Digital Wall Clock User Manual
ThreeDucksDirect@outlook.com
8 in 1 Colors
Model：PH-10
1. Installation -------------------------------------------------- 1
2. First use ------------------------------------------------------ 2
3. Overview ----------------------------------------------------- 3-5
4. Time Set ------------------------------------------------------ 6
5. Alarm Set ----------------------------------------------------- 7-8
6. Temperature / Second display ------------------------------- 8
7. Font Colors, Night light, Screen brightness -------------- 9
8. Countdown, Volume Setting -------------------------------- 10-11
9. Daylight saving time ----------------------------------------- 12
10. Settings with device buttons -------------------------------- 13-14
11. FAQ ---------------------------------------------------------- 15
12. Warranty ---------------------------------------------------- 16
Contents
ThreeDucksDirect@outlook.com
Installation
1. Align the positioning hole to nail the hanging nail to the wall.
2. Hang the clock on the nail.
3. Installation completed
ThreeDucksDirect@outlook.com
1
2 * hanging nails
Power on for the first time
Connect the DC power plug to the back of the alarm clock, and the other end to the
100V-240V home socket. As shown in the following figure:
Start to power on
ThreeDucksDirect@outlook.com
This alarm clock must work with power adapter. We provide lifetime warranty for
every customer. We strongly recommend you to contact us with your order ID to
activate the warranty. You can also visit
www.jall-us.com to activate lifetime
warranty. If missing any accessories, please contact us for replacements.
2
Device Overview
3
ThreeDucksDirect@outlook.com
Device Overview
Alarm
Setting
-
+
Time
Setting
DC
Input
Night
night
4
Remote Control Overview
Alarm 1 setting
Alarm 1 switch
DOWN “ - ”
Time
setting
12H / 24H
Change back light
Sync night light color
with display color
Brightness adjustment
Count down
1-Click count down
Auto DST
Switch Temp / Second
UP “ + ”
Display Font color
Volume adjustment
Count up
Confirm and Next
ThreeDucksDirect@outlook.com
Night light switch
Freeze display color
5
5. Then “Minute” is flashing, press to select value. Press and next.
3. Press to enter the time setting, you will set in sequence for
Hour > Minute > Year > Month > Date
Time Setting (by remote control)
Note: we strongly recommend to set with remote control for the whole setting.
1. Press to select 12-Hour or 24H military mode according to your habits.
2. Press to turn on AUTO DST, it’s for daylight saving time area.
If you don’t need it, just ignore this step.
4. The “Hour” is flashing, press to select value. Press and next.
6. Then “Year” is flashing, press to select value. Press and next.
7. Then “Month” is flashing, press to select value. Press and next.
8. Then “Date” is flashing, press to select value.
Press to finish time setting.
Note: You don’t have to set the day of the week. It’s calculated automatically.
If you find the day is wrong, it’s most likely you’ve set a wrong “YEAR”.
When you turn on Auto DST, time will auto adjust on March and November.
If you don’t need auto DST, please turn if off.
6
Alarm Setting (by remote control)
5. Then select your alarm mode. There’re 3 modes to choose from.
1-7 means alarm works for Monday to Sunday (every day).
1-5 means alarm only works for Monday to Friday.
6-7 means alarm only works for Saturday to Sunday.
Then press to finish alarm setting.
6. You can press to adjust alarm volume from OFF and V01 to V05.
Attention: If you find the alarm turned on unexpectedly and you don’t
need it, please set the volume to “OFF”. Sometimes other home device
remote signal, like TV will influence the clock alarm. However, volume
“OFF” will also take effect with countdown / up function.
ThreeDucksDirect@outlook.com
7
4. Then “Minute” is flashing, press to select value. Press and next.
2. Press to enter alarm setting, you will set in sequence for
Alarm Hour > Minute > Alarm Mode (MON-SUN, MON-FRI, SAT-SUN).
1. Press to activate / inactivate alarm. You will see the icon appears,
that means alarm is activated, while disappears means alarm is inactivated.
3. The “Hour” is flashing, press to select value. Press and next.
How to stop alarm?
1. When the alarm goes off, press any buttons on remote control to
stop the alarm. It will go off the next day.
2. Without any operation, the alarm will ring for 20 minutes and stop
automatically. It will still go off the next day.
Note: If you want to disable the alarm permanently,
press to turn it off so that it won’t go off the next day.
You will see the alarm icon disappear on the screen.
Temperature Unit / Second Display
Press to change temperature from C° to F° and you can also
press it to change from temperature display to second display.
Note: The temperature is detected by the sensor inside the clock. You
can’t set it manually.
ThreeDucksDirect@outlook.com8
Font Displaying Colors & Night Light
1. Press to change digits colors. This clock includes more
than 8 colors mode to choose from. If you want to freeze certain
color, press “Freeze” button to freeze it and unfreeze it..
2. Press to turn ON / OFF the night light at the back.
3. When the light is on, press to adjust the brightness of
the light (range: L01-L10)
4. Press button to change backlight colors C01 to C11.
5. Press to match the screen font color with the backlight color.
9
1. Press to adjust the screen brightness from High -> Low.
2. You can also press auto-dimmer button to auto adjust the
screen brightness. In this mode, the brightness will auto change
according to the environment light, makes it dimmer at night and
brighter at daytime. It shows “ON” and “OFF” to indicate.
