1
7.2 LITRE
DIGITAL AIR FRYER
USER MANUAL
MODEL: T17149
2
TABLE OF CONTENTS
THIS BOX CONTAINS 3
SPECIFICATIONS 3
IMPORTANT SAFETY INFORMATION 4
• Key safety points 4
• General safety 4
• Whilst air frying 5
• Plug and cord 6
• Wiring safety 7
GETTING TO KNOW YOUR AIR FRYER 8
• Control panel and display 8
• Preset indicators 8
• Structure of your appliance 9
BEFORE FIRST USE 10
• Preparing for use 10
USING YOUR AIR FRYER 10
• Air fryer cooking basket safety switch 10
• Removing the cooking basket 10
• Turning the appliance ON/OFF 10
• Pre-set menus 11
• Setting the temperature 11
• Setting the timer 11
• The preheating function 12
• The shake function 12
• The keep warm function 12
• Air frying 12
• Tips 13
• Settings table 13
SUGGESTED TIMES/TEMPS 14
ACCESSORIES / SPARE PARTS 15
TROUBLESHOOTING 16
CLEANING AND CARE 17
DISPOSAL OF THE UNIT / CUSTOMER SUPPORT 18
WEIGHTS & MEASURES TABLE 19
RECIPES 20-22
3
THIS BOX CONTAINS
SPECIFICATIONS
RATED VOLTAGE AC 220 - 240V~
FREQUENCY 50/60Hz
POWER CONSUMPTION 1350-1650W
CAPACITY 7.2 Litre
TEMPERATURE RANGE 80°C - 200°C
TIME RANGE Up to 60 minutes
Instruction Manual
7.2L Digital Air Fryer
Removable Grill Plates
4
Please read these safety
NOTES carefully BEFORE
using your Tower appliance.
These warnings have been
provided in the interest
of safety. Basic safety
precautions should always
be followed including the
following:
KEY SAFETY POINTS
CAUTION:
During operation:
• Surfaces are hot. DO
NOT touch the hot
surfaces.
• Hot steam is released
through the air outlet
openings. Keep your
hands and face at a safe
distance from the steam
and from the air outlet
openings.
• Hot steam and air
may escape when the
appliance cooking basket
is opened.
GENERAL SAFETY
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• Close supervision is
necessary when any
appliance is used by or
near children.
• Children should not play
with the appliance.
• This appliance can
be used by children
aged from 8 years and
above and persons
with reduced physical,
sensory or mental
capabilities or lack
of experience and
knowledge if they have
been given supervision
or instruction concerning
use of the appliance in a
safe way and understand
the hazards involved.
• Cleaning and user
maintenance should
not be undertaken
by children without
supervision.
• Take care when any
appliance is used near
pets.
• Switch off and unplug
before fitting or
removing accessories,
after use and before
cleaning.
• Allow the appliance
to cool down for
approximately 30
minutes before fitting or
removing accessories or
cleaning.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and
IMPORTANT SAFETY INFORMATION
5
seek advice from the
manufacturer, its service
agent or a similarly
qualified person.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer,
apart from those
supplied with this
product.
• DO NOT use the
appliance outdoors.
• DO NOT place the
appliance on or near a
hot stove top or heated
oven.
• Take care when moving
the appliance, or
removing accessories
and food as hot oil or
other hot liquids may be
present.
• This appliance is for
household use only.
• DO NOT place anything
on top of the appliance.
• DO NOT clean the
appliance with
metal kitchen utensils,
caustic or abrasive
cleaning agents or
scouring sponges.
• DO NOT use this
appliance for anything
other than its intended
use.
WHILST AIR FRYING
• Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• DO NOT place the
appliance on or near
combustible materials
such as a tablecloth or
curtain.
• DO NOT place the
appliance against
a wall or against other
appliances. Leave at least
10cm free space
on the back and sides
and 10cm free space
above the appliance.
• DO NOT place the
appliance in the
presence of explosive
and/or flammable fumes.
