28” TOWER FAN, 60-Degree
Oscillating Manual Knob,
with 3 Speed Settings and
Carry Handle
OWNER ’S MANUAL
FAT2835
Visit our website at www.emersonradio.com
To obtain a manual in Spanish, please download it on our website.
H�ps://www.emersonradio.com/documents/
FOR HOUSEHOLD USE ONLY.
READ AND SAVE THESE INSTRUCTIONS
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD,
RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT
BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings, and read all cautionary marking on the appliance and safety instructions
4. Do not block any ventilation openings, do not cover the air inlet and outlet while in operation. Install in
accordance with the manufacturer's instructions.
5. Do not use the fan near flammables and combustible.
6. Follow all instructions.
7. This product is intended for household use ONLY and not for commercial, indust
rial or outdoor use.
8. Always unplug before cleaning or leaving the appliance unused for a long period of time. Keep your
hands dry when plugging/unplugging.
9. Do not operate any fan with a damaged cord or plug. Discard fan or return to an authorized service
facility for examination and/or repair.
10. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a
third grounding
prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
11. Only use attachments / accessories specified by the manufacturer.
12. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do
not route cord under furniture or appliances. Arrange cord away from traffic area and where it will not
be tripped over.
13. Do not leave the appliance running unattended.
14. Keep electrical appliances out of reach from children or infirm persons. Do not allow them use the
appliances without supervision.
15. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person resp
onsible that they do not play with the
appliance.
WARNING: To reduce the risk of fire or electric shock do not use this tower fan with any solid-state
speed control device.
16. This appliance employs overload protection (fuse). A blown fuse indicates an overload or short-circuit
situation. If the fuse blows, unplug the product from the outlet. Replace the fuse as per the user
service instructions and check the appliance. If the replacement fuse blows, a short-circuit may be
present and the appliance should be discarded or returned to an authorized service facility for
examination and/or repair.
17. Check the appliance regularly and refer to TROUBLESHOOTING or contact our customer support if it
shows any of the following signs :
- Power Cord or plug is damaged
- Loud noise, unusual smell or excessive heat.
18. R
19. To mitigate the risks of fire, electric shock, or personal injury, it is crucial to avoid using replacement parts
that are not authorized by the manufacturer, including components produced at home via a 3D printing.
efer all servicing to qualified service personnel. Servicing is required when the appliance has been
damaged in any way, such as p
ower-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the appliance, the appliance has been exposed to rain or moisture, does not operate
normally, or has been dropped.
1 WARNING
EN
1
When using the appliance for the first time, remove the wraps and attach the parts by following the steps
below.
2 COMPONENTS DIAGRAM
1. Body
2. Front Base
3. Rear Base
4. Plastic Nut
5. Power Cord
3 ASSEMBLY INSTRUCTIONS
A. Base Assembly
Align the two portions of the circular base and secure them by placing the front base (2)
onto the rear base (3) of the connecting piece.
B. Gently extend the power cord (5), thread it
through the designated channel, and insert the
fan body (1) into the base assembly.
C. Secure the fan body to the base assembly using
the plastic nut (4).
CAUTION: Do not operate the tower fan if the
base assembly is not proper installed.
The outlet trough
Fig.1
EN
2
1
2
3
4
5
plastic Nut
plastic Nut
A. Control Panel Description
B. Instructions:
1. Connect the power cord (5) to a wall outlet.
2. Press the body oscillating button to turn on the oscillating mode. Press again to stop the
oscillation.
3. Speed is controlled by the rotary knob located on the top of the unit, with four settings:
0 – Off; 1 – Low; 2 – Medium; 3 – High
To maintain optimal air circulation to the motor, it is essential to keep the vents at the rear of the motor
housing free from dust and debris. Note: A vacuum c
leaner should not be used to clean these vents prior
to disconnecting the power. Do not disassemble the fan to remove any accumulated fluff.
4 OPERATING INSTRUCTIONS
5 CLEANING AND MAINTENANCE INSTRUCTIONS
Outer Surface
Gently wipe off the dust with a soft
,
dry cloth
.
Grilles and Blades
Remove the dust using a vacuum or air duster
CAUTION
1. Always unplug the fan before any cleaning or maintenance to
avoid the risk of fire, electric shock, or injury to persons.
2. Do not immerse in water or get liquid inside the motor
housing or interior parts.
3. Do not use any chemical agents, abrasive cleaners or
cleaning pads as these will damage the finis
h of fan
4.
Store in a cool
,
dry place and cover it to protect from dust
.
ENEN
3
Low speed of air flow
High speed of air flow
Off
Body oscillating button
Middle speed of air flow
Notice:
1. When you replace the fuse, please do not operate suddenly or overexert, or else the product will
be damage or cause accident
2. If you encounter any operational challenges, please make sure that you are observing the correct
procedures.
1. My fan won’t turn on
a. Make sure that the cord is connected to a powered outlet and the mains voltage corresponds
with the voltage indicated on the fan.
2. My fan is shaky and wobbling
a. Place the fan on a flat, level surface.
b. Incor
rect installation might also cause shakiness. Please refer to the assembly instruction in
page 2.
3. My fan is making vibration and noise
a. Place the fan on a flat, level surface.
b. Be sure not to insert anything into the air inlet and outlet.
If your problem is not listed or still persists, please contact our Customer Support (see page 6)
6 USER SERVICING INSTRUCTIONS
- Firmly grip the plug and remove from the receptacle or other outlet
device. Do not unplug by pulling on cord.
- If your fan loses power and you suspect that the fuse on your fan has
blown, you should first remove the spare fuse holder attached to the
cord plug. Remove the spare fuse from the plastic spare house
holder, and set the spare fuse aside.
