.
Note:
04 / DEVICE SPECIFICATION
Model
Pool Size
Min Water Depth
Device Dimension
Weight
Runtime
Charging Time
Power
Charger Input
Charger Output
Battery Capacity
Filtration
Moving Speed
Water Resistance
OTA upgrading
App Connection
WYBOT C2Pro
150m
2
9.8ft (3m)
360(L)*360(W)*240(H) mm
8kg
3 hours (Eco Floor)
3 hours
65W
100-240V, 50-60Hz
25.2V/1.5A
4600mAh
180µm+Ultra-fine filter
10m/min
IPX8
Available
Available
WYBOT C2Pro Vision
150m
2
~180m
2
9.8ft (3m)
360(L)*360(W)*240(H) mm
8kg
3 hours (Eco Floor)
3 hours
65W
100-240V, 50-60Hz
25.2V/1.5A
4600mAh
180µm+Ultra-fine filter
10m/min
IPX8
Available
Available
1. All WYBOT pool cleaners in the market have been inspected and licensed to
be sold as per local laws.
2. The warranty applies only to original buyers, and not valid to resale and any
other kinds of transfer.
3. Any damages to the unit caused by improper use, unauthorized repair or
disassembly are not covered by WYBOTICS Co., Ltd.’s warranty.
4. The order number or record must be presented for any claim or repair within
the warranty period.
Scan the QR code for the warranty policy.
14
07 / FAQ & TROUBLE SHOOTING
Q: What pool shapes and construction materials is the cleaner suitable for?
A: The machine can be applied to rectangle, oval, or irregular shapes of in-ground
swimming pools. Applicable construction materials include PVC, gunite, tile and
other materials. (Slippery materials such as tiles, mosaics, and acrylic may not
work well, and you need to do some modification.)
Q: Will obstacles such as steps, shallow water areas, drains, slopes etc. in the swim-
ming pool affect the running?
A: The machine can climb steps, drains, and shallow water areas. The above obstacl-
es may influence its cleaning path, but will not affect the operation of the machine.
If you encounter the following situations when using the cleaner, you can check
the table and solve them by yourself.
If you can not find a solution from the table, please contact after-sale team.
Note:
No.
1
2
Issues
Device does
not work
A flashing red
light
A flashing red
light
A breathing yel-
low light
Battery low Fully charge the device
and restart
Charger light
flashes
Unable to ch-
arge
Poor contact Re-plug the charger
3
4
5
6
Do not climb walls
Abnormal wall
climbing
only clean part area and cannot
clean the entire pool
Climbing slowly
Sinking down
away from wall
or floating on
the water
Filter basket blo-
cked
Filter basket blo-
cked
Filter basket blo-
cked
front side up when on the floor
Encounter Obst-
acles
Drain height is
over 3cm
The APP cannot be connected
when the device is in the pool
Wrong cleaning
mode
Firmware not la-
test
Connect to the App and
update the firmware
Clean the filter basket
7
8
Do not clean as set cleaning
path
stuck at water drains
Clean the filter basket
Help the machine away
from the obstacle
Device power off
Not available
Unable to connect to the App Restart
Connect the device
on the shore
Connect to the App
and re-choose a suit-
able cleaning mode
Clean the filter basket
Intake air Stick adhesive blocks
(Contact after-sale team
for instruction)
Clean the filter basket
Slippery constru-
ction materials
Stick adhesive blocks
(Contact after-sale team
for instruction)
Too dirty water Clean the filter basket
Possible Causes
A solid red light
Motor protection
Not put the device
into the water or
the pool water is
too shallow
Restart and put it into
the pool immediately.
Be sure the water dep-
th is over 0.5m.
Restart
Impeller is stuck
Suggested Solution
Check the impeller
and clean foreign
Details
15
07 / FAQ & TROUBLE SHOOTING
08 / CERTIFICATION
WYBOT robotic pool cleaners have passed all performance and reliability tests and
also has obtained relevant certifications from the countries in which they are sold.
you can rest assured.
09 / WYBOT CUSTOMER CARE
Due to the need for continuous products improvement, the products in the
manual are subject to the real products, and WYBOTICS Co., Ltd. reserves the
right to update products.
If you encounter any problems during use, please contact after-sale team.
For more details, please contact WYBOTICS website www.wybotpool.com
C
US
CM
Wybot Customer Service:
Email: [email protected]
Facebook: @WybotPool
Tel: 1-866-777-6655
Scan the QR code for the e-Manual.
16
