7-INCH AUDIO/VIDEO RECEIVER
iLX-W670
Thank you for purchasing this Alpine product. Please take a moment to protect your purchase by
registering your product now at the following address: www.alpine-usa.com/registration.
You will be informed of product and software updates (if applicable), special promotions, news
about Alpine.
Merci d’avoir acheté ce produit Alpine. Nous vous invitons à consacrer un moment à la protection
de votre achat en enregistrant votre produit dès maintenant à l’adresse suivante :
www.alpine-usa.com/registration.
Vous serez tenu informé des mises à jour des produits et des logiciels (le cas échéant), des
promotions spéciales et de l’actualité d’Alpine.
Gracias por adquirir este producto Alpine. Con solo unos pocos pasos podrá proteger su producto,
registrándolo a través de la siguiente dirección: www.alpine-usa.com/registration.
Recibirá información sobre nuevos productos y software, promociones especiales y novedades
sobre Alpine.
• OWNER’S MANUAL
Please read before using this equipment.
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
• MODE D’EMPLOI
Veuillez lire avant d’utiliser cet appareil.
2-EN
Operating Instructions
PRECAUTIONS
IMPORTANT INFORMATION ............................. 5
WARNING
Points to Observe for Safe Usage .............................5
WARNING ......................................................... 5
CAUTION .......................................................... 6
NOTICE ............................................................. 7
Getting Started
Location of Controls ................................................. 9
Turning Power On or O ......................................... 9
Turning the System On ............................................9
Adjusting the Volume ...............................................9
Lowering Volume Quickly .......................................9
Touch Screen Operation .........................................10
About the HOME Screen .......................................10
About the Indicator Display ..................................11
Radio
Radio Basic Operation
Listening to the Radio ............................................12
Presetting Stations Manually .................................12
Presetting Stations Automatically .........................12
Mode switching Settings ........................................12
Apple CarPlay (Optional)
Access to Apple CarPlay .........................................13
Android Auto
TM
(Optional)
What is Android Auto ............................................13
Activate Android Auto ...........................................13
USB Flash drive (Optional)
Playback ....................................................................15
Fast-forwarding/Fast-reversing
(USB Audio/Video) ............................................. 15
Repeat Play (USB Audio/Video) ...........................15
Shue Play (USB Audio/Video) ...........................15
Searching for a Desired Song/Video/Photo ......... 15
Slide Show (USB Photo) .........................................15
About USB List ........................................................15
iPod mode on iPhone (Optional)
Playback ....................................................................16
Searching for a Music File ...................................... 17
Repeat Play ...............................................................17
Shue Play ...............................................................17
SiriusXM® Satellite Radio Operation
(Optional)
Receiving Channels with the SiriusXM Tuner ....18
Tuning Channels by Category ...............................18
Checking the Sirius XM Radio ID Number ........19
Storing Channel Presets .........................................19
Tuning Channels Using Presets ............................. 19
SiriusXM List ...........................................................19
Selecting e Channel Directly ............................. 19
Parental Lock Function ..........................................19
Bluetooth
®
Operation
Setup Before Using .................................................. 20
About Bluetooth ..................................................20
About the Hands-free Phone .............................20
Before Using Bluetooth .......................................20
Hands-free Phone Control
Answering a Call .....................................................21
Hanging up the Telephone .....................................21
Calling .......................................................................21
Making a phone call using the Phone Menu ...21
Siri .............................................................................22
Phone Operation Screen ........................................23
Adjusting the Speech Volume ............................23
Changing the Voice Output ...............................23
DTMF (Touch-Tone) Function .........................23
Contents
3-EN
Phone Book Function ............................................. 23
Synchronizing the Phone Book .........................23
Bluetooth® Audio
Playback ....................................................................24
Repeat Play ...............................................................24
Shue Play ...............................................................24
AUX Operation (Optional)
AUX Operation .......................................................24
Camera Operation (Optional)
Camera Operation ..................................................25
Displaying the Camera Image
from the Menu screen .....................................25
Displaying the rear view video
while the car is in reverse ................................25
About the Rear Camera Guide ..............................25
Sound Boost and Lighting link (Optional)
Lighting Link Setting Operation ...........................26
Lighting Link settings Colors.............................27
Setup
Setup Operation ......................................................28
System Setup
Language Setup ........................................................28
Time Adjust Setup ................................................... 29
SiriusXM Setup ....................................................29
Parental Control ......................................................29
Clear Locked All ......................................................29
Changing the Lock Passcode .................................29
Version ...................................................................... 30
Product Information ............................................... 30
Updating the rmware version ..........................30
Soware License ......................................................30
Connection Status ...................................................30
SWC Adapter ...........................................................31
Steering Wheel Control .......................................... 31
DEMO MODE ......................................................... 32
Reset .......................................................................... 32
Screen/Lighting Setup
Dimmer ....................................................................32
Screen Color.............................................................33
Key Color .................................................................33
Sound Setup
Setting the Fader/Balance ................................... 33
Adjusting the Bass/Middle/Treble ..................... 34
Adjusting the Graphic Equalizer
Curve (EQ) .......................................................34
Setting an Equalizer ............................................34
Setting the Subwoofer .........................................35
Adjusting the Crossover Settings (X-Over) .....35
Adjusting the Time Correction (TCR) .............35
Setting the Speaker Level .................................... 36
Setting Defeat .......................................................36
About the Crossover ...............................................36
About Time Correction .......................................... 37
Example 1. Listening Position:
Front Le Seat ..................................................37
Example 2. Listening Position: All Seats ..........37
Volume Setup
Volume Setup ........................................................... 38
Bluetooth Setup
Device List ................................................................38
Pairing the Bluetooth Device .............................38
Fast pairing the Bluetooth Device ..................... 38
Deleting a Bluetooth Device from the list ........38
Searching for a Bluetooth Device ...................... 38
Displaying Bluetooth Information ....................39
Auto Connection .................................................39
Downloading the Phonebook ............................ 39
Rear Camera Setup
Parking Guide Adjust Setup ...................................39
Video Setup ..............................................................40
Lighting Link ON/OFF
Information
About the Supported Formats ...............................42
About Audio Format ........................................... 42
About Video Format ...........................................42
About Photo Format ...........................................43
In Case of Diculty ................................................44
If this Message Appears ..........................................45
Specications ...........................................................47
4-EN
Installation and
Connections
WARNING ....................................................... 48
CAUTION ........................................................ 48
Precautions .................................................... 48
Accessory List ..........................................................49
Installation ...............................................................49
Caution concerning the installation
location .............................................................. 49
Mounting the Microphone ................................. 49
Installation example using the Original
Mounting Bracket ............................................49
Connections ............................................................. 50
If an ACC power supply is not available ...........52
System Example ....................................................... 53
OEM Steering Wheel Control Rentention .......54
LIMITED WARRANTY
5-EN
Operating Instructions
PRECAUTIONS
IMPORTANT INFORMATION
FCC COMPLIANCE STATEMENT
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide more reasonable protection
against harmful interference in a residential installation, and are
more stringent than “outdoor” requirements.
Operation is subjected to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may
cause undesired operation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, you are
encouraged to try to correct the interference by one of the following
measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the receiver.
•
Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
•
Consult an experienced radio/TV technician.
WARNING
Points to Observe for Safe Usage
•
Read this manual carefully before using this system components.
ey contain instructions on how to use this product in a safe
and eective manner. Alpine cannot be responsible for problems
resulting from failure to observe the instructions in this manual.
•
is manual uses various pictorial displays to show you how
to use this product safely and to alert you to potential dangers
resulting from improper connections and operation. Following are
the meanings of these pictorial displays. It is important to fully
understand the meanings of these pictorial displays in order to use
this manual and the system properly.
•
is product may be used with soware applications. Please follow
all usage instructions and warnings when using this product at
all times. Do not use this product or any soware application in a
manner which will hinder safe operation of your vehicle.
WARNING
• Operation of the system while driving is dangerous. Users
should stop vehicle before operating the software.
• Road conditions and regulations take precedence over
information contained on the map display: observe actual
trac restrictions and circumstances while driving.
• This software is designed for use exclusively in the unit.
It cannot and may not be used in conjunction with other
hardware.
WARNING
This symbol means important instructions. Failure
to heed them can result in serious injury or death.
INSTALL THE PRODUCT CORRECTLY SO THAT THE DRIVER CANNOT WATCH
TV/VIDEO UNLESS THE VEHICLE IS STOPPED AND THE PARKING BRAKE IS
APPLIED.
It is dangerous for the driver to watch TV/Video while driving
a vehicle. Installing this product incorrectly enables the driver
to watch TV/Video while driving. is may cause a distraction,
preventing the driver from looking ahead, thus causing an accident.
e driver or other people could be severely injured.
DO NOT WATCH VIDEO WHILE DRIVING.
Watching the video may distract the driver from looking ahead of
the vehicle and cause an accident
DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR ATTENTION AWAY
FROM SAFELY DRIVING YOUR VEHICLE.
Any function that requires your prolonged attention should only be
performed aer coming to a complete stop. Always stop the vehicle
in a safe location before performing these functions. Failure to do
so may result in an accident.
KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL HEAR OUTSIDE
NOISES WHILE DRIVING.
Excessive volume levels that obscure sounds such as emergency
vehicle sirens or road warning signals (train crossings, etc.) can be
dangerous and may result in an accident. LISTENING AT LOUD
VOLUME LEVELS IN A CAR MAY ALSO CAUSE HEARING
DAMAGE.
MINIMIZE DISPLAY VIEWING WHILE DRIVING.
Viewing the display may distract the driver from looking ahead of
the vehicle and cause an accident.
DO NOT DISASSEMBLE OR ALTER.
Doing so may result in an accident, re or electric shock.
USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.
(Check with your dealer if you are not sure.) Failure to do so may
result in re, etc.
6-EN
KEEP SMALL OBJECTS SUCH AS SCREWS OUT OF THE REACH OF
CHILDREN.
Swallowing them may result in serious injury. If swallowed, consult
a physician immediately.
USE THE CORRECT AMPERE RATING WHEN REPLACING FUSES.
Failure to do so may result in re or electric shock.
DO NOT BLOCK VENTS OR RADIATOR PANELS.
Doing so may cause heat to build up inside and may result in re.
USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.
Use for other than its designed application may result in re,
electric shock or other injury.
MAKE THE CORRECT CONNECTIONS.
Failure to make the proper connections may result in re or
product damage.
BEFORE WIRING, DISCONNECT THE CABLE FROM THE NEGATIVE BATTERY
TERMINAL.
Failure to do so may result in electric shock or injury due to
electrical shorts.
DO NOT ALLOW CABLES TO BECOME ENTANGLED IN SURROUNDING
OBJECTS.
Arrange wiring and cables in compliance with the manual to
prevent obstructions when driving. Cables or wiring that obstruct
or hang up on places such as the steering wheel, gear lever, brake
pedals, etc. can be extremely hazardous.
DO NOT SPLICE INTO ELECTRICAL CABLES.
Never cut away cable insulation to supply power to other
equipment. Doing so will exceed the current carrying capacity of
the wire and result in re or electric shock.
DO NOT DAMAGE PIPE OR WIRING WHEN DRILLING HOLES.
When drilling holes in the chassis for installation, take precautions
so as not to contact, damage or obstruct pipes, fuel lines, tanks or
electrical wiring. Failure to take such precautions may result in re.
DO NOT USE BOLTS OR NUTS IN THE BRAKE OR STEERING SYSTEMS TO
MAKE GROUND CONNECTIONS.
Bolts or nuts used for the brake or steering systems (or any
other safety-related system), or tanks should NEVER be used for
installations or ground connections. Using such parts could disable
control of the vehicle and cause re etc.
DO NOT INSTALL IN LOCATIONS WHICH MIGHT HINDER VEHICLE
OPERATION, SUCH AS THE STEERING WHEEL OR GEARSHIFT.
Doing so may obstruct forward vision or hamper movement etc.
and results in serious accident.
CAUTION
This symbol means important instructions. Failure
to heed them can result in injury or material
property damage.
HALT USE IMMEDIATELY IF A PROBLEM APPEARS.
Failure to do so may cause personal injury or damage to the
product. Return it to your authorized Alpine dealer or the nearest
Alpine Service Center for repairing.
HAVE THE WIRING AND INSTALLATION DONE BY EXPERTS.
e wiring and installation of this unit requires special technical
skill and experience. To ensure safety, always contact the dealer
where you purchased this product to have the work done.
USE SPECIFIED ACCESSORY PARTS AND INSTALL THEM SECURELY.
Be sure to use only the specied accessory parts. Use of other
than designated parts may damage this unit internally or may not
securely install the unit in place. is may cause parts to become
loose resulting in hazards or product failure.
ARRANGE THE WIRING SO IT IS NOT CRIMPED OR PINCHED BY A SHARP
METAL EDGE.
Route the cables and wiring away from moving parts (like the seat
rails) or sharp or pointed edges. is will prevent crimping and
damage to the wiring. If wiring passes through a hole in metal, use
a rubber grommet to prevent the wire’s insulation from being cut
by the metal edge of the hole.
DO NOT INSTALL IN LOCATIONS WITH HIGH MOISTURE OR DUST.
Avoid installing the unit in locations with high incidence of
moisture or dust. Moisture or dust that penetrates into this unit
may result in product failure.
7-EN
NOTICE
Product Cleaning
Use a so dry cloth for periodic cleaning of the product. For more
severe stains, please dampen the cloth with water only. Anything
else has the chance of dissolving the paint or damaging the plastic.
Temperature
Be sure the temperature inside the vehicle is between +45°C
(+113°F) and 0°C (+32°F) before turning your unit on.
Maintenance
If you have problems, do not attempt to repair the unit yourself.
Return it to your Alpine dealer or the nearest Alpine Service Station
for servicing.
Protecting the USB connector
•
Only an Phone or USB ash drive can be connected to the USB
connector on this unit. Correct performance using other USB
products cannot be guaranteed.
•
If the USB connector is used, be sure to use only the supplied
connector cable with the unit. A USB hub is not supported.
•
Depending on the connected USB ash drive, the unit may not
function or some functions may not be performed.
•
e audio le format that can be played on the unit is MP3/
WMA/WAVE/AAC/FLAC/Ogg/APE.
•
Artist/song name, etc., can be displayed. Certain, special
characters may not be correctly displayed.
CAUTION
Alpine accepts no responsibility for lost data, etc., even if data, etc., is
lost while using this product.
On Handling USB Flash drive
•
is unit can control a memory storage device that supports
the USB Mass Storage Class (MSC) protocol. Playable audio le
formats are MP3, WMA, AAC,WAVE,APE,OGG and FLAC.
•
USB Flash drive function is not guaranteed. Use a USB ash
drive according to the terms of agreement. Read the USB ash
drive Owner’s Manual thoroughly.
•
Avoid usage or storage in the following locations:
Anywhere in the car exposed to direct sunlight or high
temperatures.
Anywhere the possibility of high humidity or corrosive
substances are present.
•
Fix the USB ash drive in a location where driver operation will
not be hindered.
•
USB Flash drive may not function correctly at high or low
temperature.
•
Use only certied USB ash drive. Note that even certied USB
ash drive, may not function correctly depending on its type or
state.
•
Depending on the settings of the USB ash drive type, memory
state or encoding soware, the unit may not play back or display
properly.
•
USB Flash drive may take time to start playback. If there is a
particular le other than audio in the USB ash drive, it may
take considerable time before the le is played back or searched.
