用户手册
ＢＤＷ－３－０２Ｃ－ＷＨ（ＷＱＰ４－２６０２Ｃ－ＡＵ）
Ｄｅｖａｎｔｉ澳大利亚
６７２０６０３１２９
Please keep it as a refer
in the later days.
BDW-3-02C-WH
or
QUICK USER GUIDE
Please read the corresponding content on the instruction manual for detailed
operating method.
Connected to power supplies
Fix the drain pipe with the back pipe of the machine.The interface
is fitted with clamps and tightened with a screwdriver.
Fix the drain pipe with
suction cups
The connection of the drain pipe: Put end of the drain into a sink or bucket.
Add water into the dishwasher’s tank
Remove the larger residue
Please remove the large residue before placing.
The power supply is 220-240VAC 50 Hz
the specification of the socket is 10 A 250 VAC
There are two ways to add water into the tank:
1
2
Connect inlet hose to the tap;
Open the cap and add water into the dishwasher’s
tank manually
Note: Before adding water , you need to press power
button to turn on the dishwasher
Prompting of the tank that full of water:
When the tank is full of water, the machine will
beep fleetly for 3 seconds.
2
or
2
1
Water Inlet
Drain Pipe
Power cord
Close the door, select the program and start the dishwasher
Open the door, placing the dishes and adding detergent
Placing order by size and from the two sides to the middle. All cutlery
are suggested to be tilted to improve cleaning performance.
The arm will be blocked with the improper placement of the cutlery
and cleaning effect may not be ideal.
Left Right
Should not place the cutlery in the right direction
or may affect the cleaning performance.
Try to leave the dirty face towards the spray arm.
The palce to add the detergent
3
CONTENTS
Please carefully read this manual before using the dishwasher, it will help you
use and maintain the dishwasher properly .
IMPORTANT SAFETY INSTRUCTIONS
5
INSTALLATION INSTRUCTION
26
Installation preparationnce
About Power Connection
Water Connection
Connection of drain hoses
27
28
27
26
29
32
TROUBLESHOOTING TIPS
Before calling for service
Error signals
Technical information
33
GETTING TO KNOW YOUR APPLIANCE
Dishwasher features
Control panel
10
10
11
USING YOUR DISHWASHER
Loading the dishwasher baskets
Filling the dispenser
16
12
12
18
19
19
PROGRAMMING THE DISHWASHER
Wash cycle table
Turning on the appliance
Change the programme
Forget to add a dish?
At the end of the wash cycle
Forced drainage operation
21
20
MAINTENANCE AND CLEANING
Filter system
Caring for the dishwasher
How to keep your dishwasher in shape
22
22
23
18
29
21
25
4
IMPORTANT SAFETY INSTRUCTIONS
WANING
When using your dishwasher , follow the
precautions listed below:
This appliance is intended to be used in household
and similar applications such as:
-staff kitchen areas in shops, offices and other
working environments;
-farm houses;
-by clients in hotels, motels and other residential type
environments;
-bed and breakfast type environments.
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision.(For AS/NZS 2007.1)
This appliance is not intended for use by
persons(including children )with reduced physical,
sensory or mental capabilities, or lack of
5
Earthing instructions
experienceand knowledge,unless they have been
given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
This appliance is for indoor use only, for household
use only.
To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in water or other
liquid.
Please unplug before cleaning and maintaining the
appliance .
Use a soft cloth moisten with mild soap, and then use
a dry cloth to wipe it again.
This appliance must be earthed. In the event of a
malfunction or breakdown, earthing will reduce the
risk of an electric shock by providing a path of least
resistance of electric current. This appliance is
equipped with a cord having an equipment-
earthing conductor and a earthing plug.
The plug must be plugged into an appropriate
outlet that is installed and earth ed in accordance
with all local codes and ordinances.
6
General use
Do not modify the plug provided with the
appliance; If it does not fit the outlet. Have a proper
outlet installed by a qualified electrician.
Improper connection of the equipment-earthing
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly earthed.
