Technical Support
If you need technical support with your Boss Audio product or have
quesons about its use, please contact us:
805.751.4853
www.BossAudio.com
6
Due to ongoing product development, specicaons are subject to change without noce.
P126DVC_1114_v2
1
Congratulaons on your purchase of the Boss Audio Phantom Series
Subwoofer. Boss Audio takes great pride in producing products that
look great, sound great, and stand up to the daily rigors applied by
audio enthusiasts around the world.
P126DVC 12” (30 cm) Subwoofer
Dual 4 Ω Voice Coils
2300 W Peak Power Handling
High Temperature Voice Coils
Butyl Rubber Surround
2
5
Enclosures
The P126DVC will operate in a sealed or ported enclosure.
Since the woofer has pole-vent, it needs a minimum clearance from
the rear wall of the enclosure of 0.75” (19 mm).
Below you will nd the dimensions to make the enclosure to suit the
subwoofers needs, it has been designed for maximum output while
retaining great sound quality.
The dimensions have already accounted for the volume displacement
of the subwoofer, and using 3/4” (19mm) MDF. All dimensions are
external.
Sealed Dimensions:
Length (L) : 16” (406 mm)
Width (W) : 12” (305 mm)
Height (H) : 14” (356 mm)
Cutout Diameter: 11” (279mm)
Minimum Int. Volume: 1.0 ³
Enclosure Dimensions
Ported Dimensions:
Length (L) : 20” (508mm)
Width (W) : 12” (305 mm)
Height (H) : 14” (356 mm)
Cutout Diameter: 11” (279 mm)
Port Diameter: 3” (76 mm)
Port Length: 6” (152 mm)
Tuning Freq: 38 Hz
Minimum Int. Volume: 1.3 ³
4
Mulple Subwoofers
8 Ω 2 Ω
Wiring your Subwoofer
Parallel Series
4 Ω
1 Ω
3
Product Specicaons
Impedance Dual 4 Ω
Resonant Frequency 31 Hz
Qts 0.517
Qms 4.99
Qes 0.577
Vas 2.472 ³ (69.9 liters)
Xmax 8 mm
Sensivity (1 W/ 1 m) 84 dB
Peak Power Handling 2300 W
Mounng Depth 6-3/4” (172mm)
Cutout Diameter 11” (279 mm)
4
Mulple Subwoofers
8 Ω 2 Ω
Wiring your Subwoofer
Parallel Series
4 Ω
1 Ω
3
Product Specicaons
Impedance Dual 4 Ω
Resonant Frequency 31 Hz
Qts 0.517
Qms 4.99
Qes 0.577
Vas 2.472 ³ (69.9 liters)
Xmax 8 mm
Sensivity (1 W/ 1 m) 84 dB
Peak Power Handling 2300 W
Mounng Depth 6-3/4” (172mm)
Cutout Diameter 11” (279 mm)
P126DVC 12” (30 cm) Subwoofer
Dual 4 Ω Voice Coils
2300 W Peak Power Handling
High Temperature Voice Coils
Butyl Rubber Surround
2
5
Enclosures
The P126DVC will operate in a sealed or ported enclosure.
Since the woofer has pole-vent, it needs a minimum clearance from
the rear wall of the enclosure of 0.75” (19 mm).
Below you will nd the dimensions to make the enclosure to suit the
subwoofers needs, it has been designed for maximum output while
retaining great sound quality.
The dimensions have already accounted for the volume displacement
of the subwoofer, and using 3/4” (19mm) MDF. All dimensions are
external.
Sealed Dimensions:
Length (L) : 16” (406 mm)
Width (W) : 12” (305 mm)
Height (H) : 14” (356 mm)
Cutout Diameter: 11” (279mm)
Minimum Int. Volume: 1.0 ³
Enclosure Dimensions
Ported Dimensions:
Length (L) : 20” (508mm)
Width (W) : 12” (305 mm)
Height (H) : 14” (356 mm)
Cutout Diameter: 11” (279 mm)
Port Diameter: 3” (76 mm)
Port Length: 6” (152 mm)
Tuning Freq: 38 Hz
Minimum Int. Volume: 1.3 ³
Technical Support
If you need technical support with your Boss Audio product or have
quesons about its use, please contact us:
805.751.4853
www.BossAudio.com
6
Due to ongoing product development, specicaons are subject to change without noce.
P126DVC_1114_v2
1
Congratulaons on your purchase of the Boss Audio Phantom Series
Subwoofer. Boss Audio takes great pride in producing products that
look great, sound great, and stand up to the daily rigors applied by
audio enthusiasts around the world.
