1
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should always
be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Coffee Maker.
• Before plugging your coffee maker into the mains, visually
check that it is intact and has not suffered any transit
damage.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• Close supervision is required when using this appliance
near children.
• Never leave this appliance within reach of children.
• This appliance can be used by children aged from 8 years
and above if they have been given supervision or
instruction concerning use if the appliance in a safe way
and if they understand the hazards involved. Cleaning and
user maintenance shall not be made by children unless
they are older than 8 and supervised. Keep the appliance
and its cord out of reach of children aged less than 8
years. This appliance can be used by persons with
reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
3
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Children shall not play with the appliance.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected
to the mains supply.
• Always use this appliance on a solid, level, non-flammable
surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• If the supply cord is damaged, it must be replaced by the
manufacturer, service agent or similarly qualified person
in order to avoid hazard.
• Repairs to electrical appliances should only be performed
by qualified personnel. Improper repairs may place user at
serious risk.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
• Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• DO NOT run the mains cable under carpets, rugs, etc.
• Allow the unit to cool before storage.
• Never place the appliance near to flammable material or
high-pressure containers.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
4
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• DO NOT immerse the appliance, base or its cord in water
or any other liquids.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Ensure appliance is situated in an open area, do not allow
it to come in contact with cupboards, curtains, wall
coverings, clothing or other flammable materials.
• Unplug after each use. Grasp the plug, not the cord.
• DO NOT cover this appliance.
• Never place this appliance on an electric, gas, or any other
type of hob.
• WARNING: DO NOT remove the filter holder whilst the
water is boiling.
• Never fill the coffee maker more than its capacity – ensure
the water level is between the min and max marks on the
water tank. If the coffee maker is overfilled, boiling water
may be ejected.
• Always close the tank lid during use and do not open the
lid or remove the filter holder whilst the water is boiling.
• CAUTION: The outside surface of the coffee maker will
get hot during use.
THIS APPLIANCE MUST BE EARTHED
5
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
ADDITIONAL SAFETY INFORMATION
• This appliance is intended for use in domestic households only,
it must not be used for commercial use.
• Hot liquid or steam is emitted from the brewing head and
steam nozzle during operation.
• Do not cover the espresso maker.
• Allow to the espresso maker to cool fully before storing.
• The surfaces of the filter holder and steam nozzle will become
hot during use. Do not touch – always use the handle.
• Ensure that the espresso machine is used in an open, well-
ventilated area well away from other appliances and not near
or under surfaces that are heat sensitive or those that may be
damaged by steam.
• Only use this espresso maker with the accessories provided.
This appliance can cause personal injury if misused.
• DO NOT place anything on top of the appliance.
• Ensure that the water level in the water tank does not exceed
the MAX mark whilst filling and that it does not drop below
the MIN mark during use.
6
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
WARNING!
This designates a hazard with moderate risk, which may result
in severe injury or damage to the product if not adhered to.
7
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
1. Power/Single Cup Button
2. Brewing Head
3. Filter Holder
4. Coffee Nozzle
5. Drip Tray Full Indicator
6. Digital Display
7. Double Cup Button
8. Steam Warm-up Button
9. Steam Nozzle
10. Filter Holder Handle
11. Steam Control
12. Water Tank Lid
13. Water Tank
14. Non-slip Feet
15. Drip Tray
10
12
4
9
7
6
14
5
1
2
3
8
11
13
14
16
10
17
18
15
16. Serving Spoon
17. Double Cup Filter
18. Single Cup Filter
19. Stainless Steel Jug
Accessories
3
19
8
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of the Digital Display (6)
1. The Digital Display (6) will show the pattern left
flashing from top to bottom whilst the espresso maker is preheating.
2. After preheating the Digital Display (6) will show the working
temperature for making coffee.
3. After preheating, the Digital Display (6) will show the working
temperature of the steam.
4. Whilst dispensing coffee or steam, the Digital Display (6) will show
the time taken in seconds.
Before first Use of Your Espresso Maker
Please read these operating instructions thoroughly and keep them in a safe place
for future reference.
