In the event of the unit being knocked over or tipped during use, please
follow the steps as below to avoid malfunction:
1.plug the unit and remove cover.
2.pour out any remaining water from the water tank.
3.shake the unit gently to drain water,and then keep it natural air drying for at least
24 hours.
If product doesn’t work well, please refer to the following points
before requesting repairs:
Will not switch
on or switch off
No mist or
abnormal mist
Water leakage
from product
Is there enough water in the tank?
--Please add water to the tank
Is the power cord connected property?
--Please disconnect, check cables and re-connect carefully.
Not enough water? or too much water?
--Please add suitable amount of water in the tank, water must
never be filled over 400ML (MAX)line.
Dirt on the ultrasonic plate?
--Please refer to maintenance instructions remove and re-install
correctly, so vapors can be released freely.
Cover and inner cover are not installed properly? Dirt on the air
suction port on the underside of the base?
--If too much dust in the air suction port, the mist will be
restricted to come out.Just clean it.
Cover and inner are not installed properly?
--Remove and reinstall correctly, so vapors can be released
freely.
Low temperature or high humidity?
--Under these conditions, the mist may condense quickly into
water droplets.
Product use time:4 hours.
The amount and intensity of mist produced will vary, but this is not unusual
and should not be considered as a fault.
Factors that affect this include water type,humidity,temperature,air currents.
Auto power off when water runs out.
Applies only 100% natural essential oils, if they contain chemical ingredients,
flavors or impurities may cause damage to the product.
Before replacing another essential oils, follow the maintenance part of the
clean-up products.
OPERATION
MAINTENANCE
PRECAUTIONS
TROUBLESHOOTING
PRECAUTIONS
ACCIDENTAL LEKAGE
User Manual
Aroma Diffuser Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
After using 5-6 times, or 3-5 days, please clean the product as follow:
Please check below to avoid malfunction of the unit:
1.unplug the unit from mains supply and remove cover.
2.pour out any remaining water from the tank.
3.add a small amount of warm kitchen detergent remover and water,use swab to
wipe it gently,and then use cleaning cloth to dry it lightiy.
4.refer to the following pictures, to avoid water flow into the air outlet,pour off
water abide by the left picture, not the right one.
5.do not use other acids or enzymes detergents,as this may give off poisonous
gas or cause malfunction.
Do not fill over 400ML”MAX”at any time.
Do not switch on power when the tank is empty.
Do not touch the Ultrasonic vibration plate.
Clean regularly as per Maintenance instructions to avoid malfunction.
Always unplug from power supply before maintenance.
For hygiene reasons, after use, pour away remaining water from “DRAIN SIDE” of
tank, and wipe with a clean dry cloth.
Essential oils can stain, In the event of spillage of contact, please wipe away with a
soft cloth.
Only use the measuring cup (not provided) to add water into the tank, do not fill water
directly from the water pipe.
Do not let mist below onto furniture, clothing, walls etc.
Keep away from directing sunshine heat sources and air conditioners or fans.
Always keep on stable plat surface do not place on carpet, duvet or unstable area.
Keep away from electronic equipment, such as TV and Auto equipment.
Do not tip the product this may cause water to enter the mechanism and cause malfunction.
Product use time: 4 hours.
Wait 60 minutes before restart to avoid damage to Ultrasonic plate.
Use tap water only, does not use mineral water, sparkling water etc.
Never move product in use.
Do not touch any part of the product with wet hands.
Keep out of reach of children and pets, Children not being supervised are suggested not
play with the product. Appliance is not suitable for children or person with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge to be
used, unless they have been given supervision or instruction.
Keep cord clear of pathways, and do not pull forcefully at any point.
If smoke or burning smell is detectd,unplug immediately.
Please refer to the table below in the event of the product operating
abnormally：
Aroma Diffuser
User Manual
This Aroma Diffuser uses Ultrasonic waves to instantly vaporize
water and essential oil in the tank, to produce a cool, dry fragrant mist.
Note: Be sure to use a mild detergent.
Aroma Diffuser
SPECIFICATIONS
User Manual
Aroma Diffuser
1.Keep product straighten, remove the upper lid and water
cap vertical direction. Fig1
2.Please connect the AC adaptor to the base of DC
jack of the main body via cable guide. Fig2
3.Please use the measure cup(not included in the
package) to supply water(Do Not add high temperature
water) from the water pipe,pay attention to the filled
waterlevel;do not exceed the max line,Please do not
add water when the product is working.Drop essential
oil into water tank vertically.Fig3
4.Install the cover of the main body with the original
channel, To fall to the vertical direction, Rotate the
cover to adjust the desired position mouth spray.
BTW:You must cover the upper cover when you
want to use the product. Fig4
5.Please connect the AC adaptor with family user
power supply socket.
6.Press“MIST”button,choose the time needed, (1H,3H,
6H or ON continuous spray time).“MIST”button
please press“MIST”button five times (from 1H,3H,6H,
ON to OFF).Fig5
7.Press "light"button to turn on the LED light,seven light
color option at verying brightness are available.Fig6
8.If you do not use it for a long time, please drain out the water from tank water, dry and
then keep it well. If you want to use it again, please use the neutral detergent to clean
the water tank again, then you can use it.
9.When the power is switched on, the initial state of Aromatherapy machine is turned off.
10.If lack of water in the tank, even though the MIST switch, aromatherapy machine will
automatically turn off.
11.Mist and light off automatically when water runs out.
1H
3H 6H
ON
LIGHT
MIST
1H
3H 6H
ON
LIGHT
MIST
DIFF-G5-LW
1H
3H 6H
ON
LIG HT
MIS T
WATER TANK COVER
LIGHT
WATER TANK
MAIN BODY
AIR OUTLET
AIR INTAKE
MIST
DRAINAGE
OUTLET
Model
Dimensions Approx 160x160x165mm
Approx 400g
Approx 24cm
Approx 9W
AC 100-240V 50.60HZ/DC24V 500MA
Weigh(excluding adaptor)
Power:Input(Output)
Length of cord
Electric consumption
Time Mode 1H/3H/6H/ON
Tank Capacity 400ML
LED light 5pcs
Materials PP/ABS/PC/Glass
Accessories AC Adaptot and manual
Method of mist production 2.4MHz
No
1
2
3
4
5
6
Button
ON/OFF
Intermittent
Continuous
Light
Big/small
Timing
Function
ON/OFF
High Mist/Low Mist
Press it to turn on the LED light,
seven light color option
To select 1H/3H/6H or ON mode
To continuous spray
Press to enter intermittent mode
WARNING
THIS PRODUCT CONTAINS A BUTTON BATTERY
If swallowed, a lithium button battery can cause severe or
fatal injuries within 2 hours.
Keep batteries out of reach of children.
If you think batteries may have been swallowed or placed
inside
any part of the body, seek immediate medical attention.
