CAUTION:
Weight limit is not applicable if product is used
properly. This unit is not designed to support a user’s weight.
Product May Vary Slightly From Pictured.
STAMINA PRODUCTS
MADE IN TAIWAN
©
2020 Stamina Products, Inc.
2020, 11
Exercise can present a
health risk. Consult a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
discontinue use of this
equipment. Serious bodily
injury can occur if this
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
!
WARNING
Owner's
Manual
This Product is Distributed Exclusively by
2040 N Alliance Ave, Springeld, MO 65803
Customer Care
1 (800) 375-7520
www.staminaproducts.com
When calling for parts or
service, please specify
the following numbers
:
Model#: 15-0141AR,
15-0141A, 15-0142A
S/N: _____________
Quickstart Guide
Go to the App Store on your device or
scan the QR Code for quick access.
Smart Audio Workouts for Your Bike
Download the app and get moving!
IMPORTANT
Apple, the Apple logo, iPhone, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service
mark of Apple Inc., registered in the U.S. and other countries. Google Play and the Google Play logo are trademarks of Google LLC.
Assembly video included in app.
TABLE OF CONTENTS
Safety Instructions ...................................... 3
Before You Begin ........................................ 5
Equipment Warning, Caution & Notice Labels
... 6
Hardware Identication Chart .................... 7
Assembly Instructions ................................ 8
Operational Instructions ........................... 10
Storage ....................................................... 12
Maintenance ............................................... 12
Conditioning Guidelines ........................... 13
Warm-Up and Cool-Down ......................... 14
Warranty ..................................................... 15
Product Parts Drawing .............................. 16
Parts List .................................................... 17
Notes ........................................................... 18
Fax/Mail Ordering Form ............................ 19
3
SAFETY INSTRUCTIONS
1. Save these instructions and ensure that other exercisers read this manual prior to using the
Stamina® Mini Exercise Bike for the rst time.
2. Read all warnings and cautions posted on the Stamina® Mini Exercise Bike.
3. The Stamina® Mini Exercise Bike should only be used after a thorough review of the Owner’s
Manual. Make sure that it is properly assembled and tightened before use.
4. Do not stand up on the Stamina® Mini Exercise Bike.
5. Keep children away from the Stamina® Mini Exercise Bike. Do not allow children to use or play
on the Stamina® Mini Exercise Bike. Keep children and pets away from the Stamina® Mini
Exercise Bike when it is in use.
6. Set up and operate the Stamina® Mini Exercise Bike on a solid level surface. Do not position
the Stamina® Mini Exercise Bike on loose rugs or uneven surfaces.
7. Make sure that adequate space is available for access to and around the Stamina® Mini
Exercise Bike.
8. Before using, inspect the Stamina® Mini Exercise Bike for worn or loose components, and
securely tighten or replace any worn or loose components prior to use.
9. Consult a physician prior to commencing an exercise program and follow his/her
recommendations in developing your tness program. If at any time during exercise you feel faint,
dizzy, or experience pain, stop and consult your physician.
10. Always choose the workout which best ts your physical strength and exibility level. Know your
limits and train within them. Always use common sense when exercising.
11. Do not wear loose or dangling clothing while using the Stamina® Mini Exercise Bike.
12. Never exercise in bare feet or socks; always wear proper footwear such as running, walking, or
cross training shoes that t well, provide foot support, and feature non-skid rubber soles.
13. Be careful to maintain your balance while using, mounting, dismounting, or assembling the
Stamina® Mini Exercise Bike, loss of balance may result in a fall and serious bodily injury.
14. The Stamina® Mini Exercise Bike should be used by only one person at a time.
15. The Stamina® Mini Exercise Bike is for consumer use only. It is not for use in public or
semipublic facilities.
!
WARNING
Cancer and Reproductive Harm www.P65Warnings.ca.gov
Consult your physician before starting this or any exercise program. This is
especially important if you are over the age of 35, have never exercised before,
are pregnant, or suer from any health problem. This product is for home use
only. Do not use in institutional or commercial applications. Failure to follow all
warnings and instructions could result in serious injury or death.
To reduce the risk of serious injury, read the following Safety Instructions
before using the Stamina® Mini Exercise Bike.
!
WARNING
!
WARNING
NEED HELP?