IMPORTANT in hard water areas it is highly recommended to use demineralised or
filtered water to avoid calcium build up which will prolong the life and prevent
damage to the machine.
Temperature and Time Display
Working Temperature (⁰C)
Working Time (Seconds)
9
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Remove the Water Tank (13) from the Espresso Maker by lifting it up and then
remove the red silicone tab from the water outlet as shown below:
Cleaning Your Espresso Maker before First Use
1. Place the Espresso Maker on a solid, level, heat resistant surface clear of all
obstructions as described above.
2. Refit and fill the Water Tank (13) with water up to the MAX line, install the Filter
to be used (17 or 18) into the Filter Holder (3).
Do not put any coffee in the filter at this stage.
3. Place one hand on the top of the espresso maker to
support the unit and attach the Filter Holder (3) using the
Filter Holder Handle (10) by holding the handle and placing
it in the position then rotating right to the locked
position as shown right:
4. Place a coffee cup on the Drip Tray (15) and align it with the Coffee Nozzle (4).
5. Insert the Mains plug into the nearest socket.
6. Press the Power/Single Cup Button (1) once.
7. The Power/Single Cup Button (1) and the Double Cup Buttons (7)
indicators will flash and the Digital Display (6) will show three dashes (see above
Description of Digital Display) whilst the espresso maker preheats.
Remove the Red Silicone Tab
Water Tank (13)
10
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
8. Once preheated the buttons will light constantly and Digital Display (6) will
show the water temperature (92⁰C).
9. Ensure the Steam Nozzle (9) is positioned over the Drip Tray (15).
10. Rotate the Steam Control (11) anticlockwise to the maximum position, the
internal pump will be heard running and hot water will be emitted from the
Steam Nozzle (9). After 30 seconds return the Steam Control (11) fully clockwise
to the off position.
NB the Power/Single Cup Button (1) and the Double Cup Buttons (7) will
pulsate whilst hot water is emitted from the Steam Nozzle (9).
11. Finally, press the Double Cup Button (7) - hot water will now wash the
Coffee Filter (17 or 18 whichever is fitted) and the Filter Holder (3) into
the cup on the Drip Tray (15). Repeat the final step above for the other
coffee filter.
12. The Espresso maker is now cleaned and ready to use.
Using Your Espresso Maker
1. Place the Espresso Maker on a solid, level, heat resistant surface clear of all
obstructions as described above.
2. Insert the Mains plug into the nearest socket.
Filling the Water Tank (13)
1. Remove the Water Tank Lid (12) and fill the
Water Tank (13) to the MAX mark.
2. DO NOT fill the tank above the MAX mark. Lift
the tank up and place it back onto the unit as
shown right:
Making Two Espresso Coffees
1. Press the Power/Single Cup Button (1) once.
The Power/Single Cup Button (1) and the
Double Cup Buttons (7) indicators will flash
and the Digital Display (6) will show three
dashes (see above) whilst the espresso maker
preheats.
2. Once the Power/Single Cup Button (1) and the Double Cup Button (7)
indicators light continuously, the unit is now preheated and the Digital Display
(6) will show the water temperature (92⁰C).
11
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3. Remove the Filter Holder (3) using the Filter Holder Handle (10).
4. Insert the Double Cup Filter (17) and fill with coffee using the Serving Spoon
(16).
5. Use the bottom of the spoon to evenly press the coffee powder tightly, remove
any excess coffee powder from the edge of the filter so the coffee sits about
3mm from the top edge of the filter.
NB Too much coffee in the filter will result in a poor seal and leakage.
6. Once the coffee is in the filter, place one hand on the top
of the Espresso Maker to support the unit and attach the
Filter Holder (3) using the Filter Holder Handle (10) by
holding the handle and placing it in the position then
rotating right to the locked position as shown right:
7. Left: Place two cups onto the Drip Tray as
shown and align them with the Coffee
Nozzle (4).
8. Press the Double Cup Button (7) the indicator light will pulsate and the
machine will start to make espresso coffee. The Digital Display (6) will also
countdown from 32 seconds.
