T17025
1.5 LITRE
AIR FRYER OVEN
SAFETY AND INSTRUCTION MANUAL
PLEASE READ CAREFULLY
*Subject to registering your Extended Guarantee online at
www.towerhousewares.co.uk.
2
Technical Data:
This box contains:
Instruction Manual
1.5L Air Fryer
1. Temperature control dial
2. Basket
3. Basket release button
4. Drawer
5. Basket handle
6. Air inlet
7. Indicator light
8. Timer dial
9. Air outlet (rear)
Specifications:
Description: 1.5L Air Fryer
Model: T17025
Rated Voltage: 220-240V~
Frequency: 50/60Hz
Power Consumption: 900W
Documentation
We declare that this product conforms to the following product legislation in accordance with
the following directive(s):
2014/30/EU Electromagnetic Compatibility (EMC)
2014/35/EU Low Voltage Directive (LVD)
1935/2004/EC Materials & Articles in Contact With Food (LFGB section 30 & 31)
2011/65/EU Restriction of Hazardous Substances Directive.
(Including amendment (EU) 2015/863).
2009/125/EC Eco-design of Energy related Products (ERP)
RK Wholesale LTD Quality Assurance, United Kingdom.
1
9
8
7
6
3
4
5
2
3
Wiring Safety for UK Use Only
IMPORTANT
As the colours in the mains lead of this
appliance may not correspond with the
coloured markings identifying the terminals in
your plug, please proceed as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L] Green/
Yellow [EARTH]
Plug Fitting Details (Where Applicable).
The wire labelled blue is the neutral and must
be connected to the terminal marked [N].
The wire labelled brown is the live wire and
must be connected to the terminal marked [L].
The wire labelled green/yellow must be
connected to the terminal marked with the
letter [E].
On no account must either the brown or the
blue wire be connected to the [EARTH] terminal.
Always ensure that the cord grip is fastened
correctly.
The plug must be fitted with a fuse of the same
rating already fitted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualified electrician who
will be pleased to do this for you.
Non-Rewireable Mains Plug.
If your appliance is supplied with a non-
rewireable plug fitted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualified electrician who
will be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - then cut it off of the mains
lead and immediately dispose of it in a safe
manner. Never attempt to reuse the plug or
insert it into a socket outlet as there is a danger
of an electric shock.
FUSE
Earth
(Green/Yellow)
Fuse
Neutral
(Blue)
Live
(Brown)
WARNING:
This appliance MUST be earthed!
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information about the
recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be
recycled, rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.
4
• Check that the voltage
of the main circuit
corresponds with the
rating of the appliance
before operating.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and
seek advice from the
manufacturer, its service
agent or a similarly
qualified person.
• WARNING: DO NOT
let the cord hang over
the edge of a table or
counter, serious burns
may result from the air
fryer being pulled off the
counter where it may be
grabbed by children or
become entangled with
the user.
• DO NOT carry the
appliance by the power
cord.
• DO NOT use any
extension cord with this
appliance.
• DO NOT pull the plug
out by the cord as this
may damage the plug
and/or the cable.
• Switch off at the wall
socket then remove the
plug from the socket
when not in use or
before cleaning.
• Switch off and unplug
before fitting or removing
tools/attachments, after
use and before cleaning.
• Close supervision is
necessary when any
appliance is used by or
near children.
• Children should not play
with the appliance.
• This appliance can be
used by children aged
from 16 years and
above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision
or instruction concerning
use of the appliance in a
safe way and understand
the hazards involved.
• Cleaning and user
maintenance should
not be undertaken
by children without
supervision.
• Take care when any
appliance is used near
pets.
Please read these notes carefully BEFORE using your
Tower appliance
Important Safety Information:
5
• DO NOT use this product
for anything other than
its intended use.
• This appliance is for
household use only.
• This appliance includes
a heating function.
Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT use the
appliance outdoors.
• DO NOT place the
air fryer on or near
combustible materials
such as a tablecloth or
curtain.
• DO NOT place the air
fryer against a wall or
against other appliances.
Leave at least 10cm
free space on the back
and sides and 10cm
free space above the
appliance.
• Allow the air fryer to cool
down for approximately
30 minutes before you
handle or clean it.
• Make sure the food
prepared in the air fryer
comes out golden-yellow
instead of dark brown.
Remove burnt remnants.
