WYBOT S2 Vision
Robotic Pool Cleaner
User Manual
Read through the entire manual before running your new
robotic pool cleaner, and keep this manual handy
for your reference.
Copyright© 2024 WYBOTICS Co., Ltd. All Rights Reserved.
www.wybotpool.com
Email: [email protected]
Facebook: @WybotPool
WYBOTICS CO.,LTD
No.30, Zhongnan 4th Street West Zone, TEDA Tianjin, China
All trade names are registered trademarks of respective manufacturers listed.
Thank you for choosing WYBOT products, your support means a lot to us. Continu-
ous providing the best solution to free you up from pool cleaning and enjoy your
family time is always our pursuit.
WYBOT Robotic Pool Cleaner is dedicated to serving you high efficiency, low power
consumption, easy operation and thorough pool cleaning work.
Its unique appearance and reliable functions as one-button activation, powerful
suction and scrubbing, fine filtration, smart navigation, remote control, and high
compatibility with various pool shapes and constructions materials assure you a
convenient, intelligent, and optimal pool cleaning.
Feel free to contact us by Email or visit our website with any questions. We are very
glad to hear your advice on our continuous improvement.
01
01
02
02
03
03
04
05
05
06
06
09
10
10
11
11
13
13
CONTENTS
Caution
Failure to operate the device as per the cautions can cause a damage to the device
or personal injury.
1. Charge the unit before first use.
2. Do not over charge the cleaner, which will reduce the battery life.
3. Ensure the camera on the front of the cleaner is free from any dirt, it may
decrease its vision performance.
4. Charge the cleaner prior to being stored for a long time (over 6 months) to main-
tain an optimal battery life.
5 Do not operate the cleaner while pool filter is running.
6. Remember to wash and clean the filter basket and cotton foam after each use.
7. Store the cleaner in a cool and ventilated place, away from direct sunshine or
any heat source.
8. Use only the pool cleaner in the following water conditions:
Chlorine
pH
Temperature
NaCl
Max 4 mg/L
7.0 - 7.8
41 - 95 ℉ (5 - 35 ℃)
Maximum 5000 PPM
Read the manual carefully before you use the cleaner. Your safety is the most
important thing. Please read through and operate the device as per instructions,
WYBOTICS Co., Ltd. is not held liable for any loss or injury caused by improper use.
Warning
Failure to operate the device as per the warnings can result in serious injury,
electrocution or death.
1. Use only the accessories recommended or sold by WYBOTICS Co., Ltd.
2. Dry the charging port after each cleaning. Wet charging port may cause an
electric shock.
3. Do not charge the cleaner when it is running (the indicator is on).
4. Use only the original and authorized power charger. Avoid charging any other
devices with this charger. Improper use may result in overheating or corrosive
liquid leakage from the battery.
5. Make sure the electrical outlet is protected by a ground fault circuit interrupter
(GFCI) and an earth leakage interrupter (ELI).
6. Do not use a cord-damaged charger to avoid any electric shock.
7. Do not try to use extension cord to connect the charger.
8. Never allow children to ride on the cleaner or play with it as a toy.
9. Do not allow child to operate or maintain the device.
10. Do not enter the pool when the cleaner is working in it.
11. Never expose or charge the device in flammable environments.
12. Only licensed professionals can disassemble the sealed parts of the cleaner.
WYBOT S2 VISION AT A GLANCE
Product External Overview
Product Internal Overview
Packing List
GET STARTED
Charge your new WYBOT S2 Vision
Setup your new WYBOT S2 Vision
Connect to your App
Choose your cleaning mode
Dirt hunting cleaning mode (floor cleaning only)
Run your new WYBOT S2 Vision
DO A FILTER CLEANING
DEVICE SPECIFICATION
LIMITED WARRANTY
HOW TO MAINTAIN YOUR DEVICE
FAQ & TROUBLE SHOOTING
CERTIFICATION
WYBOT CUSTOMER CARE
01
02
WYBOT S2 VISION AT A GLANCE
Handle
Remove and transport the device with it
Camera
Starts working when running Vision Mode
LED Indicator
Different light colors to indicate device status
on/off Button
Turn on/ turn off the device
f
a
b
c
d
Pump
pump out water through the window
Charging Port
Connect the charger
Track
Enhance device’s capability in climbing walls
and various obstacles
Scrubbing Brush
Knock loose all dirt and roll them all into the
device
e
f
g
Product External Overview
Product Internal Overview
Do not operate the device when the top cover or scrubbing brushes are broken.
If there is any liquid leakage from the sealed part, stop charging or running
the device.
Lid Open Button
Open the cover to take out the filter basket
i
h
i
k
j
m
Filter Basket (180µm)
Store collected dirt and debris, need to be installed
before cleaning, and washed after each use.
Sealed Part
Important components are sealed there.
For your safety, do not try to disassemble it
without authorization.
j
k
Filter Foam (Cotton foam)
An auxiliary filter to help trap the fine dirty
particles. Recommend to use it for floor
cleaning.