- You can gain access to the blown fuse by sliding the lid found on the
side of the plug. Slide the lid outwards on the fuse compartment until
the blown fuse is fully visible.
- Carefully remove the blown fuse and insert the replacement fuse into
place.
- Risk of fire. Replace fuse only with 2.5Amp, 125 volt fuse (provided
with product). Fully close the fuse lid by sliding back into place.
Discard the blown fuse. The plug should now be ready for normal
use.
- Risk of fire. Do not replace attached plug. Contains a safety device
(fuse) that should be removed. Discard product if the attached plug
is damaged.
7 TROUBLESHOOTING
4
ENEN
Specifications
Rate Power 35-Watts
Voltage 120V, 60 Hz
Current
350mA
Unit Weight
Unit Dimensions
9.61"W x 9.61"D x 27.95"H (244mm x 244mm x 710mm)
6.26lbs (2.84kg)
Emerson Radio Corp. warrants this product to be free from manufacturing defects in original material,
including original parts, and workmanship under normal home use and conditions (“manufacturing defect”)
for a period of one (1) year from date of original purchase in, and if used in the United States. Should service
be necessary under this warranty, Emerson will provide the following at our Return Repair Facility provided
the manufacturing defect is verified along wi
th the date of purchase:
∗ Repair service for one (1) year from date of original purchase at no charge for labor and parts.
To Receive Authorization to Return a Defective Item, please contact Emerson Customer Service at
1-800-898-9020. Have your Model number, Serial Number and dated Proof of Purchase available when you
call.
In the event the product must be returned to Emerson:
∗ Pack the unit in a well-padded heavy corrugated box. Please insure the item is well padded to avoid
damage wh
ile in transit back to our facility. If the item incurs damage, it will NOT be replaced and the
consumer will be responsible for return freight costs to receive their same unit back.
∗ Enclose your check or money order payable to Emerson Radio in the amount of $15 to cover return
shipping and handling costs.
∗ Enclose a note with your name, address, phone number, Return Authorization number and brief reason for
returning the unit.
∗ Enclose a copy of your proof of purchase (warran
ty service will not be provided without dated proof of
purchase).
∗ Ship the unit prepaid via UPS or parcel post (SHIP INSURED and obtain a tracking number).
NOTE: This warranty does not cover:
(a) Damage to equipment not properly connected to the product.
(b) Cost incurred in the shipping of the product to and from Emerson’s Return Facility.
(c) Damage or improper operation of unit caused by customer abuse, misuse, negligence or failure to follow
operating instructions (in
cluding cleaning instructions) provided with the product.
(d) Ordinary adjustments to the product which can be performed by customer as outlined in the owner’s
manual.
(e) Products not purchased in the United States.
8 FCC CAUTION
9. LIMITED WARRANTY
5
EN
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
(f) Damage to product if used outside the United States.
THIS WARRANTY IS NON-TRANSFERABLE AND APPLIES ONLY TO THE ORIGINAL PURCHASER AND
DOES NOT EXTEND TO SUBSEQUENT OWNERS OF THE PRODUCT. ANY APPLICABLE IMPLIED
WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED IN DURATION TO
A PERIOD OF THE EXPRESSED WARRANTY AS PROVIDED HEREIN BEGINNING WITH THE DATE OF
ORIGINAL PURCHASE AT RETAIL AND NO WARRANTIES, WHETHER EXPRESSED OR IMPLIED,
SHALL APPLY TO THE P
RODUCT THEREAFTER. EMERSON MAKES NO WARRANTY AS TO THE
FITNESS OF THE PRODUCT FOR ANY PARTICULAR PURPOSE OR USE. THE EXTENT OF EMERSON
RADIO CORP’S LIABILITY UNDER THIS LIMITED WARRANTY IS THE REPAIR OR REPLACEMENT
PROVIDED ABOVE AND, IN NO EVENT, SHALL EMERSON RADIO CORP’S LIABILITY EXCEED THE
PURCHASE PRICE PAID BY THE PURCHASER OF THE PRODUCT. UNDER NO CIRCUMSTANCES
SHALL EMERSON RADIO CORP. BE LIABLE FOR ANY LOSS, DIRECT, INDIRECT, INCIDENTAL,
SPECIAL, OR CONSEQUENT
IAL DAMAGE ARISING OUT OF OR IN CONNECTION WITH THE USE OF
THIS PRODUCT. THIS WARRANTY IS VALID ONLY IN THE UNITED STATES OF AMERICA. THIS
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. HOWEVER, YOU MAY HAVE OTHER RIGHTS
WHICH MAY VARY FROM STATE TO STATE. SOME STATES DO NOT ALLOW LIMITATIONS ON
IMPLIED WARRANTIES OR EXCLUSION OF CONSEQUENTIAL DAMAGE, THEREFORE THESE
RESTRICTIONS MAY NOT APPLY TO YOU.
15-01-2410
The serial number can be found on the back cabinet. We suggest that yo
u record the serial number of your
unit in the space below for future reference.
Model Number: FAT2835
Serial Number:
S E R V I C E
FOR ADDITIONAL SET-UP OR OPERATING ASSISTANCE
PLEASE CALL
1-800-898-9020
FOR CUSTOMER SERVICE,PLEASE E-MAIL TO:
OR WRITE TO:
Emerson Radio Corp.
Consumer Affairs Dept.
959 Route 46 East
Suite 210,2nd Floor
Parsippany, NJ 07054
CALIFORNIA RESIDENTS ONLY-
WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
6
EN
Emerson Part No. FAT2835-20241005-01 Printed in China
EN
