T17058
22 LITRE
5-IN-1 AIR FRYER OVEN
WITH ROTISSERIE
SAFETY AND INSTRUCTION MANUAL
PLEASE READ CAREFULLY
*Subject to registering your Extended Guarantee online at
www.towerhousewares.co.uk.
2
Technical Data:
This box contains:
Instruction Manual
Air Fryer Oven
Wire Rack
Handle
Rotisserie Skewer & Handle
2 x Airflow Racks
Baking Tray
1. Power Light
2. Temperature Dial
3. Function Dial
4. Timer Dial
5. Oven Light Button
6. Oven Door Handle
7. Baking Tray
8. Airflow Racks
9. Rotisserie Skewer
10. Rotisserie Handle
11. Wire Rack & Handle
Specifications:
Description: 22 Litre 5-In-1 Air Fryer Oven With Rotisserie
Model: T17058
Rated Voltage: 220-240V~
Frequency: 50Hz
Power Consumption: 1700W
Documentation
We declare that this product conforms to the following product legislation in accordance with
the following directive(s):
2014/30/EU Electromagnetic Compatibility (EMC)
2014/35/EU Low Voltage Directive (LVD)
1935/2004/EC Materials & Articles in Contact With Food (LFGB section 30 & 31)
2011/65/EU Restriction of Hazardous Substances Directive.
(Including amendment (EU) 2015/863).
2009/125/EC Eco-design of Energy related Products (ERP)
RK Wholesale LTD Quality Assurance, United Kingdom.
6
1 2 3 4 5
7 8 9
10 11
3
Wiring Safety for UK Use Only
IMPORTANT
As the colours in the mains lead of this
appliance may not correspond with the
coloured markings identifying the terminals in
your plug, please proceed as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L] Green/
Yellow [EARTH]
Plug Fitting Details (Where Applicable).
The wire labelled blue is the neutral and must
be connected to the terminal marked [N].
The wire labelled brown is the live wire and
must be connected to the terminal marked [L].
The wire labelled green/yellow must be
connected to the terminal marked with the
letter [E].
On no account must either the brown or
the blue wire be connected to the [EARTH]
terminal.
Always ensure that the cord grip is fastened
correctly.
The plug must be fitted with a fuse of the same
rating already fitted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualified electrician who
will be pleased to do this for you.
Non-Rewireable Mains Plug.
If your appliance is supplied with a non-
rewireable plug fitted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualified electrician who
will be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - then cut it off of the mains
lead and immediately dispose of it in a safe
manner. Never attempt to reuse the plug or
insert it into a socket outlet as there is a danger
of an electric shock.
FUSE
Earth
(Green/Yellow)
Fuse
Neutral
(Blue)
Live
(Brown)
WARNING:
This appliance MUST be earthed!
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information about the
recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be
recycled, rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.
4
• Check that the voltage
of the main circuit
corresponds with the
rating of the appliance
before operating.
• If the supply cord or
appliance is damaged,
stop using the
appliance immediately
and seek advice from
the manufacturer,
its service agent or
a similarly qualified
person.
• WARNING: DO NOT
let the cord hang over
the edge of a table or
counter, serious burns
may result from the
air fryer being pulled
off the counter where
it may be grabbed by
children or become
entangled with the
user.
• DO NOT carry the
appliance by the power
cord.
• DO NOT use any
extension cord with this
appliance.
• DO NOT pull the plug
out by the cord as this
may damage the plug
and/or the cable.
• Switch off at the wall
socket then remove the
plug from the socket
when not in use or
before cleaning.
• Switch off and
unplug before fitting
or removing tools/
attachments, after use
and before cleaning.
• Close supervision is
necessary when any
appliance is used by or
near children.
• Children should not
play with the appliance.
• This appliance can
be used by children
aged from 16 years and
above and persons
with reduced physical,
sensory or mental
capabilities or lack
of experience and
knowledge if they have
been given supervision
or instruction
concerning use of the
appliance in a safe way
and understand the
hazards involved.
• Cleaning and user
maintenance should
not be undertaken
by children without
supervision.
Please read these notes carefully BEFORE using your
Tower appliance
Important Safety Information:
5
• Take care when any
appliance is used near
pets.