Do not abuse, sit on, or stand on the door or dish rack
of the dishwasher.
Do not operate your dishwasher unless all enclosure
panels are properly in place.
Open the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.
Do not place any heavy objects on or stand on the
door when it is open. The appliance could tip forward.
When loading items to be washed:
1) Locate sharp items so that they are not likely to
damage the door seal;
2) Warning: Knives and other utensils with sharp
points must be loaded in the basket with their
points down or placed in a horizontal position.
Check that the detergent powder is empty after
completion of the wash cycle.
7
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent. For plastic items
without mark, check the manufacturer's
recommendations.
Use only detergent additives designed for an
automatic dishwasher.
Never use soap, laundry detergent, or hand washing
detergent in your dishwasher.
Children should be supervised to ensure that they do
not play with the appliance.
The door should not be left open, since this could
increase the risk of tripping.
If the supply cord is damaged, it must be replaced by
the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
During installation, the power supply must not be
excessively or dangerously bent or flattened.
Do not tamper with controls.
The appliance is to be connected to the water mains
using new hose sets and that old hose-sets should
not be reused.
The maximum number of place settings to be
washed is 3.
The maximum permissible inlet water pressure is
1MPa.
The minimum permissible inlet water pressure is
0.04MPa.
8
Disposal
For disposing of package and the
appliance please go to a recycling
center. Therefore cut off the power
supply cable and make the door closing
device unusable.
Cardboard packaging is manufactured from
recycled paper and should be disposed in the waste
paper collection for recycling.
By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences
for the environment and human health, which
could otherwise be caused by inappropriate waste
handling of this product.
For more detailed information about recycling of
this product, please contact your local city office
and your household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted
municipal waste. Collection of such waste
separately for special treatment is necessary.
9
GETTING TO KNOW YOUR APPLIANCE
IMPORTANT:
Before using this dishwasher for the first time and to get the best performance,
read these instructions.
Dishwasher features
Fruit basket Water bottle
10
Cap of water tank
Upper spray arm
Filter
Basket
Tableware basket
The place to
Add detergent
Lower spray arm
Control panel
Power
1
To turn on and off.
Program Button: Press the button to select wash cycles.
2
1
2 4 5
Program
Start/Pause
5
Press this button to start or pause the dishwasher.
11
3
Baby care
4
A special program for washing baby bottles.(Steam adding)
Program end
3
When the program is end, the indicator will be lit.
Rapid
A shorter wash for lightly soiled loads that do not
need drying.
Intensive
For extremely dirty cooking tools and cutlery using, it will
be drying after washing.(Steam adding)
ECO
This is standard program, it is suitable to clean normally
soiled tableware and it is the most efficient program in
terms of its combined energy and water consumption
for that type of tableware.
USING YOUR DISHWASHER
Loading the dishwasher baskets
Recommendation
Consider buying utensils which are identified as dishwasher-proof.
Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further
information from detergent manufacturers.
For particular items, select a program with as low temperature as possible.
To prevent damage, do not take glass and cutlery out of the dishwasher
immediately after the program has ended.
Not suitable for use:
Cutlery with wooden, horn, china or
mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that are
not temperature resistant
Bonded cutlery items or dishes
Pewter or copper items
Crystal glass
Steel items subject to rusting
Wooden items
Items made from synthetic fibres
(For the best performance of the dishwasher, follow these loading guidelines.
Features and appearance of baskets and cutlery baskets may vary from your model.)
Scrape off any large food paritcles. Soften remnants of burnt food in pans. It is not
necessary to rinse the dishes under running water. Place objects in the dishwasher
in following way:
Items such as cups, glasses, pots/pans, etc. are face downwards.
Curved items, or those with recesses, should be loaded at aslant so that water can
run off.
All utensils are stacked securely and can not tip over.
Attention before or after loading the dishwasher baskets
Limited suitability:
Some glasses can become dull
after a large number of washes.
Silver and aluminium have a
tendency to discolour during
washing.
