Stroller Tricycle
TQ10062
USER’S MANUAL
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
US:cs.us@costway.com
UK:cs.uk@costway.com
US office: Fontana UK office: Ipswich AU office: Truganina
Before You Start
General Warnings:
Danger! Keep all small parts and packaging materials for this product away from
babies and children, otherwise they may pose a choking hazard.
The product must be installed and used under the supervision of an adult.
Read through each step carefully and follow the proper order.
Remove all Packaging, separate and count all parts and hardware before
installation.
Please ensure that all parts are correctly installed, incorrect installation can lead to
a danger.
We recommend that, where possible, all items are assembled near the area in
which they will be placed in use, to avoid moving the product unnecessarily once
assembled.
Ensure a secure surface during installation, and place the product always on a flat,
steady and stable surface.
Please read all instructions carefully and keep it for future reference.
Picture for reference only. Please refer to the actual product.
The product should be assembled only by Adults
Feature
Suitable Age: 1.5-5 years old
Weight Capacity: 55 lbs
● Folding design. Compact size. More convenient to carry.
● “One Key” quick disassembly of rear wheels.
● Detachable awning with multi adjustable positions to avoid UV.
● Integrated backrest & Three-point safety harness for protection.
● Three using modes for different ages, accompanying children to grow up
Please read the manual before using this product, it will tell you the correct
operation method and installation steps. To avoid damage to the product or
injury to your child due to improper handling. This manual should be properly
kept and easily accessible.
02 03
Before You Start
General Warnings:
Danger! Keep all small parts and packaging materials for this product away from
babies and children, otherwise they may pose a choking hazard.
The product must be installed and used under the supervision of an adult.
Read through each step carefully and follow the proper order.
Remove all Packaging, separate and count all parts and hardware before
installation.
Please ensure that all parts are correctly installed, incorrect installation can lead to
a danger.
We recommend that, where possible, all items are assembled near the area in
which they will be placed in use, to avoid moving the product unnecessarily once
assembled.
Ensure a secure surface during installation, and place the product always on a flat,
steady and stable surface.
Please read all instructions carefully and keep it for future reference.
Picture for reference only. Please refer to the actual product.
The product should be assembled only by Adults
Feature
Suitable Age: 1.5-5 years old
Weight Capacity: 55 lbs
● Folding design. Compact size. More convenient to carry.
● “One Key” quick disassembly of rear wheels.
● Detachable awning with multi adjustable positions to avoid UV.
● Integrated backrest & Three-point safety harness for protection.
● Three using modes for different ages, accompanying children to grow up
Please read the manual before using this product, it will tell you the correct
operation method and installation steps. To avoid damage to the product or
injury to your child due to improper handling. This manual should be properly
kept and easily accessible.
02 03
Parts List Assembly Instruction
Part Description Qty.
Music box
Handlebar cover
Handlebar
Head tube cover
Front tube
Bowl-shaped cover
Front fork
Front wheel
Footrest
Lower connecting tube
Upper connecting tube
Brake
Rear wheel
Rear frame
Rear frame cover
Rear push rod
Rear push handlebar
Canopy
Backrest cushion
Backrest
Guardrail
Safety belt
Saddle
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
1
1
1
1
1
1
1
1
2
1
1
2
2
1
1
1
1
1
1
1
2
1
1
Battery cover
1.Remove all the packaging of the
main body as shown in the picture.
2.Install 1.5V*3 battery on the music
box and fix the battery cover, as
shown in the picture. Then install the
front music box on the handlebar
and tighten it with 4 tapping screws
of ST3.5 *15.
3.Open the guardrail as shown in the
picture.
4.Lift the main frame body back and
open it as shown in the picture.
04 05
Parts List Assembly Instruction
Part Description Qty.
Music box
Handlebar cover
Handlebar
Head tube cover
Front tube
Bowl-shaped cover
Front fork
Front wheel
Footrest
Lower connecting tube
Upper connecting tube
Brake
Rear wheel
Rear frame
Rear frame cover
Rear push rod
Rear push handlebar
Canopy
Backrest cushion
Backrest
Guardrail
Safety belt
Saddle
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
1
1
1
1
1
1
1
1
2
1
1
2
2
1
1
1
1
1
1
1
2
1
1
Battery cover
1.Remove all the packaging of the
main body as shown in the picture.
