FormNo.3394-249RevA
HeatedGripKit
PowerMaxHeavyDutySnowthrowers
ModelNo.131-6460
InstallationInstructions
Installation
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
Description
Qty.
Use
Rivet2
Heatedgrip1
Epoxypacket1
Installthekit.
1.Placetheepoxyalongtheinsideoftheheatedgrip
(Figure1).
Figure1
1.Rivets2.Heatedgrip
2.Slidetheheatedgripontothehandle,liningupthe
holesinthegripwiththeholeinthehandle(Figure1).
3.Securetheheatedgriptothehandleusing2rivets
(Figure1).
4.Connectthewireonthegriptothebottomofthe
buttonontheundersideofthedashboard(Figure2).
Operation
OperatingtheHeatedGrip
FliptheswitchtotheOnpositiontoturnonthehand
warmer.
FliptheswitchtotheOffpositiontoturnoffthehand
warmer.
Figure2
1.On/offswitch3.Offposition
2.Onposition