Glazed patterns may fade if
washed frequently.
Suitability of use in the dishwasher
12
Very small items should not be washed in the dishwasher as they could
easily fall out of the basket.
NOTE
Load hollow items such as cups, glasses, pans etc. with the opening facing
downwards so that water cannot collect in the container or a deep base.
Dishes and items of cutlery must not lie inside one another, or cover each other.
To avoid damage to glasses, they must not be touched.
Long bladed knives stored in an upright position are a potential hazard!
13
Long and/or sharp items of cutlery such as carving knives must be positioned
horizontally in the basket.
Please do not overload your dishwasher. This is important for good results and for
reasonable energy consumption.
Loading basket
Position the dishes and cookware so that they will not get moved by the spray of
water.
Dinner Plate
Soup Plate
Dessert Dish
Glass
Cup
Saucer
1
2
3
4
5
6
Item
Number
14
33
33
33
55
55
55
1
1
11
11
22
2222
44
44
44
66
66
66
Loading the cutlery basket
For personal safety and a top quality clean, make sure place the silverware in
the basket as follows:
They do not nest together.
Place silverware with handles-down.
But place knives and other potentially dangerous utensils handles-up.
Folding back the rack shelives
The spikes are used for holding plates and a platter. They can be lowered to
make more room for large items.
raise upwards fold backwards
Knife
Soup spoon
Fork
Dessert spoon
Teaspoon
1
2
3
4
5
Item
Number
11
11
11
22
22
22
33
33
33
44
44
44
55
55
55
15
Only use detergent
specifically for dishwashers.
Never use any other rinse aid and detergents.
This will damage the appliance.
The rinse aid is released during the final rinse to prevent water from forming
droplets on your dishes and utensils, which can leave spots and streaks.
Filling the dispenser
Dishwasher detergent is corrosive!
Keep dishwasher detergent out of
the reach of children.
WANING
Based on their chemical composition, detergents can be split in two basic types:
Conventional, alkaline detergents with caustic components.
Low alkaline concentrated detergents with natural enzymes.
The use of Normal washing program in combination with concentrated detergent
reduces pollution and is good for your dishes.
Detergent tablets of different brands dissolve at different speeds. For this reason
some detergent tablets cannot dissolve and develop their full cleaning power
during short Programs. Therefore please use long programs when using detergent
tablets, to ensure the complete removal of detergent residuals.
Concentrated Detergent
Detergent Tablets
The detergent must be refilled before the start of each wash cycle following the
instructions provided in the Wash Cycle Table. Your dishwasher uses less detergent
then conventional dishwasher. Generally, only one tablespoon of detergent is
needed for a normal wash load. More heavily soiled items need more detergent.
Always add the detergent just before starting the dishwasher, otherwise it could
get damp and will not dissolve properly.
Detergent
16
Adding detergent
The palce to add the detergent
17
PROGRAMMING THE DISHWASHER
Wash cycle table
The table below shows which programs are best for the levels of food residue
on them and how much detergent is needed. It also show various information
about the programs.
18
A shorter wash for lightly
soiled loads and quick wash.
175
29
0.37
0.32
Wash (47 ℃)
Rinse
Rinse (64 ℃)
Drying
Wash (50 )
Rinse
Rinse (60 ℃)
℃
This is standard programme,
it is suitable to clean normally
soiled tableware and it is the
most efficient programme in
terms of its combined energy
and water consumption for
that type of tableware.
Wash(65 ℃)
Rinse
Rinse(70 ℃)
Drying
185
0.46
For heavily soiled items include
pots and pans. With dried on
food.
7 g
7 g
6 g
5
5
(*AS/NZS 2007.1)
Program
Description
Of Cycle
Detergent
Time
(min)
Energy
(kWh)
Water
(L)
Cycle Selection
Information
Rapid
NOTE
AS/NZS 2007.1 :
test in accordance with AS/NZS 2007.1, are as follows:
This program is the test cycle. The information for comparability
The power consumption of off-mode is 0.57W,
left-on mode is 0.74W
Intensive
Wash(69 ℃)
Rinse
Rinse(70 ℃)
Drying
120
0.5
6 g
5
Baby care
Suitable for washing baby bottles
4.9
Turning on the appliance
NOTE
When you press the Start/ Pause to pause during washing, the
dishwasher will mooing every minute unless you press the Start/Pause
button to start.