CONTACT US FIRST
1 (800) 375-7520
customer.care@staminaproducts.com
Hi! From all of us here at Stamina Products, thank you for your purchase. We
know that you have big fitness goals in mind and we are here to help you along.
Call us, email us, or send us a message on Facebook. Be sure to contact us if you
have any questions on your new product. We look forward to hearing from you!
With your body in mind,
Stamina Customer Care
To enact your extended warranty and to help us better
serve you, please go online and register your new product.
register.staminaproducts.com
ONLINE
customer.care@staminaproducts.com
www.staminaproducts.com
TELEPHONE
1 (800) 375-7520
FAX
(417) 889-8064
MAIL
Stamina Products, Inc.
ATTN: Customer Care
2040 N Alliance Ave
Springfield, MO 65803
facebook.com/StaminaProducts
facebook.com/AeroPilates
CUSTOMER CARE HOURS:
Monday-Thursday, 7:30 AM-5:00 PM, Central Time
Friday, 8:00 AM-3:00 PM, Central Time
It is quick and easy to register online, but if you’re a little old school or just need a
reason to raise that little flag on your mailbox, fill out the info on the last page of this
manual and mail it in.
Endcap
MeterCrank Cover
Top Cover
Tension Knob
Left Pedal
Right Pedal
Left Cover
BEFORE YOU BEGIN
5
Caution Label
Pedal Strap
THE FOLLOWING TOOLS ARE INCLUDED FOR ASSEMBLY : Allen Wrench (6mm)
Wrench
Endcap
Endcap
Thank you for choosing the Stamina® Mini
Exercise Bike. We take great pride in this quality
product and hope it will provide many hours of
quality exercise to make you feel better, look
better, and enjoy life to its fullest.
It's a proven fact that a regular exercise program
can improve your physical and mental health.
Too often, our busy lifestyles limit our time and
opportunity to exercise. The Stamina® Mini
Exercise Bike provides a convenient and simple
method to begin your journey of getting your body
in shape and achieving a happier and healthier
lifestyle.
Before reading further, please review the
drawing below and familiarize yourself with the
parts that are labeled. Locate the serial decal on
the product and write the serial number on the
cover of the manual in the space provided. See
page 6 for an image of the serial decal. Model
number and serial number are required when
calling for assistance.
Read this manual carefully before using the
Stamina® Mini Exercise Bike.
Providing you with a quality product is Stamina's
top priority. However, sometimes there could be a
missing or incorrectly sized part. If you have any
questions or problems with the parts included with
your Stamina® Mini Exercise Bike, please do not
return the product. Contact us FIRST!
If a part is missing or defective, please contact
Customer Care for assistance. Call us toll free
at 1-800-375-7520 (in the U.S.) or live chat on
staminaproducts.com. Our Customer Care Sta is
available to assist you from 7:30 A.M. to 5:00 P.M.
(Central Time) Monday through Thursday and 8:00
A.M. to 3:00 P.M. (Central Time) on Friday.
Be sure to have the name and model number of
the product available when you contact us.
Serial Decal
This chart is provided to help identify the warning, caution, and notice labels on the Stamina® Mini
Exercise Bike. Please take a moment to familiarize yourself with all of the warning, caution, and
notice labels.
EQUIPMENT WARNING, CAUTION & NOTICE LABELS
6
CAUTION
!
Consult your physician before starting this or any exercise
program. This is especially important if you are over the
age of 35 or have any pre-existing health condition.
Always make sure all nuts and bolts are securely tightened
before using this product. This product should not be used
by person weighing more than 250 lbs. unless otherwise
stated in your Owner’s Manual.
Keep others including children & pets
away from equipment when in use.
For consumer use only. Failure to follow all warnings
and instructions could result in injury or property
damage. Before assembling or using this product, read
and follow the Owner’s Manual and all other warnings
and instructions that accompany this product. Replace
this caution label if damaged, illegible, or removed.
CAUTION LABEL(49)
To best serve you, our Customer Care Representatives will
need your serial number. For quick access, write in your
serial number on the cover of the manual.
SERIAL DECAL(54)
43 Bolt, Button Head (M8 x 1.25 x 40mm) 4
42 Washer (M8) 4
Part Number and Description Qty
7
length
length
mm.
in.
INCHES
This chart is provided to help identify the fasteners used in the assembly process. Place the washers or
the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to
check the length of the bolts and screws.