• DO NOT cover the air
inlet and outlet during
operation.
• Any accessories, baking
trays or oven dishes
used in the appliance
will become hot. Always
use oven gloves when
handling or removing
anything from the
appliance.
6
• DO NOT place food that
is still packed in plastic
wrap or plastic bags
in the appliance.
• DO NOT allow food to
come into contact with
the heating element of
the appliance.
• If the appliance begins
to emit smoke, unplug it
immediately. Only open
the door once the smoke
has cleared. Remove
burnt remnants.
• DO NOT leave this
appliance unattended
whilst operating.
PLUG AND CORD
• Check that the voltage
of the main circuit
corresponds with the
rating of the appliance
before operating.
• WARNING: DO NOT
let the cord hang over
the edge of a table or
counter, serious burns
may result from the air
fryer being pulled off the
counter where it may
be grabbed by children
or become entangled
with the user.
• DO NOT let the supply
cord touch hot surfaces.
• DO NOT carry the
appliance by the power
cord.
• DO NOT use any
extension cord
with this appliance.
• The appliance is not
intended to be operated
by means of an external
timer or separate
remote-control system.
• DO NOT pull the plug
out by the cord as this
may damage the plug
and/or
the cable.
• DO NOT plug and
unplug with wet hands.
It is important that this instruction
manual is retained for future
reference.
If the appliance is given to someone
else, it should always be accompanied
by these operating instructions, as
they form an integral part of the
appliance.
IMPORTANT SAFETY INFORMATION
7
In the unlikely event the appliance develops a fault, stop using it immediately
and seek advice from the Customer Support Team.
IMPORTANT
:
As the colours in the mains
lead of this appliance may not correspond
with the coloured markings identifying
the terminals in your plug, please proceed
as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L] Green/
Yellow [EARTH]
PLUG FITTING DETAILS (WHERE
APPLICABLE).
• Plug Fitting Details (Where
Applicable). The wire labelled blue is
the neutral and must be connected to
the terminal marked [N].
• The wire labelled brown is the live
wire and must be connected to the
terminal marked [L].
• The wire labelled green/yellow must
be connected to the terminal marked
with the letter [E].
• On no account must either the brown
or the blue wire be connected to the
[EARTH] terminal.
• Always ensure that the cord grip is
fastened correctly.
• The plug must be fitted with a fuse
of the same rating already fitted and
conforming to BS 1362 and be ASTA
approved.
• If in doubt consult a qualified
electrician who will be pleased to do
this for you.
NON-REWIREABLE MAINS
PLUG.
If your appliance is supplied with a non-
rewireable plug fitted to the mains lead
and should the fuse need replacing,
you must use an ASTA approved one
(conforming to BS 1362 of the same rating).
If in doubt, consult a qualified electrician
who will be pleased to do this for you.
If you need to remove the plug -
disconnect it from the mains - then cut
it off of the mains lead and immediately
dispose of it in a safe manner. Never
attempt to reuse the plug or insert it into
a socket outlet as there is a danger of an
electric shock.
WIRING SAFETY FOR UK USE ONLY
8
GETTING TO KNOW YOUR AIR FRYER
CONTROL PANEL AND DISPLAY
1. Keep warm key
2. Ready indicator
3. Temperature LED display
4. Shake indicator
5. Cooking time LED display
6. Shake key
7. Pre-heat key
8. Time/Temperature + key
9. Time/Temperature – key
10. Temperature selection key
11. Time selection key
12. Start/Pause key
13. Pre-Set selection menu key
14. Power On/Off key
PRESET INDICATORS
1. Fries pre-set indicator
2. Bacon pre-set indicator
3. Chicken pre-set indicator.
4. Steak pre-set indicator
5. Cake pre-set indicator
6. Vegetable pre-set indicator
7. Fish pre-set indicator
8. Prawns pre-set indicator
9. Chicken drumstick pre-set indicator
10. Dessert pre-set indicator
11. Defrost pre-set indicator
31 62 4 5
87 9 10 11 12 13 14
1 2 3 4 5 6 7 8 9 10 11
Shake
9
STRUCTURE OF YOUR APPLIANCE
Air inlet
Air outlet
Control
Panel
Cooking
basket
Basket
handles
Grill plate
10
PREPARING FOR USE
1. Read all instructions and safety
information carefully before first use.