•
e unit can play back“mp2”, “mpa”“mp3”“m4a”, “wma”, “m4a”,
“ac”/”a”,“wav”“ogg”“ape”le extensions.
•
Do not add the above extensions to a le other than audio
data. is non-audio data will not be recognized. e resulting
playback may contain noise that can damage speakers and/or
ampliers.
•
It is recommended to back up important data on a personal
computer.
•
Do not remove the USB device while playback is in progress.
Change SOURCE to something other than USB, then remove
the USB device to prevent possible damage to its memory.
8-EN
•
Windows Media and the Windows logo are trademarks, or registered
trademarks of Microso Corporation in the United States and/or other
countries.
•
Apple, iPhone, iPod, iPod nano, iPod touch, iPad, Lightning and Siri
are trademarks of Apple Inc., registered in the U.S. and other countries.
Apple CarPlay is a trademark of Apple Inc.
•
Use of the Made for Apple and Works with Apple badges means
that an accessory has been designed to connect specically to the
Apple product(s) identied in the Made for Apple badge and to
work specically with the technology identied in the Works with
Apple badge, and has been certied by the developer to meet Apple
performance standards. Apple is not responsible for the operation of
this device or its compliance with safety and regulatory standards.
•
Please note that the use of this accessory with an Apple product may
aect wireless performance.
•
Use of the Apple CarPlay logo means that a vehicle user interface meets
Apple performance standards. Apple is not responsible for the operation
of this vehicle or its compliance with safety and regulatory standards.
Please note that the use of this product with iPhone may aect wireless
performance.
•
SiriusXM and all related marks and logos are trademarks of Sirius XM
Radio Inc. All rights reserved.
•
Google, Android, Google Play and Android Auto are trademarks of
Google LLC.To use Android Auto on your car display, you'll need an
Android Auto compatible vehicle or aermarket stereo, an Android
phone running Android 6.0 or higher, and the Android Auto app.
•
e Bluetooth® word mark and logos are registered trademarks owned
by the Bluetooth SIG, Inc. and any use of such marks by Alpine
Electronics, Inc. is under license.
•
MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS
and omson. Supply of this product only conveys a license for private,
non-commercial use and does not convey a license nor imply any right
to use this product in any commercial (i.e. revenue-generation) real
time broadcasting (terrestrial, satellite, cable and/or any other media),
broadcasting/streaming via internet, intranets and/or other networks
or in other electronic content distribution systems, such as pay-audio or
audio-on-demand applications. An independent license for such use is
required. For details, please visit
http://www.mp3licensing.com
9-EN
Getting Started
Location of Controls
When system is powered o ,Short/long touch any button to turn the
power on.
A
/ (DOWN/UP) button
Touch to adjust the volume.
Touch and hold this button for at least 1.7 second to adjust the
volume to maximum or minimum
B
(MUTE) button
• Touch to activate/deactivate the mute mode.
• Touch and hold this button for at least 1.7 second to display
on/o
C
(HOME)/(Power O) button
Activates the HOME screen.
Touch and hold this button for at least 1.7 second to turn the
power o.
D
(Phone) button
Activates the Phone screen.
E
button
• When phone is connected to CarPlay, touch this button to
activate Siri
• When phone is connected to Android Auto ,touch this button
to activate VR
• When Siri is activated, the function of Siri is available
• When VR is activated, the VR setting is ON and the function of
VR is available
• When the CarPlay/Android Audio is disconnected ,the
operation in this button is invalidate
• When CarPlay/Android Audio is disconnected, touch and
long hold to enter into the Device Searching List to activate
the new device searching
E
(Reset) button
Reset& Restart.
About the button descriptions used in this Owner’s
Manual
The buttons found on the face of the unit are expressed in bold
(e.g.
(HOME)). The buttons found on the touch-screen display
are shown in bold within brackets, [ ] (e.g. [ ]).
Turning Power On or O
Some of this unit’s functions cannot be performed while the vehicle is
in motion. Be sure to stop your vehicle in a safe location and apply the
parking brake, before attempting these operations.
1
Turn the ignition key to the ACC or ON position.
The system turns on.
•
When turned on, the system displays the last screen that was
displayed before the ignition key was turned o. For example,
if the unit is in radio mode when ignition is turned o, it will
remain in radio mode when ignition is turned back on.
2
Touch and hold the (HOME)/(Power O) button for
at least 1.7 second to turn the power o.
•
When the system is used for the rst time, the language selection menu
is displayed. Select the desired language, and then touch [OK].
•
e unit can be turned on by touching the [
] (HOME) button,
[ ] button [ ] button [ ] button or [ ] (Phone) button.
•
e unit is a precision device. Careful handling of the unit should
provide you with years of trouble-free operation.
Turning the System On
When the system is used for the rst time, the language selection menu
is displayed.
Select a language, and then touch [OK].
•
Some of this unit’s functions cannot be performed while the vehicle is
in motion. Be sure to stop your vehicle in a safe location and apply the
parking brake before attempting these operations.
Adjusting the Volume
Adjust the volume by touching
/
Volume decreases increases continuously by touching and holding
/
Volume: 0 - 35
Lowering Volume Quickly
Audio Mute function instantly lowers the volume level to 0.
1
Touch the (MUTE) button to activate the MUTE mode.
The audio level will be 0.
2
Touching the (MUTE) button again will bring the
audio back to its previous level.
10-EN
Touch Screen Operation
You can operate the system by using the touch panel on the screen.
•
Be sure to touch the onscreen button lightly with the pad of your nger
to avoid scratching the display.
Touch a button or list item on the screen lightly.
About the HOME Screen
In the HOME screen, you can select the audio source and perform
various setups or operations on the unit.
Touch the
(HOME) button.
The HOME screen is displayed.
HOME screen example (Page1)
HOME screen example (Page2)
Radio Displays the Radio main screen (page 12).
Apple CarPlay You can use Apple CarPlay (page 13).
Android Auto You can use Android Auto (page 13).
USB You can play back music les, video les and
photo les stored in a USB ash drive (page
14).
• If a USB ash drive is not connected, this
widget is not available.
iPod Displays the iPod main screen (page 16)
• If an iPhone is not connected, this widget is
not available.
SiriusXM Displays the SiriusXM main screen (page 18).
• If a SiriusXM Tuner (Optional) is not
connected, this widget is not available.
Bluetooth Audio Displays the Bluetooth Audio main screen
(page 23).
Phone Displays the Phone main screen (page 23).
AUX Displays the AUX main screen (page 24).
Camera Displays the Camera main screen (page 25).
11-EN
About the Indicator Display
e Indicator Bar at the top of the screen displays various types of
information, like the current time.
A
Sound Boost.
You can turn theSound Boost (page 26).
B
Lights up when connected to a Bluetooth compatible
device.
• Sets ash when Bluetooth disconnected
C
Indicates the battery level of the connected Bluetooth
device.
Battery
Level
Level 3 Level 2 Level 1 No Battery
Icon
This may not be displayed depending on the connected
Bluetooth device.
D
Indicates the signal strength level of the connected
Bluetooth compatible device.
Displayed when Bluetooth setting is ON.
0 1 2 3 4 5
E
Indicates the current time.
You can switch between the 12 hour display and 24 hour display
options (page 29).
F
Setup
Click to enter the Settings
G
Display SiriusXM signal level
0 1 2 3
H
Indicates the volume on/o status.
12-EN
Radio
Radio main screen example
A
Band button
Switches a band.
B
Preset button
Displays the preset stations with a short touch.
Touch for at least 1.5. second to memorise the current station as
a preset station.
C
Plays each preset station for about 10 seconds.
D
Scan and memorises active stations automatically
E
Touch [
] [ ] to select the station seek up or seek
down respectively
Touch [
] [ ] to change the radio frequency up or down
respectively.
Operate in manual mode
F
Switch Local mode/Manual mode/DX mode
Seek up [
]
Seek up: From the current station ,seek forward according to the
specied step unit ,
After selecting a active station, then play If no active station, will keep
searching
Seek down [
]
Seek down: From the current station ,seek down according to the
specied step unit ,
After selecting a active station, then play If no active station, will
keep searching
Radio Basic Operation
Listening to the Radio
1
Touch the (HOME) button and select radio mode.
The display shows the radio mode screen.
2
Select the desired band from [FM1] / [FM2] / [FM3] /
[AM1]/[AM2].
3
Touch [ ], [ ] [ ], [ ] to adjust the radio
frequency.
Presetting Stations Manually
1
Tune in a desired radio station you wish to store in the
preset memory by manual or automatic seek tuning.
2
Touch and hold the Preset number you want to store for
at least 1.5 second.
The selected station is stored.
3
Repeat the procedure to store up to 5 other stations
onto the same band.
To use this procedure for other bands, simply select the desired
band and repeat the procedure.
A total of 30 stations can be stored in the preset memory (6
stations for each band; FM1, FM2, FM3, orAM1,AM2).
•
If a preset memory has already been set in the same preset number, it
will be cleared and the new station will be memorized.
Presetting Stations Automatically
From the start Frequency ,scan upon the step unit (+1) and store the
validated station ,Aer one cycle, store the station from low frequency
to high frequency
Touch [ A.MEMO] go to Scan for stations and store valid
stations
•
If a valid station is scanned, it is not required to play, the screen display
"scanning" during the scanning process and will automatically switch to
the rst stored station on FM1
Mode switching Settings
Setting item:
Manual/DX(Initial setting)/Local
Setting contents:
Manual mode:manually scanning station
DX mode: When select the DX mode and start to search ,it will be
performed until the next or previous valid station, if no valid station
is searched, the search continues
Local mode: When select the local mode and start to search ,it will be
performed until the next or previous valid station, if no valid station
is searched, the search continues
•
:By default, Dx mode is used. e Local mode stop sensitivity is
increased by 30db over Dx under AM and FM
13-EN
Apple CarPlay
(Optional)
Apple CarPlay is a smarter, safer way to use your iPhone in the car.
Apple CarPlay takes the things you want to do with your iPhone while
driving and puts them right on the unit. You can get directions, make
calls, send and receive messages, and listen to music, all in a way that
allows you to stay focused on the road. Just plug in your iPhone to the
unit and go.
•
Before using this function, plug in your iPhone using Lightning to USB
Cable (Supplied with iPhone) to the unit.
•
Some functions may not be available while driving.
•
About iPhone models usable with this unit, see “iPod mode on iPhone
(Optional)” (page 16). Only an iPhone 6 or later compatible with
Apple CarPlay function.
Access to Apple CarPlay
1
Touch the (HOME) button.
The HOME screen is displayed.
2
Touch [Apple CarPlay].
The Apple CarPlay screen is displayed.
Touch the desired App icon on the unit, or use Siri function by
touching the
button.
•
When a used iPhone 6 or later is reconnected, touch the pop-up
message-“Apple CarPlay connected.” within 5 seconds to access to Apple
CarPlay screen.
•
e App must be Apple CarPlay compatible in order to appear in the
Home screen.
Android Auto
TM
(Optional)
What is Android Auto
Android Auto is designed to make it easier to use apps from your phone
while you’re on the road. Navigate with Google Maps, listen to Playlists
or Podcasts from your favorite apps, and more.
Activate Android Auto
Download the Android Auto App from the Google Play Store before
continuing.
Just plug in your smartphone to the unit’s USB connector, then follow
the prompt to pair your smartphone with the unit.
•
e connected smartphone with Android Auto will disconnect other
phone’s Bluetooth connection and pair to the unit.
1
Touch the (HOME) button.
The HOME screen is displayed.
2
Touch [Android Auto].
The Android Auto screen is displayed.
•
You can make a call, use voice recognition function and Android Auto’s
compatible navigation app, etc,.
•
Only Google approved apps with necessary driver-safety measures in
place can be used.
14-EN
USB Flash drive
(Optional)
You can play back music les (WAVE.WMA.AAC.MP3.OGG.FLAC.
APE), video les (AVI,MPEG 1/2,MPEG4,WMV,Flash,QuickTime,ASF,
Matroska Video,TS Stream,3GP) and photo les (JPG,JPEG,PNG,BMP)
stored in a USB ash drive on the internal player of this system.
WARNING
It is dangerous for the driver to watch video while driving
the vehicle. The driver may be distracted from looking
ahead and an accident could occur.
Install the unit correctly so that the driver cannot watch
a video unless the car is stopped and the parking brake is
applied.
If the unit is not installed correctly, the driver will be able
to watch a video while driving and may be distracted
from looking ahead and cause an accident. The driver or
other people could be severely injured.
USB Audio mode screen
USB Video mode screen
USB Photo mode screen
A
Artwork display
B
Information display
C
Elapsed time/Total time for playing
D
Displays the USB List screen
E
Shue mode
F
[
] repeat_o, [ ] repeat_folder, [ ] repeat_one,
[ ] repeat_all,
G
Finds the beginning of next chapter//Fast-forwards when
touched for at least 2 second
H
Pause and Play
I
Finds the beginning of the current le/Finds a previous le
within 1 second after playback starts/Fast-reverses when
touched for at least 2 second
J
Video information display
K
Video Setup display
L
Photo information display
M
Rotate mode
•
For your safety, video is not displayed and only audio can be heard
while driving.
15-EN
Playback
1
Touch the (HOME) button and select USB mode.
The display shows the USB mode screen.
2
Touch [ ] (Search).
3
Select the desired mode.
: USB Audio mode
: USB Video mode
: USB Photo mode
4
Touch [ ] or [ ] to select the desired track(le).
Returning to the beginning of the previous track (le):
Touch [ ].
Fast reverse the current track :
Touch and hold 2s [
].
Advancing to the beginning of the next track (le) :
Touch [
].
Fast forward the current track :
Touch and hold 2s [
].
3
To pause playback, touch [ ] .
Touching [
] again will resume playback.
•
e playback time may not be correctly displayed when a VBR (Variable
Bit Rate) recorded le is played back.
•
If there is tag information, artist name/album name/track name is
displayed.
•
If there is no label information, no name is displayed.
•
ID3 tag/WMA tag
If an MP3/WMA/AAC/FLAC/WAVE/Ogg/APE le contains ID3 tag/
WMA tag information, the ID3 tag/WMA tag information is displayed.
(e.g., song name, artist name, and album name)
Fast-forwarding/Fast-reversing (USB Audio/
Video)
During playback, touch and hold [
] (Fast-reverse) or
touch and hold [ ] (Fast-forward).
Touch and hold for more than 2 second to fast-forward/fast-reverse.
•
Fast-reverse Speed:
touch [
] to change the speed, x4 x10 x32 o
•
Fast-forward Speed:
touch [
] to change the speed, x4 x10 x32 o
Repeat Play (USB Audio/Video)
1
Touch [ ].
•
e [
] button displays the currently selected mode.
2
Select your desired Repeat mode.
ALL
: All les are repeatedly played back.
One
: Only the le currently playing is repeatedly played back.
Folder : Only les in a folder are repeatedly played back.
OFF : Repeat mode is O.
Shue Play (USB Audio/Video)
1
Touch [ ].
•
e [
] button displays the currently selected mode.
2
Shue mode is only valid in [ ] [ ] [ ].
3
When in [ ] touch [ ], automatically switch [ ].
Searching for a Desired Song/Video/Photo
1
Touch [ ] (Search).
2
Select the desired mode.
: USB Audio mode
: USB Video mode
: USB Photo mode
3
Touch [ ] or [ ] to select the folder.
