USER MANUAL
WORK
SPEAKER
THE
AUX-OUT MODE
USB MODE
LIMITED WARRANTY
Welcome to your new Raycon Work Speaker!
We are Raycon. We create carefully crafted wireless audio products for
go-getters who need tech that keeps up with them. We teamed up with
expert engineers, leading taste-makers, and platinum artists to design
products you’ll love to use
We believe in the early risers and the one-more-milers of the world.
Premium audio, inspired by you.
Before using your product, we strongly encourage you to fully read
through this user guide. You can also visit our support center at
www.rayconglobal.com/support. This web page has more specific
guidelines and helpful videos for you to navigate your product. For best
performance, charge fully before first use.
Pairing ID:
For international versions of the manual, please visit
1. Power On/Off/Play/Pause
2. Audio Source Switch
3. Volume Down/Previous
4. Answer/End Call/Sound Profiles
5. Volume Up/Next
6. Mute
7. AUX Out Port/Reset Button
8. Charging Port
CONTROL PANAL TOP VIEW
Press
Connect your Work Speaker to an external speaker with AUX Mode. The
speaker will automatically switch to AUX Mode when a compatible device
is connected using the audio cable.
While speaker is in AUX Mode, the speaker will be muted automatically,
and all sound will go through the connected external speaker.
Disconnect audio cable to exit AUX Mode.
Hold “ ” and “ ” for 2 seconds to turn off/on the LED lights.
Your sound, your way! As our sound profiles were crafted by artists and
producers at the top of the industry, you’re in good hands.
• Be wary of any edges, uneven surfaces, and metal parts, including on
accessories and product packaging, to prevent any possible injury or
damage.
• Listen to music at a proper volume to avoid damaging your hearing
and speaker.
• Do not store in high temperatures, such as in a hot vehicle or in
direct sunlight.
• Store in cool and dry area.
• Do not drop or cause undue impact to the speaker.
• Do not modify, repair, or dismantle the product on your own.
• Do not expose speaker and any of its supplied parts to liquid such as
rain for prolonged periods of time. Please see IPX-Rating for more
guidelines.
• Do not expose the speaker to water while charging, as doing so may
result in damage to the speaker or the power source.
• When cleaning this speaker, use a soft dry cloth. For more severe
stains, dampen the cloth with water only. Anything else increases the
chance of dissolving the paint or damaging the plastic.
If the speaker does not turn off or
respond, the speaker can be reset
by inserting a small round pin into
the Aux Port to press the button
inside. Please be gentle when
inserting pin.
Model Number: RBS980
RDID: D980-21E-Q321
Bluetooth Version: V5.0
Speaker Size: 3.5 inch x 2
Power Output: 3W, 4Ω
Dimension: 390 x 137 x 175mm
Bluetooth Pairing Name: The Work
Speaker
Battery Capacity: 3.7V, 2600mAh
Play time: 8 Hours
Frequency Response: 80Hz-12kHz
Bluetooth Range: Up to 10 Meters
If your device is not functioning correctly, please visit
for customer support, and we will be
more than happy to help you.
Visit:
Visit:
Our most refined
sound, perfect clarity
to hear every single
note.
A leveled sound that is
great for all around
performance and clarity.
Our bass boosted
sound, great for songs
with strong beats and
a go-to for bass lovers.
1. Using the supplied USB Cable, connect
the speaker to your PC.
2. The speaker will switch to USB Mode
automatically. If not, press “ ” to
toggle to USB Mode.
3. When connected successfully, the LED
light will be blue. Enjoy your Raycon
Work Speaker with USB Mode!
4. If no sound is coming from the speaker,
go to your computer’s audio settings and
ensure “The Work Speaker” is selected as
the input and output device.
A great idea can come from anywhere in the room, that’s why
the Work Speaker features an omnidirectional mic setup.
Nothing derails a conversation like “excuse me, can you repeat
that?” So we designed the Work Speaker with Smart Voice
Enhancement.
The Work Speaker has a Voice Direction Indicator, so you know
exactly where everyone is coming from.
The Work Speaker works hard and works smart with convenient
controls and a mute button.
Control what you hear with Three Unique Sound Profiles.
With 8 hours of playtime, the Work Speaker is with you until the
job is done.
Hold for 1.5 Sec
Press
Hold for 1.5 Sec
Press
Hold for 1.5 Sec
Hold for 1.5 Sec
Press
Press
Press 2 Times
Hold for 1.5 sec
Sound Profiles
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Any changes or
modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This equipment has been tested and found
to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference
to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help. The
device has been evaluated
to meet general RF exposure statement.
The device can be used in portable exposure condition without restriction.
Radio Standards Specification RSS-Gen, issue 5
- English:
This device contains licence-exempt transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic Development Canada’s
licence-exempt RSS(s). Operation is subject
to the following two conditions:
This device may not cause interference.
This device must accept any interference, including interference that may
cause undesired operation of the device.
- French:
Cet appareil contient des émetteurs / récepteurs exemptés de licence
conformes aux RSS (RSS) d'Innovation, Sciences et Développement
économique Canada. Le fonctionnement est soumis aux deux conditions
suivantes:
Cet appareil ne doit pas causer d'interférences.
Cet appareil doit accepter toutes les interférences, y compris celles
susceptibles de provoquer un fonctionnement indésirable de l'appareil.
v
1. Use a standard , or t harge this
devi e.
. While harging, the blue LED indicator will stay on. After fully harging,
the LED indicator will turn off. Charge ti e should be 2 hours.
3. Enjoy your Raycon Work Speaker!
2. From the source device, go to Bluetooth settings and ensure Bluetooth is
on. Search for “The Work Speaker" and select it to pair.
1. Hold “ ” for about 3 seconds to power on. The Speaker will enter
pairing mode automatically.