2.Install 1.5V*3 battery on the music
box and fix the battery cover, as
shown in the picture. Then install the
front music box on the handlebar
and tighten it with 4 tapping screws
of ST3.5 *15.
3.Open the guardrail as shown in the
picture.
4.Lift the main frame body back and
open it as shown in the picture.
04 05
Instructions for Use
9.Install the rear push rod on the
rear frame as shown (until you hear
“Click” sound!) The rear push rod
can be adjusted with three positions.
10.Install the canopy on the backrest
as shown in the picture.
Click!
Left
Right
Click!
Click!
5.Open the rear frame as shown in
the picture.
6.Lock the guardrail as shown in the
picture.
7.Attach the rear wheels to the rear
frame as shown. Press it until you
hear “Click” sound!
8.Unfold the footrest as shown in the
picture. Press the folding switch of
the footrest and gently pull the
footrest down to the maximum angle
(until you hear “Click” sound). Then
unfold the footrest on both sides.
Click!
Click!
1.Infant Tricycle: Suitable for
toddlers over 18 months.
2.Learn-to-Ride Tricycle: Suitable for
toddlers over 24 months.
06 07
Instructions for Use
9.Install the rear push rod on the
rear frame as shown (until you hear
“Click” sound!) The rear push rod
can be adjusted with three positions.
10.Install the canopy on the backrest
as shown in the picture.
Click!
Left
Right
Click!
Click!
5.Open the rear frame as shown in
the picture.
6.Lock the guardrail as shown in the
picture.
7.Attach the rear wheels to the rear
frame as shown. Press it until you
hear “Click” sound!
8.Unfold the footrest as shown in the
picture. Press the folding switch of
the footrest and gently pull the
footrest down to the maximum angle
(until you hear “Click” sound). Then
unfold the footrest on both sides.
Click!
Click!
1.Infant Tricycle: Suitable for
toddlers over 18 months.
2.Learn-to-Ride Tricycle: Suitable for
toddlers over 24 months.
06 07
Folding Instruction
7.The opening width and installation
angle of canopy can be adjusted
according to your needs.
3.Classic Tricycle: Suitable for
toddlers between 36-60 months.
4.Insert 3*1.5V AA batteries (not
included) into the music box, and the
battery installation must be done by
an adult.
6.The footrest can be folded and
stored away according to different
age of children’s needs.
1.5V AA
1.5V AA
1.5V AA
5.Two modes of front wheel clutch
mechanism:
A: Set the front wheel locking device
to , and the pedals will rotate
when pushing.
B: Set the front wheel locking device
to , and the pedals will not rotate
when pushing.
2.Press the folding button to fold the
rear frame forward and up (until you
hear “Click” sound).
3.Pull the main frame body forward
close to the direction of front wheel.
1.Open the guardrail as shown in the
picture.
Folding button
08 09
Folding Instruction
7.The opening width and installation
angle of canopy can be adjusted
according to your needs.
3.Classic Tricycle: Suitable for
toddlers between 36-60 months.
4.Insert 3*1.5V AA batteries (not
included) into the music box, and the
battery installation must be done by
an adult.
6.The footrest can be folded and
stored away according to different
age of children’s needs.
1.5V AA
1.5V AA
1.5V AA
5.Two modes of front wheel clutch
mechanism:
A: Set the front wheel locking device
to , and the pedals will rotate
when pushing.
B: Set the front wheel locking device
to , and the pedals will not rotate
when pushing.
2.Press the folding button to fold the
rear frame forward and up (until you
hear “Click” sound).
3.Pull the main frame body forward
close to the direction of front wheel.
1.Open the guardrail as shown in the
picture.
Folding button
08 09
4.Lock the guardrail as shown in the
picture.
5.Fold the canopy downwards.
6.Adjust the rear push rod to the
minimum height.