4
Touch your desired File name.
When you select a Folder name, repeat the same procedure to select
another Folder name or File name.
Slide Show (USB Photo)
e Slide Show shows photos that change every 5 seconds.
To pause playback, touch [
]
Touching [
] again will resume playback.
About USB List
You can select the desired mode
•
Each page displays up to 5 les . if you want to view more than 5 les,
swipe down or touch alphabet to search
About order
Display and sort according to the head character
Display in the order of 1 -> 2 -> 3 below.
0: Folder :When there are folders ,the folders are displayed ahead of
the les
1: Number ( represented by "#" on the Right Search Bar )
2: English Alphabet
3: Shorting order of Unicode
Right Search Bar (order of list )
1: Number ( represented by "#" on the Right Search Bar )
2: English Alphabet
•
Search only the les with numeric or English alphabetic headers
16-EN
iPod mode on iPhone
(Optional)
Before using this function, plug in your iPhone using a Lightning-USB
cable (supplied with iPhone) to the unit,
•
is unit does not support video playback from iPhone which connected
to this unit via USB Connector.
•
Internet or telephone function, etc., of the iPhone is not controllable
from the unit, but these functions can be controlled using the iPhone
itself.
About iPhone models usable with this unit
• The following devices have been tested and shown to work
with this unit. Correct function of earlier versions cannot be
guaranteed.
iPhone 14 Pro Max, iPhone 14 Pro, iPhone 14 Plus, iPhone 14, iPhone
SE (3rd generation), iPhone 13 Pro Max, iPhone 13 Pro, iPhone 13,
iPhone 13 mini, iPhone 12 Pro Max, iPhone 12 Pro, iPhone 12, iPhone
12 mini, iPhone SE (2nd generation), iPhone 11 Pro Max, iPhone
11 Pro, iPhone 11, iPhone XS Max, iPhone XS, iPhone XR, iPhone X,
iPhone 8 Plus, iPhone 8, iPhone 7 Plus, iPhone 7, iPhone SE, iPhone
6s Plus, iPhone 6s, iPhone 6 Plus, iPhone 6
iPod main screen example
A
Artwork display
B
Information display*
C
Elapsed time/Total time for playing Repeat mode
D
Displays the iPod List screen
E
Shue mode
F
[
]repeat_o, [ ]repeat_one, [ ]repeat_all,
G
Finds the beginning of next chapter/Fast-forwards
When touched for at least 2 second
H
Pause and Play
I
Finds the beginning of the current le/Finds a previous
lewithin 1 second after playback starts/Fast-reverses when
touched for at least 2 second
*
Podcast mode.
Playback
1
Touch the
(HOME) button and select iPod mode.
The display shows the iPod mode screen.
2
Touch [ ] or [ ] or to select the desired track (le).
Returning to the beginning of the previous track (le):
Touch [
].
Fast reverse the current track :
Touch and hold 2s [
].
Advancing to the beginning of the next track (le) :
Touch [
].
Fast forward the current track :
Touch and hold 2s [
].
3
To pause playback, touch [ ].
Touching [
] again will resume playback.
•
If a song is playing on the iPhone before it is connected to the unit, it
will continue playing when it is connected.
•
An episode may have several chapters. e chapter can be changed by
touching [
] or [ ].
•
If the artist, album or song name, created in iTunes, has too many
characters, songs may not be played back when connected to the
unit. erefore, a maximum of 255 characters is recommended. e
maximum number of characters for the unit is 255.
•
Some characters may not be correctly displayed.
17-EN
Searching for a Music File
<Music Search Menu>
Hierarchy 1 Hierarchy 2 Hierarchy 3 Hierarchy 4
Radio — — —
Playlists Songs — —
Artists Albums Songs —
Albums Songs — —
Songs — — —
Genres Artists Albums Songs
Composers Albums Songs —
Podcasts Episodes — —
Audiobook — — —
For example: Searching by Artist name
e following example explains how an Artists search is performed.
1
Touch [ ] (Search) during playback.
2
Touch [Artists].
The Artists search screen is displayed.
3
Select the desired artist.
4
Touch the desired album’s name.
All songs of the selected album are displayed
5
Touch the desired song’s name.
The selected song is played back.
•
If you touch [
], the category browsing mode screen is displayed.
Repeat Play
1
Touch [ ].
•
e [
] button displays the currently selected mode.
2
Select your desired Repeat mode.
ALL
: All les are repeatedly played back.
One
: Only the le currently playing is repeatedly played back.
OFF
: Repeat mode is O.
Shue Play
1
Touch [ ].
•
e [
] button displays the currently selected mode.
2
Shue mode is only valid in[ ][ ][ ].
3
When in [ ] touch [ ] ,automatically switch[ ].
18-EN
SiriusXM® Satellite
Radio Operation
(Optional)
SiriusXM Tuner operation:
When an optional SiriusXM Tuner is connected to this unit, the
following operations may be performed.
SiriusXM main screen example
A
Band button
Switches a band.
B
Tune
Select the specied channel manually
C
Information display
channel name, Artist Basic, Song Basic, Cat name
D
Preset buttons
Displays the preset channels with a short touch.
Touch for at least 1.5 second to memorize the current channel
as a preset channel.
Select the channel number
E
Displays the SiriusXM setup screen
F
Displays the SiriusXM List screen
All channel:Displays all channel
Category:Select channel category
Tune:Select the specied channel manually
G
Changes to the next channel
H
Changes to the previous channel
Receiving Channels with the SiriusXM Tuner
About SiriusXM Satellite Radio
Only SiriusXM brings you more of what you love to listen to, all in one
place. Get over 140 channels, including commercial-free music plus
the best sports, news, talk, comedy and entertainment. Welcome to the
world of satellite radio. A SiriusXM Vehicle Tuner and Subscription are
required. For more information, visit www.siriusxm.com.
In the USA, you can activate online or by calling SiriusXM Listener
Care:
•
Visit www.siriusxm.com/activatenow
•
Call SiriusXM Listener Care at 1-866-635‐2349
For Canadian Subscriptions, please contact:
•
Visit www.siriusxm.ca/activate
•
Call SiriusXM Customer Care at 1-888-539-7474
•
e SiriusXM Satellite Radio controls on this unit are available only
when a SiriusXM Tuner is connected.
1
Touch the (HOME) button and select SiriusXM mode.
The display shows the SiriusXM mode screen.
2
Touch [ ] or [ ] to select the desired channel.
Touching and holding either button will rapidly browse
through the channels.
•
Refer to the SiriusXM Tuner User Guide for details on how to install
the SiriusXM Tuner.
Tuning Channels by Category
Channels are grouped into categories based on the type of content heard
on the channels.
1
Touch [ ] or [ ] to select the category browsing mode.
The channels within the category of the current channel are
listed.
Category browsing mode screen example
2
Select the desired channel.
19-EN
Checking the Sirius XM Radio ID Number
To subscribe to the SiriusXM Satellite Radio service, it is necessary to
locate and identify the Radio ID of your SiriusXM Tuner. You can check
the Radio ID on the bottom surface of the SiriusXM Tuner box. You can
also check it from this unit by performing the following procedure.
1
While receiving SiriusXM Radio, touch [ ] or [ ] to
select channel “0”.
The unit displays the Radio ID number.
2
To cancel the Radio ID number display, change the
channel to a channel other than “0”.
•
e SiriusXM Radio ID does not contain the letters I, O, S, or F.
Storing Channel Presets
You can store 18 of your favorite SiriusXM channels for easy recall with
Preset buttons.
1
Long press the Preset number you can store the channel.
A maximum of 6 channels can be displayed on a page.
2
Repeat the procedure to store up to 17 other channels.
A total of 18 channels can be stored in the preset memory.
•
If you store a new channel into a preset which already has a channel
assigned, the current channel will be cleared and replaced with the new
one.
Tuning Channels Using Presets
Touch any one of the Preset numbers you have already
stored in the Preset mode screen.
The preset channel is received.
SiriusXM List
1
Touch [ ] .
The list screen appears.
List item:All Channels / Category Name*/Tune
*
e Category name for the channel currently being received is displayed.
•
You can switch the category by touching [
] or [ ] on the List screen
aer selecting a Search item.
List by ALL Channel
2
Touch [ ].
All Channels will be displayed in a list.
3
Touch the selected channel.
The channel you selected is received.
Searching by Category
2
Touch Category Name.
The channels within the category of the current channel are
listed.
3
Touch the selected channel.
The channel you selected is received.
Selecting The Channel Directly
1
Touch [ ]or[ ].
The numeric keypad input screen is displayed.
2
Touch to input the channel number.
3
Touch [OK].
The selected channel is received.
Parental Lock Function
e Parental Control feature allows you to limit access to any SiriusXM
channels, including those with mature content. When enabled, the
Parental Control feature requires you to enter a passcode to tune to
the locked channels. For information on setting the Parental Control
passcode, see “Parental Control” (page 29).
When a locked channel is selected, “Channel [xxx] Locked” is displayed
and then the numeric keypad appears for you to enter the passcode.
Input the 4-digit passcode you set in “Parental Control” (page
29).
The initial number is 0000.
•
If you input a wrong passcode, “Incorrect Pass Code entered” is
displayed.
•
Aer entering the correct passcode, you can access all locked channels
without entering the passcode again until the unit is powered o and
then back on.
20-EN
Bluetooth
®
Operation
Setup Before Using
About Bluetooth
Bluetooth is a wireless technology allowing communication between a
mobile device or personal computer over short distances. is enables
a hands-free call or data transmission between Bluetooth compatible
devices. Bluetooth transmission is available in the unlicensed 2.4 GHz
spectrum if the distance between devices is within 10 meters. For
details, refer to the Bluetooth website (http://www.bluetooth.com/).
•
Depending on the Bluetooth version, a Bluetooth compatible device
may not be able to communicate with this unit.
•
Proper function of this unit with all Bluetooth compatible devices is not
guaranteed. For handling of the Bluetooth compatible device, consult
your Alpine dealer or Alpine website.
•
Depending on the surroundings, Bluetooth wireless connection may be
unstable.
•
When you place a call, or perform setup operations, be sure to stop
your car in a safe place.
•
Depending on the connected Bluetooth compatible device(s), the
function may dier. Also refer to the Owner’s Manual of the connected
device(s).
About the Hands-free Phone
Hands-free calls are possible when using a HFP (Hands-Free Prole)
compatible mobile phone with this unit.
•
Avoid performing a hands-free call in heavy trac or on narrow or
winding streets.
•
Close the windows while calling to reduce background noise.
•
If both calling parties are using hands-free devices, or the call is made
in a noisy location, diculty hearing the other person’s voice is normal.
•
Depending on telephone line conditions or certain mobile devices used,
voices may sound unnatural.
•
When using a microphone, speak as directly as you can into the
microphone to obtain the best sound quality.
•
Certain mobile phone features are dependent on the capabilities and
settings of your service provider’s network. Additionally, certain features
may not be activated by your service provider, and/or the provider’s
network settings may limit the feature’s functionality.
Always contact your service provider about feature availability and
functionality.
All features, functionality, and other product specications, as well as
the information contained in the Owner’s Manual are based upon the
latest available information and are believed to be accurate at the time
of printing.
Alpine reserves the right to change or modify any information or
specications without notice or obligation.
Before Using Bluetooth
Before using the hands-free phone/audio function, the following
settings need to be made.
Register a Bluetooth device in this unit.
•
See “Bluetooth Setup” (page 38).
•
You can search for this unit using a Bluetooth compatible device, and
then connect that Bluetooth compatible device to this unit. e device
name of this unit is “iLX-W670” and the initial number of the passcode
is “0000.” Also refer to the Owner’s Manual of the connected device(s).
Hands-free Phone Control
Touch [Bluetooth] in the HOME screen to display the Bluetooth menu
screen.
[Phone] button
Phone menu screen example
Recent Events list
You can display up to 100 items, such as phone numbers of
the most recent incoming calls, missed calls and outgoing
calls, and contact names that are registered in the Phone
Book. When 100 items exist in the list, the oldest item is
deleted when a further item is to be added.
Contacts list
You can make a phone call from the Phone Book, or edit the
Phone book.
Keypad screen
Use to type a phone number.
21-EN
Answering a Call
1
An incoming call triggers the ringtone and an incoming
call display.
Phone Incoming screen example
2
Touch [ ] (Call).
The call starts.
A
Touch[
]Display Keypad screen
B
Touch switch Car speaker[
]Or Phone speaker[ ]
C
Touch switch mute on/ o
D
Adjust the volume level
•
During a call, the audio for the current mode on the unit is muted.
Aer calling, playback will resume.
•
When the caller’s number is transmitted to the system, if the caller’s
name is stored in the phone book, the name is displayed. If the name is
not stored, the number is displayed.
•
Touch [Decline] to reject an incoming call.
Hanging up the Telephone
1
Touch [ ] End Call.
The call nishes.
Calling
Making a phone call using the Phone Menu
Entering a Phone Number to Make a Call
1
Touch [Keypad].
The number input screen (Keypad) appears.
Touch [ ] to delete an entered number.
2
Enter the phone number you wish to call.
•
You can enter up to 20 digits.
3
Touch [ ] (Call).
The phone call is started.
•
To change the Bluetooth device, see “Bluetooth Setup” (page 38).
Making a phone call from the Recent Events list
1
Touch [ ] to change to the Recent Events list screen.
2
Touch the name of the contact or number you want to
call.
The phone call is started.
Calling from the Contacts list (Phone Book)
1
Touch [ ] to change to the Contacts list screen.
2
Touch the name of the contact or number you want to
call.
22-EN
3
Touch the phone number.
The Phone Operation screen is displayed.
4
Touch the number you want to call.
The phone call is started
Siri
Establish iPhone Bluetooth connection and wake up Siri from phone ,
below interface will pop up and the voice output is from the unit.
23-EN
Phone Operation Screen
Adjusting the Speech Volume
You can adjust Mic. Level (Microphone Level).
Level 1:
Level 2: Level 3:
Changing the Voice Output
e voice output for calls is switchable between car speakers and the
mobile phone speaker.
Touch [
] or [ ].
DTMF (Touch-Tone) Function
Transmits a DTMF (Touch-Tone) during a call.
1
Touch [ ] (Keypad).
The number input screen (Keypad) appears.
2
Input number.
•
You can transmit a Touch-Tone signal during a call.
Phone Book Function
Phone Book screen example
A
Use to narrow down your search for names, etc.
B
You can synchronize the system’s phone book with the
mobile phone’s phone book.
Synchronizing the Phone Book
Touch [
].
Synchronization of the phone books starts.
•
You can store up to 1,000 registered name in the phone book.
•
You can store up to 5 phone numbers by one person’s name.
Bluetooth® Audio
If a Bluetooth compatible mobile phone, portable player, etc. is
connected by wireless, you can play back a song (operation is
controllable from the unit).
•
Operation may vary, depending on the Bluetooth compatible device
Bluetooth Audio main screen example
A
Default image display
B
Information display
C
Elapsed time/Total time for playing
D
Search device
E
Shue mode
F
[
]repeat_o,[ ]repeat_folder,[i ]repeat_one,
[ ]repeat_all
G
Finds the beginning of next chapter
H
Pause and Play
I
Finds the previous le
•
Song title/Artist title/Album title/Elapsed time do not display for
AVRCP Ver. 1.0.