ON/OFF
timing Big/small Light
Inter-
mittent
Con-
tinuous
2
3
4
5
1
6
In the event of the unit being knocked over or tipped during use, please
follow the steps as below to avoid malfunction:
1.plug the unit and remove cover.
2.pour out any remaining water from the water tank.
3.shake the unit gently to drain water,and then keep it natural air drying for at least
24 hours.
If product doesn’t work well, please refer to the following points
before requesting repairs:
Will not switch
on or switch off
No mist or
abnormal mist
Water leakage
from product
Is there enough water in the tank?
--Please add water to the tank
Is the power cord connected property?
--Please disconnect, check cables and re-connect carefully.
Not enough water? or too much water?
--Please add suitable amount of water in the tank, water must
never be filled over 400ML (MAX)line.
Dirt on the ultrasonic plate?
--Please refer to maintenance instructions remove and re-install
correctly, so vapors can be released freely.
Cover and inner cover are not installed properly? Dirt on the air
suction port on the underside of the base?
--If too much dust in the air suction port, the mist will be
restricted to come out.Just clean it.
Cover and inner are not installed properly?
--Remove and reinstall correctly, so vapors can be released
freely.
Low temperature or high humidity?
--Under these conditions, the mist may condense quickly into
water droplets.
Product use time:4 hours.
The amount and intensity of mist produced will vary, but this is not unusual
and should not be considered as a fault.
Factors that affect this include water type,humidity,temperature,air currents.
Auto power off when water runs out.
Applies only 100% natural essential oils, if they contain chemical ingredients,
flavors or impurities may cause damage to the product.
Before replacing another essential oils, follow the maintenance part of the
clean-up products.
OPERATION
MAINTENANCE
PRECAUTIONS
TROUBLESHOOTING
PRECAUTIONS
ACCIDENTAL LEKAGE
User Manual
Aroma Diffuser Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
After using 5-6 times, or 3-5 days, please clean the product as follow:
Please check below to avoid malfunction of the unit:
1.unplug the unit from mains supply and remove cover.
2.pour out any remaining water from the tank.
3.add a small amount of warm kitchen detergent remover and water,use swab to
wipe it gently,and then use cleaning cloth to dry it lightiy.
4.refer to the following pictures, to avoid water flow into the air outlet,pour off
water abide by the left picture, not the right one.
5.do not use other acids or enzymes detergents,as this may give off poisonous
gas or cause malfunction.
Do not fill over 400ML”MAX”at any time.
Do not switch on power when the tank is empty.
Do not touch the Ultrasonic vibration plate.
Clean regularly as per Maintenance instructions to avoid malfunction.
Always unplug from power supply before maintenance.
For hygiene reasons, after use, pour away remaining water from “DRAIN SIDE” of
tank, and wipe with a clean dry cloth.
Essential oils can stain, In the event of spillage of contact, please wipe away with a
soft cloth.
Only use the measuring cup (not provided) to add water into the tank, do not fill water
directly from the water pipe.
Do not let mist below onto furniture, clothing, walls etc.
Keep away from directing sunshine heat sources and air conditioners or fans.
Always keep on stable plat surface do not place on carpet, duvet or unstable area.
Keep away from electronic equipment, such as TV and Auto equipment.
Do not tip the product this may cause water to enter the mechanism and cause malfunction.
Product use time: 4 hours.
Wait 60 minutes before restart to avoid damage to Ultrasonic plate.
Use tap water only, does not use mineral water, sparkling water etc.
Never move product in use.
Do not touch any part of the product with wet hands.
Keep out of reach of children and pets, Children not being supervised are suggested not
play with the product. Appliance is not suitable for children or person with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge to be
used, unless they have been given supervision or instruction.
Keep cord clear of pathways, and do not pull forcefully at any point.
If smoke or burning smell is detectd,unplug immediately.
Please refer to the table below in the event of the product operating
abnormally：
Aroma Diffuser
User Manual
This Aroma Diffuser uses Ultrasonic waves to instantly vaporize
water and essential oil in the tank, to produce a cool, dry fragrant mist.
Note: Be sure to use a mild detergent.
Aroma Diffuser
SPECIFICATIONS
User Manual
Aroma Diffuser
1.Keep product straighten, remove the upper lid and water
cap vertical direction. Fig1
2.Please connect the AC adaptor to the base of DC
jack of the main body via cable guide. Fig2
3.Please use the measure cup(not included in the
package) to supply water(Do Not add high temperature
water) from the water pipe,pay attention to the filled
waterlevel;do not exceed the max line,Please do not
add water when the product is working.Drop essential
oil into water tank vertically.Fig3
4.Install the cover of the main body with the original
channel, To fall to the vertical direction, Rotate the
cover to adjust the desired position mouth spray.
BTW:You must cover the upper cover when you
want to use the product. Fig4
5.Please connect the AC adaptor with family user
power supply socket.
6.Press“MIST”button,choose the time needed, (1H,3H,
6H or ON continuous spray time).“MIST”button
please press“MIST”button five times (from 1H,3H,6H,
ON to OFF).Fig5
7.Press "light"button to turn on the LED light,seven light
color option at verying brightness are available.Fig6
8.If you do not use it for a long time, please drain out the water from tank water, dry and
then keep it well. If you want to use it again, please use the neutral detergent to clean
the water tank again, then you can use it.
9.When the power is switched on, the initial state of Aromatherapy machine is turned off.
10.If lack of water in the tank, even though the MIST switch, aromatherapy machine will
automatically turn off.
11.Mist and light off automatically when water runs out.
1H
3H 6H
ON
LIGHT
MIST
1H
3H 6H
ON
LIGHT
MIST
DIFF-G5-LW
1H
3H 6H
ON
LIG HT
MIS T
WATER TANK COVER
LIGHT
WATER TANK
MAIN BODY
AIR OUTLET
AIR INTAKE
MIST
DRAINAGE
OUTLET
Model
Dimensions Approx 160x160x165mm
Approx 400g
Approx 24cm
Approx 9W
AC 100-240V 50.60HZ/DC24V 500MA
Weigh(excluding adaptor)
Power:Input(Output)
Length of cord
Electric consumption
Time Mode 1H/3H/6H/ON
Tank Capacity 400ML
LED light 5pcs
Materials PP/ABS/PC/Glass
Accessories AC Adaptot and manual
Method of mist production 2.4MHz
No
1
2
3
4
5
6
Button
ON/OFF
Intermittent
Continuous
Light
Big/small
Timing
Function
ON/OFF
High Mist/Low Mist
Press it to turn on the LED light,
seven light color option
To select 1H/3H/6H or ON mode
To continuous spray
Press to enter intermittent mode
WARNING
THIS PRODUCT CONTAINS A BUTTON BATTERY
If swallowed, a lithium button battery can cause severe or
fatal injuries within 2 hours.
Keep batteries out of reach of children.
If you think batteries may have been swallowed or placed
inside
any part of the body, seek immediate medical attention.
