32 Inch Tower Fan
Model No. COL1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
32 Inch Tower Fan
Model No. COL1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
Only use the product as described in this user manual. Any other
use is considered improper and may result in damage to
property or persons.
The manufacturer or vendor cannot be held liable for damages
or injury incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this 32” Tower Fan.
• Before plugging your unit into the mains, visually check that
the unit is intact and has not suffered any transit damage.
• DO NOT use this product with a programmer, timer,
separate remote control system or any other device.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• Close supervision is required when using this appliance
near children.
• Never leave this appliance within reach of children
• Children of less than 3 years should be kept away unless
continuously supervised.
• DO NOT immerse the appliance or its cord in water or any
3
32 Inch Tower Fan
Model No. COL1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
other liquids.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected
to the mains supply.
• Always use this appliance on solid, level, surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Repairs to electrical appliances should be performed by a
qualified electrician. Improper repairs may place user at
serious risk.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
• Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• If the power cable is damaged, it should only be replaced
by the manufacturer or a suitable qualified-after-sales
service in order to avoid a hazard.
• DO NOT allow the mains cable to hang over sharp edges
or come into contact with hot surfaces.
• DO NOT run the mains cable under carpets, rugs etc.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliances other than those supplied or recommended by
the supplier.
• DO NOT use this appliance for anything other than
intended use.
• DO NOT push objects (including fingers) into the fan grill
or any openings as this could risk injury or damage to
the appliance.
• Unplug after each use. Grasp the plug not the cord.
4
32 Inch Tower Fan
Model No. COL1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
This Class 2 symbol indicates that the product is electrically double
insulated and does not require an earth connection.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk enter your postcode to find out your
nearest recycling site.
This symbol provides useful additional information on the
use of this product.
5
32 Inch Tower Fan
Model No. COL1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Before first use of your Pedestal Fan
Remove all packing materials and discard responsibly.
Ensure all parts are present - see Description of Parts above.
Check that there is no damage to the mains cable or product.
Assembly of your Tower Fan
The Base (6) comes in two parts, which fit around the base of the Main Unit (4)
with the power cord exiting through the hole in the centre. Both parts fit easily
together. Before assembly, place a cloth or similar underneath the appliance
parts to prevent damage.
1. Turn the base retaining nut on the underside of the Main Unit (4)
anti-clockwise to unscrew as shown right.
2. Lower the front half of the Base (6) on top of the rear half (Fig. 1)
of the base so that the two latch together (Fig. 2). Ensure that
the power cord is fed through the hole in the centre.
Ensure that the nodules on the base of the Main Unit (4) are
aligned with the cut-outs in the base (Fig. 2).
Fig. 1 Fig. 2 Fig. 3
1. Controls
2. Air Flow (out)
3. Air Inlet (rear)
4. Main Unit
5. Power Cord
6. Base (2 Sections)
7. Timer Control
8. Speed/Oscillation Control
2
1
3
5
4
6
7
8
6
32 Inch Tower Fan
Model No. COL1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3. Secure the two halves of the base by turning the base
retaining nut clockwise until firmly in place (Fig. 3).
4. Once the Base (6) is attached, thread the Power Cord (5)
through the inner cord guides (Fig. 4).
Setting Up Your Tower Fan
Place the assembled tower fan on a dry, level and stable surface.
Ensure the Timer Control (7) and Speed/Oscillation Control (8) set to the OFF
position and insert the plug into a socket and switch the socket on (if applicable).
Operating Instructions
Fan Operation
The fan has three speeds:
Speed 1 - Low Speed
Speed 2 - Medium Speed
Speed 3 - High Speed
Fan Only Mode
For Fan only mode, rotate the Speed/Oscillation Control
(8) to the appropriate number on the RIGHT HAND side
of the control. The fan will start blowing air in stationary
mode.
Fan Operation and Oscillation Mode
For Fan and Oscillation mode, rotate the
Speed/Oscillation Control (8) to the appropriate number
on the LEFT HAND side of the control. The fan will start
blowing air and oscillating side to side.
Rotate the Speed/Oscillation Control (8) to the OFF position
(either at the top or bottom) to switch off the fan.
Fig.4
7
32 Inch Tower Fan
Model No. COL1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Timer Operation:
Rotate the Timer Control (7) clockwise to the required time
period the fan will stay on for.
The timer can be set to a maximum of 2 hours, in 20 minute
steps. The fan will switch off when the set time period has
elapsed.
Care and Use of your Fan
• Ensure that the fan is not connected to the mains supply
before cleaning.
• Wipe the fan body with a clean, soft damp cloth.
• Do not immerse the fan or its cord in water or any other
liquid.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains
lead and should the fuse needed replacing, you must use an ASTA approved
one (conforming to BS 1362 of the same rating). Never use a plug with the
fuse cover missing. If in doubt, consult a qualified electrician. If you need to
remove the plug-DISCONNECT FROM THE MAINS- and then cut it off the
mains lead and immediately dispose of it safely. Never attempt to reuse the
plug or insert it into a socket outlet as there is a danger of electric shock
Technical Data
Model No.
COL1570
Voltage
220-240V~ 50/60Hz
Rated Power
45W
Protection Class
II
8
32 Inch Tower Fan
Model No. COL1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling
facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling
facilities.
Dispose of non-recyclable plastics in the appropriate plastics
collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk enter your postcode to find out your
nearest recycling site.
9
32 Inch Tower Fan
Model No. COL1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
ESG Ltd. Manchester M3 1JS UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
