S9L1721E
DA
Køleskab Brugsanvisning 3
EN
Refrigerator User Manual 15
NO
Kjøleskap Bruksanvisning 27
INSTALLATION / INSTALLATION / INSTALLASJON
(*mm)
549
548
548
551
548
1071
min. 545
min. 560
90°
36
1772
1780
LYDE / NOISES / LYDER
SSSRRR!
CLICK!
HISSS!
BRRR!
BLUBB!
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
VISIT OUR WEBSITE:
To get usage advice, brochures, trouble shooter, service and repair information:
www.smeg.com/services/customer-service
CONTENTS
1. SAFETY INFORMATION.................................................................................15
2. SAFETY INSTRUCTIONS...............................................................................17
3. CONTROL PANEL.......................................................................................... 19
4. DAILY USE......................................................................................................20
5. HINTS AND TIPS............................................................................................ 21
6. CARE AND CLEANING...................................................................................22
7. TROUBLESHOOTING.....................................................................................23
8. TECHNICAL DATA..........................................................................................25
9. INFORMATION FOR TEST INSTITUTES.......................................................26
10. ENVIRONMENTAL CONCERNS.................................................................. 26
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
ENGLISH 15
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved. Children aged from 3 to 8 years and
persons with very extensive and complex disabilities are
allowed to load and unload the appliance provided that they
have been properly instructed. Children of less than 3 years
of age should be kept away from the appliance unless
continuously supervised.
• Children should be supervised to ensure that they do not
play with the appliance.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
• Keep all packaging away from children and dispose of it
appropriately.
1.2 General Safety
• This appliance is for storing food and beverages only.
• This appliance is designed for single household domestic
use in an indoor environment.
• This appliance may be used in, offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
• To avoid contamination of food respect the following
instructions:
– do not open the door for long periods;
– clean regularly surfaces that can come in contact with
food and accessible drainage systems;
– store raw meat and fish in suitable containers in the
refrigerator, so that it is not in contact with or drip onto
other food.
• WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
• WARNING: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
16 ENGLISH
• WARNING: Do not damage the refrigerant circuit.
• WARNING: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of
the type recommended by the manufacturer.
• Do not use water spray and steam to clean the appliance.
• Clean the appliance with a moist soft cloth. Only use neutral
detergents. Do not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
• When the appliance is empty for long period, switch it off,
defrost, clean, dry and leave the door open to prevent
mould from developing within the appliance.
• Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must install this
appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Do not use the appliance before installing
it in the built-in structure due to safety
manner.
• Follow the separate instructions for the
appliance installation and door reversing
available on our website.
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Make sure the air can circulate around the
appliance.
• At first installation or after reversing the
door wait at least 4 hours before
connecting the appliance to the power
supply. This is to allow the oil to flow back
in the compressor.
• Before carrying out any operations on the
appliance (e.g. reversing the door),
remove the plug from the power socket.
• Do not install the appliance close to
radiators or cookers, ovens, or hobs,
unless otherwise specified in the
installation instructions.
• Do not expose the appliance to the rain.
• Do not install the appliance where there is
direct sunlight.
• Do not install this appliance in areas that
are too humid or too cold.
• When you move the appliance, lift it by the
front edge to avoid scratching the floor.
• Protect the floor from scratches when
reversing the appliance door.
• The appliance contains a bag of
desiccant. This is not a toy. This is not
food. Please dispose of it immediately.
2.2 Electrical connection
WARNING!
Risk of fire and electric shock.
ENGLISH 17
WARNING!
When positioning the appliance, ensure
the supply cord is not trapped or
damaged.
WARNING!
Do not use multi-plug adapters and
extension cables.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• The appliance must be earthed.
• Always use a correctly installed
shockproof socket.
• If the domestic power supply socket is not
earthed, connect the appliance to a
separate earth in compliance with current
regulations, consulting a qualified
electrician.
• Make sure not to cause damage to the
electrical components (e.g. mains plug,
mains cable, compressor). Contact the
Authorised Service Centre or an
electrician to change the electrical
components.
• The mains cable must stay below the level
of the mains plug.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
2.3 Use
WARNING!
Risk of injury, burns, electric shock or
fire.
The appliance contains flammable gas,
isobutane (R600a), a natural gas with a high
level of environmental compatibility. Be
careful not to cause damage to the refrigerant
circuit containing isobutane.