• DO NOT use this
product for anything
other than its intended
use.
• This appliance is for
household use only.
• This appliance includes
a heating function.
Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• DO NOT immerse
cords, plugs or any
part of the appliance
in water or any other
liquid.
• DO NOT use the
appliance outdoors.
• DO NOT place the air
fryer oven on or near
combustible materials
such as a tablecloth or
curtain.
• DO NOT place the air
fryer oven against a
wall or against other
appliances. Leave at
least 10cm free space
on the back and sides
and 10cm free space
above the appliance.
• Allow the air fryer
oven to cool down
for approximately 30
minutes before you
handle or clean it.
• Make sure the food
prepared in the air
fryer oven comes out
golden-yellow instead
of dark brown. Remove
burnt remnants.
• During hot air frying,
hot steam is released
through the air outlet
openings. Keep your
hands and face at a
safe distance from the
steam and from the air
outlet openings.
• Hot steam and air
may escape when you
remove the pan from
the air fryer oven.
• Any dishes or
accessories used in
the air fryer oven will
become hot. Always
use oven gloves when
handling or removing
anything from the air
fryer oven.
• WARNING: DO NOT fill
the air fryer tray with oil
as this may cause a fire
hazard.
6
• Always put ingredients
to be fried in the
basket.
• DO NOT place anything
on top of the air fryer
oven.
• DO NOT cover or
obstruct the heat
dissipation area of the
air fryer oven.
• To disconnect, turn
air fryer oven OFF by
making sure the Timer
Dial is set to OFF, then
remove plug from wall
outlet.
• Use recommended
temperature settings
for all cooking/baking,
roasting and air frying.
• Do not rest cooking
utensils or baking
dishes on glass door.
• Do not clean with metal
scouring pads. Pieces
can break off the pad
and touch electrical
parts, creating a risk of
electric shock.
• Do not attempt to
dislodge stuck on food
while the air fryer oven
is plugged into an
electrical outlet.
• In the unlikely event
the appliance develops
a fault, stop using
it immediately and
seek advice from the
Customer Support
Team.
+44 (0) 333 220 6066
Before First Use:
Read all instructions and safety information carefully before first use. Please retain this
information for future reference.
1. Remove and safety discard any packaging material, promotional labels and tape
from the oven.
2. Remove Wire Rack, Baking Tray, Airflow Racks, Rotisserie Skewer & Handle from the
packaging. Wash them with soft sponge in warm soapy water then rinse and Dry
thoroughly.
3. Wipe the interior of the oven with soft, damp sponge. Dry thoroughly.
4. Place oven on a flat dry surface. Ensure there is a minimum of 10cm of space around
each side wall of the oven. There should be no objects placed on top of the oven.
5. Before using the Air Fryer Oven for the first time, set the Temperature Dial to 230°C,
and preheat the oven for 10-15 minutes to remove any oil or protective substances
on the heating elements. It is normal for some vapours or small amount of smoke to
appear while oven is heating.
7
Using Your Appliance.
General Operation:
1. Power Light
The Power Light will light up and remain on when oven is powered on. Note: Anytime the
door is open the power is cut and the light will go out. Simply close the door and both the
power and power light will come back on.
2. Temperature Dial
The Temperature Dial allows you to set the oven temperature from 90°C to 230°C.
3. Function Dial
The Function Dial allows you to select from the following cooking methods: Grill, Oven,
Fan Oven, Airfry, Dehydrate & Rotisserie.
4. Timer Dial
The Timer Dial allows you to set the cooking time for all functions from 0 to 60 minutes.
Turn the dial clockwise to the desired cooking time. The oven will power on and remain on
until the preset time is up. When the preset time is up, you will hear a bell ring once.
5. Oven Light Button
The Oven Light button is used to toggle the internal Oven Light
ON or OFF. Note: The Oven Light will only operate when the oven is running and the oven
door is closed.
6. Rotisserie Spit, Tines, Screws and Handle
The Rotisserie Spit, Tines, Screws and Handle are to be used when using the ROTISSERIE
function. The Rotisserie Handle is supplied to help move food on the Rotisserie Spit in
and out of the oven. Refer to Figure 2 and ROTISSERIE on page 13 for further details and
instructions on how to place in the Air Fryer Oven.
