1
Espresso Maker with Steam Wand
Model No. SDA2756
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
Espresso Maker with Steam Wand
Model No. SDA2756
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should always
be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Coffee Maker.
• Before plugging your coffee maker into the mains, visually
check that it is intact and has not suffered any transit
damage.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• Close supervision is required when using this appliance
near children.
• Never leave this appliance within reach of children.
• This appliance can be used by children aged from 8 years
and above if they have been given supervision or
instruction concerning use if the appliance in a safe way
and if they understand the hazards involved. Cleaning and
user maintenance shall not be made by children unless
they are older than 8 and supervised. Keep the appliance
and its cord out of reach of children aged less than 8
years. This appliance can be used by persons with
reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
3
Espresso Maker with Steam Wand
Model No. SDA2756
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Children shall not play with the appliance.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected
to the mains supply.
• Always use this appliance on a solid, level, non-flammable
surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• If the supply cord is damaged, it must be replaced by the
manufacturer, service agent or similarly qualified person
in order to avoid hazard.
• Repairs to electrical appliances should only be performed
by qualified personnel. Improper repairs may place user at
serious risk.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
• Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• DO NOT allow the mains cable to hang over sharp edges
or come into contact with hot surfaces.
• DO NOT run the mains cable under carpets, rugs, etc.
• Allow the unit to cool before storage.
• Never place the appliance near to flammable material or
high-pressure containers.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
4
Espresso Maker with Steam Wand
Model No. SDA2756
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• DO NOT immerse the appliance, base or its cord in water
or any other liquids.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Ensure appliance is situated in an open area, do not allow
it to come into contact with cupboards, curtains, wall
coverings, clothing or other flammable materials.
• Unplug after each use. Grasp the plug, not the cord.
• DO NOT cover this appliance.
• Never place this appliance on an electric, gas, or any other
type of hob.
• WARNING: DO NOT remove the filter holder whilst the
water is boiling.
• Never fill the coffee maker more than its capacity – ensure
the water level is between the min and max marks on the
water tank. If the coffee maker is overfilled, boiling water
may be ejected.
• Always close the tank lid during use and do not open the
lid or remove the filter holder whilst the water is boiling.
• CAUTION: The outside surface of the coffee maker will
get hot during use.
• WARNING: The filling aperture must not be opened during
use.
THIS APPLIANCE MUST BE EARTHED
5
Espresso Maker with Steam Wand
Model No. SDA2756
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
ADDITIONAL SAFETY INFORMATION
• This appliance is intended for use in domestic households only,
it must not be used for commercial use.
• Hot liquid or steam is emitted from the brewing head and
steam nozzle during operation.
• Do not cover the Espresso Maker.
• Allow to the Espresso Maker to cool fully before storing.
• The surfaces of the filter holder and steam nozzle will become
hot during use. Do not touch – always use the handle.
• Ensure that the Espresso Machine is used in an open, well-
ventilated area well away from other appliances and not near
or under surfaces that are heat sensitive or those that may be
damaged by steam.
• Only use this Espresso Maker with the accessories provided.
This appliance can cause personal injury if misused.
• DO NOT place anything on top of the appliance.
• Ensure that the water level in the water tank does not exceed
the 4 cup mark whilst filling, DO NOT fill below 2 cups.
6
Espresso Maker with Steam Wand
Model No. SDA2756
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with your
Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
WARNING!
This designates a hazard with moderate risk, which may result
in severe injury or damage to the product if not adhered to.
7
Espresso Maker with Steam Wand
Model No. SDA2756
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
1. Steam Wand
2. Control Switch
3. Espresso Setting
4. Indicator Light
5. Steam Setting
6. Off Setting
7. Water Tank Lid
8. Drip Tray
9. Water Tank
10. Water Outlet
6
8
7
1
3
5
12
14
11
13
Accessories
15
2
11. Serving Spoon
12. Mesh Filter
13. Steam Wand Cover
14. Filter Holder
15. Cafetiere (4 cup)
9
4
10
2
8
Espresso Maker with Steam Wand
Model No. SDA2756
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Before first Use of Your Espresso Maker
Please read these operating instructions thoroughly and keep them in a safe place
for future reference.
IMPORTANT in hard water areas it is highly recommended to use demineralised or
filtered water to avoid calcium build up which will prolong the life and prevent
damage to the machine.
Cleaning Your Espresso Maker before First Use
NB if the Water Tank (9) is overfilled there is a drainage outlet release any excess
water, this will flow through the upper housing and down into the drip tray.
1. Place the Espresso Maker on a solid, level, heat resistant
surface clear of all obstructions.
2. Remove the Water Tank Lid (7) from the Espresso Maker by
twisting anticlockwise until it comes loose.