• Do not change the specification of this
appliance.
• Any use of the built-in product as free-
standing is strictly prohibited.
• This appliance is intended to be used at
ambient temperature ranging from 10°C to
43°C. The specified temperature range
guarantees the correct operations of the
appliance.
• Do not put electrical appliances (e.g. ice
cream makers) in the appliance unless
they are stated applicable by the
manufacturer.
• If damage occurs to the refrigerant circuit,
make sure that there are no flames and
sources of ignition in the room. Ventilate
the room.
• Do not let hot items to touch the plastic
parts of the appliance.
• Do not store flammable gas and liquid in
the appliance.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
• Do not allow food to come in contact with
the inner walls of the appliance
compartments.
2.4 Internal lighting
WARNING!
Risk of electric shock.
• This product contains one or more light
sources of energy efficiency class G.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
2.5 Care and cleaning
WARNING!
Risk of injury or damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains plug
from the mains socket.
18 ENGLISH
• This appliance contains hydrocarbons in
the cooling unit. Only a qualified person
must do the maintenance and the
recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If the
drain is blocked, defrosted water collects
in the bottom of the appliance.
2.6 Service
• To repair the appliance contact the
Authorised Service Centre. Use only
original spare parts.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts are available for
at least 7 years after the model has been
discontinued: thermostats, temperature
sensors, printed circuit boards, light
sources, door handles, door hinges, trays
and baskets. Door gaskets are available
for at least 10 years after the model has
been discontinued. The duration may be
longer in your country. For further
information, please visit our website.
• Please note that some of these spare
parts are only available to professional
repairers, and that not all spare parts are
relevant for all models.
2.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children and
pets to be closed inside of the appliance.
• The refrigerant circuit and the insulation
materials of this appliance are ozone-
friendly.
• The insulation foam contains flammable
gas. Contact your municipal authority for
information on how to discard the
appliance correctly.
• Do not cause damage to the part of the
cooling unit that is near the heat
exchanger.
3. CONTROL PANEL
1 2
5 4
3
1
Temperature indicator LED
2
Alarm light
3
FastCool indicator
4
FastCool button
5
Temperature regulator
ON/OFF button
3.1 Switching on/off
Switching on
1. Insert the plug into the wall socket.
2. Press the temperature regulator button if
all LED indicators are off.
Switching off
Keep pressing the temperature regulator
button for 3 sec. All indicators light off.
3.2 Temperature regulation
Press the temperature regulator. Current LED
temperature indicator blinks. When you press
the temperature regulator, the setting moves
by one position. Repeat the procedure until
the appliance reaches the required
temperature.
The temperature range may vary between
2°C to 8°C (recommended 4°C).
The set temperature will be reached
within 24 h. After a power failure the set
temperature remains stored.
ENGLISH 19
3.3 FastCool function
The FastCool function allows to chill large
amount of warm food rapidly to avoid
warming food already stored in the fridge.
To activate FastCool function press the
FastCool button. The FastCool indicator
switches on.
This function stops automatically after
6 h.
To deactivate the function, press the
FastCool button again. The FastCool
indicator switches off.
3.4 Door open alarm
If the fridge door is left open for approx. 5
min, the sound is on.
Press any button to switch off the sound.
The alarm deactivates after closing the door.
If you do not press any button, the
sound switches off after 1 h.
4. DAILY USE
CAUTION!
This refrigerating appliance is not
suitable for freezing foodstuffs.
4.1 Positioning the door shelves
For easier storage of food, the door shelves
can be placed at different heights. Pull the
shelf up to reposition.
4.2 Movable shelves
The walls of the fridge are equipped with
runners. You can change the position of the
shelves.
Do not move the glass shelf above
the vegetable drawer to ensure correct
air circulation.
4.3 Vegetable drawer
The drawer is suitable for the storage of fruit
and vegetables.
To remove the drawer:
1. Pull out the drawer and lift it up.
2. Push the rails inside the cabinet.
20 ENGLISH
To reassemble:
1. Pull out the rails.
2. Place the rear part of the drawer (1) on
the rails.
2
1
3. Keep the front of the drawer (2) lifted up
while pushing the drawer in.
4. Press the front part of the drawer
downwards.
5. Pull out the drawer again and check if it is
placed correctly on both rear and front
hooks.