• During air frying, hot
steam is released
through the air outlet
openings. Keep your
hands and face at a safe
distance from the steam
and from the air outlet
openings.
• Hot steam and air may
escape when you remove
the drawer from the air
fryer.
• Any dishes or accessories
used in the air fryer will
become hot. Always
use oven gloves when
handling or removing
anything from the air
fryer.
• WARNING: DO NOT fill
the air fryer drawer with
oil as this may cause a
fire hazard.
• Always put food to be
fried in the basket.
• DO NOT place anything
on top of the air fryer.
• In the unlikely event
the appliance develops
a fault, stop using
it immediately and
seek advice from the
Customer Support Team.
+44 (0) 333 220 6066
6
Before First Use:
Read all instructions and safety information carefully before first use. Please retain this
information for future reference.
1. Remove your appliance from the packaging.
2. Check that there is no damage to the cord or any visible damage to the body.
3. Dispose of the packaging in a responsible manner.
4. Remove any stickers or labels from the appliance
5. Thoroughly clean the basket and drawer with hot water, some washing-up liquid and
a non-abrasive sponge.
Note: The drawer and basket are NOT dishwasher-safe. NEVER place the drawer or basket
in the dishwasher.
6. Wipe the inside and outside of the appliance with a moist cloth. Do not fill the
drawer with oil or frying fat. This is an oil-free fryer that works on hot air.
Note: This appliance uses very little oil or no oil.
Using Your Appliance.
Preparing For Use:
1. Place the appliance on a stable, horizontal and even surface. Do not place the
appliance onto a non-heat-resistant surface.
2. Place the basket in the drawer.
3. Do not fill the drawer with oil or any other liquid.
4. Do not put anything on top of the appliance, as this will disrupt the airflow and the
air frying will be affected as a result.
Automatic Switch Off:
The Tower air fryer has a built-in timer, which will automatically shut down the air fryer
when the timer reaches zero. You can manually switch off the unit off by turning the timer
dial anti-clockwise to 0.
Air Fryer Drawer Safety Switch:
For your safety, this air fryer contains a safety switch in the drawer designed to keep if from
accidentally turning on when the frying basket and drawer are not properly situated inside
the appliance, whilst the timer is not set. To use the air fryer, please ensure the basket is
correctly fitted inside of the drawer, the drawer is fully closed and the cooking timer has
been set.
Removing the Frying Basket:
The drawer and frying basket can both be removed fully from the air fryer. Pull on the
SPARE PARTS
(not included, available to order via website/customer service should you require replacements)
Part No Description Image
T17025001 Air Fryer Basket Spare T17025
T17025002 Outer Pot Air Fryer Spare T17025
7
handle to slide the drawer and frying basket out of the air fryer. There is a small button on
the top of the handle. Push it down and lift upwards to remove the frying basket from the
drawer.
Air Frying:
1. Connect the mains plug into an earthed wall socket.
2. Carefully pull the drawer out of the air fryer.
3. Put the food in the basket.
4. Slide the drawer back into the air fryer, making sure to carefully align it with the
guides in the body of the fryer.
5. Never use the drawer without the basket in it.
CAUTION: Do not touch the drawer immediately after use, as it gets very hot. Allow it
plenty of time to cool. Only hold the drawer by the handle.
6. Determine the required preparation time for your food. (Refer to the Settings table
for more information on how to do this.)
7. Turn the timer dial to the required preparation time to turn on the appliance.
8. Turn the temperature control dial to the required temperature. Refer to the Settings
table for more information on how to determine the right temperature. Add 3
minutes to the preparation time when the appliance is cold.
Note: If you wish, you can also let the appliance pre-heat (but not cook) without any food
inside. To do this, turn the timer dial to a time longer than 3 minutes and wait until the
heating-up light goes out (after approximately 3 minutes). Once the light goes out, fill the
basket and turn the timer dial to the required preparation time.
a. The timer will start counting down the set preparation time.
b. During the air frying process, the working light will come on and go out from time
to time. This indicates that the heating element is being switched on and off to
maintain the set temperature.
c. Excess oil from the food is collected on the bottom of the drawer.
9. Some food require shaking halfway through the preparation time (Refer to the
Settings table for more information.) To shake the food, pull the drawer out of the
appliance by the handle and shake it. Then slide the drawer back into the fryer.