Change the program
19
A wash cycle can only be changed if it has been running for a short time otherwise,
the detergent may have already been released and the dishwasher may have
already drained the wash water. If this is the case, the dishwasher needs to be reset
and the detergent dispenser must be refilled. To reset the dishwasher, follow the
instructions below:
1. Press the Start/Pause button to pause the washing.
2. Press Program button for more than 3 seconds, the machine will be in stand by
state.
3. Press the program button to select the desired program.
4. Press the Start/Pause button, after 10 seconds, the dishwasher will start.
3 sec
Starting a wash cycle...
Draw out the basket(see the section entitled "Loading the Dishwasher").
Pour in the detergent (see the section“Fill the detergent”).
Insert the plug into the socket. The power supply is 220-240VAC 50 HZ, the
specification of the socket is 10 A 250 VAC.
Press the power button to turn on the appliance.
Connect the inlet hose to the tap, make sure that the water supply is turned on
to full pressure, or add water to the tank manually.
Select a suitable program according to the “Wash cycle table”.
If a program is selected, the response light will be on. Then press the
Start/ Pause button, the dishwasher begins to start.
Forget to add a dish?
A forgotten dish can be added any time before the detergent dispenser opens. If
this is the case, follow the instructions below:
1. Press the Start/Pause button
2. Open the door a little to stop the washing.
3. After the spray arms stop working, you can open the door completely.
4. Add forgotten dishes.
5. Close the door.
6. Press the Start/Pause button, the dishwasher will run.
.
NOTE
If you want to open the door during washing, please press the Start/Pause
button to pause the machine first. And then when you close the door and press
the Start/Pause button, the machine will keep on working after 10 seconds.
If your model has broken remember function, the machine will go on to finish the
selected program after the power cut.
20
Switch Off the Dishwasher
1.Switch off the dishwasher by pressing the ON/OFF button.
2.Turn off the water tap!
Open the door carefully
Hot dishes are sensitive to knocks. The dishes should be allowed to cool down
around 15 minutes before removing from the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing
the dishes. In this way they will be cooler and the drying will be improved.
Unloading the dishwasher
It is normal that the dishwasher is wet inside.
It is dangerous to open the door when washing, because the hot water
may scald you.
WANING
At the end of the Wash Cycle
When the working cycle has finished, the buzzer of dishwasher will sound 8 seconds,
then stop. Turn off the appliance using the ON/OFF button, shut off the water supply
and open the door of the dishwasher. Wait a few minutes before unloading the
dishwasher to avoid scald, the dishes and utensils are still hot and more susceptible
to breakage. They will also dry better.
21
Forced drainage operation
In standby mode, you can press and hold “Program” button + “Baby care” button
for 3 seconds simultaneously to drain the water tank.
MAINTENANCE AND CLEANING
Filter system
Never use the dishwasher without filters!
Make sure the filter is properly assembled.
The performance may be affected and dishes and utensils could become
damaged.
A.Main filter
Food and soil particles trapped in this filter
are pulverized by a special jet on the lower
spray arm and washed down to drain.
B.Fine filter
This filter holds soil and food residues in
the sump area and prevents it from being
deposited on the dishes during wash cycle.
WANING
The filter efficiently
recycled during the cycle.
For best performance and results, the filter assembly must be cleaned regularly.
For this reason, it is a good idea to remove the larger food particles trapping in
the filter after each wash cycle by rinsing the filter and cup under running water.
To remove the filter assembly, pull the cup handle in the upward direction.
removes food particles from the wash water, allowing it to be
Step 1: Contrarotate the filter assembly,
then lift it all up.
