Flame Aroma Diffuser
User Manual
This Aroma Diffuser uses Ultrasonic waves to instantly vaporize
water in the tank,to produce a cool,dry fragr ant mist.
OPERATION
1.keep product straighten,remove the cover vertical
direction.Fig1
2.please connect the AC adaptor to the base of DC
jack of the main body via cable guide.Fig2
3.Please use the measure cup to supply water (Do Not add
high temperature water)from the water pipe, pay
please do not add water when the product is working.Fig3
4.Install the cover of main body with original
channel,To fall to the vertical direction ,Rotate
the cover to adjust the desired position mouth
spray. BTW:You must cover the upper when
you want to use the product.Fig4
5.Press “MIST” buttom,choose the time needed,
(high mist output, low mist output, 2H, 4H). Long press the
“MIST” buttom to turn it off.
Fig5
6.Press “LIGHT” to adjust the light mode intensity.
8.If you do not use it for a long time, Please drain out the
water from tank,dry and then keep it well.If you
want to use it again,Please use the neutral detergent to clean
9.When the power is switched on,the initial state of
Aromatherapy machine is turned off.
10.If lack of water in the tank,even though the MIST switch,
.ffo nrut yllacitamotua lliw enihcam yparehtamora
11.Mist and light off automatically when water runs out.
PRECAUTIONS
and should not to considered as it fault.
ACCIDENTAL LEKAGE
In the event of the unit being knocked over or tipped during use,please follow the steps as
below to avoid malfunction
1.Plug the uint and remove cover.
2.Pour out any remaining water from the specify water tank position.
3.Shake the uint gently to drain water,and then keep it natural air drying for at least 24 hours.
MAINTENANCE
After using 3-5 days,please clean the product as fo
llow:
1.unplug the unit from mains supply and remove cover.
2.pour out any remaining water
from the specify water tank position.
3.add a small amount of warm kitchen detergent remover and water,use swab to
wipe it gently,and then use cleaning cloth to dry it lightly.
4.refer to the following pictures,to avoid water flow into the air outlet,pour off
water abide by the left,not the right one.
5.do not use other acids or enzymes detergents,as this may give off poisonous
gas or cause malfunction
Note: Be sure to use a mild detergent.
PRECAUTIONS
240
”
TROUBLESHOOTING
Please refer to the table below in the event of the product operating
abnormally:
If product does not work well,please refer to the following points before requesting repairs:
Will not switch on
or switch off
No mist or
Abnormal mist
Water leakage
from product
Is there enough water in the tank?
--Please add water to the tank
Is the power cord connected property?
--Please disconnect,check and re-connect careful
Not enough water? or too much water?
—Please add suitable amount of water in the tank,water must
never be filled over 240ML(MAX) line
Dirt on the Ultrasonic plate?
--Please refer to maintenance instructions remove and re-install
correctly,so vapors can be released freely
Cover and inner cover are not installed properly?Dirt on the air
suction port on the underside of the base?
--If too much dust in the air suction port,the mist will be
restricted to come out.Just clean it.
Cover and inner are not installed properly?
--Remove and reinstall correctly,so vapors can be released freely.
Low temperature or high humidity?
--Under these conditions,the mist may condense quickly into
water droplets
SPECIFICATIONS
Dimensions
MM18X531x012 xorppA
Weight(excluding adaptor) Approx 500g
Power:Input/Output AM005 V42 CD/ZH06-05 V042-001CA
Length of cord MC071 xorppA
Electric consumption w41 xorppA
Time
Mode
High Mist/Low Mist/2H/4H
Tank Capacity
LED light scp 81
Materials
PP/AB
S
Accessories etomer ,puc retaw ,launam dna retpadA CA
Method of mist production ZHM4.2
Fig1 .Fig2
Fig3 Fig4
The amount and intensity of mist produced will vary,but this is not unusual
Product use time: About 12 hours for high mist,15 hours for low mist.
Factors that affect this include water type humidity,temperature,air currents.
Auto power off when water runs out
attention to the filled waterlevel;do not exceed the max line,
(Strong(default)/weak/breathing light)Fig6
the water tank again,then you can use it.
Suggest to use 200ML water.
240ML,suggest to use 200ML
Cover
Light
Mist
DRAIN SIDE
OUTLET
AIROUTLET
AIROUTLET
AIR INTAKE
DC SOCKET
OUTLET
Fig5 Fig6
Drain Side
240ml
Maximum Water Level
2
00m
l
Add water position
Drain Side
240ml
Maximum Water Level
2
00m
l
Add water position
Drain Side
240ml
Maximum Water Level
2
00m
l
Add water position
Drain Side
240ml
Maximum Water Level
2
00m
l
Add water position
Drain Side
240ml
Maximum Water Level
2
00m
l
Add water position
No
1
2
3
Button
ON/OFF
Light
Timing
Function
ON/OFF
Press “LIGHT” to adjust the light
mode Strong(default)/weak/
breathing light
To select high mist output, low
mist output, 2H, 4H
1
REMOTE CONTROL
2
3
WARNING
THIS PRODUCT CONTAINS A BUTTON BATTERY
If swallowed, a lithium button battery can cause severe or
fatal injuries within 2 hours.
Keep batteries out of reach of children.
If you think batteries may have been swallowed or placed
inside
any part of the body, seek immediate medical attention.
DIFF-HZ003-WH