3. Fill the Water Tank (9) with water using the Cafetiere (15)
provided up to the 4 cup mark (240ml).
Do not over-fill as this can cause the water to erupt.
4. Replace the Water Tank Lid (7) by turning clockwise until secure.
5. Install the Filter Holder (14) and Mesh Filter (12). Do not
put any coffee in the filter at this stage.
Place one hand on the top of the Espresso Maker to
support the unit and attach the Filter Holder (14) by
inserting into the central cavity of the Espresso Maker, in
line with . Turn the Filter Holder (14) to the right until it
is in the locked position .
6. Place the Cafetiere (15) onto the Drip Tray (8) under the attached Filter Holder
(14).
7. Insert the Mains plug into the nearest socket.
9
Espresso Maker with Steam Wand
Model No. SDA2756
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
8. Turn the Control Switch (2) to the Espresso Setting (3), the Indicator Light
(4) will light up orange and hot water will start to fill the Cafetiere (15) up to the
4 cup mark.
9. Turn the Control Switch (2) to the Off Setting (6) and wait for 5 seconds.
10. To clean the Steam Wand (1), move the Steam Wand (1) over the Drip Tray (8).
11. Turn the Control Switch (2) to the Steam Setting (5), the internal pump will
be heard running and steam will be emitted from the Steam Wand (1). After 2
minutes return the Control Switch (2) to the Off Setting (6).
12. Remove the Steam Wand Cover (14). When cool wipe the Steam Wand (1) with
a cloth. Repeat this process 2-3 times.
13. The Espresso Maker is now cleaned and ready to use.
Using Your Espresso Maker
1. Unplug from the mains socket.
2. Place the Espresso Maker on a solid, level, heat resistant surface clear of all
obstructions.
Filling the Water Tank
Remove the Water Tank Lid (7) from the Espresso Maker by twisting anticlockwise
and lifting until it comes loose.
1. Fill the Water Tank (9) with water using the Cafetiere (15)
provided. See below:
• For 1 Espresso Coffee fill to the 2 mark (120ml) on the
Cafetiere (15).
• For 2 Espresso Coffees fill the 4 mark (240ml) on the
Cafetiere (15).
Do not over-fill as this can cause the water to erupt from the
Water Tank (9).
2. Replace the Water Tank Lid (7) by turning clockwise until secure.
3. Insert the Mains plug into the nearest socket.
Making Espresso Coffee
1. Insert the Mesh Filter (12) into the Filter Holder (14) and, using the Serving
Spoon (11) fill the Filter Holder (14) with coffee (it is recommended to use
coarse coffee).
10
Espresso Maker with Steam Wand
Model No. SDA2756
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• For 1 cup of Espresso fill to the 2 mark.
• For 2 cups of Espresso fill to the 4 mark.
2. Use the bottom of the Serving Spoon (11) to evenly press the coffee powder
tightly, remove any excess coffee powder from the top of the Mesh Filter (12).
NB Too much coffee in the filter will result in a poor seal and leakage.
3. Once the coffee is in the filter, place one hand on the top
of the Espresso Maker to support the unit and attach the
Filter Holder (14) by inserting into the central cavity of the
Espresso Maker, indicated by turn the Filter Holder (14)
to the right until it is in the locked position .
4. Place the Cafetiere (15) onto the Drip Tray (8) and align
beneath the Filter Holder (14).
5. Turn the Control Switch (2) to the Espresso Setting (3), the Indicator Light (4)
will light up orange and hot water will start to fill the Cafetiere (15) according to
your desired cup size.
6. Once the Cafetiere (15) has been filled with Espresso Coffee to the desired mark
turn the Control Switch (2) to the Off Setting (6) for a minimum of 5 seconds.
Your Espresso Coffee is ready to serve.
7. To release any pressure left in the tank, place a suitable Jug under the Steam
Wand (1), replace the Steam Wand Cover (13), and turn the Control Switch (2)
to the Steam Setting (5) until the pressure has been fully released. Return
the Control Switch (2) to the Off Setting (6).
Making a Cappuccino Coffee
1. Prepare an Expresso Coffee as above and pour the Espresso Coffee into a suitable
cup.
2. Fill a suitable Jug with cold milk (4-8⁰C). Whole milk is recommended.
3. Remove the Steam Wand Cover (13).
4. Place the Steam Wand (1) into the Jug just below the milk’s surface.
5. Turn the Control Switch (2) to the Steam Setting (5). This will begin to froth
the milk.
11
Espresso Maker with Steam Wand
Model No. SDA2756
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
6. Once the desired level of frothed milk has been achieved turn the Control Switch
(2) to the Off Setting (6).
7. Pour the frothed milk into the prepared Expresso Coffee to create the Cappuccino
Coffee. Remember to clean the steam wand with a damp cloth.