•
To play back audio, a mobile phone or a portable player conforming to
A2DP (Advanced Audio Distribution Prole) or AVRCP (Audio/Video
Remote Control Prole) is required.
Not all functions work with all devices.
•
During a call, sound on the Bluetooth audio source is paused.
Compatible AVRCP versions: 1.0, 1.3, 1.4, 1.5, 1.6.2
•
Available functions may dier depending on the AVRCP version.
24-EN
Playback
1
Touch the (HOME) button and select Bluetooth
Audio mode.
The display shows the Bluetooth Audio mode screen.
2
Touch [ ] or [ ] to select the desired track (le).
Returns the beginning of the previous le:
Touch [
].
Advance to the beginning of the next le:
Touch [
].
3
To pause playback, touch [ ].
Repeat Play
Available for AVRCP Ver. 1.0, 1.3, 1.4, 1.5, 1.6.2.
1
Touch [ ].
•
[
] displays the currently selected mode.
2
Select your desired Repeat mode.
The selected Repeat mode changes the button.
ALL
:
Once all of the songs have nished playing, play back is
repeated, starting with the rst song.
One
:
Only the track currently playing is repeatedly played back.
OFF
: Repeat mode is O.
•
Operations may dier depending on the connected Bluetooth
compatible device.
Shue Play
Available for AVRCP Ver. 1.0, 1.3, 1.4, 1.5, 1.6.2.
Touch [
].
•
All songs in the Bluetooth compatible devices are played back in
random sequence. Any one song does not play back again until all
songs have been played back.
•
Operations may dier depending on the connected Bluetooth
compatible device.
AUX Operation
(Optional)
AUX Operation
•
rough AUX connection, you can display the videos or images output
from other devices
•
For safety , video image can not be displayed when vehicle is moving.
To view the video image ,please stop in a safe zone and apply the
parking brake.
•
A mini AV cable is required to make the connection (sold separately)
Further details are given in <<Installation Manual>>
AUX screen example
1
Touch [
].
2
Touch [AUX] Display AUX screen
25-EN
Camera Operation
(Optional)
Camera screen example
Setting item:
Display Reverse video
Setting contents:
Camera Guide O (Initial setting) / On
•
No impacts on other modes (except video ,video shall be
suspended,When playing the audio,the audio shall continue
playing),Switch to this scree,other modes to run in the background
Camera Operation
Displaying the Camera Image from the Menu
screen
1
Touch the (HOME)button.
The HOME screen is displayed
2
Touch [Camera].
•
Touch the screen while the camera image is being displayed, and touch
[
] to return to the main source screen or previous screen.
•
You can perform a Guide Adjustment for the rear view image. For
details, see “Rear Camera Setup” (page 39).
Displaying the rear view video while the car is
in reverse
1
Shift the gear lever to the reverse (R) position.
The rear view image is displayed while the car remains in
reverse.
2
If you shift the gear lever to a position other than
reverse (R), the monitor returns to the previous screen.
•
Never depend solely on the camera when backing up. Always turn and
look and only use the camera for additional assistance.
•
is function is eective when the reverse wire is properly connected.
•
You can perform a Guide Adjustment for the rear view image. For
details, see “Rear Camera Setup” (page 39).
About the Rear Camera Guide
Indication mark meaning
When the car is put into reverse gear, the monitor switches to the rear
view camera image. Guides appear to help visualize the car’s width and
distance from the rear bumper.
Car width extension marks (red, yellow and green in order of
distance)
If properly calibrated, the marks indicate the car’s width. This helps
guide the car’s path when backing up in a straight line.
The marks represent the distance from the rear of the car (from the
rear end of the bumper).
• The marks do not move in synchronization with the steering
wheel.
• Set the marks to suit the car’s width.
•
Depending on the condition of the car or road surface, the range of
vision may vary.
•
e camera has a limited range of vision. Objects at extreme angles to
the camera (e.g. under the bumper or at opposite ends of the bumper)
may not be in the its eld-of-vision.
•
e rear camera image may have a tint which is dierent from the
actual surroundings.
•
Depending on the car, the guidance may deviate to the right or le. is
is not a malfunction.
26-EN
Sound Boost
and Lighting link
(Optional)
A
Current screen On/O
B
Sub.Woofer On/O
Linkage with the Settings in sound (page 35)
C
Adjust Sub.Woofer Level
Linkage with the Settings in sound (page 35)
D
Sub.Woofer Phase
Linkage with the Settings in sound (page 35)
0° (Initial setting), 180°
E
Lighting Link setting
can change the LED color of the system model, the keyColor of
this unit, and the background color in tandem.
F
Displays sound setup icon
touch the icon to sound setup screen
G
Max Mid Bass On/O
Linkage with the Settings in sound (page 33)
H
Max Bass On/O
Linkage with the Settings in sound (page 33)
•
If Lightinglink is OFF in the settings, this icon will not be displayed (page
40).
Lighting Link Setting Operation
When operating the Lighting color of the system model with
Lightinglink, it is necessary to connect a model that supports
Lightinglink. Check the Alpine website for compatible models.
1
Touch [
].
2
Touch [ ]Display Sound Boost screen
3
Touch [ ] Display Lighting Link screen
Lighting Link screen example
A
LED On/O
LED OFF: Premium Direct Color and LED Brightness and LED
Lighting Speed, Other Color is grayed out and cannot be
selected. And the Lighting of the connected system turns o.
B
Select Premium Direct Color
Blue,Red,Amber,Green,White
Each Lighting color changes in conjunction. Please refer to page
27 for the changed parts and their colors.
C
Adjust LED Brightness
Adjusts the brightness level of the LEDs on Lightinglink-
enabled models
-3 - +3 Initial: 0
D
Adjust LED Light Blinking Speed
E
Select Other Color
Select Premium Direct Color or Dynamic mode
LED Brightness
Adjusts the brightness level of the LEDs on Lightinglink-enabled
models
Setting item:
LED Brightness
Setting contents:
-3~+3,0(Initial setting)
LED Lighting Speed
Adjusts the level of LED Light Blinking Speed for Lightinglink
compatible models
Setting item:
LED Lighting Speed
Setting contents:
-5~+5,0(Initial setting)
Other Color
•
Please connect the Lighting Link compatible model with the lighting
level and speed setting values set to 0.
27-EN
Lighting Link settings Colors
• Lighting Link has 8 modes.
Lighting Link
Setting Colors
Premium Direct color select
Other
colors
Dynamic
Mode
LED OFF
Red Blue Green Amber White 7 colors
Lighting Link
& Sound boost
background,
Sub.W Ring Color
Red Blue Green Amber White Rainbow1 Rainbow2 -
Key Color* Red Blue Green Amber White White White select
Background
Screen Color*
Red Blue Green Amber White White White User
*
key Color and Background Screen Color is linked when Lighting Link is ON. Please see page 33.
*
If you select a color with the Lighting Link function, it will all change to the selected color pattern regardless of
the current color settings for each.
*
BackgroundScreen color and keyColor can be changed individually aer setting Lighting Link (page 33).
• Lighting Link System model is option.
28-EN
Setup
Setup Operation
To display the Setup Menu screen:
Your vehicle must be parked with the ignition key in the ACC or ON
position. To do this, follow the procedures below.
1 Bring your vehicle to a complete stop at a safe location.
Engage the parking brake.
2 Release the parking brake. (For safety, release the parking
brake while depressing the foot brake pedal).
3 Engage the parking brake again.
•
For automatic transmission vehicles, place the transmission lever in
the Park position.
•
“Sound Setup” (page 33) can be set even not engaging the
parking brake.
Now, the locking system for the Setup operation has been released.
Engaging the parking brake can reactivate the Setup Menu, as long as
the car’s ignition has not been turned o. It is not necessary to repeat
the above procedure (1 through 3).
Each time the ignition is turned OFF, perform the above procedure.
1
Touch the (HOME) button.
The HOME screen is displayed.
[Setup] button
2
Touch [Setup]button.
The Setup main screen is displayed.
Scroll Bar
*
Touch [
] or [ ] to show further hierarchies.
3
Touch the required setting list, then touch the setting
item.
Setting items:
System: See “System Setup” (page 28).
Screen/Lighting: See “Screen//Lighting Setup” (page 32).
Sound: See “Sound Setup” (page 33).
Volume: See “Volume Setup” (page 38).
Bluetooth: See “Bluetooth Setup” (page 38).
Rear Camera: See “Rear Camera Setup” (page 39).
Lighting Link ON/OFF: See “Lighting Link” (page 40).
System Setup
[System] is selected on the Setup menu screen.
Setting item:
System
Setting contents:
Beep, Language, Time Adjust,SiriusXM, Product Information, Software
License, Connection Status, SWC Adapter, Steering Wheel Control, Demo
Mode, Reset
Beep Setup
You can change the volume of the sound heard when a button is
touched.
Setting item:
Beep
Setting contents:
O , On (Initial setting)
Language Setup
[Language] is selected on the System Setup Menu screen. e Setup
menu, feedback information, etc. for this unit can be changed to appear
in the selected language.
Setting item:
Language
Setting contents:
English (US),French,Spanish,Portuguese
•
e currently selected language is displayed.
29-EN
Time Adjust Setup
[Time Adjust] is selected on the System Setup Menu screen.
Time Format
Setting item:
Time Format
Setting items:
12h, 24h(Initial setting)
Time Zone
Setting item:
Time Zone
Setting contents
UTC-12.00h~UTC+14.00
Daylight saving Time ON/OFF
Setting item:
Daylight saving Time
Setting contents
O (Initial setting), On
SiriusXM Setup
Change Passcode
Setting item:
Change Passcode
Setting contents:
Edit the passcode.
1
Enter the current passcode and then touch [OK].
2
Enter the new passcode and then touch [OK].
3
Enter the conrm passcode and then touch [OK].
Parental Control
You can lock out channels with passcode protection. Channels that
are locked cannot be accessed without entering the passcode. You can
unlock a channel or change the passcode using this menu option.
Setting item:
Parental Lock On/O
1
Touch [Parental Control].
A passcode input screen is displayed.
2
Touch the numeric keypad to input a 4-digit passcode
The initial default 4-digit passcode is set to 0000.
After entering the digit, it is displayed as “
”.
Touch [Clear] to delete all entered numbers.
3
Touch [OK].
The channels list screen is displayed.
Setting the Lock status of individual channels
4
Touch [ Channels].
• To lock the channel,touch the appropriate channel.
• When you touch the locked channel,the channel is unlocked.
appears and the channel is locked.
Clear Locked All
Setting item:
Clear Locked All
Setting contents:
O (Initial setting) / On
•
Touch the switch,enter the current passcode then touch [OK].
•
All stations will be cleared when O. Locking again will change to ON
automatically
Changing the Lock Passcode
1
Touch [Change Passcode].
The numeric keypad screen is displayed.
2
Use the keypad to enter the current (old) 4-digit
passcode, and then touch [OK].
The initial passcode is set to “0000.”
After entering the digit, it is displayed as
.
Touch [Clear] to delete all entered numbers.
3
Use the keypad to enter the new 4-digit passcode, and
then touch [OK].
4
Use the keypad to enter the new 4-digit passcode a
second time to verify it, and then touch [OK].
Remember to keep a note of the passcode in a safe place in case
you forget the code.
30-EN
Version
Setting item:
Version
Setting contents:
Model Brand,Model Number,Firmware Ver,HW Version.
Product Information
Setting item:
Model Number, MCU, SOC, Interface FW Version, Interface HW Version
Updating the rmware version
1
Download the rmware update le into your computer.
2
Inset a USB with FAT32 format into your computer,copy
the correct upgrade le to the root directory
3
Connect the USB storage device to this product.
4
Touch [setup]>[System setup]>
[Product Information]>[Update] .
The rmware update le information will be read
5
After readingTouch[Update]
Follow the on-screen prompts to update the rmware.
•
is product will reset automatically aer the rmware update is
completed if the update is successful.
•
If an error message on the screen,Repeat the preceding steps
Software License
[Soware License] Displaying the open source soware license.
Connection Status
GPS Antenna
• Display when there is an antenna [OK]
• Display without antenna [NOK]
Antenna: Yes Signal:0
Antenna: Yes Signal:1
Antenna: Yes Signal:2
Antenna: Yes Signal:3
Antenna: No
Positioning Status
• Display [position]: When there is positioning
• Display [Not Available]: When there is no positioning
• Display [Not Connected]: When the serial port of the GPS module
is not available
Installation
• Install and learn to successfully display [OK],
• No learning success display [NOK]
Speed Pulse
• Display pulse number "XXX" in unit time, and display "0" if not
obtained.
31-EN
SWC Adapter
Setting item:
SWC Adapter
Setting contents:
With Adapter (Initial setting)/ Without Adapter
With Adapter
• Select [With Adapter] from setup>System>SWC Adapter
• Fixed SWC is valid, learning SWC is invalid
“Steering Wheel Control” button is grayed out and invalid
• After selecting the “With Adapter”, the learned “Steering Wheel
Control” Settings are cleared
(Check with Third Party for compatible adapters.)
Some Vehicles may require a 3rd party module to achieve steering wheel
control functions (Sold Separately)
Without Adapter
• Select [Without Adapter] from setup>System>SWC Adapter
• Fixed SWC is invalid, learning SWC is valid
“Steering Wheel Control” button is valid
• After selecting the “Without Adapter”, the “Steering Wheel Control”
Settings are highlighted and can be clicked to access the Settings
Steering Wheel Control
Setting item:
Steering Wheel Control key learning
Setting contents:
Vol. Up/ Vol. Dn, ON HOOK, OFF HOOK,
Seek Up, Seek Dn, MUTE, Play/pause,
Voice Recognition, Source (Mode)
1
Please press and hold key for 2s at the same time don't
press SWC key within 2s
2
Follow the on-screen prompts to complete the operation
3
Key Learning Success:
When operation nished ,If you want to continue other key
learning , please repeat the operation
•
Please perform key learning while parked with e-brake active.
•
Keys only support learning 1 time. If you need to change the key please
clear all learned keys.
•
Touch the clear key to clear all the learned function.
•
No time limit for key learning.
32-EN
DEMO MODE
[Demo Mode] e images of the demo mode are pre stored in ash.
Execute loop playback, replace images every 8 seconds.
Setting contents:
On,O(Initial setting)
Entry condition
1 No operation screen within 120 seconds
If any situation occurs that causes page switching, button operation, or
touch operation, restart the timer after 120 seconds
Exit condition
1 During the playback of the demo mode, if it causes page
switching, button operation, or touch operation, the demo mode
will stop
2 In driving , if the demo mode is running, it stops running and
returns to the previous mode
•
Recommend switching it o when installing it on your vehicle
Reset
[Reset] is selected on the System Setup Menu screen. You can initialize
all data, to restore the factory settings.
Setting item:
Reset
1
Touch [Reset].
2
After the conrmation message appears, touch [Yes].
The system starts initialization.
•
Do not turn on/o the power, change the ignition key position or until
system restart is completed.
