— F22 DRONE INSTRUCTION MANUAL —
Warning ------------------------------------------------------------ 3-4
Flight Safety -------------------------------------------------------- 5
Remote Control Func�ons
-------------------------------------
-----------------------------------------------
-------------------------------------
6-7
Drone Diagram --------------------------------------------------
8-10
Remote Control Opera�ng Method
-------------------------------
-------------------------------
11
12-22
24-27
28-29
30
Dual Remote Controller Mode
12
WayPoint Flight --------------------------------------------------
--------------------------------------------------
--------------------------------------------------
22
Orbit Mode
Install the Con�xo F22 App
Camera Func�ons
Specifica�ons
Parts list (Included)
-------------------------------------------------------- 23
PREFACE:
IMPORTANT:
SAFETY PRECAUTIONS:
Thank you for purchasing the Con�xo F22 GPS drone. Please read all instruc�ons
and warnings carefully before opera�ng. Please keep this instruc�on manual for
future reference and maintenance.
This R/C drone can be dangerous when in use. Please make sure you keep it a safe
distance from any persons or spectators while flying. Incorrect installa�on, poor
condi�ons, or users not familiar with opera�on may cause damage to the drone,
injure people, or cause an unexpected accident. Please pay close a�en�on to flight
safety rules and learn to recognize more dangerous condi�ons which may cause an
accident due to negligence.
This R/C drone may vary slightly in speed or sensi�vity while flying and can
cause poten�al danger. Therefore, please keep it far away from crowds,
buildings, trees, structures, high-voltage wire, etc. Avoid flying in adverse
weather condi�ons such as rain, electrical storms, and high winds to ensure
safety of the user, any spectators, and surrounding property.
The inside of the drone is composed of many precision electronic and
mechanical parts. Avoid any moisture or water content from entering the
main body of the drone as it may cause a breakdown of the mechanical and
electronic parts and thus cause an accident.
Please use the original parts made by Con�xo for any re-equipping or maintenance
to ensure safe flying. Please operate and use only under the scope of the product
func�on permi�ed. Using un-approved parts will void warranty.
DO NOT use for any illegal purpose or use beyond the scope of which your local
laws and regula�ons have s�pulated.
2. Keep away from moist environments.
1. Keep away from any structures or crowds.
3. Only operate with included parts for intended use.
1. This product is not a toy. It is a precision device integra�ng machinery and
electronics with air mechanics and high frequency transmission. It requires correct
assembly and debugging to avoid any accidents. The user should operate and
control this product in a safe manner. Incorrect opera�on may cause serious injury
or damage property. The device can also be lost due to incorrect opera�on.
2. This product is suitable for experienced UAV pilots no less than 14 years of age.
3. In the event of a problem during opera�on or maintenance, please contact the
local sales agent, retailer or Con�xo customer service for help.
- 1 -
Please use the original parts made by Con�xo for any re-equipping or maintenance
to ensure safe flying. Please operate and use only under the scope of the product
func�on permi�ed. Using un-approved parts will void warranty.
4. Avoid controlling it independently.
5. Do not operate under the influence of drugs or alcohol.
6. Please keep a safe range from drone when at high speeds.
7. Store it in a cool, dry place.
New users may have certain difficul�es during the early stages of learning
to operate this drone. Please try to avoid opera�ng the drone alone. When
available, always operate this drone under the guidance of a more
experienced user.
Please operate this R/C drone according to your own state laws and flying skill.
Fa�gue, poor mental state, or incorrect opera�on may increase the probability
of accidents.
When the operator is flying at high speed, please keep the drone far from the
pilot and any surrounding persons or objects to avoid causing danger or damage.
The R/C drone is composed of material such as metal, fiber, plas�c, electronics,
etc. Therefore, please keep it away from any heat source and avoid prolonged
exposure to direct sunlight. Excessive heat exposure can cause distor�on and
damage.
NOTE: This equipment has been tested and found to comply with the limits for
a class b digital device, pursuant to part 15 of the FCC rules. These limits are
designed to provide reasonable protec�on against harmful interference in a
residen�al installa�on. This equipment generates, uses, and can radiate radio
frequency energy. If not installed and used in accordance with the instruc�ons,
the equipment may cause harmful interference to radio communica�ons.
• However, there is no guarantee that interference will not occur in a par�cular
installa�on. If your equipment does cause harmful interference to radio or
television recep�on(which can be determined by turning the equipment off and
on), the user is encouraged to try to correct the interference by one or more of
thefollowing measures:
• Please note that changes or modifica�ons not expressly approved by the
party responsible for compliance could void the user’s authority to operate
the equipment.
