400L/50L PORTABLE COMBI FUEL TANK
MODEL NO: D440T
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! This tank must ONLY be used for diesel fuel and AdBlue®.
9 Placethetankonaatsurfacebeforelling.
9 Securethetanktostrongpointswithratchetstrapsbeforetransportinginoronavehicle.
9 Maintainthepumpingoodcondition(useanauthorisedserviceagent).
9 Replaceorrepairdamagedparts.Userecommendedpartsonly.Nonauthorisedpartsmaybedangerousandwillinvalidatethe
warranty.
9 Keepthepumpcleanforbestandsafestperformance.
9 Ensurethepowersupply(vehiclebattery)correspondswiththerequirementsofthepump(12VDC).
9 Disconnectfrombatterywhennotinuse.
9 Wearprotectivegloves,andprotectiveclothingwhenworkingaroundfuel.Afullrangeofpersonalsafetyequipmentisavailablefrom
yourlocalSealeyStockist.
9 Keepchildrenandunauthorisedpersonsawayfromtheworkingarea.
8 DO NOTplacethetanknearanyheatsource.
8 DO NOTstartorstopthepumpbyconnectingordisconnectingthebatteryclamps.
8 DO NOTallowtheunittogetwet.
8 DO NOToperatethepumpwithwethands.
8 DO NOTusethepumpwhereexplosiveorammablevapoursmaybepresent.
8 DO NOTtamperwiththepumpconnections.
2. INTRODUCTION
Manufacturedfromhard-wearinganddurablepolyethylene.Main400Lcapacitytanksuitablefordiesel,suppliedwitha
12V,40L/minpumpkitandautomaticshut-o󰀨nozzle.Aremovable50LtankforAdBlue®,suppliedwitha12V,17L/minpumpkitand
manualnozzle.Includes2x4mdeliveryhoses,2xdispensernozzleholders,2x4mofcableandclampstoconnecttoabattery.
Coveredbyalockablelid.Notsuitableforpetrol.CompliestoADR1.1.3.1.CforexemptionfromrequirementsofADRregulations.
3. SPECIFICATION
MODEL NO: .......................................................D440T
Capacity: ............................... Diesel400L/AdBlue®50L
Current: ............. DieselPump;15A,AdBluePump®;6A
FlowRate: ...............Diesel;40L/min,AdBlue®;17L/min
Power: ..............................Diesel;180W,AdBlue®;72W
Size(WxDxH):...........................1130x780x830mm
Voltage: ....................................................................12V
4. OPERATION
4.1. TRANSPORT
4.1.1. Movetheemptytankassemblywithtwopersonsusingthe
handholdsmouldedintothebaseoftheunit(g.1.1).
4.1.2. Movewithaforklifttruckusingtheforklocationsshownin
(g.1.2).Ensurethattheller(g.2.4)isclosedbefore
moving.
4.1.3. Securethetanktothecarryingvehiclebyratchetstraps.
Locationsforthestrapsaremouldedintothetank.(g.1.3).
4.2. FILLING
8 DO NOTrunthepumpwithoutfuelinthetank.Todosowill
damagethepump’sinternalcomponentsandwillvoidyour
warranty.
4.2.1. Thetankislledbyunscrewingtheller(g.2.4)inand
anticlockwisedirection.Retthellercapimmediatelyafterlling.
WARNING!Takecarenottooverllthetank.
g.1
D440TIssue3(3)30/01/24
Original Language Version
©JackSealeyLimited
Refer to
instructions
Weareye
protection
Wearprotective
gloves
Wearsafety
footwear
Wearprotective
clothing
background
4.3. FUEL DISPENSING
4.3.1. Beforeconnectingtoabattery,makesurethepump
switch(g.2.5)isinthe“o󰀨”(O)position.Connectthe
batteryclipstothe12Vbattery,observingcorrectpolarity
(redclampto+terminal,blackclampto–terminal).
4.3.2. Switchthepumpswitchtothe‘on’(I)position.
4.3.3. Unwindsu󰀩cienthoseandplacethenozzle(g.2.6)in
thereceivingtankandpullthetriggeropen.DO NOT
leavethenozzleunattendedwiththetriggerlatchedopen.
4.3.4. Thetriggercanbelockedinoneofthreepositionsby
engagingthelatchtoholdthetriggeropen.
8 DO NOTleavethenozzleunattendedwiththetrigger
latchedopen.
4.3.5. Slightpressureonthetriggerwillreleasethelatch.
4.3.6. Whenthelevelinthereceivingtankreachesthenozzle,
deliverywillstopautomatically.
4.3.7. Whendeliveryiscomplete,switcho󰀨thepump.Ensure
thehoseiswoundintoitshousingonthetankandthat
thenozzleissecuredinitsstorageplace.
8 DO NOToperatethepumpcontinuouslyformorethan
30minutes.Thedutycycleoftheunitis30minutes,after
whichthemotormustbelefttocooldownforafurther
30minutes.
8 DO NOTruntheunitformorethan2-3minuteswiththedeliverynozzleclosed.
5. MAINTENANCE
WARNING!Alwaysdisconnectfromthebatterybeforeperforminganymaintenance.
5.1. Thepumpcontainsnouser-servicableparts.Repairsshouldonlybeundertakenbycompetentpersons.
5.2. Checktheintegrityofallthehoseconnectionsperiodically.Ifanyleakageisevident,stripthejointandwindPTFEtapearoundthe
male thread.
5.3. Checktheelectricalconnectionsandcablesforwearanddamage.Rectifyanyfaultsfound.
5.4. Keepclean,especiallythedispensernozzle.
5.5. Cleanwithadamp,soapycloth.
8 DO NOTuseabrasiveorsolventcleaners.
g.2
WEEE REGULATIONS
DisposeofthisproductattheendofitsworkinglifeincompliancewiththeEUDirectiveonWasteElectricalandElectronicEquipment
(WEEE).Whentheproductisnolongerrequired,itmustbedisposedofinanenvironmentallyprotectiveway.Contactyourlocalsolid
wasteauthorityforrecyclinginformation.
D440TIssue3(3)30/01/24
Original Language Version
©JackSealeyLimited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specicationsandcomponentpartswithoutpriornotice.
Important:NoLiabilityisacceptedforincorrectuseofthisproduct.
Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.
ENVIRONMENT PROTECTION
Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbe
sorted,takentoarecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.When
theproductbecomescompletelyunserviceableandrequiresdisposal,drainanyuids(ifapplicable)intoapproved
containersanddisposeoftheproductanduidsaccordingtolocalregulations.