Please retain this information for
future reference.
2. Remove your appliance from the
packaging.
3. Check that there is no damage to
the cord or any visible damage to the
body.
4. Dispose of the packaging in a
responsible manner.
5. Remove any stickers or labels from
the appliance. DO NOT remove the
rating label.
6. Thoroughly clean the grill plates and
cooking baskets with hot water, some
washing-up liquid and a non-abrasive
sponge. Dry thoroughly.
7. Place the grill plates on the bottom of
the cooking baskets before use.
8. Wipe the inside and outside of the
appliance with a damp cloth. Dry
thoroughly.
9. Do not fill the appliance with oil or
frying fat. This appliance operates
using hot air and requires very little
to no oil.
10. Familiarise yourself with the control
panel shown in the Specifications
section.
11. Situate your appliance according to
the Important Safety Instructions
section.
NOTE: When using the appliance for the
first time, a slight smoke or odour may
be emitted. This is normal and will soon
subside. Ensure that there is sufficient
ventilation around the appliance.
BEFORE FIRST USE
USING YOUR AIR FRYER
AIR FRYER COOKING BASKET
SAFETY SWITCH:
For your safety, this air fryer contains
a safety switch in the cooking basket,
designed to keep if from accidentally
turning on whenever the cooking
basket is not properly situated inside
the appliance or the timer is not set.
Before using your air fryer, please ensure
that the grill plate is inside the cooking
basket and the cooking basket is fully
closed.
REMOVING THE COOKING
BASKET:
The cooking basket can be removed fully
from the air fryer. Pull on the handle at any
time to slide the cooking basket out of the
air fryer.
NOTE: If a cooking basket is removed
from the main body of the fryer when in
operation, the unit will automatically stop
working and the digits on the LED display
will go out to indicate the cooking process
has been paused. When the cooking
basket is re-inserted, the air fryer will
resume operation on the latest selected
settings.
TURNING THE APPLIANCE ON/
OFF:
1. To use the appliance, begin by
plugging it into a mains socket,
ensuring the socket switch is in the
ON position.
2. Once the unit is plugged in, press
the key to bring it out of Standby.
There will be a sound prompt and the
LED display will come on to indicate
the unit has been turned on.
3. Long-press this button again when
the unit is paused to turn it off. The
LED display will go out and the fan
will stop working.
NOTE: The appliance will turn itself off
if left idle for a period of more than 3
minutes.
11
PRE-SET MENUS:
This unit is equipped with a choice
of 11 pre-sets: Fries, Bacon, Chicken,
Steak, Cake, Vegetable, Fish, Prawns,
Drumsticks, Dessert and Defrost.
• To start cooking, begin by selecting
the desired pre-set. To do this, press
the key on the unit’s control panel
to cycle through and select the
available functions and modes.
• The corresponding indicator will
flash on the unit’s control panel
to show each pre-set has been
selected, the default cooking time
and temperature for that function or
mode will be displayed on the unit’s
LED screen. On certain pre-sets, the
Shake key will also begin to flash.
NOTE: The default pre-set for the unit is
Fries.
• When the desired pre-set has been
selected, press the
key to begin or
resume the cooking cycle.
• The unit will automatically start
working and the remaining cooking
time will begin to count down on the
unit’s LED display.
NOTE: Cooking times and temperatures
for each pre-set can be manually adjusted,
as detailed in the corresponding sections
above.