•Reorient or relocate the receiving antenna.
•Increase the separa�on between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
1. This product is not a toy. It is a precision device integra�ng machinery and
electronics with air mechanics and high frequency transmission. It requires correct
assembly and debugging to avoid any accidents. The user should operate and
control this product in a safe manner. Incorrect opera�on may cause serious injury
or damage property. The device can also be lost due to incorrect opera�on.
2. This product is suitable for experienced UAV pilots no less than 14 years of age.
3. In the event of a problem during opera�on or maintenance, please contact the
local sales agent, retailer or Con�xo customer service for help.
- 2 -
WARNING:
1. There is important informa�on contained in this package and instruc�on manual,
please keep it for future reference.
2. It is your responsibility to ensure that this drone will not cause injury to others or
cause any damage to property.
3. Please operate strictly as shown on the instruc�on manual when debugging or
assembling this drone. During the process of flying or landing, please keep 3-6
feet between the user and the drone to avoid colliding with the head, face or
body, which may cause injury.
4. Our company and distributors are not responsible for any incorrect opera�on that
may lead to loss, damage, or injury to the body.
5. Children ages 14 and up should use this product under the guidance of an adult.
This product is FORBIDDEN to be used by children under 14 years old.
6. Correctly assemble and use this product as shown in the instruc�on manual or
packing instruc�on. Some parts should be assembled by an adult.
7. Small parts are included with this product. Please place the drone and associated
parts beyond the reach of children to avoid a CHOKING HAZARD or parts being
mistakenly swallowed.
8. Playing on the road or near high-traffic areas is strictly FORBIDDEN to help prevent
accidents.
9. Please dispose of the packing material in a �mely manner to avoid causing injury
or harming small children.
When the operator is flying at high speed, please keep the drone far from the
pilot and any surrounding persons or objects to avoid causing danger or damage.
10. Please DO NOT disassemble or re-equip the drone as it may cause a breakdown
of the drone during flying.
11. Ba�eries for the charger should be inserted into the designated power source
with the same logo as the product.
12. A Built-in rechargeable 3.7V lithium polymer ba�ery is included in the remote
control.
13. Only the original charger made from our factory can be used.
14. The charger is not a toy.
15. When charging the ba�ery, please do so under the surveillance of an adult.
Please keep the ba�ery far away from any combus�ble object when charging.
Please keep this drone within eyesight when charging.
16. Please DO NOT short-circuit or squeeze the ba�ery as it may cause an explosion.
17. DO NOT mix the Li-ion ba�ery with a different type of ba�ery.
18. An intelligent lithium ba�ery is loaded in the quad-rotor. Both built-in or external
can be used for charging.
19. Please DO NOT short-circuit the ba�ery, decompose the ba�ery, or throw the
ba�ery into the fire; DO NOT place the ba�eries near high temperature or heated
areas (such as a fire or electric hea�ng devices).
- 3 -
WARNING: PRODUCT SHOULD ONLY BE USED BY ADULTS
AND CHILDREN14 YEARS AND OLDER. ADULT SUPERVISION
REQUIRED FOR CHILDREN UNDER 14 YEARS OF AGE.
WARNING: CHARGING OF THE DRONE BATTERY MUST BE
SUPERVISED AT ALL TIMES BY AN ADULT. UNPLUG THE
BATTERY WHEN FULLY CHARGED. DO NOT OVER-CHARGE
THE BATTERY.
1. There is important informa�on contained in this package and instruc�on manual,
please keep it for future reference.
2. It is your responsibility to ensure that this drone will not cause injury to others or
cause any damage to property.
3. Please operate strictly as shown on the instruc�on manual when debugging or
assembling this drone. During the process of flying or landing, please keep 3-6
feet between the user and the drone to avoid colliding with the head, face or
body, which may cause injury.
4. Our company and distributors are not responsible for any incorrect opera�on that
may lead to loss, damage, or injury to the body.
5. Children ages 14 and up should use this product under the guidance of an adult.
This product is FORBIDDEN to be used by children under 14 years old.
6. Correctly assemble and use this product as shown in the instruc�on manual or
packing instruc�on. Some parts should be assembled by an adult.
7. Small parts are included with this product. Please place the drone and associated
parts beyond the reach of children to avoid a CHOKING HAZARD or parts being
mistakenly swallowed.
