User Manual
ATTENTION
Aroma Diffuser
r aMUse nual
ACCIDENTAL LEAKAGE
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
COVER
TIME
MIST
HIGH/LOW
LIGHT
AIR OUTLET
DRAINAGE OUTLET
BASE
WATER TANK
MAINBODY
AIR INTAKE
OUTLET
DC SOCKET
FIG1
FIG2
FIG4
FIG6
FIG3
FIG5
OUTLET
MAINTENANCE
User Manual
Aroma Diffuser
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
AIR OUTLET
This Aroma Diffuser uses Ultrasonic waves to instantly vaporize water and
essential oil in the tank, to produce a cool, dry fragrant mist.
The amount and intensity of mist produced will vary, but this is not unusual and should not be
considered as a fault.
Factors that affect this include water type, humidity, temperature, air currents.
If there is no water in the Tank, pressing the MIST will cause the unit to “beep” 3 times to
remind you to add water. The unit will not work without water.
Only 100% natural essential oil can be used in this product. Those containing chemical
fragrance, spice or impurities will cause malfunction. Use 3-5 drops per 100ML water a time.
Too much oil will clog the system and cause malfunction. Please clean the unit as per the
maintenance instructions, before changing to use a new type of essential oil.
In the event of the unit being knocked over or tipped during use, please follow the steps as below
to avoid malfunction.
Unplug the unit and remove cover.
Pour out any remaining water out of the water tank from.
Shake the unit gently to drain any water inside the mechanism, and then allow drying for at
least 24 hours.
MAINTENANCE
After using 5-6 times, or 2-3 days, please clean the product as follows.
Unplug the unit from mains supply and remove cover.
Pour out any remaining water from the “DRAIN SIDE” of the tank.
Unplug power cord from base of unit.
Put 1 tablespoon of citric acid in the water tank, add just under 100ml of warm water (up to
70℃)
Leave for 5 minutes, and then drain solution from the “DRAIN SIDE” of the tank.
Wipe with a soft cloth. Avoid Ultrasonic Vibration plate area, which can be gently cleaned
with a cotton bud.
Never use other acids, enzymes or detergents, as this may risk poisonous gas to be
created or cause malfunction.
Cover has an inner cover that can also be removed for cleaning.
1. Pull grip as indicated in the diagram to release.
2. After cleaning inner cover, replace by holding grip, and pressing down inner and outer cover
until “click” is heard.
User Manual
PRECAUTIONS
Please check below to avoid malfunction of the unit.
Do not fill over 500ML “MAX” at any time.
Do not switch on power when the tank is empty.
Do not touch the Ultrasonic vibration plate.
Clean regularly as per Maintenance instructions to avoid malfunction.
Always unplug from power supply before maintenance.
For hygiene reasons, after use, pour away remaining water from “DRAIN SIDE” of tank, and
wipe with a clean dry cloth.
Essential oils can stain. In the event of spillage of contact, please wipe away with a soft cloth.
Only use the measuring cup provided to add water to the tank. Never fill directly from the tap.
Do not let mist blow directly onto furniture, clothing, walls etc.
Keep away from directing sunshine heat sources and air conditioners or fans.
Always keep on stable flat surface do not place on carpet, duvet or unstable area.
Keep away from electronic equipment, such as TV and Audio equipment.
Do not tip the product this may cause water to enter the mechanism and cause malfunction.
Do not use for more than 10 hours any time.
Wait 60 minutes before restart to avoid damage to Ultrasonic plate.
Use tap water only, does not use mineral water, sparkling water etc.
The amount and intensity of mist produced will vary, but this is not unusual and should not be
considered as a fault.
Factors that affect this include water type, humidity, temperature, air currents.
Never move product in use.
Do not touch any part of the product with wet hands.
Keep out of reach of children and pets. Also, children being supervised not to play with the
product. Appliance is not to be used by children or persons with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction.
Keep cord clear of pathways, and do not pull forcefully at any point.