NOTICE: The length of all bolts and screws, except those with flat
heads, is measured from below the head to the end of the bolt
or screw. Flat head bolts and screws are measured from the
top of the head to the end of the bolt or screw.
After unpacking the unit, open the hardware bag and make sure that you have all the following
fasteners. Some fasteners may be already attached to the parts.
MILLIMETERS
0 10 20 30 40 50 60 70 80 90
100
110
120
130 140
150
0 1/2
1 1/2
2 1/2
3 1/2
4 1/2
5 1/2
6
6 8
10
12
3/16"
1/4"
5/16" 3/8" 1/2"
HARDWARE IDENTIFICATION CHART
ASSEMBLY INSTRUCTIONS
STEP 1
Attach the FRONT STABILIZER(35), the longer of the two stabilizers, to the front of the MAIN FRAME(1)
with BUTTON HEAD BOLTS(M8x1.25x40mm)(43) and WASHERS(M8)(42).
STEP 2
Attach the REAR STABILIZER(44) to the back end of the MAIN FRAME(1) with BUTTON HEAD
BOLTS(M8x1.25x40mm)(43) and WASHERS(M8)(42). Screw the TENSION KNOB(28) into the TOP
COVER(24).
8
Place all parts from the box in a cleared area and position them on the oor in front of you. Remove
all packing materials from your area and place them back into the box. Do not dispose of the packing
materials until assembly is completed. Read each step carefully before beginning. If you are missing
a part, please go to staminaproducts.com under the Customer Care section and order the part
(in the U.S.). Our Customer Care Sta is available to assist you from 7:30 A.M. to 5:00 P.M. (Central
Time) Monday through Thursday and 8:00 A.M. to 3:00 P.M. (Central Time) on Friday.
Some product parts are t tested at the factory to ensure proper t and alignment. Marks in
the paint may be noticeable, but are not an indication of damage.
ASSEMBLY INSTRUCTIONS
STEP 3
NOTE: The RIGHT PEDAL SHAFT(37) has an R stamped on the end of the pedal shaft. The RIGHT
PEDAL SHAFT(37) has right hand threads and is tightened by turning clockwise. The LEFT
PEDAL SHAFT(41) has an L stamped on the end of the pedal shaft. The LEFT PEDAL SHAFT
(41) has left hand threads and is tightened by turning counterclockwise.
Snap a PEDAL STRAP(39) onto the right PEDAL(38). There are two adjustment holes on each side of
the PEDAL STRAP(39). Select the adjustment holes which allow your feet to be easily removed from the
pedals. Thread the RIGHT PEDAL SHAFT(37) to the RIGHT CRANK(26) as shown. Tighten the pedal
securely. The shoulder of the PEDAL SHAFTS(37, 41) should be in contact with the CRANKS(25, 26)
when securely tightened.
Use the same procedure to attach the LEFT PEDAL SHAFT(41) to the LEFT CRANK(25) and to attach
other PEDAL STRAP(39) to the left PEDAL(38).
STEP 4
NOTE: Refer to the detail view below. Be careful not to damage the SENSOR WIRE(45) on the
METER(31) when disassembling or installing the METER(31).
By hand or by using a simple tool remove the METER(31) from the METER HOUSING(23). Install a
AAA battery into the METER(31), the battery is not included. See page 9 for detailed battery installation
instructions. Press the METER(31) back into the METER HOUSING(23).
9
Shoulder
Shoulder
OPERATIONAL INSTRUCTIONS
10
USING THE FITNESS METER
CALORIES:
1. By hand or by using a simple tool remove the METER(31) from the
METER HOUSING(23).
2. The METER(31) operates with a AAA battery (1.5V each), the
battery is not included. Refer to the illustration to install or replace
the battery.
HOW TO INSTALL AND REPLACE BATTERIES:
TIME:
Automatically scans each function of TIME, COUNT, CALORIES, and TOTAL COUNT
in sequence with change every six seconds. Press and release the button until
"SCAN" appears on the display.
Displays the time from one second up to 99:59 minutes.
Displays the total crank revolutions you have completed during the current workout
from zero to 9999 revolutions.
Displays the total accumulated crank revolutions you have taken from zero to 9999
revolutions. The total accumulated crank revolutions is retained when the meter is
turned o.
Displays the calories burned from zero to 999.9 Kcal.
The calorie readout is an estimate for an average user. It should be used only as a
comparison between workouts on this unit.