ON/OFF
timing Big/small Light
Inter-
mittent
Con-
tinuous
2
3
4
5
1
6
In the event of the unit being knocked over or tipped during use, please
follow the steps as below to avoid malfunction:
1.plug the unit and remove cover.
2.pour out any remaining water from the water tank.
3.shake the unit gently to drain water,and then keep it natural air drying for at least
24 hours.
If product doesn’t work well, please refer to the following points
before requesting repairs:
Will not switch
on or switch off
No mist or
abnormal mist
Water leakage
from product
Is there enough water in the tank?
--Please add water to the tank
Is the power cord connected property?
--Please disconnect, check cables and re-connect carefully.
Not enough water? or too much water?
--Please add suitable amount of water in the tank, water must
never be filled over 400ML (MAX)line.
Dirt on the ultrasonic plate?
--Please refer to maintenance instructions remove and re-install
correctly, so vapors can be released freely.
Cover and inner cover are not installed properly? Dirt on the air
suction port on the underside of the base?
--If too much dust in the air suction port, the mist will be
restricted to come out.Just clean it.
Cover and inner are not installed properly?
--Remove and reinstall correctly, so vapors can be released
freely.
Low temperature or high humidity?
--Under these conditions, the mist may condense quickly into
water droplets.
Product use time:4 hours.
The amount and intensity of mist produced will vary, but this is not unusual
and should not be considered as a fault.
Factors that affect this include water type,humidity,temperature,air currents.
Auto power off when water runs out.
Applies only 100% natural essential oils, if they contain chemical ingredients,
flavors or impurities may cause damage to the product.
Before replacing another essential oils, follow the maintenance part of the
clean-up products.
OPERATION
MAINTENANCE
PRECAUTIONS
TROUBLESHOOTING
PRECAUTIONS
ACCIDENTAL LEKAGE
User Manual
Aroma Diffuser Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
After using 5-6 times, or 3-5 days, please clean the product as follow:
Please check below to avoid malfunction of the unit:
1.unplug the unit from mains supply and remove cover.
2.pour out any remaining water from the tank.
3.add a small amount of warm kitchen detergent remover and water,use swab to
wipe it gently,and then use cleaning cloth to dry it lightiy.
4.refer to the following pictures, to avoid water flow into the air outlet,pour off
water abide by the left picture, not the right one.
5.do not use other acids or enzymes detergents,as this may give off poisonous
gas or cause malfunction.
Do not fill over 400ML”MAX”at any time.
Do not switch on power when the tank is empty.
Do not touch the Ultrasonic vibration plate.
Clean regularly as per Maintenance instructions to avoid malfunction.
Always unplug from power supply before maintenance.
For hygiene reasons, after use, pour away remaining water from “DRAIN SIDE” of
tank, and wipe with a clean dry cloth.
Essential oils can stain, In the event of spillage of contact, please wipe away with a
soft cloth.
Only use the measuring cup (not provided) to add water into the tank, do not fill water
directly from the water pipe.
Do not let mist below onto furniture, clothing, walls etc.
Keep away from directing sunshine heat sources and air conditioners or fans.
Always keep on stable plat surface do not place on carpet, duvet or unstable area.
Keep away from electronic equipment, such as TV and Auto equipment.
Do not tip the product this may cause water to enter the mechanism and cause malfunction.
Product use time: 4 hours.
Wait 60 minutes before restart to avoid damage to Ultrasonic plate.
Use tap water only, does not use mineral water, sparkling water etc.
Never move product in use.
Do not touch any part of the product with wet hands.
Keep out of reach of children and pets, Children not being supervised are suggested not
play with the product. Appliance is not suitable for children or person with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge to be
used, unless they have been given supervision or instruction.
Keep cord clear of pathways, and do not pull forcefully at any point.
If smoke or burning smell is detectd,unplug immediately.
Please refer to the table below in the event of the product operating
abnormally：
Aroma Diffuser
User Manual
This Aroma Diffuser uses Ultrasonic waves to instantly vaporize
water and essential oil in the tank, to produce a cool, dry fragrant mist.
Note: Be sure to use a mild detergent.
Aroma Diffuser
SPECIFICATIONS
User Manual
Aroma Diffuser
1.Keep product straighten, remove the upper lid and water
cap vertical direction. Fig1
2.Please connect the AC adaptor to the base of DC
jack of the main body via cable guide. Fig2
3.Please use the measure cup(not included in the
package) to supply water(Do Not add high temperature
water) from the water pipe,pay attention to the filled
waterlevel;do not exceed the max line,Please do not
add water when the product is working.Drop essential
oil into water tank vertically.Fig3
4.Install the cover of the main body with the original
channel, To fall to the vertical direction, Rotate the
cover to adjust the desired position mouth spray.
BTW:You must cover the upper cover when you
want to use the product. Fig4
5.Please connect the AC adaptor with family user
power supply socket.
6.Press“MIST”button,choose the time needed, (1H,3H,
6H or ON continuous spray time).“MIST”button
please press“MIST”button five times (from 1H,3H,6H,
ON to OFF).Fig5
7.Press "light"button to turn on the LED light,seven light
color option at verying brightness are available.Fig6
8.If you do not use it for a long time, please drain out the water from tank water, dry and
then keep it well. If you want to use it again, please use the neutral detergent to clean
the water tank again, then you can use it.
9.When the power is switched on, the initial state of Aromatherapy machine is turned off.
10.If lack of water in the tank, even though the MIST switch, aromatherapy machine will
automatically turn off.
11.Mist and light off automatically when water runs out.
1H
3H 6H
ON
LIGHT
MIST
1H
3H 6H
ON
LIGHT
MIST
DIFF-G5-LW
1H
3H 6H
ON
LIG HT
MIS T
WATER TANK COVER
LIGHT
WATER TANK
MAIN BODY
AIR OUTLET
AIR INTAKE
MIST
DRAINAGE
OUTLET
Model
Dimensions Approx 160x160x165mm
Approx 400g
Approx 24cm
Approx 9W
AC 100-240V 50.60HZ/DC24V 500MA
Weigh(excluding adaptor)
Power:Input(Output)
Length of cord
Electric consumption
Time Mode 1H/3H/6H/ON
Tank Capacity 400ML
LED light 5pcs
Materials PP/ABS/PC/Glass
Accessories AC Adaptot and manual
Method of mist production 2.4MHz
No
1
2
3
4
5
6
Button
ON/OFF
Intermittent
Continuous
Light
Big/small
Timing
Function
ON/OFF
High Mist/Low Mist
Press it to turn on the LED light,
seven light color option
To select 1H/3H/6H or ON mode
To continuous spray
Press to enter intermittent mode
WARNING
THIS PRODUCT CONTAINS A BUTTON BATTERY
If swallowed, a lithium button battery can cause severe or
fatal injuries within 2 hours.
Keep batteries out of reach of children.
If you think batteries may have been swallowed or placed
inside
any part of the body, seek immediate medical attention.