5. When using the brake, push the tricycle back and forth to make sure that the
brake is stopped;
6. To avoid suffocation, please keep the plastic covering (plastic bag) away from
the baby;
7. Do not place any load on the vehicle, otherwise it will affect the stability of
the vehicle;
8. Make sure that all locking devices are locked before using the stroller tricycle;
9. It is forbidden to use the stroller tricycle near stairs, thresholds, steps, or to
play near heaters, stoves, etc., or to use it as a means of transportation in
downtown areas or highways.
10. The stroller tricycle must be used in a flat and unobstructed place to ensure
that it does not tilt during normal use to avoid injury;
11. The limit time for children to ride the stroller tricycle continuously for each
time shall not exceed 1 hour. The maximum carrying capacity of the stroller is
55 lbs and the maximum carrying capacity of the carrying bag is 2.2 lbs.
Overloading is strictly prohibited, and only for one baby to use alone.
12. Please read this manual carefully before use and keep it for future reference.
If it is not used in accordance with this manual, it may affect the safety of
children.
1. When cleaning the tricycle body, please wipe it directly with a dry cloth;
2. Regularly add fixed lubricant to the corresponding positions of the
transmission components, such as front and rear axles, handlebar shafts,
etc., to improve the service life of the product;
3. Regularly check whether there are loose screws and damaged parts. If
necessary, please replace the corresponding damaged parts;
4. When disassembling and assembling, please follow the instructions carefully
to avoid unnecessary damage.
5. Regularly check whether the bolts at the joints of the handlebars and saddles
are tight.
1. This product must be assembled by an adult; when a child is riding, the
guardian must not leave;
2. Please carefully check whether the parts are connected well before the child
uses the stroller;
3. This stroller is suitable for children aged 1.5-5 years old;
4. Keep away from fire: battery installation must be done by an adult;
Cleaning and Maintenance
To avoid accidental injury to your child, please check and maintain the
tricycle frequently:
Warning
10 11
4.Lock the guardrail as shown in the
picture.
5.Fold the canopy downwards.
6.Adjust the rear push rod to the
minimum height.
5. When using the brake, push the tricycle back and forth to make sure that the
brake is stopped;
6. To avoid suffocation, please keep the plastic covering (plastic bag) away from
the baby;
7. Do not place any load on the vehicle, otherwise it will affect the stability of
the vehicle;
8. Make sure that all locking devices are locked before using the stroller tricycle;
9. It is forbidden to use the stroller tricycle near stairs, thresholds, steps, or to
play near heaters, stoves, etc., or to use it as a means of transportation in
downtown areas or highways.
10. The stroller tricycle must be used in a flat and unobstructed place to ensure
that it does not tilt during normal use to avoid injury;
11. The limit time for children to ride the stroller tricycle continuously for each
time shall not exceed 1 hour. The maximum carrying capacity of the stroller is
55 lbs and the maximum carrying capacity of the carrying bag is 2.2 lbs.
Overloading is strictly prohibited, and only for one baby to use alone.
12. Please read this manual carefully before use and keep it for future reference.
If it is not used in accordance with this manual, it may affect the safety of
children.
1. When cleaning the tricycle body, please wipe it directly with a dry cloth;
2. Regularly add fixed lubricant to the corresponding positions of the
transmission components, such as front and rear axles, handlebar shafts,
etc., to improve the service life of the product;
3. Regularly check whether there are loose screws and damaged parts. If
necessary, please replace the corresponding damaged parts;
4. When disassembling and assembling, please follow the instructions carefully
to avoid unnecessary damage.
5. Regularly check whether the bolts at the joints of the handlebars and saddles
are tight.
1. This product must be assembled by an adult; when a child is riding, the
guardian must not leave;
2. Please carefully check whether the parts are connected well before the child
uses the stroller;
3. This stroller is suitable for children aged 1.5-5 years old;
4. Keep away from fire: battery installation must be done by an adult;
Cleaning and Maintenance
To avoid accidental injury to your child, please check and maintain the
tricycle frequently:
Warning
10 11
Please give us a chance to make it right and do better !
Contact our friendly customer service department for help first.
Replacements for missing or damaged parts will be shipped ASAP !
Contact Us !
Do NOT return this item.
Stroller Tricycle
TQ10062
USER’S MANUAL
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
US:cs.us@costway.com
UK:cs.uk@costway.com
US office: Fontana UK office: Ipswich AU office: Truganina