COUNT
:
FUNCTIONS:
SCAN:
TOTAL COUNT
:
Move the Pedals or press the button.
Automatically shuts off after four minutes of
inactivity.
POWER OFF
:
POWER ON :
FUNCTION BUTTON:
Press to select display functions, including SCAN, TIME,
COUNT, CALORIES, and TOTAL COUNT.
Press and hold for two seconds to reset all functions to zero.
1. The meter will shut off automatically after four minutes of inactivity. All function
values will be kept. Press the button and hold it down for two seconds to reset all
functions to zero, except TOTAL COUNT.
2. The TOTAL COUNT will be reset to zero after battery is removed for battery
replacement or storage of the unit.
NOTE:
AAA Battery
SCAN TIME
COUNT
CAL
TOTAL COUNT
1. Rechargeable batteries are not recommended.
2. Ultimate disposal of battery should be handled
according to all state and federal laws and regulations.
3. Do not dispose of batteries in re.
NOTE:
LOAD ADJUSTMENT
To increase the load, turn the TENSION KNOB(28) clockwise.
To decrease the load, turn the TENSION KNOB(28)
counterclockwise.
OPERATIONAL INSTRUCTIONS
11
Upper Body: Place the Stamina® Mini Exercise Bike on a table
or desk. Grasp the pedals rmly with your hands and pedal the bike.
This exercise can be performed while seated or standing.
Lower Body: Place the Stamina® Mini Exercise Bike on the oor
in front of a chair. Sit in the chair and pedal the bike with your feet.
Caution: Do not stand up on the Stamina® Mini Exercise Bike.
EXERCISE WORKOUT
1. To store the Stamina® Mini Exercise Bike, simply keep it in a clean dry place.
2. To avoid damage to the electronics, remove the battery from the METER(31) before storing the
Stamina® Mini Exercise Bike for one year or more.
The safety and integrity designed into the Stamina® Mini Exercise Bike can only be maintained when
the Stamina® Mini Exercise Bike is regularly examined for damage and wear. Special attention should
be given to the following:
1. Adjust the TENSION KNOB(28) and verify that it functions properly and the resistance changes.
2. Use a wrench to verify that the PEDALS(37, 41) are tightened securely. If tightening is required,
remember that the left pedal has left hand threads and is tightened by turning counterclockwise.
3. Verify that all nuts and bolts are present and properly tightened. Replace missing nuts and bolts.
Tighten loose nuts and bolts.
4. Verify that the CAUTION LABEL(49) is in place and easy to read. Call Stamina Products immediately
at 1-800-375-7520 for a replacement CAUTION LABEL(49) if it is missing or damaged.
5. It is the sole responsibility of the user/owner to ensure that regular maintenance is performed.
6. Worn or damaged components must be replaced immediately or the Stamina® Mini Exercise Bike
removed from service until repair is made.
7. Only Stamina Products supplied components should be used to maintain/repair the Stamina® Mini
Exercise Bike.
8. Keep your Stamina® Mini Exercise Bike clean by wiping it o with an absorbent cloth after use.
STORAGE
MAINTENANCE
12
3. To move the Stamina® Mini Exercise Bike, grasp the handle
which is built into the RIGHT and LEFT COVERS(20, 22).
Do not use the PEDALS(37, 41) to move the Stamina® Mini
Exercise Bike. The PEDALS(37, 41) will move and the cranks
may pinch your hand or ngers.
Handle
How you begin your exercise program depends on your physical condition. If you have been inactive for
several years or are severely overweight, start slowly and increase your workout time gradually. Increase
your workout intensity gradually by monitoring your heart rate while you exercise.
Initially you may only be able to exercise within your target zone for a few minutes; however, your aerobic
capacity will improve over the next six to eight weeks. It is important to pace yourself while you exercise
so you don't tire too quickly.
Measure your heart rate periodically during your workout by stopping the
exercise but continuing to move your legs or walk around. Place two or
three ngers on your wrist and take a six second heartbeat count. Multiply
the results by ten to nd your heart rate. For example, if your six second
heartbeat count is 14, your heart rate is 140 beats per minute. A six second
count is used because your heart rate will drop rapidly when you stop
exercising. Adjust the intensity of your exercise until your heart rate is at the
proper level.
wrist pulse
Remember to follow these essentials:
Have your doctor review your training and diet programs.
