54-05-0157
SERVICE PARTS LIST
BULLETIN NO.
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 31-15-0136 Housing Cap (1)
2 23-66-2545 Switch (1)
3 31-50-0182 Motor Housing (1)
4 22-90-0145 Strain Relief Bushing (1)
5 22-64-0147 Power Cord (1)
6 06-95-5319 #10 x 3/8" Slt. Hex Hd. Ground Screw (1)
7 06-97-3400 #10 Split Ring Lockwasher (1)
8 43-44-0555 Motor Bottom Gasket (1)
9 23-30-0165 Motor (1)
11 42-46-0100 Ball Float (1)
12 31-15-0145 Plastic Cover Lid (1)
13 12-99-8952 Service Nameplate (1)
14 49-90-1830 Cartridge Filter (1)
15 06-95-5391 #10 x 3" Self-Tapping Slt. Hex Hd. Screw (3)
16 06-95-5330 #10 x 3/4" Self-Tapping Slt. Hex Hd. Screw (8)
17 42-68-0410 Buckle (3)
18 06-95-5320 #10 x1/2" Slt. Hex Hd. Screw (3)
19 14-34-0440 Handle Package (2 Handles and 4 Screws) (1)
20 42-51-0385 Tank (1)
21 42-86-0120 Inlet Fitting (1)
22 43-44-0540 Motor Top Gasket (1)
23 44-66-5365 Motor Plate (1)
25 10-20-8950 Warning Label (1)
26 10-20-8955 French/Spanish Label (1)
22-18-0195 Carbon Brush Set (1)
SERIES S8
MILWAUKEE ELECTRIC TOOL CORPORATION
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 3
REVISED BULLETIN
DATE
WIRING INSTRUCTION
Mar. 2001
54-05-0156
8950
8 GALLON WET OR DRY VACUUM CLEANER
STARTING
SERIAL NO.
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
0
00
CATALOG NO.
EXAMPLE:
Component Parts (Small #) Are Included
When Ordering The Assembly (Large #).
«
«
«
«
«=Part number change from
previous service parts list.