Screen Brightness
1. Countdown (00 – 99 minutes)
In the time display screen, press to set countdown time,
Press to set your desired time (range from 00~99MIN).
Press to start counting down. If you want to stop it and return to time
display screen. Just hold for 2s to quit.
2. Count up
In the time display screen, press to start counting up.
If you want to stop it and return to time display screen. Just hold
for 2s to quit.
3. How to stop the bell ringing?
1) Press any buttons to stop it.
2) The bell will ring for 60 seconds and stop automatically.
3) Volume adjustment will take effect for both alarm sound and countdown
sound. If you set volume to “OFF”, it will influence countdown function.
Countdown / up Setting
ThreeDucksDirect@outlook.com
10
One-Click Countdown
Volume Setting
In the time display screen, press to set alarm volume range
from (OFF - V01-V05). If you find the alarm is turned on
unexpectedly and you don’t need it, please set the volume to “OFF”.
Volume adjustment will take effect for both alarm sound and
countdown sound.
11
1. Press button to start One-Click countdown (00 – 99 mins).
This feature is designed to provide users with a quicker way to use the
countdown function (5 mins in default).
2. To modify the one-click countdown time, hold button for 2s to enter
countdown setting menu, press to set your desired countdown time.
At this point, DO NOT press button, but instead press button.
Then the screen will display “SUC”, which means it’s set successfully.
Now, if you press button again, it will start the countdown time you
just set instead of the default 5 minutes.
3. Press any buttons to stop the bell ringing.
Daylight Saving Time
1. Press to turn ON / OFF AUTO DST, it’s for daylight saving time area.
It will automatically adjust displaying time on the 2
nd
Sunday of March and
1
st
Sunday of November. When it’s ON, the screen will show “DST”.
2. If your area doesn’t apply to daylight saving time, please turn DST OFF.
Tips for remote control
Please aim at the product when using the remote control.
12
We recommend users to set by remote control.
For any reasons, if missing remote control, you can set up basic settings
by pressing buttons on the device. However, functions like “Night light”,
“DST”, “Countdown”, “Brightness setting”, “Display Colors”, “Volume”
can only set by remote control.
Settings without remote control
13
Alarm
Setting
-
+
Time
Setting
3. Then do the same for “Hour”, “Minute”, “Year”, “Month” and “Date”.
Time Setting (by device buttons)
Note: we strongly recommend to set with remote control for the whole setting.
1. Press button on the back of device to enter time setting. You will
set in sequence for 12/24H mode > Hour > Minute > Year > Month > Date
2. The “12H / 24H” is flashing, press to select value.
Press to confirm and next.
Note: You don’t have to set the day of the week. It’s calculated automatically.
Auto DST can only set by remote control.
Alarm Setting (by device buttons)
2. Hold button for 2 seconds to enter the alarm setting, you will set in
sequence for Alarm Hour > Minute > Alarm Mode (MON-SUN,
MON -FRI , SAT-SUN). Press button to confirm and next.
1. Press to activate / inactivate alarm. You will see the icon appears,
that means alarm is activated, while disappears means alarm #1 is inactivated.
3. After setting Hour, Minute, you will need to choose alarm mode:
1-7 = Monday to Sunday, 1-5 = Monday to Friday, 6-7 = Saturday to Sunday
14
FAQ
Q1: The day of the week is wrong.
This section summarizes the most common issues you may have. If you’re unable to
solve the issue, please feel free to contact ThreeDucksDirect@outlook.com
.
The day of the week is calculated automatically. Please check if the “Year”,
“Month”, “Date” are set correctly. Many customers may have set a wrong “Year”.
Please press “Time Set” button to enter time setting, pay attention to something like
“2024” or “2025”. That’s the year value, you have to set a correct year so that the
day of the week will calculate correctly.
The temperature is detected by the inside sensor. The inside circuit may produce
heat, making it not so accurate as professional thermometer. It’s normal. We need
your understanding, after all this is not a professional device as thermometer.
Q3: The temperature is inaccurate
The remote control is powered by CR2032 battery. If it doesn’t work, it may be run
out of battery. Please try to replace CR2032 battery.
Q4: The remote control doesn’t work.
Sometimes other home device remote signal, like TV will influence the clock alarm.
If you find the alarm turned on unexpectedly, please press the “Volume” button to
set the volume “OFF”. In this case, countdown sound will also be “OFF”.
Q2: The alarm goes off unexpectedly. How can I turn it off permanently?
15
We provide lifetime warranty to every customer.
Contact us to activate your lifetime warranty Now!
Don’t forget to include your order ID when contact.
FAQ
Email
Visit
ThreeDucksDirect@outlook.com
www.jall-us.com
Missing any accessories or any questions during usage, please contact us.
Q5: The remote control is not sensitive.
The sensor is in the front of the device. When you press the remote control, please
point directly to the front of the device.
Q6: The alarm doesn’t go off at preset time.
Please check if your alarm mode is set to 1-5 (Monday to Friday). In this mode, it
won’t go off on Saturday and Sunday.
Warranty
16