• The default times and temperatures
for each pre-set are as follows:
Preset
Temp
(ºC)
Time
(mins)
Amount
(g)
Fries
200 20 300-500
Bacon
180 5 80-120
Chicken
180 40 500-550
Steak
180 12 150-200
Bake
180 15 120-200
Preset
Temp
(ºC)
Time
(mins)
Amount
(g)
Veg
150 10 400-600
Fish
180 15 200-300
Prawns
185 8 250-500
Chicken leg
190 22 400-600
Dessert
180 15 -
Frozen food
180 20 200-300
SETTING THE TEMPERATURE:
The appliance’s cooking temperature can
be set manually, from 80ºC to 200ºC.
1. Press the key to turn the
temperature selection function
on, then press the and keys
to manually adjust the cooking
temperature, in increments of 5. The
currently selected temperature will
be displayed on the unit’s LED screen.
Short-press each key to gradually
increase or decrease the temperature,
or press and hold it to cycle through
the temperature range more quickly.
2. When the correct temperature has
been selected, press the key to
begin or resume the cooking cycle.
SETTING THE TIMER:
1. The appliance’s cooking time can be
set manually, from 0 to 60 minutes.
2. Press the key to turn the timer
selection function on, then press the
and keys to manually adjust the
cooking temperature, in increments
of 1. The currently selected cooking
time will be displayed on the unit’s
LED screen. Short-press each key to
gradually increase or decrease the
cooking time, or press and hold it to
cycle through the timer more quickly.
USING YOUR AIR FRYER
12
USING YOUR AIR FRYER
THE PREHEATING FUNCTION:
This unit is equipped with a pre-heating
function.
1. Press the key on the unit’s control
panel to activate the preheating
function. Once this function has been
selected, press the key to start a
pre-heating cycle.
NOTE: The preheating cycle runs
for a default 3 minutes, at a default
temperature of 200ºC.
2. Once the preheating cycle is
complete, there will be a sound
prompt, the control panel will light
up fully, and the ‘Ready’ indicator will
illuminate to show the food is ready
to cook.
3. Press the key again before the start
of the cycle to cancel the preheating
function. Alternatively, long press
the key while a cooking cycle is in
progress to cancel it and put the unit
into standby mode.
THE SHAKE FUNCTION:
This unit allows for a reminder to be set for
pre-set programs which require that the
ingredients be shaken halfway through.
1. Press the key on the unit’s control
panel to activate the function. The key
will begin to flash. Next, press the
key to start a cooking cycle.
As long as the Shake function is
active, the unit will automatically stop
the cooking cycle halfway through
and give off a sound prompt and
the Shake indicator will illuminate to
indicate the ingredients should be
shaken. When this occurs, pull the
cooking basket out of the air fryer,
shake the ingredients, then place the
basket back into the fryer to resume
the cooking cycle.
NOTE: If the cooking basket is not pulled
out after the first reminder, the unit will
beep again and the Shake indicator will
briefly flash.
THE KEEP WARM FUNCTION:
This unit is equipped with a separate
Keep Warm function, which allows
for food to be kept warm for up to 60
minutes after the end of a cooking cycle.
1. Press the key on the unit’s
control panel to activate the
Keep Warm function. The unit
will automatically default to a
temperature of 65ºC and a running
time of 15 minutes.
2. If necessary, adjust the cooking
time and temperature, as detailed
in the corresponding section of this
instruction manual.
3. Once the desired cooking time and
temperature have been set, press
the key to start a Keep Warm
cycle. Press this key again before
the start of the cycle to cancel the
Keep Warm function. Alternatively,
long press the key while a Keep
Warm cycle is in progress to cancel
it and put the unit into standby
mode.
AIR FRYING:
1. Once the correct cooking
temperature and time have been
selected, press the key to start
a cooking cycle. The unit’s LED
display and the indicator for the
selected function or mode will remain
illuminated but all other indicators
will go out.
CAUTION! DO NOT touch the cooking
basket during and for some time after use,
as it gets very hot. Only hold the cooking
basket by the handle.
2. When the set preparation time has
elapsed the appliance will emit an
audible signal and the unit will go into
Standby mode. The LED screen will go
out and the key will light up red.
