30 Inch Tower Fan
Model COL1602
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
30 Inch Tower Fan
Model COL1602
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read this manual carefully
paying particular attention to the safety instructions. Failure
to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Tower Fan.
• Before plugging your unit into the mains, visually check that
the unit is intact and has not suffered any transit damage.
• DO NOT use this product with a programmer, timer,
separate remote-control system or any other device.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• Close supervision is required when using this appliance
near children.
• Never leave this appliance within reach of children.
• Children of less than 3 years should be kept away unless
continuously supervised.
3
30 Inch Tower Fan
Model COL1602
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• DO NOT immerse the appliance or its cord in water or any
other liquids.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected
to the mains supply.
• Always use this appliance on a solid, level, surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Repairs to electrical appliances should only be performed
by qualified personnel. Improper repairs may place user at
serious risk.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
• Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• If the power cable is damaged, it should only be replaced
by suitably qualified personnel in order to avoid a hazard.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• DO NOT run the mains cable under carpets, rugs, etc.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
the supplier.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects (including fingers) into the fan grill
or any openings as this could risk injury, damage to the
appliance and/or electric shock.
• Unplug after each use. Grasp the plug, not the cord.
4
30 Inch Tower Fan
Model COL1602
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable provisions
of the European Economic Area.
This Class 2 symbol indicates that the product is electrically double
insulated and does not require an earth connection.
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken
to a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
This symbol provides useful additional information on the use of
this product.
This symbol indicates that the supply uses an alternating
current mains supply.
Before first use of Your Tower Fan
Remove all packing materials and discard responsibly.
Ensure all parts are present - see Description of Parts below.
Check that there is no damage to the mains cable or product.
5
30 Inch Tower Fan
Model COL1602
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
1. Controls
2. Air Outlet
3. Air Inlet
4. Main Body
5. Stand
6. Speed/Oscillate Control
7. Timer Control (0-120 minutes)
Description of Parts
Assembling Your 30 Inch Tower Fan
The stand of the tower fan comes in two parts, which fit around the base
of the fan with the power cord exiting through the hole in the centre.
Both parts fit easily together. Before assembly, place a cloth or similar
underneath it to prevent damage to the outer casing.
1. Take the two halves of the Stand (5) and
thread the mains cable through the hole in
the stand as the halves are clipped together.
2. Left: Lay the left section of the Base (5)
over the right section and clip the two
halves together until the stand is
complete as shown above and left:
Note the mains cable threaded through
the Base (5).
6
7
1
2
3
4
5
6
30 Inch Tower Fan
Model COL1602
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3. Once the Stand (5) is assembled, position it
so that the mains cable is at the back of the
fan then push it onto to base of the fan until
all four clips click home.
As the stand is attached to the fan, guide the
mains cable through the cord guide keep the
cable firmly in place and prevent the power
cable twisting or being caught during use.
Setting Up Your Tower Fan
1. Place the fan into the desired position ensuring that it is on a solid, even surface
and vertical.
2. Ensure that the Timer Control (7) is set to the ‘ON’
position and the Speed/Oscillate Control (6) is set
to the ‘0’ position.
3. Insert the mains plug into the nearest socket.
Using Your Tower Fan
Fan Speeds
The fan has three speeds:
Speed 1 - Low Speed
Speed 2 - Medium Speed
Speed 3 - High Speed
Fan Only Mode
For Fan only mode, rotate the Speed/Oscillation
Control (6) anticlockwise to the desired speed on the
LEFT-HAND side of the control. The fan will start
blowing air in stationary mode.
Fan and Oscillation Mode
For Fan and Oscillation mode, rotate the
Speed/Oscillation Control (6) clockwise to the
desired speed on the RIGHT-HAND side of the
control. The fan will start blowing air and oscillate
from side to side.
Back of the
Fan
7
30 Inch Tower Fan
Model COL1602
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Switching the Fan Off
Rotate the Speed/Oscillation Control (6) to the ‘0’
position (either at the top or bottom) to switch the
fan off.
Using the Timer (7)
• Rotate the Timer Control (7) clockwise to the
desired number of minutes that the fan is
required to be on for. Once the Timer Control
(7) has returned to the ‘OFF’ position, the fan
will switch off.
The Timer Control (7) can be set up to a maximum of 2 hours.
For normal fan operation, ensure that the Timer Control (7) is set to the ‘ON’
position.
Care and Maintenance of Your Tower Fan
• Ensure that the fan is not connected to the mains supply
before cleaning.
• Wipe the fan body clean with a clean, soft damp cloth.
• Do not immerse the fan or its cord in water or any other
liquid.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). If in doubt, consult a qualified
electrician. Do not use a plug with the fuse cover missing.
If you need to remove the plug – DISCONNECT FROM THE MAINS – and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Technical Specification
Model Number
COL1602
Rated Voltage
220 – 240V AC ~ 50Hz
Rated Power
50W
Protection Class
II
8
30 Inch Tower Fan
Model COL1602
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken
to a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
9
30 Inch Tower Fan
Model COL1602
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
10
30 Inch Tower Fan
Model COL1602
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo Steam Mop.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty vacuum should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
