SPECIFICATION SHEET
WESTINGHOUSE LIGHTING
and Westinghouse are trademarks of Westinghouse Electric Corporation.
Used under license by Westinghouse Lighting. All Rights Reserved.
^ Based on typical use, excluding lights
* Based on 12 cents per kWh and 6.4 hours use per day
† Values are per lamp
** Based on 3hrs./day
Specifications are subject to change without notice, please visit www.westinghouselighting.com for latest information.
Item Number 74007A00
52 in. Brushed Nickel Finish
Reversible Blades (Graphite/Light Maple) Opal Frosted Glass
Smart Wi Technology
Specications
Size ............................................................... 52”
Blades .......................................................... Reversible Plywood Blades
(Graphite/Light Maple)
Blade Pitch ................................................ 12°
Approved Location ............................... Indoor
Suggested Room Size .......................... Great Room (up to 20x20)
Down Rod .................................................. 3/4 x 4”
Installation ................................................. Down Rod Only
Max. Ceiling Angle ................................. N/A
Lead Wire .................................................. 54”
Light Bulb Usage .................................... Includes 16 Watt Integrated LED
Remote Control ....................................... Remote Control Included
Motor Finish .............................................. Brushed Nickel
Motor Material ......................................... Silicon Steel Motor 153mm
x 17mm
Reverse Airow ....................................... Yes
Capacitor ................................................... Dual
Switch Housing Cap........................... Not Included
Energy Information
Airow (CFM) when operated at high speed..... 4784
Energy Use (Excludes lights)^......................... 40
Airow (CFM)^.................................................... 3305
Airow Eciency (CFM/W)^........................... 84
Estimated Yearly Energy Cost^....................... $11
RPM (High)........................................................... 174
Amp (High).......................................................... 0.51
Watts (High)........................................................ 60
Light Source
Number of Lamps........................... 1
Energy Use (Watts)†....................... 16
Equiv. Incand. Wattage†................ 75
Light Appearance (Kelvin)............ 3000
Lumens†............................................. 1300
CRI...................................................... 90
Average Rated Hours..................... 25000
Life in Years**†................................. 22.80
Estimated Yearly Energy Cost..... $1.93
Alta Vista Ceiling Fan
Smart Wi Technology
With down rod
Reversible Light Maple
Finish Blades
2022
INTEGRATED
DIMMABLE
A. Top of Canopy to Bottom of Blades ...................................10.8”
B. Top of Canopy to Bottom of Switch House .....................8.4”
C. Top of Canopy to Bottom of Canopy ..................................2.4”
D. Width of Motor Housing ............................................................. 7.9”
E. Width of Canopy ..............................................................................5.1”
F. Top of Canopy to Bottom of Glass ....................................... 13.7”
Item Number 74007A00
52 in. Brushed Nickel Finish
Reversible Blades (Graphite/Light Maple) Opal Frosted Glass
Smart Wi Technology
Warranty
Ceiling fans backed by our Limited Lifetime Warranty have a lifetime motor warranty and a 2-year warranty on all other parts.
SPECIFICATION SHEET
Alta Vista Ceiling Fan
Smart Wi Technology
and Westinghouse are trademarks of Westinghouse Electric Corporation.
Used under license by Westinghouse Lighting. All Rights Reserved.
Specifications are subject to change without notice, please visit www.westinghouselighting.com for latest information.
2022
WESTINGHOUSE LIGHTING