3. When this occurs, pull the cooking
basket out of the appliance and
place it on a heat-resistant surface.
Alternatively, turn the appliance off
manually by long-pressing the key
for about one second.
4. Check if the ingredients are ready:
• If the ingredients are not ready yet,
simply slide the cooking basket back
into the appliance and set the timer
to a few extra minutes.
13
USING YOUR AIR FRYER
• If the ingredients are ready empty
the cooking basket into a bowl or
onto a plate. Take care if tilting the
cooking basket, as any excess oil
that has collected on the bottom of
the cooking basket will leak onto the
ingredients, and the grill plate may
also detach from the cooking basket
and fall onto the food.
• When a batch of food is ready, the
appliance is instantly ready for
preparing another batch.
• Unplug the appliance when the unit
is not required for further cooking.
TIPS:
• If the food is cold, increase the
cooking time by 3 minutes.
• To remove large or fragile ingredients,
lift the ingredients out of the cooking
basket with a pair of tongs.
• The cooking time will depend on the
size of your ingredients. Smaller sizes
may require a shorter cooking time.
• Shaking smaller ingredients and
turning food halfway during the
cooking time optimises the end result
and can help prevent unevenly fried
ingredients.
• For perfectly fluffy fries, it is
recommended that potatoes be
parboiled before frying.
• Add some oil to fresh potatoes for a
crispy result. Fry your ingredients in
the air fryer within a few minutes after
you added the oil.
• Be cautious of using extremely greasy
ingredients in the air fryer..
• Snacks that can be prepared in an
oven can also be prepared in the unit.
• Use pre-made dough to prepare filled
snacks quickly and easily. Pre-made
dough also requires a shorter cooking
time than home-made dough.
• When battering items, ensure they
are battered in the correct order,
so that they do not fall apart while
crisping or frying. Items should first
be coated in flour, then butter or egg,
and finally breadcrumbs.
• The table on the next page offers
reference times and quantities for
frying a variety of popular ingredients.
SETTINGS TABLE:
NOTE: The table on the next page will
help you to select the basic settings for
the ingredients. Keep in mind that these
settings are indications. As ingredients
differ in origin, size, shape and brand,
the best settings for your ingredients
cannot be guaranteed. Because the Rapid
Air technology instantly reheats the air
inside the appliance instantly, pulling the
cooking basket briefly out of the appliance
during hot air frying barely disturbs the
process.
14
SUGGESTED TIMES/TEMPS
Food Type
Default
Cooking
Time (mins)
Default
Temperature
(ºC)
Recommended
amount of
ingredients (g)
Extra
information
Shake
POTATO & FRIES
Thin frozen fries
15-20 200 300-400
shake
Thick frozen fries
20-25 200 300-400
shake
Potato gratin
20-25 190
500 shake
MEAT & POULTRY
Steak
15-20 180
100-500
Pork chops
15-20 180
100-500
Hamburger
15-20 180
100-500
Sausage roll
13-15 190
100-500
Drumsticks
15-22 200
100-500
Chicken breast
15-20 180
100-500
SNACKS
Spring rolls
8-10 190
100-400
Use oven-
ready
shake
Frozen chicken
nuggets
10-15 190
100-500
Use oven-
ready
shake
Frozen fish
fingers
15-20 200
100-400
Use oven-
ready
Frozen bread
crumbed
cheese snacks
8-10 180
100-400
Use oven-
ready
Stuffed
vegetables
10-15 160
100-400
BAKING
Cake
10-15 180
300 Use baking tin
Quiche
20-22 180
400
Use baking tin/
oven dish
Muffins
15-18 190
300 Use baking tin
Sweet snacks
20 180
400
Use baking tin/
oven dish
15
Spare part replacements and accessories are available to purchase via:
+44 (0) 333 220 6066
www.towerhousewares.co.uk
PART NO DESCRIPTION
T1714901 Cooking Basket
T1714902 Grill Plate
ACCESSORIES/SPARE PARTS
16
PROBLEM POSSIBLE CAUSE SOLUTION
The air fryer
does not work
The appliance is not plugged in.
