Potato
Pasta
Pizza
Popcorn Vegetable Beverage
Meat
Defrost
Fish
Power
Level
Air fry
Grill/
Convection
1 2 3
Express Cook
4 5 6
7 8 9
STOP
0
START
CLEAR Clock
+30 sec
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
28L Multi Function Microwave
Air Fryer Convection Oven
Part No: 053632
2
Household use only
SAVE THESE INSTRUCTIONS
.IMPORTANT SAFEGUARDS…………。。……………… ..
WARNING: If the door or door seals are damaged, the oven must
not be operated until it has been repaired by a trained person.
WARNING: It is hazardous for anyone other than a trained person
to carry out any service or repair operation, which involves the
removal of any cover, which gives protection against exposure to
microwave energy. WARNING: Liquids or other food must not be
heated in sealed containers since they are liable to explode.
1. Only use utensils that are suitable for use in microwave ovens.
2. Metallic containers for food and beverages are not al lowe d
during microwave cooking.
Except when using the single barbecue function, single hot air
f unction, or single air frying function, the built-in grill or baking
tray can be used to cook food, and the grill or baking tray must
not come into contact with the furnace chamber;）
Attention: The microwave barbecue combination function,
microwave hot air combination function, and microwave air
frying combination function can be used to cook food on a grill
rack, but cannot be used on a baking tray.
3.
4. When heating food in plastic or paper containers, keep an ey e
on the oven due to the possibility of ignition.
5. The microwave oven is intended for heating f ood an d
beverages. Drying of food or clothing and heating of w armin g
pads, slippers, sponges, damp cloth and similar may l ead t o
risk of injury, ignition or fire.
6. If smoke is observed, switch off or unplug the appliance an d
keep the door closed in order to stifle any flames microwa v e
heating of beverages can result in delayed er uptive boiling,
therefore care has to be taken when handling the container.
7. The contents of feeding bottles and baby food jars are to b e
stirred or shaken and the temperature is to be check ed befor e
consumption, in order to avoid burns.
3
8. Eggs in their shell and whole hard-boiled eggs shall not b e
heated in microwave oven since they may explode, ev e n
after microwave heating has ended.
9. Failure to maintain the oven in a clean condition could lead t o
deterioration of the surface that could adversely affect the lif e
of the appliance and possibly result in a hazardous situation.
10. Care should be taken not to displace t he turntable when
removing containers from the appliance.
11. The appliance shall not be cleaned with a steam cleaner.
Warning: When the appliance is operated in the combination
mode, children should only use the oven under adult supervision
due to the temperatures generated.
CAUTION: HOT SURFACE
12. If the supply cord is damaged, it must be replaced by th e
manufacturer or its service agent or a similarly qualifie d
person in order to avoid a hazard.
13. This appliance can be used by children aged from 8 years an d
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they hav e
been given supervision or instruction concerning use of th e
appliance in a safe way and understand the hazards involved.
14. Children shall not play with the appliance.
15. Cleaning and user maintenance shall not be made by childre n
without supervision.
16. This appliance is intended to be used in household and simila r
applications such as:
- staff kitchen areas in shops, offices and others workin g
environments;
4
19. After plug in or t he
falls into standby m ode,
and the
- farm houses;
- by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments. The appliances are
not intended to be operated by means of an external timer or
separate remote-control system.
17. Do not directly put the glass plate into cold water after us e.
Allow the plate to cool for at least 20 minutes, then put i nto
water to avoid cracking.
18. Group 2 Class B appliance
Group 2 ISM equipment: contains all ISM equipment i n which
radio-frequency energy is intentionally g enerated and/or
used in the form of electromagnetic radiation for t he
treatment of material, EDM and arc welding equipment. Class
B equipment is suitable for use in domestic establishments
and in establishments directly connected to a low v oltage
power supply network which supplies buildings used f or
domestic purposes.
.INSTALLATION………………………………………………… …..……… .
1. If there is a safe film over the oven, tear it off before use.
Check carefully for damage. If any, immediately notify our
National Customer Service team.
2. Microwave oven must be placed under dry and
non-corrosiveness environments, kept away from heat and
humidity, such as gas burner or water tank.
5
3. To ensure sufficient ventilation, the distance of the back of
microwave to the wall should be at least 10 cm, the side to the
wall should be at least 5 cm, the free distance above the top
surface at least 20 cm. A vent must be installed at the rear
side of the microwave to allow ventilation.
