OFF-ROAD MOTORCYCLE FRONT WHEEL
CHOCK
MODEL NO: FPS8
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Before use, ensure that there is nothing attached to the motorcycle, that will foul on the clamp.
9 Maintain the clamp in good condition (use an authorised service agent).
9 Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9 Locate the clamp in a suitable area. Keep area clean and tidy and free from unrelated materials and ensure that there is adequate lighting.
Also ensure that the floor/ground is level and strong enough (preferably concrete) to take the weight of the clamp and the motorcycle.
8 DO NOT mount the clamp on tarmacadam, as the surface may be unstable.
9 Ensure that the clamps are free from oil and grease before positioning a motorcycle in the clamp.
9 Keep the clamp clean for the best and safest performance.
9 Maintain correct balance and footing whilst positioning the motorcycle in the clamp.
9 Ensure that the floor is not slippery and wear non-slip shoes.
9 Ensure that the motorcycle is adequately secured to the clamp if to be used for transportation purposes.
9 Keep children and unauthorised persons away from the work area.
8 DO NOT use the clamp for a purpose it is not designed to perform.
8 DO NOT operate the clamp if it is damaged.
8 DO NOT use the clamp when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8 DO NOT allow untrained persons to use the clamp.
8 DO NOT make any modifications to the clamp.
9 Before removing a motorcycle from the clamp, ensure that there are no obstructions or persons in the path of the motorcycle.
WARNING: The warnings, cautions and instructions in this manual cannot cover all possible conditions and situations that
may occur.
9 It must be understood that common sense and caution are factors which cannot be built into this product, but must be
applied by the operator.
2. INTRODUCTION
Securely holds your motocross/dual sports bike on to a trailer, van or whilst being stored in the garage, with it’s front wheel locking
system.Allowsforfastinstallationandremovalfromtheclamp.Madefromhighqualitysteelwithapowdercoatedpaintnishfor
corrosion resistance. Increases the life of fork seals and springs by relieving the downward pressure that can be caused by
other styles of clamps. Suitable for wheels with tyre diameters Ø19-23” (Ø482-584mm).
3. SPECIFICATION
Model No.:...................................................................................FPS8
Minimum/Maximum Wheel Diameter:............. Ø19-23” (Ø482-584mm)
Nett Weight:....................................................................................3kg
4. ASSEMBLY
4.1. Boltwheelchockinplace(g.1)usingsuppliedxings.
OPEN (LOADING POSITION).
FPS8 Issue 1 10/09/24
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear protective
gloves
Wear safety
footwear
Wear protective
clothing
5. INSTALLATION
5.1. PERMANENT INSTALLATION
5.1.1. Choose the installation site carefully so that there is good access to both
insert and extract the motorcycle from the clamp.
5.1.2. Ensure that the motorcycle and clamp DO NOT become a hazard.
5.1.3. Use anchor bolt fixings (not supplied) to secure the chock to a solid
concrete surface.
5.2. INSTALLATION FOR TRANSPORTATION
5.2.1. When used for the transportation of motorcycles, the clamp must be firmly
bolted to the floor of the vehicle using suitable fixings.
Check the underside of the floor panel before drilling any holes. Make sure
that you DO NOT strike any important vehicle parts.
6. OPERATION
6.1. POSITIONING MOTORCYCLE IN THE CLAMP
6.1.1. With the pivot clamp in the open position, align the motorcycle with the clamp.
6.1.2. Push the motorcycle firmly into the clamp so that the tyre runs through to the end of the clamp.
6.1.3. When the wheel is fully inserted, pull the clamp assembly down onto the wheel and pull down the locking bar to secure the bike
upright.
6.1.4. Check that the motorcycle is stable within the clamp before leaving it. If the wheel is loose, or too high in the clamp, extract the
motorcycle from the clamp and adjust the positions of the clamp until the optimum fit is achieved.Then lock into position.
6.2. REMOVING MOTORCYCLE FROM THE CHOCK.
6.2.1. More effort will be required to remove the motorcycle from the clamp. Ensure that the space into which the motorcycle will move is free
from obstructions and people.
6.2.2. Take a firm stance and hold the motorcycle handlebar grips.
6.2.3. Release the clamp then pull back the motorcycle and release the motorcycle from the wheel chock.
7. MAINTENANCE
7.1. Keep the chock clean and wipe off any oil or grease.
7.2. Before each use check all parts. If any part of the chock is damaged or defective, remove the chock from service and take the
necessary action to remedy the problem.
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Parts support is available for this product. Please email sales@sealey.co.uk or telephone 01284 757500
FPS8 Issue 1 10/09/24
g.1
REGISTER YOUR
PURCHASE HERE
Pull down to lock
Move over the wheel