Begin your training program slowly with realistic goals that have been set by you and your physician.
Warm up before you exercise and cool down after you work out.
Take your pulse periodically during your workout and strive to stay within a range of 60% (lower
intensity) to 90% (higher intensity) of your maximum heart rate zone. Start at the lower intensity, and
build up to higher intensity as you become more aerobically t.
If you feel dizzy or lightheaded you should slow down or stop exercising.
To determine if you are working out at the correct intensity, use a heart rate monitor or use the table
below. For effective aerobic exercise, your heart rate should be maintained at a level between 60%
and 90% of your maximum heart rate. If just starting an exercise program, work out at the low end of
your target heart rate zone. As your aerobic capacity improves, gradually increase the intensity of your
workout by increasing your heart rate.
CONDITIONING GUIDELINES
Target Heart Rate Zone Estimated by Age*
* For cardiorespiratory training benefits, the American College of Sports Medicine recommends
working out within a heart rate range of 55% to 90% of maximum heart rate. To predict the
maximum heart rate, the following formula was used: 220 - Age = predicted maximum heart rate
20 years
25 years
30 years
35 years
40 years
45 years
50 years
55 years
60 years
65 years
70 years
Average Maximum
Heart Rate 100%
Age
110-180 beats per minute
107-175 beats per minute
105-171 beats per minute
102-166 beats per minute
99-162 beats per minute
97-157 beats per minute
94-153 beats per minute
91-148 beats per minute
88-144 beats per minute
85-139 beats per minute
83-135 beats per minute
200 beats per minute
195 beats per minute
190 beats per minute
185 beats per minute
180 beats per minute
175 beats per minute
170 beats per minute
165 beats per minute
160 beats per minute
155 beats per minute
150 beats per minute
Target Heart Rate Zone
(55%-90% of Maximum Heart Rate)
13
WARM-UP and COOL-DOWN
Warm-Up
The purpose of warming up is to prepare your body for exercise and to minimize injuries.
Warm up for two to ve minutes before strength training or aerobic exercising. Perform activities that
raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging,
jumping jacks, jump rope, and running in place.
Stretching
Stretching while your muscles are warm after a proper warm-up and again after your
strength or aerobic training session is very important. Muscles stretch more easily at these times
because of their elevated temperature, which greatly reduces the risk of injury. Stretches should be held
for 15 to 30 seconds. Do not bounce.
Suggested Stretching Exercises
Remember to always check with your physician before starting any exercise program.
Cool-Down
The purpose of cooling down is to return the body to its normal, or near normal, resting
state at the end of each exercise session. A proper cool-down slowly lowers your heart rate and allows
blood to return to the heart. Your cool-down should include the stretches listed above and should be
completed after each strength training session.
Lower Body Stretch
Place feet shoulder-width
apart and lean forward.
Keep this position for 30
seconds using the body as a
natural weight to stretch the
backs of the legs.
DO NOT BOUNCE!
When the pull on the back of
the legs lessens, gradually
try a lower position.
Floor Stretch
While sitting on the oor,
open the legs as wide as
possible. Stretch the upper
body toward the knee on the
right leg by using your arms
to pull your chest to your
thighs. Hold this stretch 10
to 30 seconds.
DO NOT BOUNCE!
Do this stretch 10 times.
Repeat the stretch with the
left leg.
Bent Over Leg Stretch
Stand with feet shoulder-
width apart and lean forward
as illustrated. Using the
arms, gently pull the upper
body towards the right leg.
Let the head hang down.
DO NOT BOUNCE!
Hold the position a minimum
of 10 seconds. Repeat
pulling the upper body to
the left leg. Do this stretch
several times slowly.
Bent Torso Pulls
While sitting on the oor,
have legs apart, one leg
straight and one knee bent.
Pull the chest down to touch
the thigh on the leg that is
bent, and twist at the waist.
Hold this position at least 10
seconds. Repeat 10 times
on each side.