ON/OFF
timing Big/small Light
Inter-
mittent
Con-
tinuous
2
3
4
5
1
6
In the event of the unit being knocked over or tipped during use, please
follow the steps as below to avoid malfunction:
1.plug the unit and remove cover.
2.pour out any remaining water from the water tank.
3.shake the unit gently to drain water,and then keep it natural air drying for at least
24 hours.
If product doesn’t work well, please refer to the following points
before requesting repairs:
Will not switch
on or switch off
No mist or
abnormal mist
Water leakage
from product
Is there enough water in the tank?
--Please add water to the tank
Is the power cord connected property?
--Please disconnect, check cables and re-connect carefully.
Not enough water? or too much water?
--Please add suitable amount of water in the tank, water must
never be filled over 400ML (MAX)line.
Dirt on the ultrasonic plate?
--Please refer to maintenance instructions remove and re-install
correctly, so vapors can be released freely.
Cover and inner cover are not installed properly? Dirt on the air
suction port on the underside of the base?
--If too much dust in the air suction port, the mist will be
restricted to come out.Just clean it.
Cover and inner are not installed properly?
--Remove and reinstall correctly, so vapors can be released
freely.
Low temperature or high humidity?
--Under these conditions, the mist may condense quickly into
water droplets.
Product use time:4 hours.
The amount and intensity of mist produced will vary, but this is not unusual
and should not be considered as a fault.
Factors that affect this include water type,humidity,temperature,air currents.
Auto power off when water runs out.
Applies only 100% natural essential oils, if they contain chemical ingredients,
flavors or impurities may cause damage to the product.
Before replacing another essential oils, follow the maintenance part of the
clean-up products.
OPERATION
MAINTENANCE
PRECAUTIONS
TROUBLESHOOTING
PRECAUTIONS
ACCIDENTAL LEKAGE
User Manual
Aroma Diffuser Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
After using 5-6 times, or 3-5 days, please clean the product as follow:
Please check below to avoid malfunction of the unit:
1.unplug the unit from mains supply and remove cover.
2.pour out any remaining water from the tank.
3.add a small amount of warm kitchen detergent remover and water,use swab to
wipe it gently,and then use cleaning cloth to dry it lightiy.
4.refer to the following pictures, to avoid water flow into the air outlet,pour off
water abide by the left picture, not the right one.
5.do not use other acids or enzymes detergents,as this may give off poisonous
gas or cause malfunction.
Do not fill over 400ML”MAX”at any time.
Do not switch on power when the tank is empty.
Do not touch the Ultrasonic vibration plate.
Clean regularly as per Maintenance instructions to avoid malfunction.
Always unplug from power supply before maintenance.
For hygiene reasons, after use, pour away remaining water from “DRAIN SIDE” of
tank, and wipe with a clean dry cloth.
Essential oils can stain, In the event of spillage of contact, please wipe away with a
soft cloth.
Only use the measuring cup (not provided) to add water into the tank, do not fill water
directly from the water pipe.
Do not let mist below onto furniture, clothing, walls etc.
Keep away from directing sunshine heat sources and air conditioners or fans.
Always keep on stable plat surface do not place on carpet, duvet or unstable area.
Keep away from electronic equipment, such as TV and Auto equipment.
Do not tip the product this may cause water to enter the mechanism and cause malfunction.
Product use time: 4 hours.
Wait 60 minutes before restart to avoid damage to Ultrasonic plate.
Use tap water only, does not use mineral water, sparkling water etc.
Never move product in use.
Do not touch any part of the product with wet hands.
Keep out of reach of children and pets, Children not being supervised are suggested not
play with the product. Appliance is not suitable for children or person with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge to be
used, unless they have been given supervision or instruction.
Keep cord clear of pathways, and do not pull forcefully at any point.
If smoke or burning smell is detectd,unplug immediately.
Please refer to the table below in the event of the product operating
abnormally：
Aroma Diffuser
User Manual
This Aroma Diffuser uses Ultrasonic waves to instantly vaporize
water and essential oil in the tank, to produce a cool, dry fragrant mist.
Note: Be sure to use a mild detergent.
Aroma Diffuser
SPECIFICATIONS
User Manual
Aroma Diffuser
1.Keep product straighten, remove the upper lid and water
cap vertical direction. Fig1
2.Please connect the AC adaptor to the base of DC
jack of the main body via cable guide. Fig2
3.Please use the measure cup(not included in the
package) to supply water(Do Not add high temperature
water) from the water pipe,pay attention to the filled
waterlevel;do not exceed the max line,Please do not
add water when the product is working.Drop essential
oil into water tank vertically.Fig3
4.Install the cover of the main body with the original
channel, To fall to the vertical direction, Rotate the
cover to adjust the desired position mouth spray.
BTW:You must cover the upper cover when you
want to use the product. Fig4
5.Please connect the AC adaptor with family user
power supply socket.
6.Press“MIST”button,choose the time needed, (1H,3H,
6H or ON continuous spray time).“MIST”button
please press“MIST”button five times (from 1H,3H,6H,
ON to OFF).Fig5
7.Press "light"button to turn on the LED light,seven light
color option at verying brightness are available.Fig6
8.If you do not use it for a long time, please drain out the water from tank water, dry and
then keep it well. If you want to use it again, please use the neutral detergent to clean
the water tank again, then you can use it.
9.When the power is switched on, the initial state of Aromatherapy machine is turned off.
10.If lack of water in the tank, even though the MIST switch, aromatherapy machine will
automatically turn off.
11.Mist and light off automatically when water runs out.
1H
3H 6H
ON
LIGHT
MIST
1H
3H 6H
ON
LIGHT
MIST
DIFF-G5-LW
1H
3H 6H
ON
LIG HT
MIS T
WATER TANK COVER
LIGHT
WATER TANK
MAIN BODY
AIR OUTLET
AIR INTAKE
MIST
DRAINAGE
OUTLET
Model
Dimensions Approx 160x160x165mm
Approx 400g
Approx 24cm
Approx 9W
AC 100-240V 50.60HZ/DC24V 500MA
Weigh(excluding adaptor)
Power:Input(Output)
Length of cord
Electric consumption
Time Mode 1H/3H/6H/ON
Tank Capacity 400ML
LED light 5pcs
Materials PP/ABS/PC/Glass
Accessories AC Adaptot and manual
Method of mist production 2.4MHz
No
1
2
3
4
5
6
Button
ON/OFF
Intermittent
Continuous
Light
Big/small
Timing
Function
ON/OFF
High Mist/Low Mist
Press it to turn on the LED light,
seven light color option
To select 1H/3H/6H or ON mode
To continuous spray
Press to enter intermittent mode
WARNING
THIS PRODUCT CONTAINS A BUTTON BATTERY
If swallowed, a lithium button battery can cause severe or
fatal injuries within 2 hours.
Keep batteries out of reach of children.
If you think batteries may have been swallowed or placed
inside
any part of the body, seek immediate medical attention.