4.4 Temperature indicator
There is a temperature indicator on the side
wall of the appliance. The symbol indicates
the coldest area in the fridge.
If OK is displayed (A), put fresh food into area
indicated by the symbol. If not (B), wait at
least 12 h and check again.
If it is still not OK (B), set a colder
temperature.
OK
OK
A
B
4.5 Fan
The fridge compartment is equipped with a
fan that allows for rapid cooling of foods and
keeps uniform temperature in the
compartment.
The fan activates automatically when needed.
The fan operates only when the door
is closed.
Do not remove the cover of the fan.
5. HINTS AND TIPS
5.1 Hints for energy saving
• The configuration with the drawers in the
bottom part of the appliance and shelves
evenly distributed ensures the most
efficient use of energy. Position of the
door bins does not affect energy
consumption.
• Do not open the door frequently or leave it
open longer than necessary.
ENGLISH 21
• Do not set too high temperature unless it
is required by the characteristics of the
food.
• If the ambient temperature is high and the
temperature control is set to low
temperature and the appliance is fully
loaded, the compressor may run
continuously, causing frost or ice
formation on the evaporator. In this case,
set the temperature control toward higher
temperature to allow automatic defrosting.
• Do not cover the ventilation grilles or
holes.
5.2 Hints for food refrigeration
• Fresh food compartment is marked (on the
rating plate) with .
• Good temperature setting that ensures
preservation of fresh food is a temperature
less than or equal to +4°C.
• Always use closed containers for liquids
and for food, to avoid flavours or odours in
the compartment.
• To avoid the cross-contamination between
cooked and raw food, cover the cooked
food and separate it from the raw one.
• Wrap and place meat on the glass shelf
above the vegetable drawer.
• Defrost the food inside the fridge.
• Do not insert hot food inside the
appliance.
• Clean fruit and vegetables and place in a
dedicated drawer (vegetable drawer).
• Do not keep exotic fruits in the fridge.
• Do not keep vegetables like tomatoes,
potatoes, onions, and garlic in the fridge.
• Close the bottles before you put them into
the fridge.
6. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
6.1 Cleaning the interior
Before first use clean the interior and all
accessories with lukewarm water and neutral
soap, then dry.
CAUTION!
The accessories and parts of the
appliance are not suitable for washing in
a dishwasher.
6.2 Periodic cleaning
Clean the equipment regularly:
• Clean the inside and accessories with
lukewarm water and neutral soap. Rinse
and wipe them dry.
• Wipe down the door seals regularly.
6.3 Defrosting of the fridge
Frost is automatically eliminated from the
evaporator of the fridge compartment during
normal use. The defrost water drains out
through a trough into a special container
where it evaporates.
Regularly clean the defrost water drain hole
in the middle of the fridge compartment
channel.
Use the tube cleaner provided with the
appliance.
6.4 Period of non-operation
When the appliance is not in use for long
period, take the following precautions:
1. Disconnect the appliance from electricity
supply.
2. Remove all food.
3. Clean the appliance and all accessories.
4. Leave the door open to prevent
unpleasant smells.
22 ENGLISH
7. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
7.1 What to do if...
Problem Possible cause Solution
The appliance does not operate. The appliance is switched off. Switch on the appliance.
The mains plug is not connected
to the mains socket correctly.
Connect the mains plug to the
mains socket correctly.
There is no voltage in the mains
socket.
Connect a different electrical ap‐
pliance to the mains socket. Con‐
tact a qualified electrician.
The appliance is noisy. The appliance is not supported
properly.
Check if the appliance stands
stable.
Acoustic or visual alarm is on. The door is left open. Close the door.
The compressor operates contin‐
ually.
Temperature is set incorrectly. Refer to "Control panel" chapter.
Too much food is put in at the
same time.
Wait a few hours and then check
the temperature again.
The room temperature is too
high.
Refer to "Installation" chapter.
Food placed in the appliance is
too warm.
Allow food to cool to room tem‐
perature before storing.
The door is not closed correctly. Refer to "Closing the door" sec‐
tion.
The FastCool function is switched
on.
Refer to "FastCool function" sec‐
tion.
The compressor does not start
immediately after pressing the
"FastCool", or after changing the
temperature.
The compressor starts after a pe‐
riod of time.
This is normal, no error has oc‐
curred.
Door is misaligned or interferes
with ventilation grill.
The appliance is not levelled. Refer to installation instructions.
