MILWAUKEE ELECTRIC TOOL CORPORATION
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
BULLETIN NO.
SERVICE PARTS LIST
CATALOG NO.
WIRING INSTRUCTION
REVISED BULLETIN
DATE
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
May 2012
8965
EXAMPLE:
Component Parts (Small #) Are Included
When Ordering The Assembly (Large #).
00
0
STARTING
SERIAL NO.
10 GALLON WET/DRY VACUUM CLEANER
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 31-50-0720 Upper Dome Assembly (1)
2 31-50-0730 Lower Dome Assembly (1)
3 23-30-0240 Motor (1)
4 43-44-0850 Upper Motor Gasket (1)
5 --------------- Lower Motor Gasket (1)
6 42-04-3580 Motor Platform (1)
7 06-95-5338 #10x7/8" Thrdcut Hex Hd. Screw (4)
8 43-44-0870 Motor Platform Gasket (1)
9 42-92-0740 Cover (1)
10 43-44-0880 Cover Gasket (1)
11 22-64-0695 Cord Set (1)
12 44-76-0070 Cord Protector (1)
13 23-66-1700 Switch (1)
14 42-46-0160 Float Cage (1)
15 42-46-0170 Float Ball (1)
16 06-95-0060 #6x3/8" Slot Hex Hd. (2)
17 49-90-1820 Foam Filter Sleeve (1)
18 42-51-0420 Can Assembly (1)
19 43-62-1010 Push Handle (1)
20 43-08-0200 Dolly Ring (1)
21 45-94-0140 Swivel Bearing Caster (1)
22 45-94-0285 8 Inch Wheel (2)
23 45-88-5253 Washer (4)
24 06-57-7505 Pal Locknut (2)
25 42-52-0220 Hub Cap (2)
26 45-03-0140 Screen (1)
27 06-95-3320 #8x1" Self Tap. Phillips Truss Head (4)
28 06-95-0223 #8x3/4" Self Tap. Phillips Truss Head (6)
29 49-90-0150 Swivel End Connector (1)
30 49-90-0280 Cloth Filter and Gasket (1)
31 49-90-0090 7 Ft. 1-1/2" Dia. Vacuum Hose (1)
32 43-44-0890 Float Ball Gasket (1)
33 42-68-0620 Filter Ring (1)
34 42-76-0220 Molded Vac Hose Cuff End (1)
35 42-36-1550 Handle Bracket (2)
759-1001
54-05-0605
