5L 1200W Stand Mixer
Model No.: SDA1757
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
5L 1200W Stand Mixer
Model No.: SDA1757
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions
should always be followed.
Only use the product as described in this user manual. Any
other use is considered improper and may result in damage
to property or persons.
The manufacturer or vendor cannot be held liable for
damages or injury incurred through improper or incorrect
use.
• Read and familiarise yourself with all operating
instructions before using this Stand Mixer.
• Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage.
• DO NOT use this Stand Mixer with an extension cable.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• This appliance shall not be used by children.
• Keep the appliance and its cord out of reach of children.
• Close supervision is required when using this appliance
near children.
• This appliance can be used by children aged from 8 years
and above if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Cleaning and user
3
5L 1200W Stand Mixer
Model No.: SDA1757
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
maintenance shall not be made by children unless they
are aged from 8 years and above and supervised. Keep the
appliance and its cord out of reach of children less than 8
years.
• Appliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and if they understand the hazards involved.
• Children shall not play with the appliance.
• DO NOT immerse the appliance or its cord in water or any
other liquids.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected
to the mains supply.
• Always use this appliance on a solid, level, non-flammable
surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Repairs to electrical appliances should only be performed
by qualified personnel. Improper repairs may place user at
serious risk.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
• Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• If the power cable is damaged, it should only be replaced
by suitable qualified personnel in order to avoid a hazard.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
4
5L 1200W Stand Mixer
Model No.: SDA1757
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• DO NOT run the mains cable under carpets, rugs, etc.
• Allow the unit to cool before storage.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
the supplier.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Unplug after each use. Grasp the plug, not the cord.
• Always disconnect the appliance from the mains supply if
it is left unattended and before assembling, disassembling
or cleaning.
• Switch off the appliance and disconnect from the supply
before changing accessories or approaching parts the
move in use.
• Ensure that the mixing bowl is clear of all other utensils
(attachments, spoons, etc.) before using the Mixer.
• CAUTION: DO NOT touch or remove the attachments
whilst they are rotating and/or the Stand Mixer is
connected to the mains.
5
5L 1200W Stand Mixer
Model No.: SDA1757
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste and not sent to
landfill. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for
recycling advice or visit www.recycle-more.co.uk enter your
postcode to find out your nearest recycling site.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
This Class 2 symbol indicates that the product is electrically
double insulated and does not require an earth connection.
6
5L 1200W Stand Mixer
Model No.: SDA1757
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts - Mixer
Description of Parts - Attachments
3
1
6
5
2
A
C
D
4
B
1. Top Housing
2. Splash Guard (with Shute)
3. Mixing Bowl
4. Mixer Base
5. Top Housing Release
Button
6. Speed Control
A. Dust Protector
B. Mixing Attachment
C. Dough Hook Attachment
D. Whisk Attachment
7
5L 1200W Stand Mixer
Model No.: SDA1757
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Before the first time you use your Stand Mixer
Remove all packing materials and discard responsibly.
Before using the Stand Mixer for the first time, wash all the attachments in warm
soapy water and dry thoroughly afterwards. Do not immerse the Stand Mixer in
water or any other liquids.
Operating Instructions – Preparation for mixing
1. Place the mixer on a solid, level non-flammable surface.
2. Ensure that the mains plug of the mixer is not inserted
into the mains socket whilst preparing the mixer.
3. Press the Top Housing Release Button (5)
then…...
4. Whilst holding the button down,
lift the Top Housing (1) fully up at
the front of the mixer then release
the Top Housing Release Button (5)
to lock the housing in the upright
position.
…...Lift the Top Housing (1) upwards
8
5L 1200W Stand Mixer
Model No.: SDA1757
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
6B
6A
6. Select one of the three attachments you
require that is appropriate for the mixing
job to be done. The Dough Hook
Attachment (C) is used in this example.
6A. Slide the Dust Protector (A) down over
the attachment.
6B. Rotate to fasten the dust protector in
place.
Ensure that the Dust Protector (A) is
the correct way up as in the image on the
left.
7. Align the two lugs on the mixer shaft
with the two notches in the
attachment.
7A. Once aligned, push the attachment
firmly up onto the mixer shaft.
7B. Rotate the attachment in the
direction of the arrow to lock it in place
as shown in the photo right.
7A
7B
5. Before fitting any of the
attachments, take the Splash Guard
(2) and attach it to the Motor
Housing (1) by aligning the splines in
the guard with the notches in the
housing (arrowed right - a) and
rotate to the guard towards the
front of the mixer to lock it in place
(arrowed right – b).