ON/OFF
timing Big/small Light
Inter-
mittent
Con-
tinuous
2
3
4
5
1
6
In the event of the unit being knocked over or tipped during use, please
follow the steps as below to avoid malfunction:
1.plug the unit and remove cover.
2.pour out any remaining water from the water tank.
3.shake the unit gently to drain water,and then keep it natural air drying for at least
24 hours.
If product doesn’t work well, please refer to the following points
before requesting repairs:
Will not switch
on or switch off
No mist or
abnormal mist
Water leakage
from product
Is there enough water in the tank?
--Please add water to the tank
Is the power cord connected property?
--Please disconnect, check cables and re-connect carefully.
Not enough water? or too much water?
--Please add suitable amount of water in the tank, water must
never be filled over 400ML (MAX)line.
Dirt on the ultrasonic plate?
--Please refer to maintenance instructions remove and re-install
correctly, so vapors can be released freely.
Cover and inner cover are not installed properly? Dirt on the air
suction port on the underside of the base?
--If too much dust in the air suction port, the mist will be
restricted to come out.Just clean it.
Cover and inner are not installed properly?
--Remove and reinstall correctly, so vapors can be released
freely.
Low temperature or high humidity?
--Under these conditions, the mist may condense quickly into
water droplets.
Product use time:4 hours.
The amount and intensity of mist produced will vary, but this is not unusual
and should not be considered as a fault.
Factors that affect this include water type,humidity,temperature,air currents.
Auto power off when water runs out.
Applies only 100% natural essential oils, if they contain chemical ingredients,
flavors or impurities may cause damage to the product.
Before replacing another essential oils, follow the maintenance part of the
clean-up products.
OPERATION
MAINTENANCE
PRECAUTIONS
TROUBLESHOOTING
PRECAUTIONS
ACCIDENTAL LEKAGE
User Manual
Aroma Diffuser Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
After using 5-6 times, or 3-5 days, please clean the product as follow:
Please check below to avoid malfunction of the unit:
1.unplug the unit from mains supply and remove cover.
2.pour out any remaining water from the tank.
3.add a small amount of warm kitchen detergent remover and water,use swab to
wipe it gently,and then use cleaning cloth to dry it lightiy.
4.refer to the following pictures, to avoid water flow into the air outlet,pour off
water abide by the left picture, not the right one.
5.do not use other acids or enzymes detergents,as this may give off poisonous
gas or cause malfunction.
Do not fill over 400ML”MAX”at any time.
Do not switch on power when the tank is empty.
Do not touch the Ultrasonic vibration plate.
Clean regularly as per Maintenance instructions to avoid malfunction.
Always unplug from power supply before maintenance.
For hygiene reasons, after use, pour away remaining water from “DRAIN SIDE” of
tank, and wipe with a clean dry cloth.
Essential oils can stain, In the event of spillage of contact, please wipe away with a
soft cloth.
Only use the measuring cup (not provided) to add water into the tank, do not fill water
directly from the water pipe.
Do not let mist below onto furniture, clothing, walls etc.
Keep away from directing sunshine heat sources and air conditioners or fans.
Always keep on stable plat surface do not place on carpet, duvet or unstable area.
Keep away from electronic equipment, such as TV and Auto equipment.
Do not tip the product this may cause water to enter the mechanism and cause malfunction.
Product use time: 4 hours.
Wait 60 minutes before restart to avoid damage to Ultrasonic plate.
Use tap water only, does not use mineral water, sparkling water etc.
Never move product in use.
Do not touch any part of the product with wet hands.
Keep out of reach of children and pets, Children not being supervised are suggested not
play with the product. Appliance is not suitable for children or person with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge to be
used, unless they have been given supervision or instruction.
Keep cord clear of pathways, and do not pull forcefully at any point.
If smoke or burning smell is detectd,unplug immediately.
Please refer to the table below in the event of the product operating
abnormally：
Aroma Diffuser
User Manual
This Aroma Diffuser uses Ultrasonic waves to instantly vaporize
water and essential oil in the tank, to produce a cool, dry fragrant mist.
Note: Be sure to use a mild detergent.
Aroma Diffuser
SPECIFICATIONS
User Manual
Aroma Diffuser
1.Keep product straighten, remove the upper lid and water
cap vertical direction. Fig1
2.Please connect the AC adaptor to the base of DC
jack of the main body via cable guide. Fig2
3.Please use the measure cup(not included in the
package) to supply water(Do Not add high temperature
water) from the water pipe,pay attention to the filled
waterlevel;do not exceed the max line,Please do not
add water when the product is working.Drop essential
oil into water tank vertically.Fig3
4.Install the cover of the main body with the original
channel, To fall to the vertical direction, Rotate the
cover to adjust the desired position mouth spray.
BTW:You must cover the upper cover when you
want to use the product. Fig4
5.Please connect the AC adaptor with family user
power supply socket.
6.Press“MIST”button,choose the time needed, (1H,3H,
6H or ON continuous spray time).“MIST”button
please press“MIST”button five times (from 1H,3H,6H,
ON to OFF).Fig5
7.Press "light"button to turn on the LED light,seven light
color option at verying brightness are available.Fig6
8.If you do not use it for a long time, please drain out the water from tank water, dry and
then keep it well. If you want to use it again, please use the neutral detergent to clean
the water tank again, then you can use it.
9.When the power is switched on, the initial state of Aromatherapy machine is turned off.
10.If lack of water in the tank, even though the MIST switch, aromatherapy machine will
automatically turn off.
11.Mist and light off automatically when water runs out.
1H
3H 6H
ON
LIGHT
MIST
1H
3H 6H
ON
LIGHT
MIST
DIFF-G5-LW
1H
3H 6H
ON
LIG HT
MIS T
WATER TANK COVER
LIGHT
WATER TANK
MAIN BODY
AIR OUTLET
AIR INTAKE
MIST
DRAINAGE
OUTLET
Model
Dimensions Approx 160x160x165mm
Approx 400g
Approx 24cm
Approx 9W
AC 100-240V 50.60HZ/DC24V 500MA
Weigh(excluding adaptor)
Power:Input(Output)
Length of cord
Electric consumption
Time Mode 1H/3H/6H/ON
Tank Capacity 400ML
LED light 5pcs
Materials PP/ABS/PC/Glass
Accessories AC Adaptot and manual
Method of mist production 2.4MHz
No
1
2
3
4
5
6
Button
ON/OFF
Intermittent
Continuous
Light
Big/small
Timing
Function
ON/OFF
High Mist/Low Mist
Press it to turn on the LED light,
seven light color option
To select 1H/3H/6H or ON mode
To continuous spray
Press to enter intermittent mode
WARNING
THIS PRODUCT CONTAINS A BUTTON BATTERY
If swallowed, a lithium button battery can cause severe or
fatal injuries within 2 hours.
Keep batteries out of reach of children.
If you think batteries may have been swallowed or placed
inside
any part of the body, seek immediate medical attention.