The timer has not been set.
The ON/OFF key has not been pressed.
Plug the appliance into an earthed wall
socket.
Set the time required.
Press the ON/OFF key.
The
ingredients
are not done.
Too much food has been added to the
unit.
The set temperature is too low.
The cooking time is too short.
Put smaller batches of ingredients in the air
fryer. Smaller batches are fried more evenly.
Set to an appropriate temperature, re-fry food.
Set an appropriate cooking time, re-fry food.
Food is not
evenly fried.
Certain foods need to be shaken mid-
way through the cooking process.
Midway through the cooking process, pull the
cooking basket out and shake it to separate
the overlapped food material, then push the
cooking basket back to continue.
Fresh fries are
fried unevenly.
Wrong type of potatoes used.
The potato sticks were not rinsed
adequately before frying.
Use fresh potatoes and make sure they stay
firm during frying.
Rinse the potato sticks properly to remove
starch from the outside.
Fried snacks
are not crispy
when they
come out of
the unit.
Some food materials have to be fried
with oil.
Wrong type of snacks used.
Coat the surface of the food with a thin layer
of oil on first, then start to fry them.
Use oven snacks or lightly brush some oil onto
the snacks for a crispier result.
Fresh fries
are not crispy
when they
come out of
the unit.
The crispiness of the fries depends on
the amount of oil and water in the fries.
Make sure you dry the potato sticks properly
before you add the oil.
Cut the potato sticks smaller for a crispier
result.
Add slightly more oil for a crispier result.
The appliance
is smoking.
The ingredients have a high oil content.
The unit contains grease from previous
use.
The cooking settings have not been
correctly programmed.
Smoking will be normal.
White smoke is caused by grease heating up
inside the fryer. Clean the unit properly after
each use.
Adjust the cooking settings as required.
The unit is
showing an
unexpected
message (E2
or E4.)
The sensor has malfunctioned or short-
circuited.
The unit will automatically self-diagnose and
return to normal working mode. If this does
not occur, unplug the appliance immediately
and contact the Customer Service Team.
TROUBLESHOOTING
17
Troubleshooting:
PROBLEM POSSIBLE CAUSE SOLUTION
The air fryer
does not
work
The appliance is not plugged in.
A drawer or cooking mode has not
been selected.
The Start/Stop key has not been
pressed.
The drawers are open and the
selected function is paused.
Plug the appliance into an
earthed wall socket.
Select the required drawer and
cooking mode by pressing the
corresponding buttons on the
unit’s control panel.
Press the Start/Stop key.
Close the drawers to automatically
resume the selected function.
The drawers
will not slide
inside the
unit properly.
There is too much food in the
drawers.
Take care not to overfill the
drawers.
The fried
ingredients
are not done.
Too much food has been added to
the air fryer.
The set temperature is too low.
The cooking time is too short.
Put smaller batches of ingredients
in the air fryer. Smaller batches are
fried more evenly.
Set to an appropriate temperature
or select the appropriate pre-set
program from the unit’s control
panel.
Set an appropriate cooking time
or select the appropriate pre-set
program from the unit’s control
panel.
Fresh fries
are fried
unevenly in
the air fryer.
Wrong type of potatoes used.
The potato sticks were not rinsed
adequately before frying.
Use fresh potatoes and make sure
they stay firm during frying.
Rinse the potato sticks properly to
remove starch from the outside.
Fried snacks
are not crispy
or evenly
fried when
they come
out of the air
fryer.
Some food materials have to be fried
with oil.
Wrong type of snacks used.
Food is stuck together or not in an
even layer.
Brush a thin layer of oil on the
surface of the food first, then start
to fry it.
Use oven snacks or lightly brush
some oil onto the snacks for a
crispier result.
Shake or turn the food periodically
through the cooking process.