Step 2: Lift fine filter up from main filter.
22
NOTE
If do it from step1 to step 2, the filter system will be removed; while if do it
from Step 2 to Step 1, the filter system will be installed.
The entire filter assembly should be cleaned once a week.
Inspect the filters for blocking after every time the dishwasher has been used.
By unscrewing the coarse filter, you can remove the filter system. Remove any food
remnants and clean the filters under running water.
WANING
When cleaning the filters, don't knock on them. Otherwise, the filters could
be contorted and the performance of dishwasher could be decreased.
The control panel can be cleaned by using a lightly dampened cloth. After
cleaning, make sure to dry it thoroughly. For the exterior use a good appliance
polish wax.Never use sharp objects, scouring pads or harsh cleaners on any part of
the dishwasher.
WANING
Caring for the Dishwasher
Never use a spray cleaner to clean the door panel as it may damage
the door lock and electrical components.
Abrasive agents or some paper towel should not be used because of
the risk of scratching or leaving spots on the stainless steel surface.
Cleaning The Door
To clean the edge around the door, you should use only a soft warm, damp cloth.
To avoid penetration of water into the door lock and electrical components, do
not use a spray cleaner of any kind.
23
Protect against freezing
1. Cut off electrical power to the dishwasher.
2. Turn off the water supply and disconnect the water inlet pipe from the
water valve.
3. Drain water from the inlet pipe and water valve (Use a pan to catch the water).
4. Reconnect the water inlet pipe to the water valve.
5. Remove the filter at the bottom of the tub and use a sponge to soak up water
in the sump.
please take frost protection measures on the dishwasher in winter. E fter
washing cycles, please operate as follows.
ach time a
NOTE
If your dishwasher cannot work because of the ice, please contact
authorised service person.
Cleaning the spray arms
The spray arms can be easily removed for periodic cleaning of the nozzles to prevent
possible clogging. Wash them under running water and carefully replace them in
their seats, checking that their rotary movement is in no way impeded.
Grasp the middle of the spray arm, pull it upwards to remove it. Wash the arms
under a jet of running water and replace it carefully to its seat. After reassembly,
check that the spray arms rotate freely. Otherwise, check that they have been
installed correctly.
24
How to keep your dishwasher in shape
After every wash
After every wash, turn off the water supply to the appliance and leave the door
slightly open so that moisture and odours are not trapped inside.
Remove the plug
Before cleaning or performing maintenance, always remove the plug from
the socket.
No solvents or abrasive cleaning
To clean the exterior and rubber parts of the dishwasher,do not use solvents
or abrasive cleaning products.Only use a cloth with warm soapy water.
To remove spots or stains from the surface of the interior, use a cloth
dampened with water an a little vinegar, or a cleaning product made
specifically for dishwashers.
When not in use for a longtime
It is recommend that you run a wash cycle with the dishwasher empty and then
remove the plug from the socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door seals to last longer and
prevent odours from forming within the appliance.
Moving the appliance
If the appliance must be moved, try to keep it in the vertical position. If absolutely
necessary, it can be positioned on its back.
25
INSTALLATION
WANING
Electrical Shock Hazard
Disconnect electrical power before
installing dishwasher.
Failure to do so could result in death or
electrical shock.
The installation of the pipes and electrical equipments should be done by
professionals.
Attention
Installation preparation
The installation position of dishwasher should be near the existing water inlet tap
and drain outlet and power socket.
One side of the cabinet sink should be chosen to facilitate the connection of drain
hoses of the dishwasher.
Positioning the Appliance
Position the appliance in the desired location. The back should rest against the wall
behind it, and the sides, along the adjacent cabinets or wall. The dishwasher is
equipped with water supply and drain hoses that can be positioned to the right or
the left to facilitate proper installation.
26
About Power Connection
Please look at the rating label to know the rating voltage and connect the
dishwasher to the appropriate power supply. Use the required fuse 10 amp, time
delay fuse or circuit breaker recommended and provide separate circuit serving
only this appliance.