9. Once the indicator light has gone out and the Digital Display (6) has returned
to 92⁰C, the coffee is made and the espresso coffees are ready to serve.
10. After making the coffee, remove the Filter Holder (3) and remove the filter.
Wash both the filter and holder clean in hot water and dry thoroughly.
11. Press the Power/Single Cup Button (1) or the Double Cup Button (7) to
flush the espresso maker clean.
12. Replace the filter and Filter Holder (3) ready for making the next cups of coffee.
12
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Making a Single Espresso Coffee
1. Making one espresso coffee is the same as making two above except the Single
Cup Filter (18) is inserted into the Filter Holder (3).
2. Press the Power/Single Cup Button (1) the indicator light will pulsate and
the machine will start to make espresso coffee. The Digital Display (6) will also
countdown from 18 seconds.
3. Once the indicator light has gone out and the Digital Display (6) has returned
to 92⁰C, the coffee is made and the espresso coffee is ready to serve.
4. Right: Place one cup onto the Drip Tray (15)
when making a single cup of coffee.
5. After making the coffee, remove the Filter Holder (3) and remove the filter.
Wash the filter and holder clean in hot water and dry thoroughly.
6. Press the Power/Single Cup Button (1) or the Double Cup Button (7) to
flush the espresso maker clean.
7. Replace the filter and Filter Holder (3) ready for making the next cups of coffee.
Making a Cappuccino Coffee
1. Prepare an Expresso Coffee as above
but use a larger cup.
2. Fill the Jug (19) with cold milk (4-8⁰C) to
1/3 full.
3. Press the Press the Power/Single Cup
Button (1) once.
4. After the and indicators stop
flashing, press the Steam Warm-Up
Button (8) which will flash whilst the
water is heated for steam.
5. Once button has stopped flashing, the
Digital Display (6) will show 130⁰C
showing that the steam is ready.
13
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
6. Place the Steam Nozzle (9) into the milk just below the surface.
7. Rotate the Steam Control (11) anticlockwise to the maximum position to froth
the milk.
8. Return the Steam Control (11) fully clockwise to the minimum position once the
desired amount of frothed milk has been achieved.
9. Pour the frothed milk into the prepared Expresso Coffee to create the
Cappuccino Coffee.
NB the Digital Display (6) will count in seconds and the indicator will pulse
whilst the Steam Control (11) is open.
Making Hot Water
The hot water function can be used to preheat cups, jugs, etc. prior to making the
coffee.
1. Place a cup under the Steam Nozzle (9), press the Power/Single Cup Button (1)
once.
2. After the and indicators have stopped flashing, the Digital Display (6)
will show 92⁰C showing that the hot water is ready.
3. Rotate the Steam Control (11) anticlockwise to the maximum position, the
internal pump will be heard running and hot water will be dispensed out of the
Steam Nozzle (9).
4. Return the Steam Control (11) clockwise to the minimum position once enough
hot water has been dispensed.
NB the Digital Display (6) will count in seconds and the and indicators will
pulse whilst the Steam Control (11) is open.
Notes on Coffee
This Espresso Maker uses ground powdered coffee which is available from most
good supermarkets and coffee retailers.
Do not use instant coffee or similar with this Espresso Maker.
Distance to the surface of pressed coffee powder should be about 3mm away from
the edge of the filter cup (important indicator). Too high or too low will affect the
extraction pressure and effect of coffee. Reduce or increase the amount of coffee
powder accordingly:
14
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Drip Tray Full Indicator (5)
Right: If the Drip Tray Full Indicator (5) rises
through the Drip Tray (15) as shown right,
the drip tray compartment will require
emptying.
Cleaning and Maintenance
• Always unplug the Espresso Maker from the mains
supply and allow to cool before cleaning.
• Do not immerse the Espresso Maker in water or
any other liquids.
• Wipe the body of the Espresso Maker clean with a
clean damp cloth.
• Do not use harsh or abrasive, powders or cleaners.
• Do not clean any part of the Espresso Maker in a dishwasher.
• Remove the Filter Holder (3) and remove the filter. Wash the filter and holder
clean in hot water and dry thoroughly.