Screen/Lighting Setup
Setting item:
Screen/Lighting
Setting contents:
Dimmer,ScreenBrightness(Day),ScreenBrightness(Night), Screen Color, Key
Color
Dimmer
You can set day, night and auto three modes in dimmer
1. The screen backlighting brightness can be set in day/night mode
2. Auto Mode adjusts the backlighting brightness to the appropriate
day/night brightness setting value based on the current ambient
brightness
Setting contents:
Day,Night,Auto(Initial setting)
Day:
The backlight brightness is adjusted by setting the screen brightness
setting(Day)
Night:
The backlight brightness is adjusted by setting the screen brightness
setting(night)
Auto:
Automatically adjust the backlight brightness and select the
Screen brightness(Day) or Screen Brightness (Night) setting value
as the backlight brightness value based on the Day/Night lighting
threshold
Screen Brightness(Day)
Setting item:
Level
Setting contents:
1 to 32
Screen Brightness(Night)
Setting item:
Level
Setting contents:
1 to 32
33-EN
Screen Color
Setting item:
Background Picture
Setting contents:
You can set blue, red, amber, green, white ve colors or other background
pictures, you can also select the background picture to be set from the USB
ash drive
Setting item:
Background custom
1
Insert a USB ash drive.
2
Touch [ ] to the Wallpaper screen.
3
Select the custom picture.
Setting item:
Color Link (Key/Screen)
Setting contents:
Color link ON (Initial setting)
•
You can select ON/OFF whether the button light and background
picture linkage.
Key Color
Setting item:
Key Color
Setting contents:
blue, red, amber, green, white
•
Key color Settings can be set blue, red, amber, green, white ve colors
•
When the Color Link is ON, key Color is grayed out and cannot be
selected.
•
When the Lighting Link function is used, that selection takes precedence
and all colors are switched (page 27).
•
You can change the Key Color individually aer selecting the color with
the Lighting Link function.
Sound Setup
[Sound] is selected on the Setup menu screen.
You can set up items related to the sound quality.
<Setting item>
Fader/Balance (page 33)
Bass/Treble (page 34)
EQ Setting (page 34)
Preset EQ (page 34)
X-Over (page 35)
Speaker Level (page 36)
Time Correction (page 35)
Sub Woofer (page 35)
Defeat (page 36)
*
Touch [
] or [ ] to show further .
Setting the Fader/Balance
A
Back
Exit[Fader/Balance]Return [SOUND].
B
Close
Close the current screen and return to the source screen
C
Fader/Balance Image area
Touch the desired point within the image area, or touch [
],
[ ], [ ] or ].
Fader:
[15]Front to [15]Rear
Balance:
[15]Left to [15]Right
•
To reset to the initial setting (Fader: F=R, Balance: L=R), touch [
].
34-EN
Adjusting the Bass/Middle/Treble
Touch [ ] or [ ] for each item to be adjusted.
Setting item:
Bass, Middle, Treble
Setting contents:
-12 to 12 (Initial setting: 0)
•
To reset the initial setting (Bass: 0, Middle: 0, Treble: 0), touch [Flat].
•
When the Defeat setting is [On], you cannot perform the set up.
Adjusting the Graphic Equalizer Curve (EQ)
Setting item:
EQ
•
When the Defeat setting is [On], you cannot perform the set up.
1
Adjust the EQ to your preference.
Adjusting the Band
Touch [Band] to select the band to be adjusted.
Band1
Band2
•••
Band8
Band13
Band1
•
You can select a band directly by touching the screen.
Adjusting the Frequency
Touch of “Frequency” to adjust the frequency of the selected band
Adjustable frequency bands:
Band1: 50 Hz
Band2: 80 Hz
Band3: 125 Hz
Band4: 200 Hz
Band5: 315 Hz
Band6: 500 Hz
Band7: 800 Hz
Band8: 1.25k Hz
Band9: 2k Hz
Band10: 3.15k Hz
Band11: 5k Hz
Band12: 8k Hz
Band13: 12.5k Hz
Adjusting the Level
1
Select Band Slide up or down to adjust the level of
selected band.
Setting contents:
-12 to 12 (Initial setting: 0)
2
To adjust another band, repeat step 1, and adjust all
bands.
3
To store the adjusted setting value, touch and hold
[Preset 1], [Preset 2], or [Preset 3] for at least 2 seconds.
•
Band2, Band7 and Band12 are the same as the Bass and Middle
controls. For details on setting Bass and Treble, see “Adjusting the Bass/
Middle/Treble” (page 34).
•
Settings exceeding the frequency of adjacent bands are not available
•
While adjusting the EQ Setting, you should consider the frequency
response of the connected speakers.
•
When you apply the adjusted Band in the EQ setting screen,Preset EQ
(page 34) is unselected
•
Touch [Flat] to initialize all values.
Calling the EQ Setting adjusted value
Calling the pre-set EQ Setting adjusted value.
Touch [Preset 1], [Preset 2], or [Preset 3] on the EQ Setting
screen.
The setting stored in the Preset will be recalled.
Setting an Equalizer
6 typical equalizer settings are preset at the factory for a variety
of musical source material. You can also preset an equalizer by
customizing.
Setting item:
Preset EQ
Setting contents:
Flat (Initial setting), Hip Hop/R&B, Rock, Easy Listening, Pop, Bass Boost Mid
Bass Boost
•
When the Defeat setting is [On], you cannot perform the set up.
•
Only one type can be set .
•
you can set [preset1/preset2/preset3 ]in the EQ setting screen. (page
34)
•
When you set [preset1/preset2/preset3 ]in the EQ setting screen.(page
34). Preset EQ is unselected
35-EN
Setting the Subwoofer
Turning Subwoofer ON/OFF
If an optional subwoofer is connected to the unit, make the following
setting.
Setting item:
Sub Woofer
Setting contents:
O (Initial setting), On
Adjusting the Subwoofer Level
Setting item:
Level
Setting contents:
0 (Initial setting) to 15
•
is setting is only available when “Sub Woofer” is set to [On].
Setting the Subwoofer Phase
e subwoofer output phase is toggled Subwoofer Normal (0°) or
Subwoofer Reverse (180°).
Setting item:
Phase
Setting contents:
0° (Initial setting), 180°
•
is setting is only available when “Sub Woofer” is set to [On].
Adjusting the Crossover Settings (X-Over)
Before performing the following procedures, see “About the Crossover”
(page 36).
Selecting the Front HPF
Setting item:
Front HPF
Setting contents:
O (Initial setting)/ 25 / 32 / 40 / 50 / 63 / 80 / 100 / 125 / 160 / 200 / 250 Hz
Selecting the Rear HPF
Setting contents:
Rear HPF
Setting contents:
O (Initial setting)/ 25 / 32 / 40 / 50 / 63 / 80 / 100 / 125 / 160 / 200 / 250 Hz
Selecting the LPF
Setting contents:
LPF
Setting contents:
O (Initial setting)/ 25 / 32 / 40 / 50 / 63 / 80 / 100 / 125 / 160 / 200 / 250 Hz
•
is setting is only available when “Sub Woofer” is set to [On].
Adjusting the Time Correction (TCR)
Before performing the following procedures, see “About Time
Correction” (page 37).
Setting item:
TCR
Touch [
] or [
] for each speaker to adjust the time .
0.0 msec to 10.0 msec (0.1 msec/step)
•
If the Subwoofer setting is [O], the Subwoofer setting cannot be edited
(page 35).
36-EN
Setting the Speaker Level
Setting item:
Speaker Level
Touch [
] or [
] for each speaker to adjust the Speaker.
-24dB to 10dB (0.1 dB/step)
Setting Defeat
If Defeat is [On], the EQ and Equalizer setting are turned O. is
disables any settings made for these functions.
Setting item:
Defeat
Setting contents:
O (Initial setting) / On
About the Crossover
Crossover (X-Over):
is unit is equipped with an active crossover. e crossover limits
the frequencies delivered to the outputs. Each channel is controlled
independently. us, each speaker pair can be driven by the frequencies
for which they have been optimally designed.
e crossover adjusts the HPF (high pass lter) or LPF (low pass lter)
of each band.
Adjustments should be made according to the reproduction
characteristics of the speakers. Depending on the speakers, a passive
network may not be necessary. If you are unsure about this point, please
consult your authorized Alpine dealer.
25 Hz, 32Hz, 40Hz, 50Hz, 63Hz, 80Hz
Cut-o frequency
HPF LPF
Subwoofer
(LPF)
---
25Hz, 32Hz, 40Hz, 50Hz,
63Hz, 80Hz
100Hz, 125Hz, 160Hz,
200Hz, 250Hz
Rear speaker
(HPF)
25Hz, 32Hz, 40Hz, 50Hz,
63Hz, 80Hz
100Hz, 125Hz, 160Hz,
200Hz, 250 Hz
---
Front
speaker
(HPF)
25Hz, 32Hz, 40Hz, 50Hz,
63Hz, 80Hz
100Hz, 125Hz, 160Hz,
200Hz, 250Hzz
---
•
HPF (high pass lter): Cuts the lower frequencies and allows the higher
frequencies to pass.
•
LPF (low pass lter): Cuts the higher frequencies and allows the lower
frequencies to pass.
•
Do not use a tweeter without the HPF on or set to a low frequency, as it
may cause damage to the speaker due to the low frequency content.
•
Adjustment should be made according to the recommended crossover
frequency of the connected speakers. Determine the recommended
crossover frequency of the speakers. Adjusting to a frequency range
outside that recommended may cause damage to the speakers.
For the recommended crossover frequencies of Alpine speakers, refer to
the respective Owner’s Manual.
We are not responsible for damage or malfunction of speakers caused
by using the crossover outside the recommended value.
37-EN
About Time Correction
e distance between the listener and the speakers in a car vary widely
due to the complex speaker placement. is dierence in the distances
from the speakers to the listener creates a shi in the sounds image and
frequency characteristics. is is caused by the time delay between the
sound reaching the listener’s right versus the le ear.
To correct this, this unit is able to delay the audio signal to the speakers
closest to the listener. is eectively creates a perception of increased
distance for those speakers. e listener can be placed at an equal
distance between the le and right speakers for optimum staging. e
adjustment will be made for each speaker in 3.4 cm steps.
Example 1. Listening Position: Front Left Seat
Adjust the time correction level of the front le speaker to a high value
and the rear right to zero or a low value.
The sound is not balanced because the distance between the
listening position and the various speakers is dierent.
The dierence in distance between the front left speaker and the rear
right speaker is 1.75 m (68-7/8").
Here we calculate the time correction value for the front left speaker
in the diagram on the above.
Conditions:
Farthest Speaker – listening position : 2.25 m (88-9/16")
Front left speaker – listening position : 0.5 m (19-11/16")
Calculation: L = 2.25 m – 0.5 m = 1.75 m (68-7/8")
Time correction = 1.75 ÷ 343* × 1,000 = 5.1 (ms)
*
Speed of sound: 343 m/s (765 mph) at 20°C
In other words, giving the front left speaker a time correction value of
5.1 ms makes it seem as if its distance from the listener is the same as
the distance to the farthest speaker.
Time correction eliminates the dierences in the time required for
the sound to reach the listening position.
The time of the front left speaker is corrected by 5.1 ms so that its
sound reaches the listening position at the same time as the sound
of other speakers.
Example 2. Listening Position: All Seats
Adjust the time correction level of each speaker to almost the same
level.
1
Sit in the listening position (driver’s seat, etc.) and
measure the distance (in meters) between your head
and the various speakers.
2
Calculate the dierence between the distance correction
value to the farthest speaker and the other speakers.
L = (distance to farthest speaker) – (distance to other speakers)
These values are the time correction values for the dierent
speakers. Setting these values to make each sound reach
the listening position at the same time as the sound of other
speakers.
Time Correction Value List
Time
Dierence
(msec)
Distance
(cm)
Distance
(inch)
Time
Dierence
(msec)
Distance
(cm)
Distance
(inch)
0.0 0.0 0.0 5.1 173.4 68.3
0.1 3.4 1.3 5.2 176.8 69.7
0.2 6.8 2.7 5.3 180.2 71.0
0.3 10.2 4.0 5.4 183.6 72.4
0.4 13.6 5.4 5.5 187.0 73.7
0.5 17.0 6.7 5.6 190.4 75.0
0.6 20.4 8.0 5.7 193.8 76.4
0.7 23.8 9.4 5.8 197.2 77.7
0.8 27.2 10.7 5.9 200.6 79.1
0.9 30.6 12.1 6.0 204.0 80.4
1.0 34.0 13.4 6.1 207.4 81.7
1.1 37.4 14.7 6.2 210.8 83.1
1.2 40.8 16.1 6.3 214.2 84.4
1.3 44.2 17.4 6.4 217.6 85.8
1.4 47.6 18.8 6.5 221.0 87.1
1.5 51.0 20.1 6.6 224.4 88.4
1.6 54.4 21.4 6.7 227.8 89.8
1.7 57.8 22.8 6.8 231.2 91.1
1.8 61.2 24.1 6.9 234.6 92.5
1.9 64.6 25.5 7.0 238.0 93.8
2.0 68.0 26.8 7.1 241.4 95.1
2.1 71.4 28.1 7.2 244.8 96.5
2.2 74.8 29.5 7.3 248.2 97.8
2.3 78.2 30.8 7.4 251.6 99.2
2.4 81.6 32.2 7.5 255.0 100.5
2.5 85.0 33.5 7.6 258.4 101.8
2.6 88.4 34.8 7.7 261.8 103.2
2.7 91.8 36.2 7.8 265.2 104.5
2.8 95.2 37.5 7.9 268.6 105.9
2.9 98.6 38.9 8.0 272.0 107.2
3.0 102.0 40.2 8.1 275.4 108.5
3.1 105.4 41.5 8.2 278.8 109.9
3.2 108.8 42.9 8.3 282.2 111.2
3.3 112.2 44.2 8.4 285.6 112.6
3.4 115.6 45.6 8.5 289.0 113.9
3.5 119.0 46.9 8.6 292.4 115.2
3.6 122.4 48.2 8.7 295.8 116.6
3.7 125.8 49.6 8.8 299.2 117.9
3.8 129.2 50.9 8.9 302.6 119.3
3.9 132.6 52.3 9.0 306.0 120.6
4.0 136.0 53.6 9.1 309.4 121.9
4.1 139.4 54.9 9.2 312.8 123.3
4.2 142.8 56.3 9.3 316.2 124.6
4.3 146.2 57.6 9.4 319.6 126.0
4.4 149.6 59.0 9.5 323.0 127.3
4.5 153.0 60.3 9.6 326.4 128.6
4.6 156.4 61.6 9.7 329.8 130.0
4.7 159.8 63.0 9.8 333.2 131.3
4.8 163.2 64.3 9.9 336.6 132.7
4.9 166.6 65.7
5.0 170.0 67.0
38-EN
Volume Setup
Volume Setup
[Volume] is selected on the Setup menu screen.
Setting item:
Main.Ring Vol.Talking.Voice/Navi Guidance.TA
Setting contents:
Main :01 to 35(Initial setting: 10)
Ring Vol :01 to 35(Initial setting: 18)
Ring Vol :01 to 35(Initial setting: 18)
Voice/Navi Guidance :01 to 35(Initial setting: 18)
TA :01 to 35(Initial setting: 10)
Bluetooth Setup
[Bluetooth] is selected on the Setup menu screen.
Setting item:
Bluetooth
Setting contents:
Bluetooth,Devices List, Devices Info,
Bluetooth
•
You can turn Bluetooth on or o
Device List
[Devices] is selected on the Bluetooth Setup Menu screen.
You can register and set up Bluetooth compatible devices.
Pairing the Bluetooth Device
1
Touch [ ] to enter [Search] screen to search for
Devices.
2
Select a device and follow the on-screen prompts to
connect devices
3
Screen prompts 6 character Numeric passkey to pair
When the device registration is complete, a message appears
and the device returns to [Device List].