Fresh fries
are not crispy
when they
come out of
the air fryer.
The crispiness of the fries depends
on the amount of oil and water in
the fries.
Make sure you dry the potato
sticks properly before you add
the oil.
Cut the potato sticks smaller for a
crispier result.
Add slightly more oil for a crispier
result.
The
appliance is
smoking.
The ingredients have a high oil
content.
The appliance contains grease from
a previous use.
An inappropriate temperature has
been set.
Smoking will be normal.
White smoke is caused by grease
heating up inside the fryer.
Clean the appliance properly after
each use.
Follow the suggested settings
or food manufacturer’s
recommendations.
The food is
burned
The food was added before pre-
heating was complete.
The food was cooked for too long.
The food was left in the appliance
after the cooking time had elapsed.
Add food to the appliance only
once pre-heating is completed.
Check on the progress of the
food periodically throughout the
cooking process.
Remove the food from the
appliance as soon as the cooking
time has elapsed.
CLEANING AND CARE
WARNING! Do not immerse the appliance
in water or any other liquid.
NOTE: Clean the appliance after every use.
1. Do not use metal kitchen utensils or
abrasive cleaning materials to clean
the cooking baskets and grill plates,
as this may damage the non-stick
coating.
2. Clean the cooking baskets and grill
plates with hot water, some washing-
up liquid and a non-abrasive sponge
or brush.
Tip: If food residue is stuck to the grill
plates or the bottom of the cooking
baskets, leave them to soak in hot water
and some washing-up liquid for a few
hours or overnight.
3. DO NOT allow water or any other
liquid to enter the unit.
4. Wipe the outside of the appliance
with a damp cloth.
5. Wipe the inside of the appliance with
hot water and a non-abrasive sponge.
6. Clean the heating element with a
cleaning brush to remove any food
residues.
7. Ensure all parts are thoroughly dry
before use.
NOTE: The cooking basket is NOT
dishwasher-proof. NEVER place the
cooking basket in the dishwasher.
STORAGE
• Ensure that the air fryer is cool, clean
and dry before you store it.
• Store the power cord in the dedicated
cord storage area.
• Store the appliance in a cool and dry
place.
18
Appliances bearing the symbol shown
here may not be disposed of in domestic
rubbish. You are required to dispose of old
electrical and electronic appliances like
this separately.
Please visit www.recycle-more.co.uk
or www.recyclenow.co.uk for access
to information about the recycling of
electrical items.
Please visit www.weeeireland.ie for
access to information about the recycling
of electrical items purchased in Ireland.
If you have any questions or concerns about your new product,
please contact our helpful Customer Support Team:
+44 (0) 333 220 6066
www.towerhousewares.co.uk
Please have your Model No. available. This can be found on the front
cover of this instruction manual and on the appliance’s rating label.
The WEEE directive, introduced in August
2006, states that all electrical items must
be recycled, rather than taken to landfill.
Please arrange to take this appliance to
your local Civic Amenity site for recycling,
once it has reached the end of its life.
DISPOSAL OF THE UNIT
CUSTOMER SUPPORT
19
WEIGHTS AND MEASURES
Check these charts for basic imperial to metric conversions of weights.
IMPERIAL Metric
1/2 oz 15g
1 oz 30g
2 oz 60g
3 oz 90g
4 oz 110g
5 oz 140g
6 oz 170g
7 oz 200g
8 oz 225g
9 oz 255g
10 oz 280g
11 oz 310g
12 oz 340g
13 oz 370g
14 oz 400g
16 oz 425g
1 lb oz 450g
METRIC IMPERIAL US CUPS
250ml 8 fl oz 1 cup
180ml 6 fl oz 3/4 cup
150ml 5 fl oz 2/3 cup
120ml 4 fl oz 1/2 cup
75ml 2 ½ fl oz 1/3 cup
60ml 2 fl oz 1/4 cup
30ml 1 fl oz 1/8 cup
15ml 1/2 fl oz 1 tablespoon
20
INGREDIENTS
2 large potatoes
½ tbsp. paprika
Pinch of salt
Pinch of pepper
1 tbsp. sunflower oil
1. Wash, peel and slice the potatoes.
2. Dry with kitchen paper.
3. Cut the potatoes into your desired
length and thickness.