Door does not open easily. You attempted to re-open the
door immediately after closing.
Wait a few seconds between
closing and re-opening of the
door.
The lamp does not work. The lamp is in stand-by mode. Close and open the door.
ENGLISH 23
Problem Possible cause Solution
The lamp is defective. Contact the Authorized Service
Centre.
There is too much frost and ice. The door is not closed correctly. Refer to "Closing the door" sec‐
tion.
The gasket is deformed or dirty. Refer to "Closing the door" sec‐
tion.
Food is not wrapped properly. Wrap the food properly.
Temperature is set incorrectly. Refer to "Control panel" chapter.
Appliance is fully loaded and is
set to the lowest temperature.
Set a higher temperature. Refer
to "Control panel" chapter.
Temperature set in the appliance
is too low and the ambient tem‐
perature is too high.
Set a higher temperature. Refer
to "Control panel" chapter.
Water flows on the rear plate of
the refrigerator.
During the automatic defrosting
process, frost melts on the rear
plate.
This is correct.
There is too much condensed
water inside the fridge.
Door was opened too frequently. Open the door only when neces‐
sary.
Door was not closed completely. Make sure the door is closed
completely.
Stored food was not wrapped. Wrap food in suitable packaging
before storing it in the appliance.
This is normal that during sum‐
mer and autumn more condensa‐
tion can form due to the in‐
creased air and food humidity.
Fridge does not produce any
moisture. After this period, the
humidity in the fridge decreases
itself.
In summer and autumn, set the
warmer temperature in the refrig‐
erator (approx. 6-7°C).
There are water drops on the
glass shelves.
There is too much moisture in‐
side the fridge.
Wipe the glass shelves with a
cloth to remove water drops.
Water flows inside the fridge. Food prevents the water from
flowing into the water collector.
Make sure that food does not
touch the rear plate.
The water outlet is clogged. Clean the water outlet.
Temperature cannot be set. The FastCool function is switched
on.
Switch off FastCool function man‐
ually, or wait until it deactivates
automatically. Refer to "FastCool
function" section.
24 ENGLISH
Problem Possible cause Solution
The temperature in the appliance
is too low/too high.
The temperature is not set cor‐
rectly.
Set a higher/lower temperature.
The door is not closed correctly. Refer to the "Closing the door"
section.
The food is too hot. Let the food cool down before
storage.
Too much food is stored at the
same time.
Store less food at the same time.
The door has been opened often. Open the door only if necessary.
The FastCool function is switched
on.
Refer to the "FastCool function"
section.
There is no cold air circulation in
the appliance.
Ensure cold air circulation in the
appliance. Refer to the "Hints and
tips" chapter.
Temperature setting LEDs flash
at the same time.
An error has occurred in measur‐
ing the temperature.
Contact the Authorised Service
Centre. The cooling system will
continue to keep food cold, but
temperature adjustment will not
be possible.
If the problem persists, contact the
Authorised Service Centre.
7.2 Replacing the lamp
For replacing the lamp, contact the
Authorized Service Centre.
7.3 Closing the door
1. Clean the door gaskets.
2. To adjust the door, refer to installation
instructions.
3. To replace the defective door gaskets,
contact the Authorized Service Centre.
8. TECHNICAL DATA
The technical information is situated in the
rating plate on the internal side of the
appliance and on the energy label.
The QR code on the energy label supplied
with the appliance provides a web link to the
information related to the performance of the
appliance in the EU EPREL database. Keep
the energy label for reference together
with the user manual and all other documents
provided with this appliance.
It is also possible to find the same information
in EPREL using the link
https://eprel.ec.europa.eu
and the model
name and product number that you find on
the rating plate of the appliance.
See the link
www.theenergylabel.eu
for
detailed information about the energy label.
ENGLISH 25
9. INFORMATION FOR TEST INSTITUTES
Installation and preparation of the appliance
for any EcoDesign verification shall be
compliant with EN 62552 (EU). Ventilation
requirements, recess dimensions and
minimum rear clearances shall be as stated
in this User Manual in "Installation". Please
contact the manufacturer for any other further
information, including loading plans.
10. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put the
packaging in relevant containers to recycle it.
Help protect the environment and human
health by recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol with
the household waste. Return the product to
your local recycling facility or contact your
municipal office.
26 ENGLISH
www.smeg.com
222383778-A-362024