•
e Bluetooth registration process diers depending on the device
version and SSP (Simple Secure Pairing). If a 4 or 6 character Numeric
Comparison appears on this system, enter the Numeric Comparison on
the Bluetooth device.
•
If a 6 character Passkey appears on this system, make sure the same
passkey is displayed on the Bluetooth device, and follow the screen.
Fast pairing the Bluetooth Device
Select one of 5 paired Bluetooth compatible devices that you previously
registered.
1
Touch [Connect] on the Bluetooth Setup Menu screen.
Deleting a Bluetooth Device from the list
You can delete the information of a previously connected Bluetooth
compatible device.
1
Touch [ ] on the Bluetooth Setup Menu screen.
2
Touch [Yes].
•
Touching [No] will cancel the setting.
Searching for a Bluetooth Device
Setting item:
Search
1
Touch [ ] on the device list interface in Bluetooth
Setup.
The Bluetooth devices can be searched are displayed in a list.
2
Touch the device you want to connect from the list.
You can register up to 5 Bluetooth compatible mobile phones.
3
When the device registration is complete, a message
appears and the device returns to [Device List].
•
Connect to new Bluetooth compatible device when there are 5 paired
devices registered , the system will delete the last paired device
automatically
39-EN
Displaying Bluetooth Information
[Info] is selected on the Bluetooth Setup Menu screen.
You can display the Bluetooth device name and device address of this
unit.
Auto Connection
When the ACC is turned ON, the Bluetooth Hands-Free device is
automatically connected. Aer connecting to the Hands-Free device,
the Bluetooth Audio device is also connected automatically.
Downloading the Phonebook
If PBAP is connected, you can download the phonebook from the
device.
•
When the device is disconnected, the downloaded phonebook is not
shown.
Rear Camera Setup
[Camera] is selected on the Setup Menu screen.
You can set up items related to the Rear Camera.
Setting item:
Rear Camera
Setting contents:
Camera,Mute While Backing Up, Parking Guide Adjust,Video Setup
Camera
Setting item:
Camera
Setting contents:
O, On (Initial setting),
•
e rear camera initial setting is ON , when you turn o the camera ,
you cannot open and setup the camera.
Mute While Backing Up
Setting item:
Mute While Backing Up
Setting contents:
O (Initial setting), On ,
Parking Guide Adjust Setup
You can adjust the camera guide position.
Setting item:
Parking Guide Adjust
Setting contents:
Touch the icon you want to move.
1
Touch the icon you want to move.
2
Touch [ ] [ ] [ ] [ ]to move the icon.
Touching [Reset] clears adjustments and returns to the setting
before guide line alteration.
3
Touch [ ]to complete the adjustment and return to the
previous screen.
40-EN
Video Setup
Adjusting Brightness
Setting item:
Brightness
Setting contents:
-10 to 10 (Initial setting: 0)
•
You can adjust the brightness of USB Video and reverse video between
MIN(-10)and MAX(10)
Adjusting Color of Display
Setting item:
Colors
Setting contents:
-10 to 10 (Initial setting: 0)
•
You can adjust the color of USB Video and reverse video between
MIN(-10)and MAX(10)
Adjusting Display Contrast
Setting item:
Contrast
Setting contents:
-10 to 10 (Initial setting: 0)
•
You can adjust the Contrast of USB Video and reverse video between
MIN(-10)and MAX(10)
Lighting Link ON/OFF
[Lighting link] is selected on the Setup menu screen.
Setting item:
Lighting Link
Setting contents
On:
Lighting link icon displayed on sound boost screen
O:
The Lighting link icon on the sound boost screen is not displayed
41-EN
Distance guidance mark
e distance guides represent the ground level distance from the rear
bumper. It is dicult to accurately estimate the distance to objects above
ground level.
In the following example, the distance to A is 0.5 m and the distance to
B is 1 m.
<Screen>
A (about 0.5 m)
B
C
<Positions of A, B and C>
about 1 m
In the screen, according to the distance guidance marks, the
truck seems to be parked about 1 m away (at the position
B). In actual fact, however, if you reversed to position A, you
would collide with the truck.
In the screen, positions A, B and C seem to be located in
order of proximity. However, in actual fact, the position
A and C are the same distance, and B is farther away than
positions A and C.
•
e car width extension mark represents the distance to the road
surface. e distance to an object on the road is not accurately
represented by the guides.
Error between the screen and the actual road surface
In the following conditions, errors are produced between the screen
guidance and the actual road surface. (e illustrations represent a case
when the camera is installed in the standard position.)
When there is a steep upward slope behind the car
(example)
<Screen>
Distance guidance marks
<Situation of the car>
Actual distances
Error Error
The distance guidance mark represents the distance to a
at road surface. Therefore in the case of an upward slope
behind the car, the distance guides are displayed closer
to the rear bumper than the actual distance. For example,
if there is an obstacle on the upward slope, it may appear
farther away than its actual position.
Also, an error may occur between the guidance and the
actual path of the car on the road surface.
When there is a steep downward slope behind the car
(example)
<Screen>
<Situation of the car>
Error Error
In the case of a downward slope behind the car, the distance
guides are displayed farther from the rear bumper than the
actual distance.
If there is an obstacle on the downward slope, it seems closer
than its actual position.
Also, an error may occur between the guidance and the
actual path of the car on the road surface.
42-EN
Information
About the Supported Formats
CAUTION
Except for private use, duplicating audio data or
distributing, transferring, or copying it, whether for
free or for a fee, without permission of the copyright
holder is strictly prohibited by the Copyright Act and by
international treaty.
About Audio Format
Method for creating WAVE/WMA/AAC/AC3/MPEG/Ogg/FLAC/
APE (USB Flash drive) les
Audio data is compressed using software with WAVE/WMA/AAC/
AC3/MPEG/Ogg/FLAC/APE (USB Flash drive) codecs. For details on
creating WAVE/WMA/AAC/AC3/MPEG/Ogg/FLAC/APE(USB Flash
drive les, refer to the user’s manual for that software.
WAVE/WMA/AAC/AC3/MPEG/Ogg/FLAC/APE (USB Flash drive) les
that are playable on this device have the le extensions.
WAVE:.WAV
WMA:.WMA,.asf
AAC:.aac
AC3:.ac3,.ec3
MPEG:.mp1,mp2,mpa,mp3,.mp4,m4a
Ogg:.ogg
FLAC:.ac
APE:.ape
WMA is not supported for the following les, Windows Media Audio
Professional, Windows Media Audio 10 std or Windows Media Audio
10 Pro Lossless.
There are many dierent versions of the AAC format. Conrm that
the software being used conforms to the acceptable formats listed
above. It’s possible that the format may be unplayable even though
the extension is valid.
Playback of AAC les encoded by iTunes is supported.
WAVE (USB Flash drive)
Filename : .wav
Container: Waveform Audio File Format(base on RIFF)
Audio Coding: LPCM,IMA-ADPCM
WMA (USB Flash drive)
Filename : .wma,.asf
Container: Advanced Systems Format(ASF)
Audio Coding: WMA STD
*
Support object:
Content Description Object: only
Title,Artist
AAC (USB Flash drive)
Filename : .aac
Container: Audio Data Transport Stream (ADTS)
Audio Coding: AAC-LC/HE-AAC
AC3 (USB Flash drive)
Filename : .ac3,.ec3
Container: AC3 bit streams
Audio Coding: AC3
Container: Enhanced AC3 Bit Stream
Audio Coding: E-AC3
MPEG (USB Flash drive)
Filename : .mp1
Container: MPEG PS
Audio Coding: MP1
Filename: .mp2,.mpa
Container: MPEG PS
Audio Coding: MP2
Filename : .mp3
Container: MPEG PS
Audio Coding: MP3
*
Support Tag:ID3V1 ID3v2.3 : only
TPE1, TALB, TCONTIT2, TYER
Filename : .mp4,.m4a
Container: MP4 File Format
Audio Coding: AAC-LC,HE-AAC
OGG (USB Flash drive)
Filename. : .ogg
Container: Ogg
Audio Coding: Vorbis
FLAC (USB Flash drive)
Filename. : .ac
Container: FLAC
Audio Coding: FLAC
APE (USB Flash drive)
Filename. : .ape
Container: APE (Monkey's Audio Lossless Audio File)
Audio Coding: Monkey's Audio
About Video Format
Files that are playable on this device have the le extensions.
AVI: .avi
MPEG 1/2: .mpg,.mpeg,.vob(with.info),.dat
MPEG4: .mp4,.mpeg4,.m4v
Flash:.v,.swf
QuickTime:.mov,.qt
Matroska Video:.mkv
TS Stream:.ts,.tp,.trp,.m2ts <BD>,.MTS<AVCHD>
3GP:.3gp
WMV:.wmv
ASF:.asf
Format: AVI
Filename .: .avi
Video Coding: MPEG-4 SP/ASP(FMP4), Sorenson H.263(FLV1), H.264,
Xvid, WMV 9 / VC - 1,
MJPEG (Maximum resolution:1280x720),
MPEG-2 Video, MPEG-1 Video
Audio Coding: MP3, AC3, WMA St, LPCM /ADPCM
Format: MPEG 1/2
File Name:.mpg .mpeg
Video Coding: MPEG-1 Video, MPEG-2 Video, H.264
Audio Coding: MP1 / MP2 / MP3, AAC-LC, AC3, LPCM
File Name:.vob (with.info)
Video Coding: MPEG-2 Video Main
Audio Coding: MP1 / MP2 / MP3, AC3, LPCM
File Name:.dat
Video Coding: MPEG-1 Video
Audio Coding: MPEG-1 Audio Layer II
Format: MPEG4
File Name:.mp4,.mpeg4
Video Coding: MPEG-2 Video, MPEG-4 SP/ASP, H.264,
MJPEG (Maximum resolution:1280x720)
Audio Coding: MP3, AAC-LC/HE-AAC, AC3, LPCM
File Name:.m4v
Video Coding: H.264
Audio Coding: AAC-LC / HE-AAC, AC3
43-EN
Format: Flash
File Name:.v
Video Coding: Sorenson H.263(FLV1), H.264
Audio Coding: MP3, AAC-LC, ADPCM
File Name:.swf
Video Coding: Sorenson H.263(FLV1), H.264
Audio Coding: MP3, ADPCM
Format: QuickTime
File Name:.mov .qt
Video Coding: MPEG-4 SP/ASP, H.264,
MJPEG (MJPEG(Maximum resolution:1280x720)
Audio Coding: MP3, AAC-LC / HE-AAC, LPCM
Format: Matroska Video
File Name:.mkv
Video Coding: MPEG-1 Video, MPEG-2 Video, MPEG-4 SP/ASP, H.264,
Xvid, WMV9 / VC-1
Audio Coding: MP3, AC3, LPCM, AAC-LC / HE-AAC
Format: TS Stream
File Name:.ts .trp
Video Coding: MPEG-1 Video, MPEG-2 Video, MPEG-4 H.264,
WMV 9 / VC-1
Audio Coding: MP1 / MP2 / MP3, AC3, AAC-LC / HE-AAC
File Name:.m2ts <BD>
Video Coding: MPEG-2 Video, H.264, WMV 9 / VC-1
Audio Coding: AC3, LPCM
File Name:..MTS <AVCHD>
Video Coding: H.264
Audio Coding: AC3, LPCM
Format: 3GP
File Name:.3gp
Video Coding: MPEG-4 SP/ASP, H.263, H.264
Audio Coding: ACC-LC / HE-ACC
Format: WMV
File Name:.wmv
Video Coding: VC-1
Audio Coding: WMA Std
Format: ASF
File Name:.asf
Video Coding: VC-1
Audio Coding: WMA Std
About Photo Format
Format: Jpg,jpeg
Resolution ratio: Maximum 4096 x 4096, minimum 32x32
Format:Png
Resolution ratio: Maximum 576 x 720 minimum 32x32
Format:bmp
Resolution ratio: Maximum 936 x 1920 minimum 32x32
ID3 tags/WMA tags
If the music supports ID3 tag and track title ,music title, author,
album name and album cover are to be displayed.
If there is no track title ,”No Name” will be displayed.
If there is no album name, the name of the folder will be displayed,
if the song name is not recognized, it will be garbled, if there is no
album cover, it will not be displayed.
Playing back le
•
e les are prepared, then written to a USB ash drive.
•
Connect iPod/Android MSC
Maximum numbers of playable les/folders
Maximum les numbers of device:
USB Flash drive(Auido/Video/):9999
USB Flash drive(Photo):999
IPod:2000
Android MSC: Same as USB
Maximum les numbers of folders:
USB Flash drive (Auido/Video/Photo):999
IPod:No folder , only a playlist is available with up to 100 les
Android MSC: Same as USB
Maximum folders numbers of device:
USB Flash drive(Auido/Video/Photo):1000
IPod:No folder ,up to 100 playlists
Android MSC: Same as USB
· Supports a maximum of 256 GB USB
· Largest playable le size:
Audio les :4GB
Video les: 4 GB
Photo les: 10K-6M
Playback may not be performed if a disc exceeds the limitations
described above.
Media supported
The media that this device can play back a USB ash drive.
Corresponding File Systems
This device supports FAT 16/32, NTFS.
The maximum nested folder depth is 8 (including the root directory).
Order/Search of les
Display and sort according to the head characte
Display in the order of 1 -> 2 -> 3 below.
0: Folder :When there are folders, the folders are displayed ahead of
the les
1: Number ( represented by "#" on the Right Search Bar )
2: English Alphabet
3: Shorting order of Unicode
Right Search Bar (order of list )
1: Number ( represented by "#" on the Right Search Bar )
2: English Alphabet
•
Search only the les with numeric or English alphabetic headers
Terminology
Bit rate
This is the “sound” compression rate specied for encoding. The
higher the bit rate, the higher the sound quality, but also the larger
the les.
Sampling rate
This value shows how many times per second the data is sampled
(recorded). For example, music CDs use a sampling rate of 44.1 kHz,
so the sound is sampled (recorded) 44,100 times per second. The
higher the sampling rate, the higher the sound quality, but also the
larger the volume of data.
Encoding
Converting music CDs, WAVE (AIFF) les, and other sound les into
the specied audio compression format.
Ta g
Song information such as track titles, artist names, album names,
etc., written into MP3/WMA/AAC/FLAC/WAVE/Ogg/APE (USB ash
drive) les.
Root folder
The root folder (or root directory) is found at the top of the le
system. The root folder contains all folders and les. It is created
automatically for all burned discs.
44-EN
In Case of Diculty
If you encounter a problem, please turn the power o,
then on again. If the unit is still not functioning normally,
please review the items in the following checklist. This
guide will help you isolate the problem if the unit is at
fault. Otherwise, make sure the rest of your system is
properly connected, or then consult your authorized
Alpine dealer.
Basic
No function or display.
•
Vehicle’s ignition is o.
- If connected according to the instructions, the unit will not
operate with the vehicle’s ignition o.
•
Improper power lead connections.
- Check power lead connections.
•
Blown fuse.
- Check the fuse on the battery lead of the unit; replace with the
proper value if necessary.
No sound or unnatural sound.
•
Incorrect setting of volume/balance/fader controls.
- Readjust the controls.
•
Connections are not properly or securely made.
- Check the connections and rmly connect.
Screen not displayed.
•
Brightness/Contrast control is set at the minimum position.
- Adjust the Brightness/Contrast control.
•
Temperature in the vehicle is too low.
