1.5L AUXILIARY FUEL TANK
MODEL NO: VS666
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! DO NOT SMOKE OR USE A NAKED FLAME WHILE USING THIS ITEM. BE AWARE THAT PETROL VAPOUR IS
HEAVIER THAN AIR AND FORMS AN EXPLOSIVE MIXTURE.
WARNING! Ensure Health & Safety, local authority and general practice regulations are adhered to when using this equipment.
WARNING! Always wear approved eye protection and appropriate protective clothing including gloves.
8 DO NOT use to store fuel.
8 DO NOT use the tank for any other purpose than that for which is designed.
9 Ensure that the working area is well ventilated.
9 Refer to manufacturers data before working on the fuel system.
9 Check that the hose clips are tight before use.
9 Check the condition of the hose before use.
9 Ensurethatthehosedeliveryvalveisclosedbeforelling.
9 Fill with the minimum amount of petrol necessary for each engine test.
9 Ensure that the cap is secure.
9 Check the unit for leaks before use.
9 Any fuel spillage should be cleaned up immediately to avoid the risk of accidental ignition.
9 If fuel leakage is noticed at any time, abort the engine test, close the delivery valve and remove the tank to an open area.
9 Afteruse,drainthetankofpetrolintoanapprovedcontainer.Leavethecapoandthevalveopentoallowanyfuelresidueinthe
portable fuel tank to evaporate.
9 When dry and clear of vapour: store in a cool, dry, childproof location.
9 Familiariseyourselfwiththeextractorsapplicationandlimitations,aswellasthespecicpotentialhazardspeculiartothisproduct.
9 Maintain the extractor in good condition.
9 Replace or repair damaged parts. Use genuine parts only. Non authorised parts will invalidate the warranty.
9 Ensure safety eye protection and protective clothing are worn when using this product.
9 Keep the work area clean, uncluttered and ensure there is adequate lighting.
9 Maintaincorrectbalanceandfooting.Ensuretheoorisnotslipperyandwearnonslipshoes.
9 Keep children and unauthorised persons away from the working area.
9 Dispose of waste liquids in accordance with local authority regulations.
8 DO NOTstoreuidsinthecontainer.Onceusedtoextractuid,itmustbeemptiedintoanapprovedreceptacleassoonaspossible.
8 DO NOT dismantle, tamper or adapt the extractor for any purpose other than for which it is designed.
8 DO NOT use the unit if it has been dropped or mishandled, check the unit to ensure there is no damage.
8 DO NOTusetostoreanyuids,ensureunitiscleanedaftereveryuse,especiallywhenfuelhaspassedthroughthepump.Washthrough
with a mild detergent and water by drawing the detergent through the pump to remove all pumped liquid.
9 Keep the extractor clean and store in a safe dry location. DO NOT store in areas of high temperature, direct sunlight, rain or snow.
2. CONTENTS
2.1. Refer to parts list for contents.
VS666 Issue 1 21/05/25
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
Wear eye
protection
Wear protective
gloves
Wear safety
footwear
Wear protective
clothing
Highly
flammable
3. INTRODUCTION
Large 1.5L tank, that gives enough runtime to perform diagnostics. Fuel delivery and return pipe that connects to the low-pressure
side of the fuel system. Making it ideal for bypassing the fuel tank when fuel contamination is suspected. Supplied with 10 fuel line
connectors, ensuring the VS666 is compatible with most petrol and diesel passenger and light commercial vehicles. It can also be
used for motorcycle maintenance eliminating the need to balance the fuel tank in an awkward positions.
4. SPECIFICATION
5. OPERATION
Securelyattachthecorrectadaptortothelow-pressurecircuitandensurethetankisrmlyinplaceduringuse.Afterward,cleanit
thoroughly with warm soapy water, then allow it to dry completely before using again.
6. MAINTENANCE
6.1. Ensure unit is empty and cleaned by passing a mild detergent and water through it after every use and allowing to dry before
storage. Dispose of detergent in accordance with local authority regulations.
VS666 Issue 1 21/05/25
Original Language Version© Jack Sealey Limited
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 24 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved
containers and dispose of the product and fluids according to local regulations.
REGISTER YOUR
PURCHASE HERE
Model No VS666
TankSize 1.5L
Supply/Return Hose Length 1m
Nett Weight 0.3kg