4. The distance of the microwave to ground should be at least
85cm. The position of the oven shall be as far away from the
TV, Radio or antenna as picture disturbance, or noise may
occur.
5. The appliance must be positioned so that the plug is
accessible, and must ensure a good grounding in case
leakage, ground loop can be formed to avoid electric shock.
6. The microwave oven must be operated with the door closed.
7. As there is manufacturing residue or oil remained on the oven
cavity or heat element, it usually would emit an odor, even a
slight smoke, It is normal and would not occur after
several use, keep the door or window open to ensure good
ventilation. It is strongly recommended to place a cup of water
in the cavity, setting at high power and operate for several
times.
POSITION PLACEMENT AND PRECAUTIONS
To avoid contaminating furniture with oil, smoke, steam, and other
pollutants discharged from the exhaust during cooking, and even
cause fire due to overheating, the microwave should be kept at a
certain distance from walls and cabinets. Please place it at the
safe distance marked in the following diagram.
6
.CLEANING …………………… …………
MICROWAVE OVEN CARE
The oven should be cleaned regularly and any food deposits
removed.
a. Remove the power cord from the wall outlet before cleaning.
Allow the microwave oven to cool before cleaning.Do not
immerse the microwave oven in water or other fluids when
cleaning.
b. Failure to maintain the oven in a clean condition could lead to
deterioration of the surface that could adversely affect the life
of the appliance and possibly result in a hazardous situation.
c. Never use hard detergent, gasoline, abrasive powder or
metal brush to clean any part of the appliance.
d. Do not remove the waveguide cover.
e. When the microwave oven has been used for a long time,
there may be odor emitted from the oven, following 3
methods can reduce the odor
Above /Above 30cm
Left and right /Above 10cm
Front /Open area
Rear area /Above 10cm
Microwave oven
Maintain distance from surrounding objects.
Please check if it is placed on even surface before cooking.
Keep away from high temperatures and
damp place s. Ensure
that the microwave is well grounded.
7
How to clean surfaces in contact with food:
After use wipe the waveguide cover with a damp cloth, followed
by dry cloth to remove any food splashes and grease. Built -up
grease may overheat and may cause smoke or fire.
TIPS FOR CLEANING
How to clean door seals, cavity and adjacent parts:
Exterior:
Wipe the enclosure with a damp soft cloth.
Door:
Using a damp soft cloth, wipe clean the door and window.
Wipe the door seals and adjacent parts to remove any spill
or spatter.
Wipe the control panel with a slightly damp soft cloth.
Interior walls:
Wipe clean the interior surfaces with a damp soft cloth. Wipe
clean the waveguide cover to remove any food remains.
Turntable / Rotation ring / Rotation axis:
Wash with mild soap water.
Rinse with clean water and dry thoroughly.
f. When the product is not used, it should be placed in dry and
ventilated areas as well as possible.
1) Place several lemon slices in a cup, then heat with high
micro power for 2-3 min.
2) Place a cup of red tea in oven, then heat with high micro
power.
3) Put some orange peel into oven, and then heat them with
high micro power for 1 minute.
8
.PRODUCT INSTRUCTION…………………………....................
Waveguide cover
Never remove the waveguide cover.
To prevent moisture or fat from
entering the waveguide cover when
the microwave oven is working.
1) Door lock
Microwave oven door must be properly closed in order for it to
operate
2) Viewing window
Allow user to see the cooking status
3) Rotating ring
The glass turntable sits on its wheels; it supports the turntable
and helps it to balance when rotating
4) Rotating axis
The glass turntable sits on the axis; the motor underneath
it drives the rotation of the turntable
5) Turntable
The food is placed on the turntable, its rotation during
operation helps to cook food evenly
9
- Place the rotating ring first
- Fit the turntable onto the rotating axis and make sure that
it is fitted in properly
6) Control panel
See below in details (the control panel is may differ
from the product)
7) Grill rack
Use for air fry or roast functions.
8) Waveguide cover
It is inside the microwave oven, next to the wall of control
9) Baking tray
Never remove the waveguide cover
10
OPERATION OF CONTROL PANEL…。。。。。。。 。
Potato
Pasta
Pizza
Popcorn Vegetable Beverage
Meat
Defrost
Fish
Power
Level
Air fry
Grill/
Convection
1 2 3
Express Cook
4 5 6
7 8 9
STOP
0
START
CLEAR Clock
+30 sec
1. BEFORE COOKING
The display lights up when plugged in power supply, then enter
11
the standby state and display shows 1:00.
