MOTORCYCLE WHEEL CHOCK
MODEL NO’S: WC06, WC07, WC08
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! The warnings, cautions and instructions referred to in this manual cannot cover all possible conditions and situations that may
occur. It must be understood that common sense and caution are factors which cannot be built into this product, but must be applied by the
operator. It is the operators responsibility to secure the load. Check with vehicle manufacturer’s Manual before installing.
9 Make sure the wheel of the equipment being mounted or dismounted is aligned with the chock.
9 Inspect chock before each use. Check fasteners for tightness, replace any worn or damaged parts.
8 DO NOT attempt to use a chock that is damaged in any way.
8 DO NOT modify the chock in any way.
9 Proper care and maintenance of the chock is critical to safety.
9 Proper use of this product is critical to safety. Improper use may result in personal or property damage which is not covered by the
warranty.
2. i INTRODUCTION
Wheel chock supports the wheel of the motorcycle when in transit or storage. Made from black powder coated heavy-duty tubular steel with pre-
drilled holes and fixings which allow chock to be fixed to any suitable surface. A range of three sizes is available covering maximum tyre widths of
95mm, 140mm, and 165mm.
3. SPECIFICATION
Model Number Maximum Tyre Width
WC06 95mm
WC07
140mm
WC08 165mm
4. CONTENTS
Part Description Quantity Part Description Quantity
A Wheel Chock 1 E 1/4” x 5/8” Screws 2
B Spacer Mounting Plates 2 F 2” Screws 4
C Slotted Mounting Plates 2 G Washers 4
D Steel Threaded Studs 2 H Locking Nuts 4
WC06, WC07, WC08 Issue 2 (5) 16/09/20
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
Wear protective
gloves
5. ASSEMBLY
5.1. From the underside of the wheel chock place the Steel Threaded Studs (D) into the front holes. Secure in position from the top surface
usingthe1/4”x5/8”screws(E),seeg.1.
5.1.1. Identifythephysicallocationforthexingsontheintendedmountingsurfaceandcheckforanyobstructions.Drilltherequiredholes
using a 1/4” drill.
5.1.2. SpacerMountingPlate(A)islaiddirectlyonthetopofthexingsurfaceandalignedwithxingholes,seeg.2.
5.1.3. PlaceSlottedMountingPlate(C)ontopofSpacerMountingPlate(A)andsecurewiththe2”screws(F)xedfromtheundersideusing
Washers (G) and Locking Nuts (H).
WARNING: Ensure that the round hole in the Slotted Mounting Plate (C) is nearest to the direction of loading of the wheel into the
chock.Thiswillensurethatthechockissecuredwhenpushedforward.Ifadditionalxingisrequiredtoensuresafeoperationthere
aretwofurtherpossiblexingholesateitherendoftheWheelChock.
Original Language Version
© Jack Sealey Limited
fig.
1
fig.
2
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
