Anemometer
Instruction manual
1. Function:
1)Wind speed & temperature measurement
2)Wind chill indication.
3)Temperature display in Celsius or
Fahrenheit
4)Different wind speed measurement unit
5)Measure wind speed in:
Current/Average/Max
6) Low battery warning
7) LCD back-light
8) Auto/Manual off
2. Operation:
1) Put battery into battery compartment,
LCD will blink all display for a second.
2) Recover battery door, push MODE in 1
second to turn on the unit. LCD will display
wind speed, temperature and battery icon.
LCD backlight will lasting for 5 seconds.
3) Setting different wind measurement:
Push MODE for 3 seconds until "m/s" start to
blink. Push SET to select desired
measurement unit. To confirm the desired
measurement unit by push MODE
Digit symbol: m/s meter per second;
km/h kilometer per hour; ft/min feet per
minute; knots nautical mile per hour; mph
mile per hour; Cu Current wind speed,
MAX max wind speed, average average
wind speed.
4) ℃/℉ switch option: Press the ℃/℉
key to select different temperature unit.
5) Press any key will active LCD
back-light for 5 seconds.
6) Measurement: when the wind vane
(impeller) turns, LCD will instant display
wind speed and temperature. When
temperature below 0 ℃, wind chill symbol
will shown on the LCD.
7) Push SET to turn off the unit.
3. Specification
Wind speed range
Unit
Range
Resolution
Threshold
Accuracy
M/s
0~30
0.1
0.1
±5%
Ft/min
0~5860
19
39
Knots
0~55
0.2
0.1
Km/h
0~90
0.3
0.3
Mph
0~65
0.2
0.2
Temperature range
Unit
Range
Resolution
Accuracy
℃
-10℃~45℃
0.2
±2℃
℉
14℉~113℉
0.36
±3.6℉
Battery
CR2032 3.0V
Thermometer
NTC thermometer
Operating temperature
-10℃~45℃(14℉~113℉)
Operating humidity
≤90%RH
Store temperature
-40℃~60℃(-40℉~140℉)
Current consumption
About 3mA
Weight
53g(with battery land yard)
Above picture and content just for
your reference. Please be subject to
the actual products if anything
different or updated. Please pardon
for not informing in advance.
Anemometer