4. Bring a large pot of water to the boil with
a pinch of salt. Add the chips and allow
to part boil for 10 minutes.
5. Strain the fries and immediately run
under cold water to stop them from
cooking any more.
6. Pour the oil in a bowl, with the paprika,
salt and pepper. Put the fries on top and
mix until all the fries are coated.
7. Remove the fries from the bowl with
your fingers or kitchen utensil so that the
excess oil stays behind in the bowl.
8. Place the fries in the air fryer and
then set the fryer to cook as per the
suggested times/temperature in the
Settings Table.
Variations: Try replacing ½ tbsp. of paprika
with ½ tbsp. garlic powder, or ½ tbsp. of
grated parmesan cheese.
HOMEMADE FRIES
FAMILY SIZE
SERVES
4
21
HONEY LIME CHICKEN WINGS
INGREDIENTS
12 chicken wings
2 tbsp soy sauce
2 tbsp honey
1 ½ tsp salt
¼ tsp white pepper
¼ tsp black pepper
2 tbsp fresh lime
juice
METHOD
1. Place all the ingredients inside a large
mixing bowl or zip-locked sealing
bag and mix them well. Marinate in
the refrigerator for at least 4 hours
(preferably overnight)
2. Evenly scatter the chicken wings across
the basket.
3. Cook the wings, turning halfway
through as per the suggested time and
temperature most
FAMILY SIZE
SERVES
4
22
MOLTEN CHOCOLATE LAVA CAKE
INGREDIENTS
100g dark chocolate
chips
100g unsalted butter
1 ½ tbsp. self-raising flour
2 eggs
2 ½ tbsp. sugar
METHOD
1. Melt the chocolate and the butter,
stirring all the time.
2. Stir the flour into the mixture, mix it in
lightly and set the mixture aside.
3. In a separate mixing bowl, mix together
the eggs and sugar until light and
frothy. Mix in the chocolate sauce slowly
until the ingredients are well blended
together.
4. Pour the batter into an oven-safe cup or
ramekin and place it inside the air fryer.
5. Turn the air fryer to 190ºC for 6 minutes.
6. When ready, top with ice-cream and
serve immediately.
FAMILY SIZE
SERVES
4
23
SUGGESTED TIMES/TEMPS
24
This product is guaranteed for 12
months from the date of original
purchase.
If any defect arises due to faulty
materials of workmanship, the faulty
products must be returned to the place
of purchase.
Refund or replacement is at the
discretion of the retailer.
THE FOLLOWING CONDITIONS APPLY:
The product must be returned to the
retailer with proof of purchase or a
receipt.
The product must be installed and used
in accordance with the instructions
contained in this instruction guide.
It must be used only for domestic
purposes.
It does not cover wear and tear, damage,
misuse or consumable parts.
Tower has limited liability for incidental
or consequential loss or damage.
This guarantee is valid in the UK and
Eire only.
The standard one year guarantee is only
extended to the maximum available
for each particular product upon
registration of the product within 28
days of purchase. If you do not register
the product with us within the 28 day
period, your product is guaranteed for
1 year only.
To validate your extended warranty,
please visit www.towerhousewares.
co.uk and register with us online.
Please note that length of extended
warranty offered is dependent on
product type and that each qualifying
product needs to be registered
individually in order to extend its
warranty past the standard 1 year.
Extended warranty is only valid with
proof of purchase or receipt.
Your warranty becomes void should you
decide to use non Tower spare parts.
Spare parts can be purchased from
www.towerhousewares.co.uk
Or call our Customer Support Team on:
+44 (0) 333 220 6066
We hope you enjoy your appliance for many years...
YEAR
GUARANTEE
3
1123V1