Please do not install it when the pool
water is heavily soiled, it may influence the
operation of the cleaner.
m
e
g
f
c
d
a
b
h
Packing List
Device x 1
User Manual x 1
Filter x 2
Charger x 1Quick Start Guide x 1
Floating Parts
Hook x 1
03
04
The device has a lithium-ion rechargeable battery, and you need to charge the batte-
ry before first use and when the battery is low.
Connect your device to a power outlet using the included cable and adaptor.
GET STARTED
Charge your new WYBOT S2 Vision
Setup your new WYBOT S2 Vision
Below is the indication of the LED lights, you may refer to it to know different device
status.
Turn on the device by pressing the on/off button. The LED indicator on the front will
display a solid green to display current battery level and then a solid blue when
the device is on. If the battery level is too low to start cleaning, the LED lights will
show a flashing
Fully Charged！
The adaptor has an indicator, Which will display blue light indicating the power
supply status.
The LED indicators in the front of the cleaner turn solid green light one by one when
charging, and all LED lights turn when fully charged.
Below is the indication of the LED lights, you may refer it to know different device
status.
LED Light Indication
Solid
Flashing
Solid
Flashing
Solid or flashing
Status
Power On
Under working
Connecting to App
Low battery/under
self-parking in the pool/
Running Vision mode
Fault
Flashing
Solid
Charging in progress
Fully charged
Battery Level (%)
0~20
20-40
Quantity
40-60
60-80
80-100
Note:
1. When charging ,you should ensure your device at least 3m (appr. 10ft) away from
the edge of the pool.
2. For reducing fire risk, keep your device and adaptor away from direct
sunshine or water when charging.
3. For your important safety, you need to double check the device is powered off
and the charging port is dry before charging.
4. The best charging environment is temperature at 32℉ -95℉ (0℃ -35℃), RH at
5%-95%.
Low battery！
05 06
Note:
You can download the WYBOT App to your smart mobile device by scanning QR code
below, or from Google Play or App Store.
Connect to your App
Note:
1. When yellow lights flash,you should charge the device immediately.
2. If red LED lights on, you can find solution from trouble shooting in this manual
or call for service.
iOS Android
iOS 15.0 or later Android 8.0 or later
1. There are more cleaning mode options in the app, and you can refer to it below.
2. You should modify your cleaning modes via App when out of pool.
3. If the device restarts, it will automatically enter the cleaning mode you set
last time.
You can choose a cleaning mode for your cleaner on the device or through the app
after connecting to your App.
Choose your cleaning mode
Mode
Cleaning Coverage
Standard Full Pool
Floor Only
Wall Only
Waterline
Wall then floor (Combo)
Eco floor
Turbo Floor
Wall+ Floor+Waterline
Pool Floors
Pool Walls
Pool Waterline
Wall *1+ Floor *1
Eco mode, floor cleaning only
Strong cleaning, floor cleaning only
Select a mode by
pressing the on/off button
Indication
Icon
Wall*1 then floor*1 (default)
There are two types of full-pool cleaning in the app, you can customize this icon there.
Pool floor cleaning
There are three types of floor cleaning in the app, you can customize this icon there.
Pool walls cleaning
Waterline cleaning
Dirt hunting
Vision-based cleaning mode
Dirt hunting (floor)
Vision-based floor cleaning only
Dirt hunting cleaning mode (floor cleaning only)
After setting up the dirt hunting cleaning mode through the APP or the on/off button,
your cleaner will start cleaning floor in a v-cleaning path after entering the pool.
During the regular cleaning, the camera on the front of the cleaner will automatically
detect and target for the dirt in front when has recognized them.
Detect, and perform
a targeted cleaning!
The camera on the front is protected by a sticker when out of the factory, please
peel it off if before running the “Dirt-hunting cleaning mode”.
The robot needs to enrich its recognition of the dirt from the start, and it may
turn on and record its floor dirt types during cleaning. It may reach its regular
targeted cleaning performance after one month of cleaning.
Your robot will continue to enhance its capability. Please help to update it to
have the best cleaning experience.
Run your new WYBOT S2 Vision
07 08
Note:
To achieve an optimal cleaning performance, you should ensure the water depth
of the pool is at least 19.5 in (50 cm) high from the top of the device.
2
1
Hold the handle of thecleaner, and put it
into the pool vertically.
Let it sink down to the floor to empty tra-
pped air inside.
You should take the cleaner out verti-
cally to drain inside water out quickly.
5
The device will automatically move to
stop by the edge of wall when finishing
cleaning or battery low.
You can insert the included hook into
a pool pole and lift the cleaner out of
the pool.
6
4
3
About 20 seconds of self-calibration,
the indicator light will turn to be a flashing
blue. The cleaner is ready to clean.
The cleaner begins to clean walls, floor
and waterline as default or your set
through App.
7
MODE
Note:
1. The camera on the robot will only be turned on when being underwater.
2. The dirt hunting cleaning mode is performed based on vision, thus the camera
must be kept from any dust or scratch as it may decrease its performance.
09
1. All WYBOT pool cleaners in the market have been inspected and licensed to
be sold as per local laws.