ON/OFF
timing Big/small Light
Inter-
mittent
Con-
tinuous
2
3
4
5
1
6
In the event of the unit being knocked over or tipped during use, please
follow the steps as below to avoid malfunction:
1.plug the unit and remove cover.
2.pour out any remaining water from the water tank.
3.shake the unit gently to drain water,and then keep it natural air drying for at least
24 hours.
If product doesn’t work well, please refer to the following points
before requesting repairs:
Will not switch
on or switch off
No mist or
abnormal mist
Water leakage
from product
Is there enough water in the tank?
--Please add water to the tank
Is the power cord connected property?
--Please disconnect, check cables and re-connect carefully.
Not enough water? or too much water?
--Please add suitable amount of water in the tank, water must
never be filled over 400ML (MAX)line.
Dirt on the ultrasonic plate?
--Please refer to maintenance instructions remove and re-install
correctly, so vapors can be released freely.
Cover and inner cover are not installed properly? Dirt on the air
suction port on the underside of the base?
--If too much dust in the air suction port, the mist will be
restricted to come out.Just clean it.
Cover and inner are not installed properly?
--Remove and reinstall correctly, so vapors can be released
freely.
Low temperature or high humidity?
--Under these conditions, the mist may condense quickly into
water droplets.
Product use time:4 hours.
The amount and intensity of mist produced will vary, but this is not unusual
and should not be considered as a fault.
Factors that affect this include water type,humidity,temperature,air currents.
Auto power off when water runs out.
Applies only 100% natural essential oils, if they contain chemical ingredients,
flavors or impurities may cause damage to the product.
Before replacing another essential oils, follow the maintenance part of the
clean-up products.
OPERATION
MAINTENANCE
PRECAUTIONS
TROUBLESHOOTING
PRECAUTIONS
ACCIDENTAL LEKAGE
User Manual
Aroma Diffuser Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
After using 5-6 times, or 3-5 days, please clean the product as follow:
Please check below to avoid malfunction of the unit:
1.unplug the unit from mains supply and remove cover.
2.pour out any remaining water from the tank.
3.add a small amount of warm kitchen detergent remover and water,use swab to
wipe it gently,and then use cleaning cloth to dry it lightiy.
4.refer to the following pictures, to avoid water flow into the air outlet,pour off
water abide by the left picture, not the right one.
5.do not use other acids or enzymes detergents,as this may give off poisonous
gas or cause malfunction.
Do not fill over 400ML”MAX”at any time.
Do not switch on power when the tank is empty.
Do not touch the Ultrasonic vibration plate.
Clean regularly as per Maintenance instructions to avoid malfunction.
Always unplug from power supply before maintenance.
For hygiene reasons, after use, pour away remaining water from “DRAIN SIDE” of
tank, and wipe with a clean dry cloth.
Essential oils can stain, In the event of spillage of contact, please wipe away with a
soft cloth.
Only use the measuring cup (not provided) to add water into the tank, do not fill water
directly from the water pipe.
Do not let mist below onto furniture, clothing, walls etc.
Keep away from directing sunshine heat sources and air conditioners or fans.
Always keep on stable plat surface do not place on carpet, duvet or unstable area.
Keep away from electronic equipment, such as TV and Auto equipment.
Do not tip the product this may cause water to enter the mechanism and cause malfunction.
Product use time: 4 hours.
Wait 60 minutes before restart to avoid damage to Ultrasonic plate.
Use tap water only, does not use mineral water, sparkling water etc.
Never move product in use.
Do not touch any part of the product with wet hands.
Keep out of reach of children and pets, Children not being supervised are suggested not
play with the product. Appliance is not suitable for children or person with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge to be
used, unless they have been given supervision or instruction.
Keep cord clear of pathways, and do not pull forcefully at any point.
If smoke or burning smell is detectd,unplug immediately.
Please refer to the table below in the event of the product operating
abnormally：
Aroma Diffuser
User Manual
This Aroma Diffuser uses Ultrasonic waves to instantly vaporize
water and essential oil in the tank, to produce a cool, dry fragrant mist.
Note: Be sure to use a mild detergent.
Aroma Diffuser
SPECIFICATIONS
User Manual
Aroma Diffuser
1.Keep product straighten, remove the upper lid and water
cap vertical direction. Fig1
2.Please connect the AC adaptor to the base of DC
jack of the main body via cable guide. Fig2
3.Please use the measure cup(not included in the
package) to supply water(Do Not add high temperature
water) from the water pipe,pay attention to the filled
waterlevel;do not exceed the max line,Please do not
add water when the product is working.Drop essential
oil into water tank vertically.Fig3
4.Install the cover of the main body with the original
channel, To fall to the vertical direction, Rotate the
cover to adjust the desired position mouth spray.
BTW:You must cover the upper cover when you
want to use the product. Fig4
5.Please connect the AC adaptor with family user
power supply socket.
6.Press“MIST”button,choose the time needed, (1H,3H,
6H or ON continuous spray time).“MIST”button
please press“MIST”button five times (from 1H,3H,6H,
ON to OFF).Fig5
7.Press "light"button to turn on the LED light,seven light
color option at verying brightness are available.Fig6
8.If you do not use it for a long time, please drain out the water from tank water, dry and
then keep it well. If you want to use it again, please use the neutral detergent to clean
the water tank again, then you can use it.
9.When the power is switched on, the initial state of Aromatherapy machine is turned off.
10.If lack of water in the tank, even though the MIST switch, aromatherapy machine will
automatically turn off.
11.Mist and light off automatically when water runs out.
1H
3H 6H
ON
LIGHT
MIST
1H
3H 6H
ON
LIGHT
MIST
DIFF-G5-LW
1H
3H 6H
ON
LIG HT
MIS T
WATER TANK COVER
LIGHT
WATER TANK
MAIN BODY
AIR OUTLET
AIR INTAKE
MIST
DRAINAGE
OUTLET
Model
Dimensions Approx 160x160x165mm
Approx 400g
Approx 24cm
Approx 9W
AC 100-240V 50.60HZ/DC24V 500MA
Weigh(excluding adaptor)
Power:Input(Output)
Length of cord
Electric consumption
Time Mode 1H/3H/6H/ON
Tank Capacity 400ML
LED light 5pcs
Materials PP/ABS/PC/Glass
Accessories AC Adaptot and manual
Method of mist production 2.4MHz
No
1
2
3
4
5
6
Button
ON/OFF
Intermittent
Continuous
Light
Big/small
Timing
Function
ON/OFF
High Mist/Low Mist
Press it to turn on the LED light,
seven light color option
To select 1H/3H/6H or ON mode
To continuous spray
Press to enter intermittent mode
WARNING
THIS PRODUCT CONTAINS A BUTTON BATTERY
If swallowed, a lithium button battery can cause severe or
fatal injuries within 2 hours.
Keep batteries out of reach of children.
If you think batteries may have been swallowed or placed
inside
any part of the body, seek immediate medical attention.