5A
5B
9
5L 1200W Stand Mixer
Model No.: SDA1757
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
8. Place the Mixing Bowl (3) on
the Base (4) of the mixer (4).
Turn the Mixing Bowl (3)
clockwise slightly in the
direction of the arrow to lock
the bowl into position.
Support the Top
Housing (1) at the front
9. Insert the food mixture into
the Mixing Bowl (3). Hold and
support the Top Housing (1) at
the front, Press the Top Housing
Release Button (5) and carefully
guide the Top Housing (1) down,
release the button.
Repeat the above process for the Mixing Attachment (B)
The Dust Protector (A) does not lock onto the Whisk Attachment (D) but
is simply placed on top of the attachment.
10
5L 1200W Stand Mixer
Model No.: SDA1757
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Operating Instructions – Using the Mixer
2. Any further mixture required
during mixing can be added
through Shute in the Splash
Guard (2) arrowed right:
1. Before use, place the mixer
on a solid, level and even
work surface that is near to
a mains outlet socket.
3. Ensure the Speed Control
(6) is set to ‘0’ as in the
picture left.
11
5L 1200W Stand Mixer
Model No.: SDA1757
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
To mix or knead dough:
• The Dough Hook Attachment (C) should be used.
• A suggested flour and water ratio of 5:3 is recommended.
• Start with speed 1 and mix for approximately 10 seconds, then increase to
speed 2 and mix for another 10 seconds, thereafter turn to speed 3 for
approximately 3 minutes.
• When filling the mixing bowl, please ensure that the maximum quantity is not
exceeded, please see the loading chart below.
Whipping egg whites or cream:
• The Whisk Attachment (D) should be used.
• Use speed 4 to speed 6 and whip the egg whites without stopping for
approximately 5 minutes, the time will vary according to the size and quantity
of the eggs, repeat until the desired consistency is achieved.
• For whipped cream, whip 250ml fresh cream at speed 4 to 6 for approximately
5 minutes.
• When filling the Mixing Bowl (3) with fresh milk, cream or other ingredients,
please ensure that the maximum quantity is not exceeded, please see loading
chart below.
4. Insert the mains plug (with dry hands)
into the mains socket and switch the
socket on (if applicable).
5. To operate the Mixer, rotate the Speed
Control (6) clockwise from the ‘0’ position
through the increments (1-6) to steadily
increase the speed. Use the following speed
guidelines to select the required speed:
12
5L 1200W Stand Mixer
Model No.: SDA1757
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Mixing Cakes, Buns, Puddings, etc.
• The Mixing Attachment (B) should be used.
• Mix the ingredients according to the available recipe, from speed 1 to 6 for
about 5 minutes.
• Do not exceed the maximum quantity for the mixing bowl.
Maximum Loading Chart
Ingredients
Quantity
Bread Dough
1kg
Cake Mix
2.5kg
Cream/Milk
1L
Egg Whites
16
Flour
1.5Kg
Pastry
0.5kg
Mixing Tips
1. For most recipes, it is better to begin your mixing on a lower speed until the
ingredients begin to combine, then move up to the appropriate speed for the
particular mixture.
2. Generally, there is not one set speed for an entire recipe. You will need to
change the speed of the mixer depending on what stage of the recipe you are
working on.
3. Whilst mixing larger quantities, you may need to increase the speed of the
mixer due to the larger load on the machine.
4. If additional ingredient needs adding to the recipe whilst mixing, it is advised to
lower the speed to avoid the ‘snow storm’ effect. The speed can be raised
again once the additional ingredients are added.
Care and Maintenance of your Stand Mixer
• Always disconnect the Stand Mixer from the mains power supply before
cleaning.
• Wash all the attachments in warm soapy water.
• Clean the outside of the Stand Mixer with a clean damp cloth. Never clean with
harsh or abrasive cleaners.
• Do not submerge the Stand Mixer in water or any other liquids.
• Do not clean any parts of this stand mixer in a dishwasher otherwise damage
will occur.
13
5L 1200W Stand Mixer
Model No.: SDA1757
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug -DISCONNECT FROM THE MAINS- and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Technical Data
Model Number
SDA1757
Rated Voltage
220-240V~ 50-60Hz
Rated Power
1200W
Protection Class
II
Mixing Bowl Capacity
5L (Max.)
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
14
5L 1200W Stand Mixer
Model No.: SDA1757
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
15
5L 1200W Stand Mixer
Model No.: SDA1757
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
16
5L 1200W Stand Mixer
Model No.: SDA1757
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof of
purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the discretion
of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the requirements
contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and covers
the main body and housing). If you do not register your product within 28 days of the original
purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28 days
of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo® is a registered trademark.
Produced and imported under license by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