8. Playing on the road or near high-traffic areas is strictly FORBIDDEN to help prevent
accidents.
9. Please dispose of the packing material in a �mely manner to avoid causing injury
or harming small children.
20. The drone should be kept away from any other electric appliances, equipment,
or magne�c objects, as these may cause interference with each other and your
drone.
21. Please keep a safe distance from the high-speed rota�ng rotor to prevent
dangerous wounds, cuts, or twis�ng in the rotors.
22. The engine will heat up. Please DO NOT touch it to avoid being burned or
injured.
23. Please DO NOT put this product close to your ears as it may cause damage to
your hearing.
24. The included mini USB 5V wall charger is recommended for charging. DO NOT
use a charger stronger than 5V.
25. To comply with the command of the magne�c environment requirement
formulated by the avia�on radio bureau and the related authority, during the
regulated period in certain areas please stop using the remote control of this
model when such regula�on command is issued.
26. Keep your UAS within sight.
27. Never fly over groups of people.
28. Never fly over stadiums or spor�ng events.
29. Understand airspace restric�ons and requirements.
- 4 -
Flight Safety
Fly in Open Strong GPS Maintain Line Fly Below
Areas Signal of Sight 400 feet (120 m)
Avoid flying over or near obstacles, crowds, high voltage power lines, trees,
airport s or water.
DO NOT fly near strong electromagne�c sources such as power lines and
base sta�ons as it may affect the onboard compass.
DO NOT use the drone in adverse weather condi�ons such as rain, snow,
fog and wind speeds exceeding 10 m/s or 22 mph.
No Fly Zone
Stay away from the rota�ng
propellers and motors.
- 5 -
Remote Control Func�ons
It’s important to understand basic flight guidelines, for the safety of both
you and those around you. Don’t forget to read the safety guidelines
before flight.
1. Thro�le S�ck
2. Direc�on S�ck
3. 1-Click Return-To-Home
4. Power Bu�on:
ON – Click Once, White Light Comes ON
OFF – Click Once, Then Hold 2 Seconds Un�l White Light Turns Off
When there is no opera�on in 10 minutes, the remote controller will be
automa�cally powered off.
- 6 -
1
3
7
9
8
10
4
5
6
2
5. 1-Click Headless Mode
(Hold the bu�on for 3 seconds to turn off GPS mode)
6. 1-Click Takeoff with Auto-Hover; 1-Click Landing
(Hold the bu�on for 3 seconds for Emergency Stop)
7. 1-Click Photo Capture; Hold 3 Seconds to Enter Trim Mode
(Note: No need to trim under the GPS mode)
8. 1-Click Video Recording; Click Again to Stop Video
9. Adjust the Speed –
Scroll Right: + Speed
Scroll Le�: - Speed
1. Full Charge: Green Light
2. Charging: Red Light
3. Power On: White Light
4. Indicates Returning To Home
5. Speed
6. Photo/Video
7. Headless Mode/Trim
There is a snap lock on the antenna, please follow PIC.1 to open the antenna.
- 7 -
1
4 6
5 7
2 3
PIC.1
10. Adjust the Camera Angle –
Scroll Right: Camera Down
Scroll Le�: Camera Up
- 8 -
2. Install the Propellers
Drone Diagram
1. HD Camera
2. Propeller
3. Propeller Motor
4. LED Indicator
5. Intelligent Ba�ery
①. Drone Unfold
②. Drone Fold
Unfold the front arm first, then expand the back arm.
Fold the back arm first, then fold the front arm.
Please note that the le�er “A” or “B” is printed on each propeller, and make
sure all the propellers are a�ached in the correct motor posi�on.
1
2
3
4
5
F22
11
22
1 1
2 2
B
B
A
A
3. Intelligent Flight Ba�ery
4. Charge the Ba�ery
— To power ON, hold the bu�on for 3 seconds.; To power OFF, hold the bu�on
for 3 seconds.
— When the ba�ery is at low power, the blue power indicator will start flashing.
At this �me, return the drone immediately and charge the ba�ery to
avoid unnecessary power failures.
- 9 -
1. Power Bu�on
2. Ba�ery Power Indicator
3. USB Charging Port
Low Electricity High
Push 2 Side Buttons In,
Pull the Battery from the Drone
1
2
3
5. Lithium Ba�ery Charging Instruc�ons
(While charging, the indicator on the remote control is Red. When fully charged,
the indicator on the remote control will turn to solid Green).
Tip: When the remote control ba�ery is low, the power indicator light on the
remote control will keep flashing. Please charge the remote control.