Ensure the voltage and frequency of the power being corresponds to those on
the rating plate. Only insert the plug into an electrical socket which is earthed
properly. If the electrical socket to which the appliance must be connected is not
appropriate for the plug , replace the socket, rather than using a adaptors or the
like as they could cause overheating and burns.
Electrical Requirements
Electrical Connection
Ensure that proper earthing exists before use
WANING
For personal safety:
Do not use an extension cord or an adapter plug
with this appliance.
Do not, under any circumstances, cut or remove
the earthing connection from the power cord.
Connect the cold water supply hose to a threaded 3/4(inch)
connector and make sure that it is fastened tightly in place.
If the water pipes are new or have not been used for an
extended period of time, let the water run to make sure that
the water is clear and free of impurities. If this precaution is
not taken, there is a risk that the water inlet can get blocked and damage
the appliance.
Please Note: If the supplied hose cloes not fit your tap, please contact your local
plumbing supply center where adapters are available for purchase.
Water Connection
27
Connection of drain hoses
The connection of the drain pipe: Put end of the drain into a sink or bucket.
If the sink is more than1000 mm higher than the floor, the excess water in hoses
cannot be drained directly into the sink. It will be necessary to drain excess water
from hoses into a bowl or suitable container that is held outside and lower than
the sink.
How to Drain Excess Water From Hoses
Water Outlet
Connect the water drain hose. The drain hose must be correctly fitted to avoid
water leaks. Ensure that the water drain hose is not kinked or squashed.
If you need a drain hose extension, make sure to use a similar drain hose. It must
be no longer than 4 metres, otherwise the cleaning effect of the dishwasher could
be reduced.
Extension Hose
28
or
Fix the drain pipe with suction cups
Fix the drain pipe with the back
pipe of the machine.The interface
is fitted with clamps and tightened
with a screwdriver.
29
Before calling for service
Reviewing the charts on the following pages may save you from calling for service.
Problem Possible Causes What To Do
Dishwasher doesn't
start
Fuse blown, or the
circuit break tripped.
Replace fuse or reset circuit breaker.
Remove any other appliances sharing
the same circuit with the dishwasher.
Power supply is not
turned on.
Make sure the dishwasher is turned
on and the door is closed securely.
Make sure the power cord is
properly plugged into the wall socket.
Check that the water supply is
connected properly and the water
is turned on.
Door of dishwasher
not properly closed.
Make sure to close the door
properly and latch it.
Water not pumped
form dishwasher
Twisted or trapped
drain hose.
Filter clogged.
Kitchen sink clogged.
Check the drain hose.
Check coarse the filter.
Check the kitchen sink to make sure
it is draining well.If the problem is
the kitchen sink that is not draining ,
you may need a plumber rather than
a serviceman for dishwashers.
TROUBLESHOOTING TIPS
Suds in the tub Wrong detergent.
Water inflow abnormal;
Water pressure is low
Use only the dedicated dishwasher
detergent to avoid suds. If suds exist
in the washer. Open the door for
20-
30 minutes to allow the foam to
evaporate. If the foam still exists in
the liner. Add 1.5L of water to the
liner, close the dishwasher door and
run a forced drain to drain it with the
water. Repeat above operation until
the foam is cleared.
Spilled rinse-aid. Always wipe up rinse-aid spills
immediately.
Stained tub interior Detergent with
colourant may
have been used.
Make sure that the detergent has no
colourant.
White film on
inside surface
Hard water minerals. To clean the interior, use a damp
sponge with dishwasher detergent
and wear rubber gloves. Never use
any other cleaner than dishwasher
detergent otherwise, it may cause
foaming or suds.
There are rust
stains on cutlery
The affected items
are not corrosion
resistant.
A program
was not run after
dishwasher salt was
added. Traces of
salt have gotten
into the wash cycle.
Always run a wash program
without any crockery after adding
salt. Do not select the Turbo function
(if present).
The lid of the softer
is loose.
Check the softener lid is secure.