Caution: Be careful not to press the button on the handle (basket release) during
shaking.
Tip: To reduce the weight, you can remove the basket from the drawer and shake it
individually. To do this, pull the drawer out of the appliance, place it on a heat-resistant
surface, press the button on the handle and lift the basket out of the drawer. If you set the
timer to half the preparation time, the timer bell will sound to indicate when you have
to shake the food. However, you will then have to set the timer again to the remaining
preparation time.
10. When you hear the timer bell, the set preparation time has elapsed. Pull the drawer
out of the appliance and place it on a suitable work surface.
Note: You can also switch off the appliance manually. To do this, turn the timer control dial
to 0.
11. Check if the food is ready. If the food is not ready yet, simply slide the drawer back
into the appliance and set the timer to a few extra minutes.
12. To remove the food (e.g. fries), pull the drawer out of the air fryer and place it on a
suitable surface, then press the basket release button and lift the basket out of the
drawer. Do not turn the basket upside down with the drawer still attached to it, as
any excess oil that has collected on the bottom of the drawer will leak onto the food.
Both the drawer and food will be very hot. Depending on the type of food in the fryer,
steam may escape from the drawer so care is needed.
13. Empty the basket into a bowl or onto a plate.
Tip: To remove large or fragile food, lift the food out of the basket with a pair of tongs.
14. When a batch of food is ready, the air fryer is instantly ready for preparing another
batch.
Timer:
The air fryer has a 30 minute manual timer with a bell. Turn the timer dial to set the
required cooking time. A bell will sound to indicate cooking has finished.
8
Settings:
The table on the next page will help you select the basic settings for a variety of common
food.
Note: Keep in mind that these settings are indications. As food differ in origin, size, shape
and brand, we cannot guarantee the best settings for your food. Because the Rapid Air
technology instantly reheats the air inside the appliance, pulling the drawer briefly out of
the appliance during frying barely disturbs the process.
Tips:
• The preparation time will depend on the size of your food. Smaller sizes may require
a shorter cooking time.
• Shaking smaller food halfway during the cooking time optimizes the end result and
can help prevent unevenly fried food.
• Add some oil to fresh potatoes for a crispy result. Fry your food in the air fryer within a
few minutes after you added the oil.
• Be cautious of using extremely greasy food such as sausages in the air fryer.
• Snacks that can be prepared in an oven can also be prepared in the air fryer
• The optimal amount for preparing crispy fries is 700 grams.
• Use pre-made dough to prepare filled snacks quickly and easily. Pre-made dough
also requires a shorter preparation time than home-made dough.
• Place a baking tin or oven dish in the air fryer basket if you want to bake a cake or
quiche, or if you want to fry fragile food or filled food.
• You can also use the air fryer to reheat food. To reheat food, set the temperature to
150°C for up to 10 minutes.
SETTINGS TABLE:
Min-max
Amount (g)
Time (min.)
Temperature
(ºC)
Extra
information
Shake
Potato & fries
Thin frozen fries 600-700 15-20 200 Yes
Thick frozen fries 600-700 20-25 200 Yes
Potato gratin 800-1000 25-30 200 Yes
Meat & Poultry
Steak 500-800 10-15 180
Pork chops 500-800 10-15 180
Hamburger 400-800 10-15 180
Sausage roll 400-800 13-15 200
Drumsticks 400-800 25-30 180
Chicken breast 400-800 15-20 180
Snacks
Spring rolls 500-800 8-10 200
Use oven-
ready
Yes
Frozen chicken
nuggets
500-1000 6-10 200
Use oven-
ready
Yes
Frozen fish fingers 500-800 6-10 200
Use oven-
ready
Frozen bread crumbed
Cheese snacks
500-800 8-10 180
Use oven-
ready
Stuffed vegetables 400-800 10 160
9
Min-max
Amount (g)
Time (min.)
Temperature
(ºC)
Extra
information
Shake
Baking
Cake 800 20-25 160 Use baking tin
Quiche 800 20-22 180
Use baking tin/
oven dish
Muns 800 15-18 200 Use baking tin
Sweet snacks 800 20 160
Use baking tin/
oven dish
Troubleshooting:
PROBLEM POSSIBLE CAUSE SOLUTION
The air fryer does not
work
The appliance is not plugged in.
Plug the appliance into an earthed wall
socket.
The appliance is not turned on.