ON/OFF
timing Big/small Light
Inter-
mittent
Con-
tinuous
2
3
4
5
1
6
In the event of the unit being knocked over or tipped during use, please
follow the steps as below to avoid malfunction:
1.plug the unit and remove cover.
2.pour out any remaining water from the water tank.
3.shake the unit gently to drain water,and then keep it natural air drying for at least
24 hours.
If product doesn’t work well, please refer to the following points
before requesting repairs:
Will not switch
on or switch off
No mist or
abnormal mist
Water leakage
from product
Is there enough water in the tank?
--Please add water to the tank
Is the power cord connected property?
--Please disconnect, check cables and re-connect carefully.
Not enough water? or too much water?
--Please add suitable amount of water in the tank, water must
never be filled over 400ML (MAX)line.
Dirt on the ultrasonic plate?
--Please refer to maintenance instructions remove and re-install
correctly, so vapors can be released freely.
Cover and inner cover are not installed properly? Dirt on the air
suction port on the underside of the base?
--If too much dust in the air suction port, the mist will be
restricted to come out.Just clean it.
Cover and inner are not installed properly?
--Remove and reinstall correctly, so vapors can be released
freely.
Low temperature or high humidity?
--Under these conditions, the mist may condense quickly into
water droplets.
Product use time:4 hours.
The amount and intensity of mist produced will vary, but this is not unusual
and should not be considered as a fault.
Factors that affect this include water type,humidity,temperature,air currents.
Auto power off when water runs out.
Applies only 100% natural essential oils, if they contain chemical ingredients,
flavors or impurities may cause damage to the product.
Before replacing another essential oils, follow the maintenance part of the
clean-up products.
OPERATION
MAINTENANCE
PRECAUTIONS
TROUBLESHOOTING
PRECAUTIONS
ACCIDENTAL LEKAGE
User Manual
Aroma Diffuser Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
After using 5-6 times, or 3-5 days, please clean the product as follow:
Please check below to avoid malfunction of the unit:
1.unplug the unit from mains supply and remove cover.
2.pour out any remaining water from the tank.
3.add a small amount of warm kitchen detergent remover and water,use swab to
wipe it gently,and then use cleaning cloth to dry it lightiy.
4.refer to the following pictures, to avoid water flow into the air outlet,pour off
water abide by the left picture, not the right one.
5.do not use other acids or enzymes detergents,as this may give off poisonous
gas or cause malfunction.
Do not fill over 400ML”MAX”at any time.
Do not switch on power when the tank is empty.
Do not touch the Ultrasonic vibration plate.
Clean regularly as per Maintenance instructions to avoid malfunction.
Always unplug from power supply before maintenance.
For hygiene reasons, after use, pour away remaining water from “DRAIN SIDE” of
tank, and wipe with a clean dry cloth.
Essential oils can stain, In the event of spillage of contact, please wipe away with a
soft cloth.
Only use the measuring cup (not provided) to add water into the tank, do not fill water
directly from the water pipe.
Do not let mist below onto furniture, clothing, walls etc.
Keep away from directing sunshine heat sources and air conditioners or fans.
Always keep on stable plat surface do not place on carpet, duvet or unstable area.
Keep away from electronic equipment, such as TV and Auto equipment.
Do not tip the product this may cause water to enter the mechanism and cause malfunction.
Product use time: 4 hours.
Wait 60 minutes before restart to avoid damage to Ultrasonic plate.
Use tap water only, does not use mineral water, sparkling water etc.
Never move product in use.
Do not touch any part of the product with wet hands.
Keep out of reach of children and pets, Children not being supervised are suggested not
play with the product. Appliance is not suitable for children or person with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge to be
used, unless they have been given supervision or instruction.
Keep cord clear of pathways, and do not pull forcefully at any point.
If smoke or burning smell is detectd,unplug immediately.
Please refer to the table below in the event of the product operating
abnormally：
Aroma Diffuser
User Manual
This Aroma Diffuser uses Ultrasonic waves to instantly vaporize
water and essential oil in the tank, to produce a cool, dry fragrant mist.
Note: Be sure to use a mild detergent.
Aroma Diffuser
SPECIFICATIONS
User Manual
Aroma Diffuser
1.Keep product straighten, remove the upper lid and water
cap vertical direction. Fig1
2.Please connect the AC adaptor to the base of DC
jack of the main body via cable guide. Fig2
3.Please use the measure cup(not included in the
package) to supply water(Do Not add high temperature
water) from the water pipe,pay attention to the filled
waterlevel;do not exceed the max line,Please do not
add water when the product is working.Drop essential
oil into water tank vertically.Fig3
4.Install the cover of the main body with the original
channel, To fall to the vertical direction, Rotate the
cover to adjust the desired position mouth spray.
BTW:You must cover the upper cover when you
want to use the product. Fig4
5.Please connect the AC adaptor with family user
power supply socket.
6.Press“MIST”button,choose the time needed, (1H,3H,
6H or ON continuous spray time).“MIST”button
please press“MIST”button five times (from 1H,3H,6H,
ON to OFF).Fig5
7.Press "light"button to turn on the LED light,seven light
color option at verying brightness are available.Fig6
8.If you do not use it for a long time, please drain out the water from tank water, dry and
then keep it well. If you want to use it again, please use the neutral detergent to clean
the water tank again, then you can use it.
9.When the power is switched on, the initial state of Aromatherapy machine is turned off.
10.If lack of water in the tank, even though the MIST switch, aromatherapy machine will
automatically turn off.
11.Mist and light off automatically when water runs out.
1H
3H 6H
ON
LIGHT
MIST
1H
3H 6H
ON
LIGHT
MIST
DIFF-G5-LW
1H
3H 6H
ON
LIG HT
MIS T
WATER TANK COVER
LIGHT
WATER TANK
MAIN BODY
AIR OUTLET
AIR INTAKE
MIST
DRAINAGE
OUTLET
Model
Dimensions Approx 160x160x165mm
Approx 400g
Approx 24cm
Approx 9W
AC 100-240V 50.60HZ/DC24V 500MA
Weigh(excluding adaptor)
Power:Input(Output)
Length of cord
Electric consumption
Time Mode 1H/3H/6H/ON
Tank Capacity 400ML
LED light 5pcs
Materials PP/ABS/PC/Glass
Accessories AC Adaptot and manual
Method of mist production 2.4MHz
No
1
2
3
4
5
6
Button
ON/OFF
Intermittent
Continuous
Light
Big/small
Timing
Function
ON/OFF
High Mist/Low Mist
Press it to turn on the LED light,
seven light color option
To select 1H/3H/6H or ON mode
To continuous spray
Press to enter intermittent mode
WARNING
THIS PRODUCT CONTAINS A BUTTON BATTERY
If swallowed, a lithium button battery can cause severe or
fatal injuries within 2 hours.
Keep batteries out of reach of children.
If you think batteries may have been swallowed or placed
inside
any part of the body, seek immediate medical attention.
