READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
Only use the product as described in this user manual. Any other
use is considered improper and may result in damage to property
or persons.
The manufacturer or vendor cannot be held liable for damages or
injury incurred through improper or incorrect use.
Read and familiarise yourself with all operating instructions
before using this 12” Desk Fan.
Before plugging your unit into the mains, visually check that the
unit is intact and has not suffered any transit damage.
DO NOT use this product with a programmer, timer, separate
remote-control system or any other device.
Check that the voltage indicated on the data plate corresponds
with that of the local network before connecting the appliance
to the mains power supply.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
Close supervision is required when using this appliance near
children.
Never leave this appliance within reach of children
Children of less than 3 years should be kept away unless
continuously supervised.
DO NOT immerse the appliance or its cord in water or any
3
12 Inch Rose Gold Desk Fan
Model No. COL1134
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
other liquids.
DO NOT leave the appliance unattended during use.
DO NOT leave the appliance unattended whilst connected to
the mains supply
Always use this appliance on solid, level, surface.
DO NOT use this appliance outdoors.
It is imperative to unplug the power cord after the appliance
has been used, before it is cleaned and whilst being repaired.
Repairs to electrical appliances should be performed by a
qualified electrician. Improper repairs may place user at serious
risk.
DO NOT operate this appliance with a damaged plug or cord,
after a malfunction or after being dropped or damaged in any
way.
Regular, periodic checks should be carried out on the mains
cable to ensure no damage is evident. Should there be any
signs of damage the appliance should not be used.
If the power cable is damaged, it should only be replaced by
the manufacturer or a suitable qualified-after-sales service in
order to avoid a hazard.
DO NOT allow the mains cable to hang over sharp edges or
come in contact with hot surfaces.
DO NOT run the mains cable under carpets, rugs, etc.
This appliance is intended for household use only and should
not be used for industrial purposes.
DO NOT use any accessories or attachments with this
appliances other than those supplied or recommended by the
supplier.
DO NOT use this appliance for anything other than intended
use.
DO NOT push objects (including fingers) into the fan grill or any
openings as this could risk injury or damage to the appliance.
Unplug after each use. Grasp the plug not the cord
4
12 Inch Rose Gold Desk Fan
Model No. COL1134
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, www.weeeireland.ie and enter your
postcode to find out your nearest recycling site.
This symbol provides useful additional information on the use of
this product.
5
12 Inch Rose Gold Desk Fan
Model No. COL1134
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of parts
Before first use of your Desk Fan
Remove all packing materials and discard responsibly.
Ensure all parts are present – see Description of parts above.
Check that there is no damage to the mains cable or product.
Assembling your Desk Fan
1. Remove the 4 screws from the front of the Motor Housing
(9) as shown right.
2. Attach the Rear Guard (8) to the Motor Housing (9),
ensuring that the 4 holes on the Rear Guard (8) align with
the 4 holes on the Motor Housing (9). Fix into place using
the screws removed above, take care not to overtighten.
Ensure that the carry handle on the Rear Guard (8) is
upright when fixing into place.
3. Remove the protective sleeving from the motor spindle
and slacken the blade retaining screw on the Fan Blade
(2).
4. Place the Fan Blade (2) over the motor spindle and tighten the
blade retaining screw.
5. Remove the Front Guard Nut & Screw
(4) from the Front Guard (1).
6. Turn the four clips around the outer
edge of the Front Guard (1) outwards.
1. Front Guard
2. Fan Blade
3. Pivot Adjustment Screw
4. Front Guard Nut & Screw
5. Base
6. Oscillation Control
7. Rotary Switch
8. Rear Guard
9. Motor Housing
1
2
3
4
6
7
8
9
5
6
12 Inch Rose Gold Desk Fan
Model No. COL1134
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
7. Hang the Front Guard (1) over the top of the Rear Guard (8) Fig.1 and push the
clips inwards until the Front Guard (1) is fastened to the Rear Guard (8) as per
Fig. 2 below.
Fig. 1 Fig. 2 Fig. 3
8. Fit the Front Guard Nut & Screw (4), ensuring that the screw goes through both
the Front Guard (1) and the Rear Guard (8), tighten the nut to fix into place as
per Fig. 3 above.
Using your Desk Fan
1. Place the fan on a stable, level surface.
2. If desired the fan can be adjusted. To adjust the direction of
airflow, slacken the Pivot Adjustment Screw (3) and adjust the
Motor Housing (9) up or down accordingly. When desired position
has been achieved tighten the Pivot Adjustment Screw (3) to fix
into place.
3. Ensure that the Rotary Switch (7) is in the ‘0’ position, to ensure
that the fan is in the off mode.
4. Insert the mains plug into the nearest available socket.
5. Adjust the Rotary Switch (7) to the desired speed setting from;
Position I for Low Speed
Position II for Medium Speed
Position III for High Speed
Making your Fan oscillate from side to side
Press the Oscillation Control (6) down to allow your fan to oscillate.
Pull the Oscillation Control (6) up to stop oscillation
Never adjust the fan whilst connected to the mains and/or
switched on.
7
12 Inch Rose Gold Desk Fan
Model No. COL1134
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Care and Use of your Fan
Ensure that the fan is switched off and it is not connected to the
mains supply before cleaning.
Wipe the fan body clean with a clean, soft damp cloth.
Do not immerse the fan or its cord in water or any other liquid.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). If in doubt, consult a qualified
electrician who will be pleased to do this for you. If you need to remove the plug -
DISCONNECT FROM THE MAINS - and then cut it off the mains lead and
immediately dispose of it safely. Never attempt to reuse the plug or insert it into a
socket outlet as there is a danger of electric shock.
Technical Data
Model No.
COL1134
Voltage
220-240V ~ 50-60Hz
Rated Power
35W
Protection Class
I (Must be Earth connection)
Disposal of the packaging
Dispose of paper and cardboard in appropriate paper re-cycling
facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling
facilities.
Dispose of non-recyclable plastics in the appropriate plastics
collection service.
Disposal of the product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk,
www.weeeireland.ie and enter your postcode to find out your
nearest recycling site.
8
12 Inch Rose Gold Desk Fan
Model No. COL1134
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
SPORTSDIRECT.COM Retail Limited, Shirebrook UK NG20 8RY www.sportsdirect.com
SPORTSDIRECT.COM Retail Europe, Avenue Ernest Solvay 29, 1480 Saintes, Belgium
SPORTSDIRECT.COM Austria, Gmbh Flugplatzstrasse 30, 4600 Wels Austria
9
12 Inch Rose Gold Desk Fan
Model No. COL1134
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo® is a registered trademark.
Produced and imported under licence by
Eurosonic Group Ltd. Manchester M3 1JS UK
EU Rep: Euromagppie Ireland Ltd. DO5 X006 Ireland
www.esgltd.com