2. MICROWAVE FUNCTION
There are ten microwave power levels, 100P, 90P, 80P, 70P, 60P,
50P, 40P, 30P, 20P and 10P. Press the “Power Level”
button continuously and select the desired microwave power.
Press 0~9 number buttons to input the cooking time, the
maximum time that can be input is 99:99. After entering the
cooking time, press “START/+30s” button to start work. A
buzzer will sound to indicate operation complete.
HIGH
100% and 90%
power output
(Applic
able for quick and
thorough cooking)
M.High
80% and 70% power
output
(
Applicable for medium
express cooking)
Med
60% and 50% power
output
(
Applicable for steaming
food)
M.Low
40% and 30% power
output
(
Applicable for defrosting
food)
LOW
20% and 10% power
output
(
Applicable for keeping
warm)
a. The maximum time setting is 99 minutes and 99
seconds.
b. Never use the grill rack during microwave cooking.
c. Never operate the oven when empty.
d. At the maximum microwave power, the oven will
automatically reduce the power after a certain time to lengthen
the service life.
e. If you turn the food during operation, press the Start/+30s
button once and the preset cooking procedure will continue.
12
f. If you intend to remove the food before the preset time, you
must press Stop button once to clear the preset procedure to
avoid unintended operation for subsequent use.
3. DEFROST
There are two defrost mode, dEF1 and dEF2, dEF1 for
defrost by weight and dEF2 for defrost by time. Press “Defrost”
button to select defrost by weight or by time, and the display
screen will show "dEF1" or "dEF2". Press 0~9 number
buttons to input the food weight or defrosting time. The weight
range of dEF1 is from 100 to 1500g, and the maximum time of
dEF2 is 99:99. Press the “START/+30s” button to commence
operation. A buzzer will sound to indicate operation complete.
The dEF1 defrost mode by weight will have buzzer to prompt
the food to be turned over during defrosting.
Below is the range for the respective defrosting mode:
dEF1 For defrosting, the weight range from 100 to 1500g.
dEF2 For defrosting, the maximum time is 99:99.
a. It is necessary to turn over the food during operation to
obtain uniform effect.
b. Usually defrosting will need longer time than cooking food.
c. If the food can be cut by knife, the defrosting process is
considered completed.
d. Microwave penetrates around 4cm into most food
13
e. Defrosted food should be consumed as soon as possible, it is
advised to not freeze the food again.
4. AUTO COOKING
There are eight automatic menus, potato, pasta, pizza, popcorn,
vegetable, beverage, meat and fish respectively. Select the
desired auto menu button and press the corresponding
menu button continuously to select the desired food weight, and
the display shows the corresponding weight. After selecting
the cooking weight, press “START/+30s” button to start work. A
buzzer will sound to indicate operation complete.
Display Kind Method
A.1 Potato The optional weights are 250g, 500g and 750g.
A.2 Pasta The optional weights are 50g, 100g and 150g.
A.3 Pizza The optional weights are 200g and 400g.
A.4 Popcorn The optional weight is 100g.
A.5 Vegetable The optional weights are 200g, 400g and 600g.
A.6 Beverage
The optional weights are
1 cup, 2 cups or 3 cups,
each one about 250ml.
A.7 Meat The optional weights are 200g, 400g and 600g.
A.8 Fish The optional weights are 200g, 400g and 600g.
a. The food temperature before cooking should be between
20-25℃.
14
Higher or lower food temperature before cooking would affect
cooking time.
b. The temperature, weight and shape of food will affect
the cooking effect. Adjust the cooking time, as required for
better result.
5. GRILL FUNCTION
There are six modes of Grill(see table below) The display
screen will show G., G-1, G-2, and the set temperature.
Press this button continuously, select the desired mode and then
press the 0~9 number buttons to input the cooking time, the
maximum time that can be entered is 99:99. After entering
the cooking time, press the “START/+30s” button to commence
operation. A buzzer will sound to indicate operation complete.
G.
Grill, the heat element will be energized during
operation. Which is applicable for rolling thin meats or
pork, sausage, chicken wing as good brown color
can be obtained
G-1
Combination of grill and microwave cooking. 30%
microwave and 70% grill.
G-2
Combination of grill and microwave cooking. 55%
microwave and 45% grill.
When using grill function, all of the oven parts, as well as the rack
a
nd cooking containers, may become very hot. Use with caution
when removing any item from the oven. Use heavy potholders or
oven mitts to PREVENT BURNS.
15
Convection
Five temperature shifts can be set
C-1
Combination of convection
and microwave cooking.