2. The warranty applies only to original buyers, and not valid to resale and any
other kinds of transfer.
3. Any damages to the unit caused by improper use, unauthorized repair or
disassembly are not covered by WYBOTICS Co., Ltd.’s warranty.
LIMITED WARRANTY
Note:
1. You should ensure the device is power off when open the top cover.
2. You need to clean the filter basket after each use.
3
4
5
Take out the filter basket and cotton
foam.
Empty all debris and rinse it with clean
water.
As electric components inside the
cleaner, store the cleaner in a cool and
ventilated place, away from direct sun-
shine or any heat source.
Charge the cleaner prior to being stor-
ed for a long time (over 6 months) to
maintain an optimal battery life.
After rinsing, put the filter basket and
cotton foam into the cleaner and close
the cover.
DO A FILTER CLEANING
1
2
Press the filter cover handle and lift the cover up.
DEVICE SPECIFICATION
Model
Pool Size
Depth
Device Dimension
Weight
Runtime
Charging Time
Voltage
Power
Charger Input
Charger Output
Battery Capacity
Filtration
Flow Rate
Moving Speed
Water Resistance
OTA upgrading
App Connection
WYBOT S2 Vision
Up to 300
m
2
9.8ft (3m)
400(L)*390(W)*255(H) mm
8.5 Kg
3.5 hours
3 hours
Battery/25.2V
90W
100-240V, 47-63Hz
29.4V/3A
7800mAh
Double-level
14m³/H
10m/min.
IPX8
Available
Available
10
No.
1
2
Issues
Device does
not work
A flashing red
light
A flashing red
light
A breathing yel-
low light
Battery low Fully charge the device
and restart
Charger light
flashes
Unable to ch-
arge
Poor contact Re-plug the charger
3
4
5
6
Do not climb walls
Abnormal wall
climbing
only clean part area and cannot
clean the entire pool
Climbing slowly
Sinking down
away from wall
or floating on
the water
Filter basket blo-
cked
Filter basket blo-
cked
Filter basket blo-
cked
front side up when on the floor
Encounter Obst-
acles
Drain height is
over 3cm
The APP cannot be connected
when the device is in the pool
Wrong cleaning
mode
Firmware not la-
test
Connect to the App and
update the firmware
Clean the filter basket
7
8
Do not clean as set cleaning
path
stuck at water drains
Clean the filter basket
Help the machine away
from the obstacle
Device power off
Not available
Unable to connect to the App Restart
Connect the device
on the shore
Connect to the App
and re-choose a suit-
able cleaning mode
Clean the filter basket
Intake air Stick adhesive blocks
(Contact after-sale team
for instruction)
Clean the filter basket
Slippery constru-
ction materials
Stick adhesive blocks
(Contact after-sale team
for instruction)
Too dirty water Clean the filter basket
Possible Causes
A solid red light
Motor protection
Not put the device
into the water or
the pool water is
too shallow
Restart and put it into
the pool immediately.
Be sure the water dep-
th is over 0.5m.
Restart
Impeller is stuck
Suggested Solution
Check the impeller
and clean foreign
Details
11 12
4. The order number or record must be presented for any claim or repair within
the warranty period.
Note:
If your device do not work after a long-term low battery life or being off, please
contact after-sale team for help. For your safety, do not try to disassemble it
without authorization.
Note:
If you can not find a solution from the table, please contact after-sale team.
You should follow the steps to store your cleaner to maintain good performance.
a) Ensure the device is power off
b) Dry out the cleaner and filter basket
c) Fully charge the battery
d) Store the cleaner in a cool and ventilated place, away from direct sunshine,
heat source, frost and squeezing with an ambient temperature between 5℃/ 41
℉ and 45℃ / 113℉.
e) Charge the cleaner every three months to ensure an optimal battery life.
HOW TO MAINTAIN YOUR DEVICE
Q: What pool shapes and construction materials is the cleaner suitable for?
A: The machine can be applied to rectangle, oval, or irregular shapes of in-ground
swimming pools. Applicable construction materials include PVC, gunite, tile and
other materials.
Q: Will obstacles such as steps, shallow water areas, drains, slopes etc. in the swim-
ming pool affect the running?
A: The machine can climb steps, drains, and shallow water areas. The above obstacl-
es may influence its cleaning path, but will not affect the operation of the machine.
FAQ & TROUBLE SHOOTING
If you encounter the following situations when using the cleaner, you can check
the table and solve them by yourself.
Scan the QR code for the warranty policy.
13
WYBOT robotic pool cleaners have passed all performance and reliability tests
and also has obtained relevant certifications from the countries in which they are
sold. you can rest assured.
CERTIFICATION
WYBOT CUSTOMER CARE
Wybot Customer Service:
Email: [email protected]
Facebook: @WybotPool
Tel: 1-866-777-6655
Due to the need for continuous products improvement, the products in the
manual are subject to the real products, and WYBOTICS Co., Ltd. reserves the
right to update products.
If you encounter any problems during use, please contact after-sale team.
For more details, please contact WYBOTICS website www.wybotpool.com
C
US
CM
Scan the QR code for the e-Manual.