14
LIMITED WARRANTY
MODEL 15-0141AR, 15-0141A, 15-0142A
15
WARRANTY
Stamina Products, Inc. (“Stamina”) warrants to the original purchaser that this product will be free from
defects in materials and workmanship that arise under normal use, service, proper assembly and proper
operation in accordance with product warnings/instructions for a period of 90 days on the parts and one
year on the frame from the date of the original purchase from an authorized retailer. THIS WARRANTY
SHALL NOT APPLY TO ANY PRODUCT WHICH HAS BEEN SUBJECT TO COMMERCIAL USE,
ABUSE, MISUSE, ALTERATION OF ANY KIND OR TO ANY DEFECT OR CHANGE CAUSED BY
IMPROPER ASSEMBLY, REPAIR, REPLACEMENT, SUBSTITUTION OR USE WITH PARTS NOT
PROVIDED BY STAMINA. Commercial use includes use of product in athletic clubs, health clubs, spas,
gyms, and all other public or semipublic facilities whether or not the product’s use is in furtherance of a
prot making enterprise, and all other use which is not for personal purposes.
To implement this limited warranty, send a written notice stating your name, date, and place of purchase
and a brief description of the defect along with your receipt to Stamina Products, Inc. 2040 N Alliance
Ave, Springeld, Missouri, USA, MO 65803, or email us at customer[email protected], or call
us at 1-800-375-7520. If the defect is covered under this limited warranty, you will be requested to return
the product or part to us for free repair or replacement at our option.
NO ACTION FOR BREACH OF THIS LIMITED WARRANTY MAY BE COMMENCED MORE
THAN ONE (1) YEAR AFTER THE DATE THE ALLEGED BREACH WAS OR SHOULD HAVE
BEEN DISCOVERED. NO ACTION FOR BREACH OF ANY IMPLIED WARRANTY (INCLUDING
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE) MAY BE COMMENCED MORE
THAN ONE (1) YEAR AFTER DELIVERY OF THE PRODUCT TO THE PURCHASER. These warranties
are not transferable. IF ANY PART OF THE PRODUCT IS NOT IN COMPLIANCE WITH THIS LIMITED
WARRANTY OR ANY IMPLIED WARRANTY, THE REMEDY OF REPAIR OR REPLACEMENT IS THE
EXCLUSIVE REMEDY. If any claim is made under this limited warranty or any implied warranty, Stamina
reserves the right to require the product to be returned for inspection, at the purchaser’s expense, to
Stamina’s premises in Springfield, Missouri. Return of the enclosed warranty registration card is not
required for warranty coverage, but is merely a way of establishing the date and place of purchase.
Stamina SHALL NOT BE LIABLE FOR THE LOSS OF USE OF ANY PRODUCT, LOSS OF TIME,
INCONVENIENCE, COMMERCIAL LOSS OR ANY OTHER INDIRECT, CONSEQUENTIAL, SPECIAL
OR INCIDENTAL DAMAGES DUE TO BREACH OF THE ABOVE WARRANTY OR ANY IMPLIED
WARRANTY.
THIS LIMITED WARRANTY IS THE ONLY EXPRESS WARRANTY. NO ORAL OR WRITTEN
INFORMATION GIVEN BY STAMINA, ITS AGENTS OR EMPLOYEES, SHALL CREATE A WARRANTY
OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY. This warranty gives you specic legal
rights, and you may also have other legal rights which vary from state to state. ANY OTHER RIGHT
WHICH YOU MAY HAVE, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, IS LIMITED IN DURATION TO THE DURATION OF THIS
WARRANTY.
The laws in some states aect the disclaimer or limitation of implied warranties and consequential and
incidental damages. If any such law is found applicable, the foregoing disclaimers and limitations of and
on implied warranties and consequential and incidental damages shall be deemed to be modied to the
extent necessary to comply with applicable law.