1. Balanced Charging: Turn the ba�ery OFF before charging. Insert the USB
cable into the USB port of the charger and connect to the charging port
of the ba�ery to charge. The indicator on the drone will begin blinking
blue when charging. When fully charged, the indicator on the drone will
turn to a solid blue.
2. The drone can be charged by a travel or car charger.
3. The drone ba�ery takes about 110 minutes for a full charge. Full flight �me
is about 18 minutes.
4. The remote control lithium ba�ery takes about 60 minutes for a full charge.
Phone adapter:
5V/2A(Not include)
Charging �me:
Remote Control
Charging Es�ma�on
�me : Around
60 minutes
- 10 -
About 110 minutes
- 11 -
Note: When the drone is indoors with a weak GPS signal, (lights rapidly blinking
Blue + White), holding (compass) for 3 seconds to turn off GPS mode and the
drone can be operated under the normal mode. All GPS func�ons will be disabled.
— Press (camera) then press (power) at the same �me. A beeping sound
means the Right Joys�ck has switched to the thro�le s�ck. When you turn
off the remote control and turn it on again, the remote resets to default with
the Le� Joys�ck as the thro�le s�ck.
Dual-Se�ng Remote Controller
UP
DOWN
T
u
r
n
L
e
�
T
u
r
n
R
i
g
h
t
F
o
r
w
a
r
d
Le�
Right
B
a
c
k
w
a
r
d
Left Stick Right Stick
- 12 -
Direc�on Joys�ck
REMOTE CONTROL OPERATING METHOD
Thro�le Joys�ck
T
u
r
n
L
e
�
UP
DOWN
T
u
r
n
R
i
g
h
t
F
o
r
w
a
r
d
Le�
Right
B
a
c
k
w
a
r
d
Con�xo F22
Install the Con�xo F22 App
QR code for “Con�xo F22” applica�on for Apple iOS system (Please scan this QR
code to install this so�ware).
QR code for “Con�xo F22” applica�on for Android system (Please scan this QR
code to install this so�ware).
Scan the following code with your smart phone in order to download
the flight control app.
F22
- 13 -
Step 3: Connect App
— Connect your smartphone to the WiFi of the drone and check the drone’s
status on the “Con�xo F22 ” app.
— Open the “Con�xo F22” applica�on on your smartphone to access the
control interface.
Con�xo - F22 - XXXX
Step 2: Turn On The Remote Control & Pair With Drone
— Power on the remote control and push the le� joys�ck up then
down to pair with the drone.
— When rear lights flash blue and front lights white, pairing is successful.
Thro�le Joys�ck
NOTE: You can connect to the drone WiFi signal at this �me to view the
current drone on the Con�xo F22 app, or wait un�l a�er GPS is calibrated.
Flight
Step 1: Turn on the drone and set down on a level surface
— The drone will auto-trim to this level surface.
— All lights blinking red.
- 14 -
APP INTRODUCTION
Wait un�l the Drone Status at the bo�om right of the screen reads “Ready to Fly”
before ini�a�ng flight. This will ensure that your GPS is synced and your drone
is ready to fly.
First select the drone model F22, then click the “CONTROLS” bu�on to enter
the APP interface.
1
2
10. Please DO NOT disassemble or re-equip the drone as it may cause a breakdown
of the drone during flying.
11. Ba�eries for the charger should be inserted into the designated power source
with the same logo as the product.
12. A Built-in rechargeable 3.7V lithium polymer ba�ery is included in the remote
control.
13. Only the original charger made from our factory can be used.
14. The charger is not a toy.
15. When charging the ba�ery, please do so under the surveillance of an adult.
Please keep the ba�ery far away from any combus�ble object when charging.
Please keep this drone within eyesight when charging.
16. Please DO NOT short-circuit or squeeze the ba�ery as it may cause an explosion.
17. DO NOT mix the Li-ion ba�ery with a different type of ba�ery.
18. An intelligent lithium ba�ery is loaded in the quad-rotor. Both built-in or external
can be used for charging.
19. Please DO NOT short-circuit the ba�ery, decompose the ba�ery, or throw the
ba�ery into the fire; DO NOT place the ba�eries near high temperature or heated
areas (such as a fire or electric hea�ng devices).
— Keeping the drone level and parallel to the ground, pick it up from the back
and rotate your body in one full circle (360°).
— Back lights will turn to solid blue.
Part 2: Compass Calibra�on
NOTE: If using the app, the on-screen instruc�ons can guide you as well.