7. Wire Rack
The Wire Rack can be used in the UPPER, MIDDLE and LOWER rack positions .
8. Baking Tray
The Baking Tray can be used during the Oven, Fan Oven, AIRFRY and ROTISSERIE
functions.
9. Oven Tray Handle
The Oven Tray Handle is designed to help place and remove the Wire Rack and Baking
Tray from the Air Fryer Oven.
Place food on the Baking Tray, Airflow Racks or Wire Rack. Select the desired FUNCTION
and TEMPERATURE. Using the TIMER Dial, preheat oven for 10 minutes. After the oven has
preheated, insert food into the appropriate rack position. Start the oven by turning the
Timer Dial to the desired cooking time. When the preset time on the Timer Dial is up, you
will hear a bell ring once.
Note: Your Air Fryer Oven will not operate while the oven door is open. For your safety,
there is a switch that will cut the power whenever the oven door is opened. The power will
resume again when then the oven door is closed. Please note the Power Light will also
switch off anytime the power is cut.
8
OVEN RACK POSITIONS
Each FUNCTION will tell you where the Wire Rack, Baking Tray and Airflow Racks should
be positioned for the best results. Please refer to the diagram below for rack positions.
(Refer to the diagram below)
Functions:
Grill
Rack Positions: UPPER or MIDDLE
Heating Element Configuration: Top 2 outer elements
1. Set the Function Dial to Grill.
2. Use the Temperature Dial to select the Grill setting (230°C). The temperature can be
lowered if desired.
3. Use the Timer Dial to preheat oven for 10 minutes. The Power Light will illuminate,
indicating the oven is heating.
4. Place food on the Baking Tray.
5. Once the oven is preheated, open the oven door and place the Baking Tray in the
UPPER or MIDDLE rack position.
6. Set the Timer Dial to desired cooking time.
7. Close the oven door.
8. When the preset time on the Timer Dial is up, you will hear a bell ring once.
WARNING! Do not leave the oven unattended during broiling.
Oven
Rack Positions: MIDDLE and LOWER
Heating Element Configuration: Top 2 outer elements and bottom 2 elements
1. Set the Function Dial to Oven.
2. Use the Temperature Dial to select desired cooking temperature.
3. Use the Timer Dial to preheat oven for 10 minutes. The Power Light will illuminate,
indicating the oven is heating.
4. Place food on the Oven Tray.
5. Open the oven door and place the Oven Tray in the MIDDLE or LOWER rack position.
6. Set the Timer Dial to the desired cooking time.
7. Close the oven door.
8. When the preset time on the Timer Dial is up, you will hear a bell ring once.
Fan Oven
Rack Positions: MIDDLE
Heating Element Configuration: Top 2 outer elements + Fan and bottom 2 elements
1. Set the Function Dial to Fan Oven.
2. Use the Temperature Dial to select desired cooking temperature.
3. Use the Timer Dial to preheat the oven for 10 minutes. The Power Light will illuminate,
indicating the oven is heating.
4. Place food on Baking Tray.
UPPER
MIDDLE
LOWER
9
5. Open the oven door and place the Baking Tray in the Middle rack position.
6. Set the Timer Dial to the desired cooking time.
7. Close the oven door.
8. When the preset time on the Timer Dial is up, you will hear a bell ring once.
Airfry
Rack Positions: MIDDLE and UPPER
Heating Element Configuration: Top 4 elements + Fan.
1. Set the Function Dial to AIR FRY.
2. Use the Temperature Dial to select desired the cooking temperature.
3. Use the Timer Dial to preheat the oven 10 minutes. The Power Light will illuminate,
indicating the oven is heating.
4. Place food in the Air Fryer Basket. Be sure to spread the food out evenly to allow
maximum air flow around the food.
5. Set the Timer Dial to the desired cooking time.
6. Open the oven door and place the Air Fryer Basket in the MIDDLE or UPPER rack
position.
7. Place the Oven Tray in the closest rack position directly below the Air Fryer Basket to
catch any drippings.