30% microwave and 70% convection.
C-2
Combination of convection
and microwave cooking.
55% microwave and 45% convection.
When using convection function, all of the oven parts, as well
as the rack and cooking containers, may become very hot. Use
with caution when removing any item from the oven. Use heavy
potholders or oven mitts to PREVENT BURNS.
6. AIR FRY
There are three modes of air fry: air fry, AC-1 and AC-2. They are
air fry, combination 1 of air fry and microwave cooking and
combination 2 of air fry and microwave cooking. The display
screen displays "the set temperature", "AC-1" or "AC-2". Press the
"Air Fry" button continuously, select the desired mode. Then,
press the 0~9 number buttons to input the cooking time, the
maximum time that can be entered is 99:99. After entering the
cooking time, press the “START/+30s” button to commence
operation.. A buzzer will sound to indicate operation complete.
16
Air Fry Five temperature shifts can be set
AC-1
Combination of air fry and microwave cooking. 30%
microwave and 70% air fry.
AC-2
Combination of air fry and microwave cooking. 55%
microwave and 45% air fry.
In the mode of air fry, all of the oven parts, as well as the rack and
cooking containers, may become very hot. Use caution when
removing any item from the oven. Use heavy potholders or oven
mitts to PREVENT BURNS.
Cooking Guide
Food
Weight（g） Time（min）
Temperature（℃）
French Fries 250 25 230
Chicken
Wing
200/300/400/500
30（500g）
230
Fried ribs 200/300/400/500
30（500g ）
230
Chicken
Drumsticks
300/400/5 00
40（500g ）
230
Popcorn
Chicken
200/300/4 00
30（400g ）
230
Chicken
Nuggets
200/300/4 00
30（400g ）
230
7. EXPRESS COOK
7.1 In standby mode, you can directly press the 1~6 number
buttons to start the microwave oven. The working time is 1~6
minutes, that is, press 1 to operate for 1 minute, press 2 to operate
for 2 minutes, etc. After select the time, press “START/+30s”
button to commence operation.A buzzer will sound to indicate
operation complete.
7.2 In standby mode, press the “START/+30s” button to start the
microwave. The default operating time is 30 seconds. When in
operation, press the “START/+30s” button once for cooking time
increments of 30 seconds. A buzzer will sound to indicate
operation complete.
8. 0/Clock
The clock function and "0" button are combined in one button. The
clock is 24-hour system. The operation of the clock function is as
follows:
In standby mode, press and hold down the “0/Clock” button for
more than 3 seconds to enter the clock setting function., press the
0 ~ 9 number buttons to input the clock time directly and press the
“START/+30s” button to confirm the set time and exit the clock
setting function.
17
1) Set lock: Press and hold the STOP button for 3 seconds.
2) Cancel
lock: Press and hold the STOP button for 3
seconds.
18
9. STOP
In the process of cooking functions, press “STOP” button to
cancel the selections and return to standby mode. In the process
of microwave oven in operation, press “STOP” button to pause
operation. In the standby mode, press “STOP” button again to
cancel the function and return to standby mode.
10. START/+30s
After setting the cooking time or food weight, press “START/+30s”
button to start microwave oven immediately. During operation,
press “START/+30s” button to increase time, press once to
increase cooking time by 30 seconds, Note: Time adjustment
is not available for auto cooking and weight defrosting
functions. When operation is paused, press “START/+30s” button
to continue operation.
11. CHILD LOCK FUNCTION
Use this function to lock the control panel when you are cleaning
or to prevent children from using the microwave oven when
unsupervised. All the buttons are inoperable in this mode.
.UTENSILS GUIDELINE…… 。………… …………..
It is strongly recommended to use the containers which are
suitable and safe for microwave cooking. Generally speaking, the
containers which are made of heat-resistant ceramic, glass or
plastic are suitable for microwave cooking. Never use the metal
containers for microwave cooking and combination cooking
as spark is likely to occur. See table below.
Container
Material
Microwave Grill Combi Notes
Heat-resistant
ceramic
Yes Yes Yes
Never use
ceramics which are
decorated with
metal rim or glazed
Heat-resistant
plastic
Yes No No
Do not use for long
period with
microwave cooking
Heat-resistant
glass
Yes Yes Yes
Plastic film Yes No No
Do not use when
cooking meat or
chops as the
overtemperature may
damage the film
Grill rack No Yes Yes
The grill rack can only
be used in grill and
combination mode.
Metal container No No No
Do not use in
microwave oven.