• Press the Power/Single Cup Button (1) or the Double Cup Button (7) to
flush the espresso maker clean.
• Rinse the Water Tank (13) clean, dry thoroughly and replace onto the machine.
• Hand wash the glasses in warm soapy water, rinse and dry thoroughly. The
glasses and not dishwasher safe.
Removing Mineral (Calcium) deposits
1. To ensure the normal use of the coffee machine, the internal water channels
need to be descaled, cleaned after 2-3 months of use.
2. Pour water and descaling agent into the water tank up to MAX capacity (water
and descaling agent ratio is 4:1 or follow the instructions with the descaling
agent). Citric acid can be used instead of the descaling agent in a water and citric
acid ratio of 100:3.
3. Press the button, wait for the and indicator lights to stay on, press
the button, as to make a double cup of coffee (no powder).
4. Rotate the Steam Control (11) fully anticlockwise for 2 minutes (measured on
the Digital Display (6)) of hot water from the Steam Nozzle (9) then turn the
Steam Control (11) off to allow the descaling agent to stay in the machine for at
least 15 minutes.
5. Repeat steps 3 & 4 for 3 more times.
15
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Indicator Light Tips
Power/Single
Cup button
indicator
Double
Cup
button
indicator
Steam
Indicator
Possible
Cause
Possible Solution
flashing
flashing
off
Coffee and
hot water are
preheating
N/A
on
on
off
Coffee and
hot water
preheating
finished
N/A
pulsating
off
off
Single cup
coffee or
water making
N/A
off
pulsating
off
Double cup
coffee making
N/A
off
off
flashing
Steam is
preheating
N/A
off
off
on
Steam
preheating
finished
N/A
off
off
pulsating
Steam making
N/A
off
off
on
Steam
finished
N/A
flashing
quickly
flashing
quickly
flashing
quickly
Temperature
sensor short
circuit or
open circuit
N/A
flashing
quickly
flashing
quickly
off
The
temperature
is too high
after making
the steam
Wait for the
temperature to
naturally fall or open
steam control to
allow hot water to
quickly cool
off
off
off
Switched off
Switch on
Thermal fuse
is open circuit
N/A
16
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Digital Display Error Codes
Display Showing
Possible Cause
Possible Solution
Steam Control is open and
the steam indicator light
flashing quickly
Rotate the Steam Control
fully clockwise to turn it off
Faulty steam control
N/A
Coffee temperature is too
high
Allow time for the machine
to cool
Unit has failed
N/A
Troubleshooting
Problem
Possible Cause
Possible Solution
Little or no water
coming out
Water tank is empty
Fill the water tank
Machine is blocked with
Calcium deposits
See Removing Mineral
(Calcium) deposits.
No steam being
produced
Steam pipe nozzle
blockage
Clean steam nozzle
Water tank is empty
Fill the water tank
Coffee runs out
around the edge of
the filter holder
Too much powder in the
filter
Clean the Filter and Filter
Holder, dry and put fresh
powder in.
Coffee powder residue on
the sealing ring of the filter
holder
Coffee comes out
too slow or not at
all
Coffee powder is too fine
and the filter is clogged
Clean the Filter, dry and put
fresh powder in.
Filter holes are blocked
Clean the Filter, dry and put
fresh powder in.
Water tank is not inserted
Insert water tank
Water leakage on
the bottom of
machine
Drip tray is full
Empty the Drip Tray
The steam cannot
froth.
Steam indicator not
flashing
Wait for the steam
indicator to flash.
The container is too large
Use a tall narrow cup
Skimmed milk been used
Use whole milk
17
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Technical Specification
Rated Voltage
220-240V~ 50/60Hz
Rated Power
1230-1465W
Model Number
SDA2700
Protection Class
I (This Appliance Must Be Earthed)
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug -DISCONNECT FROM THE MAINS- and then cut it off
the mains lead and immediately dispose of it safely. Never attempt to reuse the
plug or insert it into a socket outlet as there is a danger of electric shock.
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and sent to landfill. Please ensure it is taken to a
suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
18
Barista Espresso Maker
Model No. SDA2700
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