8. Close the oven door.
9. When the preset time on the Timer Dial is up, you will hear a bell ring once.
Dehydrate
Rack Positions: MIDDLE and UPPER
Heating Element Configuration: Top 2 middle elements + Fan
1. Set the Function Dial to DEHYDRATE.
2. When in the DEHYDRATE function, the oven temperature is fixed at between
50-70°C and cannot be adjusted using the Temperature Dial.
3. Use the Timer Dial to preheat the oven 10 minutes. The Power Light will illuminate,
indicating the oven is heating.
4. Place food in the Air Fryer Basket and/or Oven Rack. Be sure to spread the food out
evenly to allow maximum airflow around the food.
5. Open the oven door and place the Airfryer Basket and/or Oven Rack in the MIDDLE
and/or UPPER rack position.
6. Set the Timer Dial to 60 minutes.
7. Close the oven door.
8. Since the Timer Dial can only be set to a maximum of 60 minutes, you will need
to manually track your time in the DEHYDRATE function as most recipes call for
dehydration times up to 8 hours.
9. Dehydration is set to a fixed temperature of 50-70C and power will remain on until
manually turned off. This function is not connected to the timer & temperature dials.
Rotisserie
Heating Element Configuration: Top 4 elements + Fan
1. Place one ROTISSERIE TINE on the squared end of the ROTISSERIE SPIT with the
tines facing the centre of the spit and tighten the ROTISSERIE SCREW slightly.
2. Slide the pointed end of the spit through the centre of the meat to be cooked. Secure
the tine through the meat.
3. Place the other tine on the rounded end of the spit with the tines facing the centre.
Secure the tines through the opposite end of the meat.
4. Adjust the meat so that it is centred on the spit. Make sure the tines secure the meat
onto the spit and tighten the rotisserie screws.
5. Use the ROTISSERIE Handle to insert the rounded end of the spit into the drive
socket on the right interior wall of the oven.
6. Rest the squared end of the spit on the spit support on the left interior wall of the
oven.
7. Place the Oven Tray in the LOWER rack position.
8. Set the Function Dial to ROTISSERIE.
9. Use the Temperature Dial to select the desired cooking temperature.
10. Set the Timer Dial to the desired cooking time. The Power Light will illuminate,
indicating the oven is heating.
11. Close the oven door.
12. When the preset time on the Timer Dial is up, you will hear a bell ring once.
Air Fryer Cooking Chart
The Air Fryer Cooking Chart below shows recommended food quantities, temperatures
and cooking times for various food items. Smaller portions may require shorter cooking
times.
10
Food Recommended Amount
Temperature
(ºC)
Time (min.)
Bacon (Thick Cut) 6 to 8 slices. 230 12 to 14
Chicken Drumsticks 2 to 3 lbs. (about 8 drumsticks) 230 30 to 35
Chicken Wings 2 lbs. ( about 20 wings) 230 40 to 45
Hand Battered
Chicken Strips
2 lb. (about 10 pieces) 200 15 to 20
Frozen French Fries 1 to 2 lbs. 230 25 to 30
Hand Cut French Fries
2 lbs. (about 3 russet potatoes, cut into
1/4-inch thick sticks, about 4 inches
long)
200 30 to 35
Frozen Meatballs
(Dinner size)
1 to 2 lbs., in a single layer 190 15 to 18
Handmade Meatballs
(Dinner Size)
1 to 2 lbs., in a single layer 230 15 to 18
Pita Chips
2 to 3 pitas, brushed with oil, torn into 2
inch pieces, and sprinkled with salt.
200
6 to 8 turn over
halfway through
cooking
Tortilla Chips
3 corn tortillas, brushed with oil, torn
into pieces, and sprinkled with salt
200 8 to 10
Shrimp 1.5 lbs. (about 36 large shrimp) 190 10 to 12
Air Frying doesn’t require as much oil as deep frying, but a light spray can enhance
browning and crispness. Use a non-stick cooking spray to keep it extra light, or pour a little
oil into a bowl, add food, and toss.
Troubleshooting:
PROBLEM POSSIBLE CAUSE SOLUTION
The air fryer does not
work
The appliance is not plugged in.
Plug the appliance into an earthed wall
socket.
The appliance is not turned on.
Press the On/Off button to switch on the
appliance.
Fried snacks are not
crispy when they come
out of the air fryer.
Wrong type of snacks used.