PRODUCT PARTS DRAWING
BACK
FRONT
16
PART# PART NAME QTY
PARTS LIST
17
1 Main Frame 1
2 Flywheel 1
3 Sun Gear 1
4 Bolt, Button Head (M6 x 1 x 10mm) 10
5 Shaft 1
6 Planet Carrier 1
7 Carrier Support Plate 1
8 Large Washer (ø16 x ø26 x 0.8mm) 5
9 Planet Gear (M1.5 - 27T) 3
10 Screw, Round Head (M5 x 15mm) 13
11 Magnet 1
12 Bushing 3
13 Washer (M5) 3
14 Bolt, Round Head Self-Drill (M6 x 10mm) 4
15 Brake Support 1
16 Felt Brake Pad 1
17 Threaded Insert 8
18 C Ring (M16) 2
19 Flange Bearing 2
20 Right Cover 1
21 Ring Gear (M1.5 - 72T) 1
22 Left Cover 1
23 Meter Housing 1
24 Top Cover 1
25 Left Crank 1
26 Right Crank 1
27 Crank Cover 2
28 Tension Knob 1
29 Sensor Clip 1
30 Square Nut (M8 x 1.25) 1
31 Meter 1
32 Collar 1
33 C Ring 1
34 Bolt, Hex Washer Head (M8 x 1.25 x 18mm) 2
35 Front Stabilizer 1
36 Endcap 4
37 Right Pedal Shaft 1
38 Pedal 2
39 Pedal Strap 2
40 E Ring (M10) 2
41 Left Pedal Shaft 1
42 Washer (M8) 4
43 Bolt, Button Head (M8 x 1.25 x 40mm) 4
44 Rear Stabilizer 1
45 Sensor Wire 1
46 Brake Support Pad 1
47 Flange Washer 4
48 Screw, Round Head (M5 x 10mm) 4
49 Caution Label 1
50 Allen Wrench (5mm) 1
51 Wrench 1
52 Manual 1
53 Screw, Round Head (M4 x 13.5mm) 1
54 Serial Decal 1
NOTES
18
Model Number: ...................................................................................... Serial Number: .............................................................................................
Product Name: ..................................................................................................................................................................................................................................
Place Purchased: ..............................................................................................................................................................................................................................
Date of Purchase: .................................................................................. Purchase Price: ............................................................................................
First Name: ............................................................................................ Last Name: ...................................................................................................
City: .................................................................. State: ................................................................ Zip Code: .................................................
Email Address: ....................................................................................... Phone #: ( ) ......................................................................................
Would you like to receive email information or special oers from Stamina Products?* ____Yes ____No
*If yes, be sure your email address is included above.
Stamina Products, Inc.
2040 N Alliance Ave, Springeld, MO 65803
If there are missing or damaged parts, you can go to parts.staminaproducts.com and order those parts. If you have questions,
please contact customer care. Do not return the product. To order parts by mail, fill out the sheet below and fax it to
417-889-8064. The part will be mailed to your address.
Mr./Ms: ..............................................................................................................................................................................................................................................
Address: ........................................ ............................................................................................. Apt. #:..........................................................................
City: .................................................................. State: ................................................................ Zip Code: .................................................
IMPORTANT : We require your phone number to process the order!
Phone #: ( ) ................................................................................ Work Phone #: ( ) .............................................................................
Date of Purchase: ..................................................................................
Model #: ............................................................................................................................................................................................................................................
Purchased From: ..............................................................................................................................................................................................................................
IMPORTANT: Before lling out the portion below, make sure you have the correct information.
Refer to the parts list to make sure you're ordering the right parts!
Stamina Products, Inc.
2040 N Alliance Ave, Springeld, MO 65803
Detach and Mail or Fax the Form Above
TO CONTACT CUSTOMER CARE
For your convenience, Stamina’s customer care representatives can be reached by email at customer.care@staminaproducts.
com or by phone at 1-800-375-7520 (in the U.S.). Our customer care representatives are available Monday through Thursday
from 7:30 a.m. until 5:00 p.m., and Friday 8:00 a.m. until 3 p.m. Central Time.
TO REGISTER YOUR PRODUCT
Would you like to recieve email information or special oers from Stamina Products? Register at contact.staminaproducts.com
TELEPHONE
CUSTOMER CARE
Tel: 1 (800) 375-7520
FAX
CUSTOMER CARE
Fax: (417) 889-8064
MAIL
STAMINA PRODUCTS, INC.
ATTN: Customer Care
2040 N Alliance Ave, Springeld, MO 65803
ONLINE
CUSTOMER CARE
customer[email protected]
www.staminaproducts.com
To enact your warranty, please register your product by going to register.staminaproducts.com. Please have your product model
number (printed on the cover of this owner’s manual) and the serial number (printed on the black and white sticker on your
product) ready.
If you don’t have internet access, you can call customer care at 1-800-375-7520, or ll out and mail the product registration form
below to Stamina Products, Inc.; 2040 N Alliance Ave, Springeld, MO 65803.
PRODUCT REGISTRATION FORM
TO ORDER PARTS
Detach and Mail or Fax the Form Below
PARTS ORDER FORM
PART # DESCRIPTION QUANTITY
1 Rear Unit Assembly 1
EXAMPLE:
