Foldable Swing Chair Assembly Instruction
Team
Assembly
Recommended
Trouble shooting:
Missing / Wrong / Broken parts and installation issues
Send email with your question,pic and order NO. to
support@garvee.com
Respond within 24 hours
Issue resolved
1/4
ASSEMBLY INSTRUCTION
B-1
Pic
B-2 (1pc)
B-3
(1pc)
B-4
(1pc)
B-5
Pic
(1pc)
B-6
(1pc)
B-7
(1pc)
B-8 (2pcs)
B-9 (4pcs)
Pic
Wrench M6 (1pc)
Wrench M8 (1pc)
Allen Key M6 (1pc)
Allen Key M8 (1pc)
Washer M6 (28pcs)
Washer M8 (8pcs)
M6x35 Screw(8pcs)
M6x20 Screw(4pcs)
Pic
M6x15 Screw(8pcs)
M8x40 Screw(2pcs)
Nut M6 (8pcs)
Nut M8 (6pcs)
rubber ring (8pcs)
DO NOT tighten any screws before assemble completely .
Step 1
B-2
B-1
Step 2
(Using rubber ring)
B-4
B-6
M6x35 Screw*4
M6x20 Screw*2
(1pc)
Check all the components & screws before assembly.
Do not install in case part is missing,
We will resend within 24 hours.
contact us to get.
Send email with your question to support@garvee.com
2/4
B-10 (1pc)
Step 3
DO NOT tighten any screws before assemble completely .
ASSEMBLY INSTRUCTION
(Using rubber ring)
Step 4
B-3
M6x20 Screw*2
M6x15 Screw*4
Step 5 Step 6
(Using rubber ring)
M6x15 Screw*4
B-5
M6x35 Screw*4
B-8
B-8
Step 7 Step 8
B-9
M8x40 Screw*2
B-9
B-9
B-9
M8 Nut*2
B-7
3/4
IMPORTANT SAFETY INFORMATION
Please carefully read the instructions and caution warnings below before assembling the product.
Following this guide will ensure that you install, use and maintain the product properly.
●
●
●
●
●
●
●
Please keep this installation and user manual/instructions for future reference in case you need
to assemble the product.
Do not assemble if you notice serious damage such as cracks or bends.
During installation, please use work gloves for hand safety.
Please assemble the unit on carpeted floor or the flat cardboard box to avoid scratching the
surface or your floor while assembling on the floor.
To assemble, please use the complimentary installation tools (Allen Wrench). Pay more attention
to the direction of components at each steps.
It is recommended that two people work together to assemble the product.
Please do not tighten the screws up too much, just to 80% before you finish to make the installion
go on successfully.
RETURN POLICY
We believe you will absolutely love your new product. But for some reason you want to return your
item, please contact us within 30 days after receiving and ensure that the product which you want
to return is in a good condition in the original box with all original certificates of purchase, manuals
and accessories attached.
HOW TO MAINTAIN YOUR PRODUCT:
Check the screws of the product are not loose from regular use.
●
●
●
Do not use sharp instruments, rubbing alcohol, corrosive chemicals, or abrasive cleaners to
clean the product.
Do not keep the product in a damp environment for a long period of time. The damp environment
may cause the iron components to rust and the plates to bulge and crack.
How to find us?
Customer Service
Email: [email protected]