- 15 -
Step 4: Compass Calibra�on
Part 1: Compass Calibra�on
— Move and posi�on le� joys�cks to 1 o’clock & right joys�ck to 11 o’clock.
— Rear lights will rapidly blink Blue/Red and White/Red in front.
— App Drone Status: “Compass Calibra�on”.
— From the bo�om, hold the drone ver�cally so the camera is facing toward
the ground. Rotate your body in one full circle (360°).
— Front lights will turn to solid white.
— App Drone Status: “Compass Calibra�on Okay”
Part 3: Compass Calibra�on
NOTE: If compass does not calibrate quickly, tap the screen on the
Con�xo F22 App and restart the calibra�on process.
Step 5: Reset to factory Se�ng/Calibrate Gyroscope
— Push the joys�cks into the 11 o’clock (le� joys�ck) & 1 o’clock (right joys�ck)
posi�on.
— Lights will rapidly blink Blue (rear) and White (front).
— App Drone Status: “Gyroscope is Being Calibrated” then “Gyroscope okay”.
- 16 -
Step 6: GPS Searching (DO NOT use GPS Mode Indoors)
— Set the drone back down on a level surface.
— Lights will return to rapid-blinking Blue (rear) and White (front). This means
the drone is searching for the GPS signal.
— This process can take a few minutes.
— App Drone status: “Wai�ng for GPS Signal”
NOTE: Wait for rear lights to be solid blue and front lights white before
ini�a�ng takeoff.
- 17 -
Star�ng/Stopping motors
Star�ng Motors:
Stopping Motors:
1. Push the joys�cks into the 5 o’clock (le� joys�ck) & 7 o’clock (right joys�ck)
posi�on.
2. Motors will start working. Push the le� joys�ck up to takeoff or press the
1-Key Take off bu�on.
1. Push the joys�cks back into the 5 o’clock (le� joys�ck) & 7 o’clock (right
joys�ck) posi�on and the motors will shut off.
2. The motors will go idle if they are not operated a�er 20 seconds.
Once the lights have switched to all solid, you are ready to fly!
— Blue (rear) and white (front) lights are all solid (no blinking).
— App Drone Status: “Ready to fly”
NOTE: Start the motors before drone takeoff.
Take off/Landing/Emergency Stop
Rota�ng propellers can be dangerous. DO NOT start the motors when
there are people nearby.
About 5 feet
1. Thro�le S�ck
2. Direc�on S�ck
3. 1-Click Return-To-Home
4. Power Bu�on:
ON – Click Once, White Light Comes ON
OFF – Click Once, Then Hold 2 Seconds Un�l White Light Turns Off
When there is no opera�on in 10 minutes, the remote controller will be
automa�cally powered off.
- 18 -
WARNING: When using the emergency stop feature during flying opera�on, it may
cause the damage if the drone crashes or can injure people underneath the drone.
Always fly in open and clean area, the F22 drone does not have obstacle avoidance
capability when the drone returns back to assigned area.
When the Follow Me func�on is ac�vated, the drone will follow the GPS in your
smartphone wherever you go (Make sure your smartphone is connected with the
drone successfully using the Con�xo F22 App).
1. Be sure to keep the drone about 9 feet away and 90 feet high.
2. Click (running person) on the app interface.
4. Click the (running person) on the app interface again to exit the Follow Me
mode. Common Issues: Follow Me mode may not work if your phone’s GPS signal
is too weak. This could be due to signal loss from surrounding buildings and trees
or conges�on from too many mobile phones in the area.
3. Wait for Drone Status on the app to display “Follow Me Ready” in the bo�om
right corner of the screen. The drone will then follow the phone’s GPS coordinates.
Follow Me Mode
1-Key Take Off: Press and the propellers will spin and the drone will li� to
an al�tude of about 5 feet. (Always keep the front of the drone facing forward).
Emergency Stop: Hold for 3 seconds and the drone will immediately shut off
and drop. An air-born unit will drop from the sky.
1-Key Landing: Press and the drone will slowly lower to the ground and
land automa�cally. Remember to always keep your hands on the remote control
as long as the motor is s�ll spinning.)
- 19 -
Click (running person) then click (box around person or Object ). Tap on
the object or person you want to track, then tap again to confirm your selec�on.
Follow Object
NOTE: Make sure the size of the frame you mark is the same as the object or
person you tap, the frame should not exceed the object or person in the
capture frame.
NOTE: Hand gestures are based on your right hand.