- Increase the vehicle’s interior temperature to operation
temperature range.
•
Connections to the Auxiliary Device are not securely made.
- Check the connections and rmly connect.
•
e Parking Brake Lead is not connected.
•
e Parking Brake is not engaged.
- Connect the Parking Brake Lead, then engage the Parking
Brake.
Movement of displayed picture is abnormal.
•
Temperature in the vehicle is too high.
- Allow the vehicle’s interior temperature to cool.
Radio
Unable to receive stations.
•
No antenna, or open connection in the antenna cable.
- Make sure the antenna is properly connected; replace the
antenna or cable if necessary.
Unable to tune stations in the seek mode.
•
You are in a weak signal area.
- Change the radio frequency manually.
•
If the area you are in is a primary signal area, the antenna may
not be grounded and connected properly.
- Check your antenna connections; make sure the antenna is
properly grounded at its mounting location.
•
e antenna may not be the proper length.
- Make sure the antenna is fully extended; if broken, replace the
antenna with a new one.
Broadcast is noisy.
•
e antenna is not the proper length.
- Extend the antenna fully; replace it if it is broken.
•
e antenna is poorly grounded.
- Make sure the antenna is grounded properly at its mounting
location.
•
e station signal is weak and noisy.
- If above solution does not work, tune in another station.
USB Audio
Unit does not operate.
•
Condensation.
- Wait a while (about 1 hour) for the condensation to dry.
Picture is unclear or noisy.
•
Vehicle’s battery power is weak.
- Check the battery power and wiring.
(e unit may malfunction if the battery power is under 11
volts with a load applied.)
45-EN
If this Message Appears
Various messages are displayed on the screen during operation. In
addition to the messages telling you the current status or providing
guidance for the next operation, there are also the following error
messages. If one of these error messages is displayed, carefully follow
the instructions in the solution column.
System
ATTENTION!
Viewing of front seat video source while driving is strictly
prohibited.
•
A setup operation, etc., was carried out while the vehicle was
running.
- Move the vehicle to a safe location, stop, and engage the
parking brake, then carry out this operation.
Audio/Visual
This content cannot be played.
•
Unsupported content .
- Change to play supported contents type.
This device is not supported./Unsupport USB device
•
Unsupported device.
- Change to play supported USB device.
Device No Response.
•
No response from the device.
USB Hub is not supported.
•
e USB hub is not supported.
No Audio.
•
ere is no audio data in the current video le.
- Download a video le whit audio date in it .
Audio format not supported
•
Not supported audio format.
- Download supported audio format to USB ash drive.
Audio trick not supported/Video Trick not supported
•
Prompts fast forwarding / reversing or jumping on current audio
/video is not supported.
- Change the current audio /video format.
Video other warning
•
Prompts unexpected warning message.
- Change to play other video.
Video format not supported
•
Unsupported video format.
- Change to play the supported video format.
Video other error
•
Unknown error.
- Change to play other video.
No Artist (/ No Song / No album)
•
ere are no tag-info in the USB Audio / iPod Audio.
- Change to play audio-le with tag-info
No Date
•
·ere are no data in the USB ash drive.
- Download data to the USB ash drive and connect to this unit.
SiriusXM
Check Tuner
•
e SiriusXM Tuner is disconnected or the unit is having trouble
communicating with the Tuner.
- Connect the Tuner or check the Tuner connection to the back
of the unit.
Check Antenna
•
e SiriusXM Satellite Radio antenna or cable is either damaged
or not connected correctly to the SiriusXM Tuner.
- Check that the SiriusXM antenna cable is connected to the
SiriusXM Tuner and check that the antenna cable is not kinked
or otherwise damaged. Replace the antenna if necessary.
- SiriusXM products are available at your local car audio retailer
or online at www.shop.siriusxm.com.
No Signal
•
e SiriusXM satellite signal is too weak at the current location.
- Move the vehicle to a location with a clear view of the southern
sky.
- Make sure the Satellite Radio antenna is properly mounted and
not obstructed by metal objects.
Channel [xxx] Not Subscribed
Call SiriusXM to Subscribe
•
e active channel has become unsubscribed or the requested
channel is not available in your subscription package.
- In the USA, you can activate online or by calling SiriusXM
Listener care:
•
Visit www.siriusxm.com/activatenow
•
Call SiriusXM Listener Care at 1-866-635-2349
- For Canadian Subscriptions, please contact:
•
Visit www.siriusxm.ca/activate
•
Call SiriusXM Customer Care at 1-888-539-7474
- e unit will revert to the previously selected channel or to
channel 1 automatically.
Channel [xxx] Not Available
•
e active channel is no longer in the SiriusXM channel lineup
or the user has entered an invalid channel number.
- Visit www.siriusxm.com for information on the current
channel lineup.
•
e unit will revert to the previous channel or to channel 1
automatically.
Subscription Updated
Press Enter to Continue
•
Your subscription has been updated.
- Touch [Enter] to clear this message.
Password modied successfully
•
Password entered incorrectly.
- Enter the correct password
46-EN
Bluetooth
No Bluetooth device were found
•
e Bluetooth audio device was not connected correctly.
- Check the settings for the unit and the Bluetooth audio device
and reconnect
Phone
Empty
•
e phone book is empty.
Phone book access is not authorized
•
e phone book download is not supported.
- On Enable phone book permission.
Handsfree device is not connected
•
Hands-Free Prole is not connected.
- Connect Hands- Free Prole .
AUX
Picture o for your safety.
•
While the vehicle is moving.
- Parking.
HOME
No devices available connect an Android Phone with USB
cable.
•
When Android Auto is not connected , touch Android Auto icon
, this message is displayed .
Caution! AMP Overload.
•
When two volume cables are connected ,this message is
displayed.
- Take apart the volume cable and reboot the unit.
Caution! USB Overcurrent.
•
Prompts USB Overcurrent
- Remove the USB and reboot the unit
Apple CarPlay
The GNSS antenna is disconnected.
•
e GPS antenna is disconnected or bad connected.
- Connect the GPS antenna.
Setup
Data check error..
•
Upgrade rmware check error
- Exit upgrade progress
There is no photo in this device.
•
No photo in this device
- Download the photo with supported format
((JPG,JPEG,PNG,BMP))to this device
47-EN
Specications
MONITOR SECTION
Screen Size 6.75”
LCD Type Normally white, Transmissive
Operation System a-Si TFT active matrix
Number of Picture Elements 1,152,000 pcs.
(800 × 480 × 3(RGB))
Eective Number of Picture Elements
99% or more
Illumination System LED
FM TUNER SECTION
Tuning Range 87.7 – 107.9 MHz
Mono Usable Sensitivity < 9 dBu (75 ohms)
50 dB Quieting Sensitivity < 5 dBu (75 ohms)
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
AM TUNER SECTION
Tuning Range 530 – 1710 kHz
Usable Sensitivity 34 dBu
USB SECTION
USB requirements USB 2.0
Max. Power Consumption 1,500 mA (CDP Support)
USB Class USB (Play From Device)/
USB (Mass Storage Class)
File System FAT16/32, NTFS
Number of Channels 2-Channels (Stereo)
Frequency Response
*1
17 – 20,000 Hz (±1 dB)
Total Harmonic Distortion 0.05% (at 1 kHz)
Dynamic Range 90 dB (at 1 kHz)
Signal-to-Noise Ratio 85 dB
Channel Separation 75 dB (at 1 kHz)
*1
Frequency response may dier depending on the encoder soware/bit
rate.
Bluetooth SECTION
Bluetooth Specication Bluetooth V5.0
Output Power < +4dBm Ave. (Power class 2)
Prole HFP (Hands-Free Prole)
PBAP (Phone Book Access Prole)
A2DP (Advanced Audio
Distribution Prole)
AVRCP (Audio/Video Remote
Control Prole)
GENERAL
Power Requirement 14.4 V DC
(10.8 – 15.1 V allowable)
Operating temperature -4°F to +140°F
(-20°C to + 60°C)
Power Output 16 W RMS × 4
*2
*2
Primary amplier ratings per CEA-2006 Standard
•
Power output: measured at 4 Ohms and ≤ 1% THD+N
•
S/N: 80 dBA (reference: 1 W into 4 Ohms)
Weight 0.9 kg
Audio output level
Preout (Front, Rear): 4V/10k ohms (max.)
Preout (Subwoofer): 4V/10k ohms (max.)
CHASSIS SIZE
Width 178 mm
Height 100 mm
Depth 68 mm
•
Due to continuous product improvement, specications and design are
subject to change without notice.
•
e LCD panel is manufactured using an extremely high precision
manufacturing technology. Its eective pixel ratio is over 99.99%. is
means that there is a possibility that 0.01% of the pixels could be either
always ON or OFF
48-EN
Installation and Connections
Before installing or connecting the unit, please read the
following and pages 5 to 8 of this manual thoroughly
for proper use.
WARNING
KEEP SMALL OBJECTS SUCH AS SCREWS OUT OF THE REACH OF
CHILDREN.
Swallowing them may result in serious injury. If swallowed, consult
a physician immediately.
MAKE THE CORRECT CONNECTIONS.
Failure to make the proper connections may result in re or
product damage.
USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.
(Check with your dealer if you are not sure.) Failure to do so may
result in re, etc.
BEFORE WIRING, DISCONNECT THE CABLE FROM THE NEGATIVE BATTERY
TERMINAL.
Failure to do so may result in electric shock or injury due to
electrical shorts.
DO NOT ALLOW CABLES TO BECOME ENTANGLED IN SURROUNDING
OBJECTS.
Arrange wiring and cables in compliance with the manual to
prevent obstructions when driving. Cables or wiring that obstruct
or hang up on places such as the steering wheel, gear lever, brake
pedals, etc. can be extremely hazardous.
DO NOT SPLICE INTO ELECTRICAL CABLES.
Never cut away cable insulation to supply power to other
equipment. Doing so will exceed the current carrying capacity of
the wire and result in re or electric shock.
DO NOT DAMAGE PIPE OR WIRING WHEN DRILLING HOLES.
When drilling holes in the chassis for installation, take precautions
so as not to contact, damage or obstruct pipes, fuel lines, tanks or
electrical wiring. Failure to take such precautions may result in re.
DO NOT USE BOLTS OR NUTS IN THE BRAKE OR STEERING SYSTEMS TO
MAKE GROUND CONNECTIONS.
Bolts or nuts used for the brake or steering systems (or any
other safety-related system), or tanks should NEVER be used for
installations or ground connections. Using such parts could disable
control of the vehicle and cause re etc.
DO NOT INSTALL IN LOCATIONS WHICH MIGHT HINDER VEHICLE
OPERATION, SUCH AS THE STEERING WHEEL OR GEARSHIFT.
Doing so may obstruct forward vision or hamper movement etc.
and results in serious accident.
CAUTION
HAVE THE WIRING AND INSTALLATION DONE BY EXPERTS.
e wiring and installation of this unit requires special technical
skill and experience. To ensure safety, always contact the dealer
where you purchased this product to have the work done.
USE SPECIFIED ACCESSORY PARTS AND INSTALL THEM SECURELY.
Be sure to use only the specied accessory parts. Use of other
than designated parts may damage this unit internally or may not
securely install the unit in place. is may cause parts to become
loose resulting in hazards or product failure.
ARRANGE THE WIRING SO IT IS NOT CRIMPED OR PINCHED BY A SHARP
METAL EDGE.
Route the cables and wiring away from moving parts (like the seat
rails) or sharp or pointed edges. is will prevent crimping and
damage to the wiring. If wiring passes through a hole in metal, use
a rubber grommet to prevent the wire’s insulation from being cut
by the metal edge of the hole.
DO NOT INSTALL IN LOCATIONS WITH HIGH MOISTURE OR DUST.
Avoid installing the unit in locations with high incidence of
moisture or dust. Moisture or dust that penetrates into this unit
may result in product failure.
Precautions
•
Be sure to disconnect the cable from the (–) battery post before
installing your unit. is will reduce any chance of damage to the
unit in case of a short-circuit.
•
Be sure to connect the color coded leads according to the
diagram. Incorrect connections may cause the unit to
malfunction or damage to the vehicle’s electrical system.
•
When making connections to the vehicle’s electrical system,
be aware of the factory installed components (e.g. on-board
computer). Do not tap into these leads to provide power for
this unit. When connecting the unit to the fuse box, make sure
the fuse for the intended circuit of the unit has the appropriate
amperage. When in doubt, consult your Alpine dealer.
•
e unit uses female RCA-type jacks for connection to other
units (e.g. amplier) having RCA connectors. You may need
an adaptor to connect other units. If so, please contact your
authorized Alpine dealer for assistance.
•
Be sure to connect the speaker (–) leads to the speaker (–)
terminal. Never connect le and right channel speaker cables to
each other or to the vehicle body.
49-EN
Accessory List
Main unit ............................................................................................................. 1
Power cable........................................................................................................ 1
RCA cable ............................................................................................................ 1
GPS antenna ............................................................................................... 1set
Microphone ....................................................................................................... 1
USB extension cable ...................................................................................... 1
Screw .................................................................................................................... 4
Countersunk screw .........................................................................................4
Quick Reference Guidance ........................................................................... 1
Card note1 ..........................................................................................................1
Card note2 ..........................................................................................................1
Warranty card .................................................................................................... 1
Installation
CAUTION
• Do not cover the heat sink to block air circulation, as heat can
accumulate in the chamber and cause a re.
Heat sink
Rear of the Unit
Caution concerning the installation location
Angle of installation
Install at an angle between horizontal and 30°. Note that installing at
an angle outside of this range will result in a loss of performance and
possibly damage.
0-30°
Mounting the Microphone
For safe use, make sure of the following:
• Location is stable and rm.
• Does not interfere with safety equipment.
• Driver’s view and operations are not obstructed.
• Microphone is located where the driver’s voice can be easily
picked up (for example, on the sun visor).
When you speak into the microphone, you should not have to
change your driving posture. This may cause a distraction, taking
your attention away from safely driving your vehicle. Carefully
consider direction and distance while mounting the microphone.
Conrm that the driver’s voice can be easily picked up at the selected
location.
Cable clamp
(sold separately)
Microphone
Installation example using the Original
Mounting Bracket
1
Mount the original mounting bracket to the unit using
the supplied screws.
Original Mounting Bracket
Screws (M5×8)
(included)
Ground Lead*
Chassis
The original mounting
bracket is not included with
the product.
2
Connect all other leads of the unit according to details
described in the “Connections” (page 50).
3
Mount the unit in a car.
•
To securely connect the ground lead, use an already installed screw on
a metal part of the vehicle (marked (
)) or a clean, bare metal spot
on the vehicle's chassis.
•
Fix the cables carefully. Do not damage them by mounting them into
movable parts, such as the seat rail, or by locating them against sharp
or pointed edges.
4
Reattach the removed vehicle parts (panels, etc.) or
other aftermarket dash kit back onto the vehicle.
50-EN
Connections
51-EN
A
Radio Antenna Receptacle
B
GPS Antenna Receptacle
C
Power Antenna Lead (Blue)
Connect this lead to the +B terminal of your power antenna, if
applicable.
•
is lead should be used only for controlling the vehicle’s power
antenna. Do not use this lead to turn on an amplier or a signal
processor, etc.
D
Remote Turn-On Lead (Blue/White)
Connect this lead to the remote turn-on lead of your amplier
or signal processor.