Press the On/Off button to switch on the
appliance.
Fried snacks are not
crispy when they come
out of the air fryer.
Wrong type of snacks used.
Use oven snacks or lightly brush some
oil onto the snacks for a crispier result.
The fryer contains grease from
previous use.
White smoke is caused by grease
heating up inside the fryer. Make sure
you clean the fryer properly after each
use.
The fried food are not
done.
Too much food has been added to
the air fryer.
Put smaller batches of food in the air
fryer. Smaller batches are fried more
evenly.
The set temperature is too low.
Set the temperature to the required
temperature setting.
(Refer to the ‘Settings table for a
temperature reference guide).
The preparation time is too short.
Set unit to the required preparation
time (Refer to the ‘Settings table for a for
a timer reference guide).
Fresh fries are fried
unevenly in the air fryer.
Wrong type of potatoes used.
Use fresh potatoes and make sure they
stay firm during frying.
The potato sticks were not rinsed
adequately before frying
Rinse the potato sticks properly to
remove starch from the outside.
10
PROBLEM POSSIBLE CAUSE SOLUTION
Fresh fries are not crispy
when they come out of
the air fryer.
The crispiness of the fries depends
on the amount of oil and water in
the fries.
Make sure you dry the potato sticks
properly before you add the oil.
Cut the potato sticks smaller for a crisp-
ier result.
Add slightly more oil for a crispier result.
Cleaning & Care:
WARNING! DO NOT IMMERSE THE APPLIANCE IN WATER OR ANY OTHER LIQUID.
Clean the appliance after every use.
Cleaning the drawer and the non-stick coating basket:
1. Do not use metal kitchen utensils or abrasive cleaning materials to clean them, as
this may damage the non-stick coating.
2. Remove the mains plug from the wall socket and let the appliance cool down.
Note: Remove the drawer to let the air fryer cool down more quickly.
3. Wipe the outside of the appliance with a moist cloth.
4. Clean the drawer, separator and basket with hot water, some washing-up liquid and
a non-abrasive sponge.
5. You can use degreasing liquid to remove any remaining dirt.
Note: The drawer and basket are NOT dishwasher-safe. NEVER place the drawer or basket
in the dishwasher.
Tip: If dirt is stuck to the basket or the bottom of the drawer, fill the drawer with hot water
with some washing-up liquid. Put the basket in the drawer and let the drawer and the
basket soak for approximately 10 minutes.
6. Clean the inside of the appliance with hot water and non-abrasive sponge.
7. Clean the heating element with a cleaning brush to remove any food residues.
To store your appliance:
• Ensure that the air fryer is cool, clean and dry before you store it.
• Store the appliance in a cool and dry place.
11
Weights & Measures:
Check these charts for basic imperial to metric conversions of weights.
Metric Imperial US cups
250ml 8 floz 1 cup
180ml 6 fl oz 3/4 cup
150ml 5 floz 2/3 cup
120ml 4 floz 1/2 cup
75ml 2 1/2 floz 1/3 cup
60ml 2 floz 1/4 cup
30ml 1 floz 1/8 cup
15ml 1/2 floz 1 tablespoon
Imperial Metric
1/2 oz 15g
1 oz 30g
2 oz 60g
3 oz 90g
4 oz 110g
5 oz 140g
6 oz 170g
7 oz 200g
8 oz 225g
9 oz 255g
10 oz 280g
11 oz 310g
12 oz 340g
13 oz 370g
14 oz 400g
15 oz 425g
1 lb 450g
Food Allergies
Important Note: Some of the recipes contained in this document may contain nuts and/or other
allergens. Please be careful when making any of our sample recipes that you ARE NOT allergic
to any of the ingredients. For more information on allergies, please visit the Food Standards
Agency’s website at: www.food.gov.uk
12
Ingredients
2 large potatoes
½ tbsp. paprika
Pinch of salt
Pinch of pepper
1 tbsp. Sunflower oil
Ingredients
1 free range egg
1 strip of bacon
1 English mun
Cheese to slice
Pinch of pepper and salt to taste
Ingredients
12 chicken wings
2 tbsp soy sauce
2 tbsp honey
1 ½ tsp salt
¼ tsp white pepper
¼ tsp black pepper
2 tbsp fresh lime juice
Homemade Fries
Bacon and Egg Breakfast Muffin
Honey Lime Chicken Wings
Method
1. Wash, peel and slice the potatoes.
2. Dry with kitchen paper.
3. Cut the potatoes into your desired length and thickness.
4. Bring a large pot of water to the boil with a pinch of salt. Add the
chips and allow to part boil for 10 minutes.