Click (hand with two fingers) on the App, follow the “Warm Tip” on the App
Screen. Hold up 2 fingers to take a picture. Wave your hand to begin recording
video. There is a 3 second countdown before taking a video or picture.
Selfie Mode
This func�on can only be used when there is adequate light. Low light or
dimly lit areas may prevent the camera from detec�ng your hand gestures
- 20 -
The Return to Home (RTH) func�on brings the drone back to the Take Off Point.
This func�on can only be achieved under GPS mode.
There are 3 types of RTH: Smart RTH/Low-ba�ery RTH/Fail connec�on RTH
Return-to-home GPS Feature Descrip�on
When the drone is doing The Return to Home feature, it will first fly straight up to
the according to the return to home al�tude se�ng. When you take the drone
out of beginner mode, you must set the return al�tude so that it will clear any
objects (buildings or trees) in the area. A�er the drone reaches this height, it will
then relocate to the home (take off) posi�on and then descend and land to the
star�ng point.
Return-to-Home (RTH)
RTH Bu�on
RTH Bu�on in App
①. Smart Return To Home
②. Low-Ba�ery Return-to-Home
③. Fail connec�on Return-to-Home (RTH)
Low-Ba�ery RTH is triggered when the flight ba�ery is depleted to a point that
may affect the safe return of the drone. The drone flies back to about 100 feet
from the last known home loca�on.
The drone will enter Return-to-Home Mode if the signal to the remote control
is lost. Re-sync the remote control to the drone if the drone flies back into your
view. Pull the thro�le down to land the drone in a safe area.
Headless Mode
Don’t change your direc�on. Don’t change your direc�on.
The direc�on of control when the drone is paired.
While in Headless Mode, the forward direc�on is the direc�on the pilot faces when
the pilot pairs the drone with the remote control. If the pilot pushes the direc�on
joys�ck forward the drone will fly forward. If the pilot pushes the direc�on joys�ck
backward, the drone will fly towards him/her. If the pilot moves the right s�ck le�
or right, then the drone will also move le� or right, rela�ve to the pilot. It is very
important that the pilot does not change posi�ons or the direc�on he or she is
facing because this will cause misdirec�on of the drone flight control.
1. The drone defaults to Normal Mode when the drone and remote control
are matched successfully. Click (compass) to enter into Headless mode.
Click (compass) again to exit Headless mode.
2. Normal Mode: Before takeoff, the white lights on the drone indicate the
forward-facing direc�on.
3. Headless Mode: Before takeoff, the white lights on the drone indicate
the forward-facing direc�on. When the drone rotates in flight, the flight
direc�on is not changed.
- 21 -
Adjus�ng Trim in No GPS Mode
If the drone flies in None GPS Mode, you can trim the drone to obtain more balanced
flight. Press and hold (camera bu�on) for 3 seconds, it will enter trim mode.
Holding the bu�on and pushing the direc�on joys�ck to the opposite side at the
same �me, the drone dri�s to rebalance it. For example, if the drone dri�s to the
le�, push the joys�ck to the right to make the drone balanced. Release (camera
bu�on) to exit trim mode.
- 22 -
— To start a WayPoint Flight, first download and save your local map in your
smartphone. (Connect your smartphone to network via WiFi or 4G LTE, open
the Con�xo F22 App and enable the Waypoint mode, you will see a map then
zoom in to the maximum, when the map is fully displayed.)
WayPoint Flight
— Successfully connect the drone WiFi with your smartphone,click
(2 rectangles) on the App. Find the Red Circle (LIMITED FLIGHT RANGE)
/ TAKEOFF POSITION / DRONE CURRENT POSITION on the map. Mark the
points (up to 16) you plan to fly within the Red Circle range on the map. If
you would like to reset the points or flight path, click or Click
and confirm to start the WayPoint Flight. Push the right joys�ck at any�me to
cancel the WayPoint Flight func�on.
Delete single
Delete all
Send
- 23 -
1. Hover the drone around the center point.
4. Press (camera) + (video camera) on the remote control at the same
�me again. The drone will begin to fly according to the radius range you set
in STEP 2 (Note: If the radius range is less than 6 feet, the drone will fly to 6 feet
automa�cally) . Move the direc�on joys�ck to cancel the Point of Interest mode.
2. Press (camera) + (video camera) on the remote control at the same �me.
3. Move and set the drone in the radius range you prefer (within 6 feet – 30 feet)
using the direc�on joys�ck.