ON/OFF
timing Big/small Light
Inter-
mittent
Con-
tinuous
2
3
4
5
1
6
In the event of the unit being knocked over or tipped during use, please
follow the steps as below to avoid malfunction:
1.plug the unit and remove cover.
2.pour out any remaining water from the water tank.
3.shake the unit gently to drain water,and then keep it natural air drying for at least
24 hours.
If product doesn’t work well, please refer to the following points
before requesting repairs:
Will not switch
on or switch off
No mist or
abnormal mist
Water leakage
from product
Is there enough water in the tank?
--Please add water to the tank
Is the power cord connected property?
--Please disconnect, check cables and re-connect carefully.
Not enough water? or too much water?
--Please add suitable amount of water in the tank, water must
never be filled over 400ML (MAX)line.
Dirt on the ultrasonic plate?
--Please refer to maintenance instructions remove and re-install
correctly, so vapors can be released freely.
Cover and inner cover are not installed properly? Dirt on the air
suction port on the underside of the base?
--If too much dust in the air suction port, the mist will be
restricted to come out.Just clean it.
Cover and inner are not installed properly?
--Remove and reinstall correctly, so vapors can be released
freely.
Low temperature or high humidity?
--Under these conditions, the mist may condense quickly into
water droplets.
Product use time:4 hours.
The amount and intensity of mist produced will vary, but this is not unusual
and should not be considered as a fault.
Factors that affect this include water type,humidity,temperature,air currents.
Auto power off when water runs out.
Applies only 100% natural essential oils, if they contain chemical ingredients,
flavors or impurities may cause damage to the product.
Before replacing another essential oils, follow the maintenance part of the
clean-up products.
OPERATION
MAINTENANCE
PRECAUTIONS
TROUBLESHOOTING
PRECAUTIONS
ACCIDENTAL LEKAGE
User Manual
Aroma Diffuser Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
After using 5-6 times, or 3-5 days, please clean the product as follow:
Please check below to avoid malfunction of the unit:
1.unplug the unit from mains supply and remove cover.
2.pour out any remaining water from the tank.
3.add a small amount of warm kitchen detergent remover and water,use swab to
wipe it gently,and then use cleaning cloth to dry it lightiy.
4.refer to the following pictures, to avoid water flow into the air outlet,pour off
water abide by the left picture, not the right one.
5.do not use other acids or enzymes detergents,as this may give off poisonous
gas or cause malfunction.
Do not fill over 400ML”MAX”at any time.
Do not switch on power when the tank is empty.
Do not touch the Ultrasonic vibration plate.
Clean regularly as per Maintenance instructions to avoid malfunction.
Always unplug from power supply before maintenance.
For hygiene reasons, after use, pour away remaining water from “DRAIN SIDE” of
tank, and wipe with a clean dry cloth.
Essential oils can stain, In the event of spillage of contact, please wipe away with a
soft cloth.
Only use the measuring cup (not provided) to add water into the tank, do not fill water
directly from the water pipe.
Do not let mist below onto furniture, clothing, walls etc.
Keep away from directing sunshine heat sources and air conditioners or fans.
Always keep on stable plat surface do not place on carpet, duvet or unstable area.
Keep away from electronic equipment, such as TV and Auto equipment.
Do not tip the product this may cause water to enter the mechanism and cause malfunction.
Product use time: 4 hours.
Wait 60 minutes before restart to avoid damage to Ultrasonic plate.
Use tap water only, does not use mineral water, sparkling water etc.
Never move product in use.
Do not touch any part of the product with wet hands.
Keep out of reach of children and pets, Children not being supervised are suggested not
play with the product. Appliance is not suitable for children or person with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge to be
used, unless they have been given supervision or instruction.
Keep cord clear of pathways, and do not pull forcefully at any point.
If smoke or burning smell is detectd,unplug immediately.
Please refer to the table below in the event of the product operating
abnormally：
Aroma Diffuser
User Manual
This Aroma Diffuser uses Ultrasonic waves to instantly vaporize
water and essential oil in the tank, to produce a cool, dry fragrant mist.
Note: Be sure to use a mild detergent.
Aroma Diffuser
SPECIFICATIONS
User Manual
Aroma Diffuser
1.Keep product straighten, remove the upper lid and water
cap vertical direction. Fig1
2.Please connect the AC adaptor to the base of DC
jack of the main body via cable guide. Fig2
3.Please use the measure cup(not included in the
package) to supply water(Do Not add high temperature
water) from the water pipe,pay attention to the filled
waterlevel;do not exceed the max line,Please do not
add water when the product is working.Drop essential
oil into water tank vertically.Fig3
4.Install the cover of the main body with the original
channel, To fall to the vertical direction, Rotate the
cover to adjust the desired position mouth spray.
BTW:You must cover the upper cover when you
want to use the product. Fig4
5.Please connect the AC adaptor with family user
power supply socket.
6.Press“MIST”button,choose the time needed, (1H,3H,
6H or ON continuous spray time).“MIST”button
please press“MIST”button five times (from 1H,3H,6H,
ON to OFF).Fig5
7.Press "light"button to turn on the LED light,seven light
color option at verying brightness are available.Fig6
8.If you do not use it for a long time, please drain out the water from tank water, dry and
then keep it well. If you want to use it again, please use the neutral detergent to clean
the water tank again, then you can use it.
9.When the power is switched on, the initial state of Aromatherapy machine is turned off.
10.If lack of water in the tank, even though the MIST switch, aromatherapy machine will
automatically turn off.
11.Mist and light off automatically when water runs out.
1H
3H 6H
ON
LIGHT
MIST
1H
3H 6H
ON
LIGHT
MIST
DIFF-G5-LW
1H
3H 6H
ON
LIG HT
MIS T
WATER TANK COVER
LIGHT
WATER TANK
MAIN BODY
AIR OUTLET
AIR INTAKE
MIST
DRAINAGE
OUTLET
Model
Dimensions Approx 160x160x165mm
Approx 400g
Approx 24cm
Approx 9W
AC 100-240V 50.60HZ/DC24V 500MA
Weigh(excluding adaptor)
Power:Input(Output)
Length of cord
Electric consumption
Time Mode 1H/3H/6H/ON
Tank Capacity 400ML
LED light 5pcs
Materials PP/ABS/PC/Glass
Accessories AC Adaptot and manual
Method of mist production 2.4MHz
No
1
2
3
4
5
6
Button
ON/OFF
Intermittent
Continuous
Light
Big/small
Timing
Function
ON/OFF
High Mist/Low Mist
Press it to turn on the LED light,
seven light color option
To select 1H/3H/6H or ON mode
To continuous spray
Press to enter intermittent mode
WARNING
THIS PRODUCT CONTAINS A BUTTON BATTERY
If swallowed, a lithium button battery can cause severe or
fatal injuries within 2 hours.
Keep batteries out of reach of children.
If you think batteries may have been swallowed or placed
inside
any part of the body, seek immediate medical attention.
ON/OFF
timing Big/small Light
Inter-
mittent
Con-
tinuous
2
3
4
5
1
6