Use oven snacks or lightly brush some
oil onto the snacks for a crispier result.
The fryer contains grease from
previous use.
White smoke is caused by grease
heating up inside the fryer. Make sure
you clean the fryer properly after each
use.
The fried food is not
done.
Too much food has been added to
the air fryer.
Put smaller batches of food in the air
fryer. Smaller batches are fried more
evenly.
The set temperature is too low.
Set the temperature to the required
temperature setting.
(refer to the ‘Settings Table).
The food hasn’t been cooked for
long enough.
Set unit to the required cooking time
(refer to the ‘Settings Table).
11
PROBLEM POSSIBLE CAUSE SOLUTION
Fresh fries are fried
unevenly in the air fryer.
Wrong type of potatoes used.
Use fresh potatoes and make sure they
stay firm during frying.
The potato sticks were not rinsed
adequately before frying
Rinse the potato sticks properly to
remove starch from the outside.
Fresh fries are not crispy
when they come out of
the air fryer.
The crispiness of the fries depends
on the amount of oil and water in
the fries.
Make sure you dry the potato sticks
properly before you add the oil.
Cut the potato sticks smaller for a crisp-
ier result.
Add slightly more oil for a crispier result.
Cleaning & Care:
WARNING! DO NOT IMMERSE THE APPLIANCE IN WATER OR ANY OTHER LIQUID.
Clean the appliance after every use.
Cleaning the appliance.
• Always allow the oven to cool completely before cleaning.
• Always unplug the oven from the electrical outlet.
• Do not use abrasive cleaners, as they will damage the finish.
• Simply wipe the exterior with a clean, damp cloth and dry thoroughly. Apply the
cleansing agent to a cloth, not directly onto the oven, before cleaning. To clean
interior walls, use a damp cloth and a mild liquid soap solution or a spray solution on
a sponge. Never use harsh abrasives or corrosive products. These could damage the
oven.
• The Oven Rack, Oven Tray, Airfryer Basket, Rotisserie Spit, Tines, Screws, Rotisserrie
Handle, Oven Tray Handle and Crumb Tray should be hand washed in hot sudsy
water or use a nylon scouring pad or brush. They are NOT dishwasher safe.
• After cooking greasy foods and after your oven has cooled, always clean top interior of
oven. If this is done on a regular basis, your oven will perform at an optimum level.
• To remove crumbs, slide out the Crumb Tray and discard crumbs. Wipe clean and
return to the oven.
• To remove baked-on grease, soak the tray in hot, sudsy water or use nonabrasive
cleaners. Never operate the oven without the Crumb Tray in place.
• Never wrap the cord around the outside of the oven.
• Any servicing should be performed by an authorised service representative.
To store your appliance:
• Ensure that the air fryer is cool, clean and dry before you store it.
• Store the appliance in a cool and dry place.
0120.V1
0620.V1
thank you!
We hope you enjoy your appliance for many years.
This product is guaranteed for 12 months from the date of original purchase.
If any defect arises due to faulty materials of workmanship, the faulty products must be returned to the place
of purchase.
Refund or replacement is at the discretion of the retailer.
The Following Conditions Apply:
The product must be returned to the retailer with proof of purchase or a receipt.
The product must be installed and used in accordance with the instructions contained in
this instruction guide.
It must be used only for domestic purposes.
It does not cover wear and tear, damage, misuse or consumable parts.
Tower has limited liability for incidental or consequential loss or damage.
This guarantee is valid in the UK and Eire only.
The standard one year guarantee is only extended to the maximum available for each particular
product upon registration of the product within 28 days of purchase. If you do not register the product
with us within the 28 day period, your product is guaranteed for 1 year only.
To validate your extended warranty, please visit
www.towerhousewares.co.uk and register with us online.
Please note that length of extended warranty offered is dependent on product type and that each qualifying
product needs to be registered individually in order to extend its warranty past the standard 1 year.
Extended warranty is only valid with proof of purchase or receipt.
Your warranty becomes void should you decide to use non Tower spare parts.
Spare parts can be purchased from www.towerhousewares.co.uk
Should you have a problem with your appliance, or need any spare parts,
please call our Customer Support Team on:
+44 (0) 333 220 6066