NOTE: Press (camera) + (video camera) on the remote control at the
same �me and the Point of Interest func�on can be ac�vated if the drone
and remote control successfully paired and the drone flies up.
Orbit Mode
- 24 -
2. Press (camera) + (video camera) on the remote control at the same �me.
Flight
The Default GPS Mode is Beginner Mode. In Beginner Mode:
1. Flight Distance from remote control is limited to between 0 – 90 feet.
2. Flight Al�tude from remote control is limited to between 0 – 90 feet.
3. Return-To-Home Al�tude is below 75 feet.
You can turn off the Beginner Mode to modify the parameters in the App on
your phone.
Flight Se�ng
On APP
CAMERA FUNCTIONS
Press (camera) on the remote control or tap (camera) on the App to take a
picture. The red light above the camera on your remote control will flash once,
indica�ng the camera took a photo.
Press (video camera) on the remote control or tap (video camera) on the
App to record a video. The red indicator will con�nuously blink, indica�ng the
camera is recording video.
Press (video camera) again to save the video. DO NOT take photos while
recording video.
Take Photo
Take Video
App Icons
NOTE: When using the “Con�xo F22” App, the original photos and videos
will be compressed and saved to your smartphone.
- 25 -
Figure 1. One Bu�on Media Sharing
Figure 2. Control Bu�ons
2017-12-28
Photo Video
NO
Check all Share Save to the Delete
phone album
1. One-Bu�on Media Sharing
- 26 -
Figure 3. Viewing Photos
Figure 4. AirDrop Photo Sharing
2. Click once or press (checkmark list) to choose the photos you want to share.
Click (box with arrow) to choose the pla�orms to share to (Pic 3).
1. Open the App, click (gallery) to access your picture and video files (Pic 1.)
Reminder: You can share up to 9 pictures at the same �me, but you can only
choose one video for sharing each �me.
- 27 -
2. How To Find a Lost Drone
①. Click the (satellite) 3 �mes to open the map to search for the drone.
②. The last posi�on of the lost drone will appear on the map, and you can
find the last posi�on of the drone according to the label on the map
(about 30 feet error).
Note: The APP must remain open all the �me. If the APP is closed, the
last posi�on of the drone will disappear on the map.If you reach the last
known point on the map, and are s�ll unable to locate the drone, you can
try to toggle the drone wifi connec�on off/on. Reconnec�ng to the drone
wifi would establish a live feed connec�on and give you a further clue to
loca�ng the drone. The drone Wifi will broadcast as long as the ba�ery s�ll
has power.
Waiting for GPS Signal D:00 H: 0.0 DS: 0.0 VS: 0.0
The original images and videos are saved on the Micro SD card. Push the Micro SD
card slightly to release the memory card. Next, insert the card into the card reader.
Insert the card reader into the USB outlet of a computer to retrieve the photos
and videos from the Micro SD card. The images can be also viewed in the App.
Micro SD Card
You can use up to a 32GB memory card with your drone.
There are a few restric�ons for recording over wi-fi. The best quality possible
transmi�ng via Wi-Fi is 720p. Wi-Fi signal loss from interference will cause the
jumps or delays in video recordings. The best solu�on is to add a micro SD card to
capture uninterrupted video.
A micro SD card helps ensure best video quality is recorded. The largest size
capacity is 32GB, which will hold a good amount of recording �me. A high quality,
brand name micro SD is recommended for op�mal performance, some lower
quality brands may not be compa�ble. If the card is larger than 32GB, you may
format at 32GB fat32 or NTFS par��on on the drive and that will resolve size
compa�bility.
If the micro SD card is new, first make sure the card is readable in your laptop or
other device. Format the micro SD card on the first use if your unable to read the
memory card.