E
Parking Brake Lead (Yellow/Blue)
Connect this lead to the power supply side of parking brake
switch to transmit the parking brake status signals to the unit.
F
Reverse Lead (Violet/White)
G
Right Rear (+) Speaker Output Lead (Violet)
H
Right Rear (–) Speaker Output Lead (Violet/Black)
I
Right Front (+) Speaker Output Lead (Gray)
J
Right Front (–) Speaker Output Lead (Gray/Black)
K
Left Front (+) Speaker Output Lead (White)
L
Left Front (–) Speaker Output Lead (White/Black)
M
Left Rear (+) Speaker Output Lead (Green)
N
Left Rear (–) Speaker Output Lead (Green/Black)
O
Switched Power Lead (Ignition) (Red)
Connect this lead to an open terminal on the vehicle’s fuse box
or another unused power source that provides (+) 12V only
when the ignition is turned on or in the accessory position.
P
Fuse Holder (15A)
Q
Battery Lead (Yellow)
Connect this lead to the positive (+) post of the vehicle’s battery.
R
Ground Lead (Black)
Connect this lead to a good chassis ground on the vehicle.
Make sure the connection is made to bare metal and is securely
fastened using the sheet metal screw provided.
S
SPEED SENSOR(Green/White)
T
LIGHTING LINK(Brown)
U
SW1 (Black/Brown)
Steering Wheel Control
V
SW2 (Black/Blue)
Steering Wheel Control
W
SWG (Black/White)
Steering Wheel GND
X
REAR CAMERA Input RCA Connector(Black)
Use when connecting a camera with RCA Output Connector.
Y
Rear Output RCA Connectors
Can be used as Rear Output RCA Connectors. RED is right and
WHITE is left.
Z
Front Output RCA Connectors
Can be used as Front Output RCA Connectors. RED is right and
WHITE is left.
!
Subwoofer RCA Connectors
_
AUX INPUT (Black)
Audio and video input.
#
MIC Input Connector
To microphone (included)
$
SiriusXM Tuner Input Connector
To SiriusXM Tuner (sold separately).
•
For more information on how to install the SiriusXM Connect
Vehicle tuner, consult the installation guide included with the
tuner.
%
USB Connector
To USB ash drive, iPhone or Android smartphone.
^
Power Supply Connector
&
CAMERA/SWC PRE OUT/AUX
52-EN
If an ACC power supply is not available
Connection Diagram of SPST Switch (sold separately)
ACC
(Red)
BATTERY
(Yellow)
iLX-W670
SPST SW (Optional)
FUSE (5A)
(Optional)
FUSE (20A)
(Optional)
Battery
•
If your vehicle has no ACC power supply, add an SPST (single-pole, single-throw) switch (sold separately) and fuse (sold separately).
•
e diagram and the fuse amperage shown above are in the case when the unit is used individually.
•
If the switched power (ignition) lead of the unit is connected directly to the positive (+) post of the vehicle’s battery, the unit draws some current (several
hundred milliamperes) even when its switch is placed in the OFF position, and the battery may be discharged.
IMPORTANT
Please record the serial number of your unit in the space provided
below and keep it as a permanent record. e serial number plate is
located on the bottom of the unit.
SERIAL NUMBER:
INSTALLATION DATE:
INSTALLATION TECHNICIAN:
PLACE OF PURCHASE:
To prevent external noise from entering the audio system.
• Locate the unit and route the leads at least 10 cm away from the car harness.
• Keep the battery power leads as far away from other leads as possible.
• Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis.
• If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise
suppressors, contact them for further information.
• Your Alpine dealer knows best about noise prevention measures so consult your dealer for further information.
53-EN
System Example
Connection of an iPhone
When connecting to an iPhone with a Lightning connector
USB connector
iPhone with a Lightning
connector (sold separately)
USB extension cable (included) Lightning to USB Cable KCU-471i
(sold separately)
•
Do not leave an iPhone in a vehicle for a long time. Heat and humidity may damage the iPhone, and you may not be able to play it again.
Connection of a USB Flash Drive
USB connector
USB extension cable (included)
USB Flash Drive (sold separately)
•
Do not leave a ash drive in a vehicle for a long time. Heat and humidity may damage the ash drive.
54-EN
Connection of a camera
CAMERA OUT
Connector
Power Supply Connector
Power cable
Camera with RCA video output
(sold separately)
To Video Output terminal
Connect to the plus side of the car’s reverse lamp.
Reverse
(Violet/White)
PRE OUT cable
REAR VIEW CAMERA
*
*
RCA Extension Cable (sold separately)
Connection of Lighting Link System
⊕⊖
SUB.W OUTPUT
LIGHTING LINK (BROWN)
AMP REMOTE
Amplier
OPTION
OPTION
Sound input
•
For complete installation and Sub . Enclosure features, please see Prisma Link enclosure manual.
•
When connecting the Lighting Link cable, set the LED Brightness/LED Lighting Speed setting of this unit to 0 (page 26).
OEM Steering Wheel Control Rentention
To use this feature the vehicle must have resistive steering wheel controls. (Most Japanese and KoreanVehicles)
If the vehicle does not have restisive steering and uses data controlled steering wheel controls then a 3rd party Steering Wheel Interface with a female
3.5mm connection to be hardwired to the iLX-W670 steering wheel control wires is needed. (Sold Separately)
Please check what kind of Steering Wheel controls you have before install.
Professional Installation is reccomended.
For programming please see page 31.
LIMITED WARRANTY
ALPINE ELECTRONICS OF AMERICA, INC. (“Alpine”), is dedicated to quality craftsmanship and is pleased to oer this Warranty. We suggest that you
read it thoroughly. Should you have any questions, please contact your Dealer or contact Alpine at one of the telephone numbers listed below.
PRODUCTS COVERED:
This Warranty covers Car Audio Products and Related Accessories (“the
product”). Products purchased in the Canada are covered only in
the Canada. Products purchased in the U.S.A. are covered only in the
U.S.A.
LENGTH OF WARRANTY:
This Warranty is in eect for one year from the date of the rst
consumer purchase.
WHO IS COVERED:
This Warranty only covers the original purchaser of the product,
who must reside in the United States, Puerto Rico, Mexico,
Brazil,Argentina or Canada.
WHAT IS COVERED:
This Warranty covers defects in materials or workmanship (parts and
labor) in the product.
WHAT IS NOT COVERED:
This Warranty does not cover the following:
Damage occurring during shipment of the product to Alpine for
repair (claims must be presented to the carrier).
Damage caused by accident or abuse, including burned voice coils
caused by over-driving the speaker (amplier level is turned up and
driven into distortion or clipping). Speaker mechanical failure (e.g.
punctures, tears or rips). Cracked or damaged LCD panels. Dropped
or damaged hard drives.
Damage caused by negligence, misuse, improper operation or
failure to follow instructions contained in the Owner’s manual.
Damage caused by act of God, including without limitation,
earthquake, re, ood, storms or other acts of nature.
Any cost or expense related to the removal or reinstallation of the
product.
Service performed by an unauthorized person, company or
association.
Any product which has the serial number defaced, altered or
removed.
Any product which has been adjusted, altered or modied without
Alpine’s consent.
Any product not distributed by Alpine within the United States,
Puerto Rico or Canada.
Any product not purchased from an Authorized Alpine Dealer.
HOW TO OBTAIN WARRANTY SERVICE:
A
You are responsible for delivery of the product to an Authorized
Alpine Service Center or Alpine for repair and for payment of any
initial shipping charges. Alpine will, at its option, repair or replace
the product with a new or reconditioned product without charge.
If the repairs are covered by the warranty, and if the product was
shipped to an Authorized Alpine Service Center or Alpine, Alpine
will pay the return shipping charges.
B
You should provide a detailed description of the problem(s) for
which service is required.
C
You must supply proof of your purchase of the product.
D
You must package the product securely to avoid damage during
shipment. To prevent lost packages it is recommended to use a
carrier that provides a tracking service.
HOW WE LIMIT IMPLIED WARRANTIES:
ANY IMPLIED WARRANTIES INCLUDING FITNESS FOR USE AND
MERCHANTABILITY ARE LIMITED IN DURATION TO THE PERIOD OF
THE EXPRESS WARRANTY SET FORTH ABOVE AND NO PERSON IS
AUTHORIZED TO ASSUME FOR ALPINE ANY OTHER LIABILITY IN
CONNECTION WITH THE SALE OF THE PRODUCT.
HOW WE EXCLUDE CERTAIN DAMAGES:
ALPINE EXPRESSLY DISCLAIMS LIABILITY FOR INCIDENTAL AND
CONSEQUENTIAL DAMAGES CAUSED BY THE PRODUCT. THE TERM
“INCIDENTAL DAMAGES” REFERS TO EXPENSES OF TRANSPORTING
THE PRODUCT TO THE ALPINE SERVICE CENTER, LOSS OF THE
ORIGINAL PURCHASER’S TIME, LOSS OF THE USE OF THE PRODUCT,
BUS FARES, CAR RENTALS OR OTHERS COSTS RELATING TO THE CARE
AND CUSTODY OF THE PRODUCT. THE TERM “CONSEQUENTIAL
DAMAGES” REFERS TO THE COST OF REPAIRING OR REPLACING OTHER
PROPERTY WHICH IS DAMAGED WHEN THIS PRODUCT DOES NOT
WORK PROPERLY. THE REMEDIES PROVIDED UNDER THIS WARRANTY
ARE EXCLUSIVE AND IN LIEU OF ALL OTHERS.
HOW STATE/PROVINCIAL LAW RELATES TO THE
WARRANTY:
This Warranty gives you specic legal rights, and you may also have
other rights which vary from state to state and province to province.
In addition, some states/provinces do not allow limitations on how
long an implied warranty lasts, and some do not allow the exclusion
or limitation of incidental or consequential damages. Accordingly,
limitations as to these matters contained herein may not apply to
you.
IN CANADA ONLY:
This Warranty is not valid unless your Alpine car audio product has
been installed in your vehicle by an Authorized Installation Center,
and this warranty stamped upon installation by the installation
center.
HOW TO CONTACT CUSTOMER SERVICE:
Should the product require service, please call the following number
for your nearest Authorized Alpine Service Center.
CAR AUDIO 1-800-ALPINE-1 (1-800-257-4631)
NAVIGATION 1-888-NAV-HELP (1-888-628-4357)
Or visit our website at; http://www.alpine-usa.com
ALPINE ELECTRONICS OF AMERICA, INC., 1500 Atlantic Blvd, Auburn Hills, Michigan 48326, U.S.A.
Do not send products to this address.
Call the toll free telephone number or visit the website to locate a service center.
About the Rules of Bluetooth Electromagnetic Radiation Regulation
USA/Canada
FCC/IC CAUTION
This device complies with Part 15 of the FCC Rules and Industry Canada’s licence-exempt RSSs. Operation is subject to the following two
conditions:
• This device may not cause interference; and
• This device must accept any interference, including interference that may cause undesired operation of the device.
Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency
(RF) Exposure Guidelines and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that
it deemed to comply without maximum permissive exposure evaluation (MPE). But it is desirable that it should be installed and operated
keeping the radiator at least 20 cm or more away from person’s body.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée
aux deux conditions suivantes :
• l’appareil ne doit pas produire de brouillage;
• l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le
fonctionnement.
Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non contrôlé et respecte les
règles les radioélectriques (RF) de la FCC lignes directrices d’exposition et d’exposition aux fréquences radioélectriques (RF) CNR-102 de
l’IC. Cet équipement émet une énergie RF très faible qui est considérée conforme sans évaluation de l’exposition maximale autorisée (MPE).
Cependant, il est souhaitable qu’il devrait être installé et utilisé en gardant une distance de 20 cm ou plus entre le radiateur et le corps
humain.
“La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia
perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.”
resolution 680: “Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência em sistemas
devidamente autorizados.”
Don’t forget to take a moment to protect your purchase by registering your product now at the following address: www.alpine-usa.com/
registration.
N’oubliez pas de consacrer un moment à la protection de votre achat en enregistrant votre produit dès maintenant à l’adresse suivante :
www.alpine-usa.com/registration.
Recuerde que con solo unos pocos pasos podrá proteger su producto, registrándolo a través de la siguiente dirección: www.alpine-usa.com/
registration.
Open source licenses
This software includes open source software codes licensed under
GNU General Public
GNU GENERAL PUBLIC LICENSE
Version 2, June 1991
Copyright (C) 1989, 1991 Free Software Foundation, Inc.
51 Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA
Everyone is permitted to copy and distribute verbatim copies of this
license document, but changing it is not allowed.
Preamble
The licenses for most software are designed to take away your
freedom to share and change it. By contrast, the GNU General Public
License is intended to guarantee your freedom to share and change
free software--to make sure the software is free for all its users.
This General Public License applies to most of the Free Software
Foundation's software and to any other program whose authors
commit to using it. (Some other Free Software Foundation software
is covered by the GNU Lesser General Public License instead.) You
can apply it to your programs, too.
When we speak of free software, we are referring to freedom, not
price. Our General Public Licenses are designed to make sure that you
have the freedom to distribute copies of free software (and charge
for this service if you wish), that you receive source code or can get
it if you want it, that you can change the software or use pieces of
it in new free programs; and that you know you can do these things.
To protect your rights, we need to make restrictions that forbid
anyone to deny you these rights or to ask you to surrender the rights.
These restrictions translate to certain responsibilities for you if you
distribute copies of the software, or if you modify it.
For example, if you distribute copies of such a program, whether
gratis or for a fee, you must give the recipients all the rights that
you have. You must make sure that they, too, receive or can get the
source code. And you must show them these terms so they know
their rights.
We protect your rights with two steps:
(1) copyright the software.
(2) oer you this license which gives you legal permission to copy,
distribute and/or modify the software.
Also, for each author's protection and ours, we want to make certain
that everyone understands that there is no warranty for this free
software. If the software is modied by someone else and passed
on, we want its recipients to know that what they have is not the
original, so that any problems introduced by others will not reect
on the original authors' reputations.
Finally, any free program is threatened constantly by software
patents. We wish to avoid the danger that redistributors of a free
program will individually obtain patent licenses, in eect making the
program proprietary. To prevent this, we have made it clear that any
patent must be licensed for everyone's free use or not licensed at all.
Detailed license notice, full license texts and machine readable copy
of the corresponding source code are readily available on our OSS
website (*)
*
http://www.alpine.com/e/oss/download
Disclaimer
TO THE EXTENT PERMITTED BY APPLICABLE LAW, AND AS PROVIDED
IN THE GPL AND LGPL, PIONEER AND ITS LICENSORS PROVIDE AND
YOU ACCEPT THE FIRMWARE "AS IS" WITHOUT WARRANTY OF ANY
KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. YOU ACCEPT THE ENTIRE RISK AS TO THE
QUALITY AND PERFORMANCE OF THE FIRMWARE.
UNLESS REQUIRED BY APPLICABLE LAW, AND AS PROVIDED IN
THE GPL AND LGPL, IN NO EVENT WILL PIONEER OR ITS LICENSORS
BE LIABLE TO YOU OR ANY THIRD PARTIES FOR DAMAGES OF
ANY KIND ARISING OUT OF YOUR USE OR INABILITY TO USE THE
FIRMWARE, INCLUDING WITHOUT LIMITATION ANY DIRECT, INDIRECT,
INCIDENTAL, SPECIAL, CONSEQUENTIAL, PUNITIVE OR EXEMPLARY
DAMAGES, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