If smoke or burning smell is detected, unplug immediately.
TROUBLESHOOTING
Please refer to the table below in the event of the product operating abnormally
Symptom Possible Cause Solution
Will not
switch
on-switch off
early
Is there enough water in
the tank?
Is the power cord
connected property?
Add water to the tank
Disconnect, check cables and re-connect
carefully.
No mist or
abnormal
mist
Not enough water?
Too much water?
Dirt on the Ultrasonic
plate?
Cover and inner cover are
not installed properly?
Dirt on the air suction port
on the underside of the
base?
Add suitable amount of water in the tank.
Water must never be filled over 500ML
(MAX) line.
Please refer to Maintenance instructions
Remove and re-install correctly, so vapors
can be released freely.
Clean the air suction port of any dust.
Restricted airflow will affect mist.
Water
leakage from
product
Cover and inner cover are
not installed properly?
Has the unit been tipped
over?
Low temperature or high
humidity?
Remove and reinstall correctly, so vapors
can be released freely.
Follow accidental leakage instructions.
Under these conditions, the mist may
condense quickly into water droplets.
OPERATION
1. Please put the product upside, and remove the upper
cover. Fig 1
2. Please connect the AC adaptor to the base of DC jack
of the main body via cable guide. Fig 2
3. Please use the measure cup to supply water from the
water pipe. Please take care, do not pour water out of
the cup and fill water into the water tank with
measuring cup. Fig 3
Pay attention to the filled water level; do not exceed
the max line on the water tank.
Water with high temperature and the mist may fly out,
please never fill in water during operating.
4. Drop essential oil into water tank vertically. The
dosage is about 2-3 drops (about 0.1-0.15ML) per
100ML water. Fig 3
5. Install the cover of the main body with the original
channel.
BTW: You must cover the upper cover when you want to use the product.
6. Please connect the AC adaptor with family user power supply socket.
7. If you press the MIST switch on main body of the product, mist function is on. You can set up
the timer, each time you press down this button; the timer will be changed between 60
minutes, 120 minutes, 180 minutes, ON and OFF. Fig 4
When the power supply is connected, the original state is OFF.
If there is few water in the water tank, the power supply will turn off immediately even
with power connected.
If the timing mode is off, LED light will be off at the same Time.
8. Press “HIGH/LOW” to adjust the spray intensity. (Strong or Weak) Fig5.
9. If you press the LIGHT on, you can chose ON/OFF state of the LED light. If you press this
button for each time, the light color and lightness will be changed. Fig6
10. If you do not use it for a long time, please drain out the water from tank water, dry and then
keep it well. If you want to user it again, please use the neutral detergent to clean the water
tank again, then you can use it.
SPECIFICATIONS
Dimensions Approx 168 x 121MM
Weight (excluding adaptor) Approx 520g
Power: Input / Output AC100-240V 50.60HZ / DC 24V 650MA
Length of cord Approx 170CM
Electric consumption Approx 13W
Time Mode 60/120/180/ON minutes
Tank Capacity 500ML
LED light 9 Bulbs
Materials Upper parts PP, lower base ABS
Accessories AC Adapter and measuring jug
Method of mist production Ultrasonic vibration at approx 2.4MH
No
1
2
3
4
5
6
Button
ON/OFF
Intermittent
Continuous
Light
Big/small
Timing
Function
ON/OFF
High Mist/Low Mist
Press it to turn on the LED light,
seven light color option
To select 1H/3H/6H or ON mode
To continuous spray
Press to enter intermittent mode
WARNING
THIS PRODUCT CONTAINS A BUTTON BATTERY
If swallowed, a lithium button battery can cause severe or
fatal injuries within 2 hours.
Keep batteries out of reach of children.
If you think batteries may have been swallowed or placed
inside
any part of the body, seek immediate medical attention.
ON/OFF
timing Big/small Light
Inter-
mittent
Con-
tinuous
2
3
4
5
1
6
DIFF-202LW-LW