Microwave can
not penetrate
through metal.
Lacquer No No No
Poor heat-resistant.
Do not use for
High-temperature
cooking
Bamboo wood
and paper
No No No
Poor heat-resistant.
Do not use for
High-temperature
cooking
19
.COOKING TIPS… …………… . ..
The following factors may affect the cooking result:
Food arrangement
Place thicker areas towards outside of dish, the thinner part
towards the centre and spread it evenly. Do not overlap if
possible.
Cooking time period
Start cooking with a short time setting, evaluate after time out
and extend cooking, if required. Over cooking may result in
smoke and burns.
Cooking food evenly
Food such as chicken, hamburger or steak should be turned
once during cooking.
Depending on the type of food, if applicable, stir it from outside
to centre of dish once or twice during cooking
Allow cooling time
After cooking, leave the food in the oven for an adequate
period of time, this allows it to complete its cooking cycle and cool
gradually.
Whether the food is done
Color and hardness of food help to determine if it is done,
these include:
- Steam coming out from all parts of food, not just the edge
- Joints of chicken can be moved easily
- Pork or chicken shows no signs of blood
- Fish is opaque and can be cut easily with a fork
Browning dish
When using a browning dish or self-heating container, always
place a heat-resistant insulator such as a porcelain plate under it
to prevent damage to the turntable and rotating ring.
Microwave safe plastic wrap
When cooking food with high fat content, do not allow the plastic
wrap come into contact with food as it may melt
Microwave safe plastic cookware
20
Some microwave safe plastic cookware might not be suitable
for cooking foods with high fat and sugar content. In
addition, the preheating time specified in the cooking
instruction must not be exceeded
.MAINTENANCE…… 。………………… ………… …
SERVICING
Please check
the following before contacting our National
Customer Service team.
1. Place one cup of water (approx.150ml) in a glass measure in the
oven and close the door securely. Oven lamp should go off if the
door is closed properly. Let the oven operate for 1 min.
2. Does the oven lamp light?
3. Does the cooling fan work?
(Put your hand over the rear ventilation openings.)
4. Does the turntable rotate?
(The turntable can rotate clockwise or counter clockwise. This is
quite normal.)
5. Is the water inside the oven hot?
If “NO” is the answer to any of the above questions, please
check your wall socket and the fuse in your electrical wiring
connection.
If both the wall socket and the fuse are functioning properly,
contact our National Customer Service team.
SERVICING SAFEGUARDS
Caution: MICROWAVE RADIATION
1. The high voltage capacitor remains charge after
disconnection; short the negative terminal of H. V capacitor to
the oven chassis (use a screwdriver) to discharge before
touching.
2. During servicing below listed parts can be removed and is
exposed to potentials above 250V to earth.
● Magnetron
● High voltage transformer
● High voltage capacitor
21
● High voltage diode
● High voltage fuse
3. The following conditions may cause undue microwave
exposure during servicing.
Improper fitting of magnetron;
Improper matching of door interlock, door hinge and door;
Improper fitting of switch support;
Door, door seal or enclosure has been damaged.
Correct Disposal of this product
This marking indicates that this product should not
be disposed with other household wastes
throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled
was
te disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To
return your used device, please use the return and
collection systems or contact the retailer where the
product was purchased. They can take this product
for environmental safe recycling.
22
Warranty
This product is covered under a 12 months warranty period. Kindly refer to the
warranty policy terms and conditions available on Camec website.
For further information or assistance, please contact our National Customer Support
Team or visit Camec website.
1. Australia on 1300 422 632 or camec.com.au
2. New Zealand on 09 257 2419 or camec.co.nz
For any retail or trade enquiries, please contact our Sales office.
CAMEC NEW ZEALAND
44 Montgomerie Road
Mangere Auckland 2022
Phone: (09) 2572419
CAMEC QUEENSLAND
Building 3 Archerfield Industrial
Park Cnr Kerry & Beaudesert
Road Archerfield QLD 4108
Phone: (07) 3710 9000
CAMEC VICTORIA
47-63 Remington Drive
Dandenong South VIC 3175
23-27 Freight Drive
Somerton VIC 3062
Phone: 1300 422 632
CAMEC NEW SOUTH WALES
Units 2 & 3 No. 1 Koonya Circuit
Caringbah NSW 2229
Phone: (02) 9525 2588
CAMEC WESTERN AUSTRALIA
190 Welshpool Road
Welshpool WA 6106
Phone: (08) 9351 0044