Micro SD
Micro SD Card (Sold separately)
- 28 -
- 29 -
SPECIFICATIONS
MODEL: F22
Weight (Including Ba�ery): 242g/8.5 oz
Flight Time: About 18 minutes
WIFI Camera Distance: 50m～300m( 150feet～1000 feet) (Outdoors and
unobstructed, depending on condi�ons and your
mobile device)
Motor Model: 1020
Auto-Hovering: Enabled
Opera�ng Temperature Range: 32°to 104°F ( 0°to 40°C)
Satellite Systems: GPS / GLONASS
Dimensions: Open – 11.81” L x 11.41” W x 2.56” H
Folded – 5.71” L x 3.94” W x 2.56” H
Controllable Range: Pitch: -90°to 0°
Lens: FOV 90°/2.0
S�ll Photography Mode: Single shot
Photo: JPEG
Video: MP4
Supported External Memory: Micro SD Card up to 32GB (not included)
Opera�ng Temperature: 32°to 104°F ( 0°to 40°C )
● Drone
● Camera
Mobile App: “Con�xo F22” in App Store & Google Play Store
Live View Working Frequency: 2.4 GHz ISM
Latency: Low Latency Video (depend on condi�ons and mobile device)
Required Opera�ng Systems: iOS 8.0 or later / Android 4.4.4 or later
Recommended Devices: 4.7” to 5.5” Smartphones
● App / Live View
1080P
Phone
Video
TF card
Video
3840X2160P
1280X720P
2048X1152P
2048X1152P
25 fps
25 fps
F22
CAMERA STORAGE RESOLUTION
FRAME PER
SECOND
- 30 -
Voltage: 5V/2A
Rated Power: ≤10 W
Opera�ng Frequency: 2.4 GHz
Ba�ery Capacity: 300 mAh
Opera�ng Voltage: 3.7V
Max Control Distance: 548M (1800 feet) (Outdoor and unobstructed)
Max Charging Time: About 60 minutes
Ba�ery life on control: 10 hours Max
Mobile Device Holder: 4.7” to 5.5” Smartphones
Opera�ng Temperature: 32°to 104°F ( 0°to 40°C )
Capacity: 1500 mAh
Voltage: 7.4V
Ba�ery Type: Lipo Lithium-Ion Ba�ery
Energy: 8.88Wh
Net Weight: 66 g / 2.3 oz
Max Charging Power: 5-7.5W
Max Charging Time: About 110 minutes
● Micro USB Cable
● Remote Control
● Drone Ba�ery
PARTS LIST (Included)
Blade x 4
Instruc�ons x 1
Screw driver x 1
Screw x 12
USB cable
Only for charging
- 31 -
How to fix Android Not Connec�ng to Wi-Fi Problem
COMMON PROBLEMS AND SOLUTIONS
Tip 1. Restart Phone
Tip 2. Toggle WiFi Off and on
Tip 3. Turn Airplane Mode Off
Tip 4. Turn Bluetooth off while troubleshoo�ng
Tip 5. Turn Power Saving Mode off
Tip 6. Turn off Smart Network Switch
Tip 7. Adjust Auto-Reconnect se�ngs
Tip 8. Use a WiFi Connec�on Manager app if necessary
Tip 9. Make sure your phone supports 2.4 Ghz Wifi (5 Ghz for Pro edi�on.)
Drone lights flashing and
no response from the drone
when opera�ng.
The blades spin, but the
drone cannot takeoff.
The
drone shakes
heavily.
Drone cannot stay balanced
in flight.
Drone is unstable in flight
like in Follow Me mode
Drone will not auto
hover in one place
Unstable magne�c field Recalibrate compass / do
factory reset
1. The blades distorted.
2. Motor isn’t working
properly.
Three-axis accelera�on
sensor is unbalanced
1. Insufficient ba�ery power.
The blades distorted. Replace the blades.
1. Replace the blades.
2. Replace the motor.
Restart and re-calibrate the
drone.
1. Remote is not synced to
the drone.
2. Insufficient ba�ery power.
1. Refer to the App Quick Start
and re-sync the drone.
2. Recharge the ba�ery.
1. Recharge the ba�ery.
2. Replace the blades.
THE PROBLEM REASON TROUBLESHOOT
- 32 -
2. The blades distorted.
3. The blades Side A and
Side B are reversed.
In order to make sure that your drone meets the requirements
of the electromagne�c environment of the avia�on radio sta�on,
flying within the scope of 7 miles on each side by taking the airport
runway center line as the middle line is HIGHLY FORBIDDEN.Flying
within the scope of 13 miles by taking both ends of the runway as
the center is HIGHLY FORBIDDEN. Flying on the route of the airline
is also PROHIBITED.Do not use drone or other flying drones in areas
that are forbidden or prohibited by your local laws and regula�ons.
Technical Support
Website: www.contixo.com
E-mail: support@con�xo.com
Mon-Fri 9:00 am - 4:00 pm PST
Have ques�ons ?
F22
CONTACT INFORMATION
E-Mail: support@con�xo.com
Website: www.con�xo.com
©2022 Con�xo Inc. All rights reserved. Con�xo®, the Con�xo logo and
associated characters, trademarks and design elements are owned and
licensed by Con�xo Company.