Note on Coffee
This Espresso Maker uses ground powdered coffee which is available from most
good supermarkets and coffee retailers.
Do not use instant coffee or similar with this Espresso Maker.
Cleaning and Maintenance
• Always unplug the Espresso Maker from the mains
supply and allow to cool before cleaning.
• Do not immerse the Espresso Maker in water or any
other liquids.
• Wipe the body of the Espresso Maker clean with a
clean damp cloth.
• Do not use harsh or abrasive, powders or cleaners.
• Do not clean any part of the Espresso Maker in a
dishwasher.
Remove the Filter Holder (14) by placing one hand on the
top of the Espresso Maker to support the unit. detach by
turning from the locked position towards the Symbol.
Use the filter grip to hold the Mesh Filter (12) in place,
empty the used coffee from the filter, when cool remove the
filter. Wash the filter and holder in warm soapy water and
dry thoroughly.
Descaling your Espresso Maker
1. To ensure the normal use of the coffee machine, the internal water channels
need to be descaled and cleaned after 2-3 months of use.
2. Place the Espresso Maker on a solid, level, heat resistant
surface clear of all obstructions.
3. Remove the Water Tank Lid (7) from the Espresso Maker by
twisting anticlockwise until loose.
4. Fill the Water Tank (9) with water and descaler using the
Cafetiere (15) up to the 4 mark. (Use a descaling agent
according to the descaling products instructions).
5. Replace the Water Tank Lid (7) by turning clockwise until
secure.
6. Insert the mains plug into the nearest socket.
7. Insert the Filter Holder (14) and Mesh Filter (12).
8. Turn the Control Switch (2) to the Espresso Setting (3), the Indicator Light
(4) will light up orange, allow the hot water/descaler to fill the Cafetiere (15) up
12
Espresso Maker with Steam Wand
Model No. SDA2756
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
to the 2 cup mark only.
9. Turn the Control Switch (2) to the Off Setting (6) and wait for 5 seconds.
10. Move the Steam Wand (1) over a suitable Jug.
11. Turn the Control Switch (2) to the Steam Setting (5), the internal pump will
be heard running and steam will be emitted from the Steam Wand (1), make
sure the Steam Wand Cover (13) is attached. After 2 minutes return the Control
Switch (2) to the Off Setting (6). Allow the descaler to remain in the unit for 15
minutes. Repeat the descaling steps 2 more times, do not refill the Water Tank
(9). Empty the Drip Tray (8) as necessary.
12. To release any pressure left in the tank turn the Control Switch (2) to the Steam
Setting (5) and allow to steam to release until all water/descaler, and steam has
been removed.
13. Turn the Control Switch (2) to the Off Setting (6). Unplug the Espresso
Maker from the mains socket.
Rinsing your Espresso Maker (after descaling)
Follow the steps for ‘Cleaning your Espresso Maker before First Use’ and repeat
twice.
Troubleshooting
Problem
Possible Cause
Possible Solution
Little or no water
coming out
Water tank is empty
Fill the water tank
Machine is blocked with
Calcium deposits
See Removing Mineral
(Calcium) deposits.
No steam being
produced
Steam pipe nozzle
blockage
Clean steam nozzle
Water tank is empty
Fill the water tank
Coffee runs out
around the edge of
the filter holder
Too much powder in the
filter
Clean the Filter and Filter
Holder, dry and put fresh
powder in.
Coffee powder residue on
the sealing ring of the filter
holder
Coffee comes out
too slow or not at
all
Coffee powder is too fine
and the filter is clogged
Clean the Filter, dry and put
fresh powder in.
Filter holes are blocked
Clean the Filter, dry and put
fresh powder in.
Water tank is not inserted
Insert water tank
Water leakage on
the bottom of
machine
Drip tray is full
Empty the Drip Tray
The steam cannot
froth.
Steam indicator not
flashing
Wait for the steam
indicator to flash.
The container is too large
Use a tall narrow cup
Skimmed milk been used
Use whole milk
13
Espresso Maker with Steam Wand
Model No. SDA2756
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Technical Specification
Rated Voltage
220-240V – 50-60Hz
Rated Power
800W
Model Number
SDA2756
Protection Class
I (This Appliance Must Be Earthed)
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug -DISCONNECT FROM THE MAINS- and then cut it off
the mains lead and immediately dispose of it safely. Never attempt to reuse the
plug or insert it into a socket outlet as there is a danger of electric shock.
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and sent to landfill. Please ensure it is taken to a
suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
14
Espresso Maker with Steam Wand
Model No. SDA2756
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
15
Espresso Maker with Steam Wand
Model No. SDA2756
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Notes
16
Espresso Maker with Steam Wand
Model No. SDA2756
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