Problem Possible Causes What To Do
Avoid washing items that are not
corrosion resistant in the dishwasher.
Knocking noise in
the dishwasher
A spray arm is
knocking against
an item in a basket
Interrupt the program and
rearrange the items which are
obstructing the spray arm.
Rattling noise in
the dishwasher
Items of crockery
are loose in the
dishwasher.
Interrupt the program and
rearrange the items of crockery.
Knocking noise in
the water pipes
This may be caused
by on-site installation
or the cross-section
of the piping.
This has no influence on the
dishwasher function. If in doubt,
contact a qualified plumber.
The dishes
are not clean
The dishes were not
loaded correctly.
See notes in “Loading & unloading
your dishwasher”.
The program was
not powerful enough.
Select a more intensive program.
30
Not enough detergent
was dispensed.
Use more detergent, or change
your detergent.
Items are blocking
the movement of
the spray arms.
Rearrange the items so that the spray
can rotate freely.
The filter combination
is not clean or is not
correctly fitted in the
base of washcabinet.
This may cause the spray
arm jets to get blocked.
Clean and/or fit the filter correctly.
Clean the spray arm jets.
Cloudiness on
glassware.
Combination of soft
water and too much
detergent.
Use less detergent if you have soft
water and select a shorter cycle to
wash the glassware and to get
them clean.
Problem Possible Causes What To Do
The dishes
are not clean.
White spots
appear on dishes
and glasses.
Add more detergent.
Black or grey
marks on dishes
Aluminium utensils
have rubbed against
dishes
Use a mild abrasive cleaner to
eliminate those marks.
The dishesare
not drying
Hard water area
can cause limescale
deposits.
Improper loading Load the dishwasher as suggested in
the directions.
Dishes are removed
too soon
Do not empty your dishwasher
immediately after washing. Open
the door slightly so that the steam
can come out. Take out the dishes
until the inside temperature is safe
to touch. Unload the lower basket
first to prevent the dropping water
from the upper basket.
Detergent left in
dispenser
Dishes block
detergent dispenser
Re-loading the dishes properly.
31
Problem
The dishesare
not drying
Wrong program has
been selected.
With a short program, the
washing temperature is lower,
decreasing cleaning performance.
Choose a program with a long
washing time.
Use of cutlery with a
low-quality coating.
Water drainage is more difficult with
these items. Cutlery or dishes of this
type are not suitable for washing in
the dishwasher.
Error signals
Signals
Meanings
Possible Causes
Longer inlet time.
Not reaching required
temperature
Heating tube or thermistor anomaly,
it should be repaired by a qualified worker.
A flow meter, drain valve, or pump failure,
it should be repaired by a qualified worker.
Possible Causes What To Do
When some malfunctions come on, the appliance will show a signal to warn you:
Touch button adhesion
Water or other material in the key area
causes it or it should be repaired by a
qualified worker.
Communication anomaly
It should be repaired by a qualified worker.
It should be repaired by a qualified worker.
Overflow. Some element of dishwasher leaks .
Water tank doesn’t get
WANING
If overflow occurs, turn off the main water supply before calling a service.
If there is water in the base pan because of an overfill or small leak,
the water should be removed before restarting the dishwasher.
32
The Baby Care light
flicker fleetly
The Eco and Baby Care
light flicker fleetly
The Intensive
light flicker fleetly
The Rapid and Baby Care
light flicker fleetly
The Rapid, Intensive
and Baby Care
light flicker fleetly
The Rapid and Eco
light flicker fleetly
Steam generator anomaly
The Rapid, Intensive,
Eco and Baby Care
light keep lighting
enough water within
3 minutes
It should be added more water until
listening a quick beep. Then press Start/Pause
button to make sure machine work properly.
Technical information
33
420420
435435
435435
750750
Height
Width
Depth
Voltage connected Load
Water pressure
Power supply
Capacity
435mm
420mm
435mm
see rating label
0.04 - 1.0MPa
see rating label
3 place settings