5. Strain the fries and immediately run under cold water to stop
them from cooking any more.
6. Pour the oil in a bowl, with the paprika, salt and pepper. Put the
fries on top and mix until all the fries are coated.
7. Remove the fries from the bowl with your fingers or kitchen
utensil so that the excess oil stays behind in the bowl.
8. Place the fries in the air fryer Cook as per the suggested times/
temperature in the Settings Table
Variations: Try replacing ½ tbsp. of paprika with ½ tbsp. garlic powder,
or ½ tbsp. of grated parmesan cheese.
Method
1. Crack the egg into a small ramekin or oven proof dish.
2. Cut the English mun in half and layer cheese on one half.
3. Place the mun, bacon and egg (in the ramekin) into the Air
Fryer drawer.
4. Turn the Air Fryer to 200°C for 6 minutes.
5. Once it’s cooked, assemble your breakfast mun and enjoy.
6. Tip: Try adding some mustard on the mun for extra flavour.
Method
1. Place all the ingredients inside a large mixing bowl or zip-locked
sealing bag and mix them well. Marinate in the refrigerator for at
least 4 hours (preferably overnight)
2. Line a baking tray with baking paper and evenly scatter the
chicken wings across it.
3. Cook as per the suggested times/temperature in the Settings
Table turning halfway through.
13
Ingredients
4 skin-on salmon fillets
4 tbsp butter
1 clove garlic, minced
1 tsp salt
1 tsp fresh dill, chopped
1 tbsp fresh parsley, chopped
Juice of 1 lemon
Ingredients
100g dark chocolate chips
100g unsalted butter
1 ½ tbsp. self-raising flour
2 eggs
2 ½ tbsp. sugar
Lemon Garlic Salmon
Molten Chocolate Lava Cake
Method
1. Melt the butter and mix in the remaining ingredients to create
a butter sauce.
2. Coat the fish in the sauce on both sides and place it on a baking
tray lined with baking paper.
3. Place the baking tray inside the air fryer and Cook as per the
suggested times/temperature in the Settings Table
Method
1. Melt the chocolate and the butter, stirring all the time.
2. Stir the flour into the mixture, mix it in lightly and set the
mixture aside.
3. In a separate mixing bowl, mix together the eggs and sugar
until light and frothy. Mix in the chocolate sauce slowly until the
ingredients are well blended together.
4. Pour the batter into an oven-safe cup or ramekin and place it
inside the air fryer.
5. Turn the air fryer on in the Cake setting or at 190ºC for 6
minutes.
6. When ready, top with ice-cream and serve immediately.
14
Add your own recipes Here
Ingredients: Method:
15
Add your own recipes Here
Ingredients: Method:
0120.V1
0320.V8
thank you!
We hope you enjoy your appliance for many years.
This product is guaranteed for 12 months from the date of original purchase.
If any defect arises due to faulty materials of workmanship, the faulty products must be returned to the place
of purchase.
Refund or replacement is at the discretion of the retailer.
The Following Conditions Apply:
The product must be returned to the retailer with proof of purchase or a receipt.
The product must be installed and used in accordance with the instructions contained in
this instruction guide.
It must be used only for domestic purposes.
It does not cover wear and tear, damage, misuse or consumable parts.
Tower has limited liability for incidental or consequential loss or damage.
This guarantee is valid in the UK and Eire only.
The standard one year guarantee is only extended to the maximum available for each particular
product upon registration of the product within 28 days of purchase. If you do not register the product
with us within the 28 day period, your product is guaranteed for 1 year only.
To validate your extended warranty, please visit
www.towerhousewares.co.uk and register with us online.
Please note that length of extended warranty offered is dependent on product type and that each qualifying
product needs to be registered individually in order to extend its warranty past the standard 1 year.
Extended warranty is only valid with proof of purchase or receipt.
Your warranty becomes void should you decide to use non Tower spare parts.
Spare parts can be purchased from www.towerhousewares.co.uk
Should you have a problem with your appliance, or need any spare parts,
please call our Customer Support Team on:
+44 (0) 333 220 6066
